Scheme 687
![Scheme 687: AUTOMATIC TRANSAXLE LOCATION INDEX [FS5A-EL]](https://i.diagnostdata.com/repair/9f/9f592e0e8c83e7f8b67b8ae653c34566518d015573762427288468bad248e6c8.webp)
| 1 | Oil pressure switch (See OIL PRESSURE SWITCH INSPECTION [FS5A-EL] .) (See OIL PRESSURE SWITCH REMOVAL/INSTALLATION [FS5A-EL] .) |
|---|---|
| 2 | Drive plate (See DRIVE PLATE REMOVAL/INSTALLATION [FS5A-EL] .) |
| 3 | Input/turbine speed sensor (See INPUT/TURBINE SPEED SENSOR INSPECTION [FS5A-EL] .) (See INPUT/TURBINE SPEED SENSOR REMOVAL/INSTALLATION [FS5A-EL] .) |
| 4 | VSS (See VEHICLE SPEED SENSOR (VSS) INSPECTION [FS5A-EL] .) (See VEHICLE SPEED SENSOR (VSS) REMOVAL/INSTALLATION [FS5A-EL] .) |
| 5 | Intermediate sensor (See INTERMEDIATE SENSOR INSPECTION [FS5A-EL] .) (See INTERMEDIATE SENSOR REMOVAL/INSTALLATION [FS5A-EL] .) |
| 6 | Secondary control valve body (See CONTROL VALVE BODY REMOVAL/INSTALLATION [FS5A-EL] .) |
| 7 | Pressure control solenoid B Shift solenoid F (See SOLENOID VALVE INSPECTION [FS5A-EL] .) (See SOLENOID VALVE REMOVAL/INSTALLATION [FS5A-EL] .) |
| 8 | Pressure control solenoid A Shift solenoid A Shift solenoid B Shift solenoid C Shift solenoid D Shift solenoid E (See SOLENOID VALVE INSPECTION [FS5A-EL] .) (See SOLENOID VALVE REMOVAL/INSTALLATION [FS5A-EL] .) |
| 9 | TFT sensor (See TRANSAXLE FLUID TEMPERATURE (TFT) SENSOR INSPECTION [FS5A-EL] .) (See TRANSAXLE FLUID TEMPERATURE (TFT) SENSOR REMOVAL/INSTALLATION [FS5A-EL] .) |
| 10 | Oil seal (See OIL SEAL REPLACEMENT [FS5A-EL] .) |
| 11 | Primary control valve body (See CONTROL VALVE BODY REMOVAL/INSTALLATION [FS5A-EL] .) |
| 12 | TR switch (See TRANSAXLE RANGE (TR) SWITCH INSPECTION [FS5A-EL] .) (See TRANSAXLE RANGE (TR) SWITCH ADJUSTMENT [FS5A-EL] .) (See TRANSAXLE RANGE (TR) SWITCH REMOVAL/INSTALLATION [FS5A-EL] .) |
| 13 | Automatic transaxle (See MECHANICAL SYSTEM TEST [FS5A-EL] .) (See ROAD TEST [FS5A-EL] .) (See AUTOMATIC TRANSAXLE FLUID (ATF) INSPECTION [FS5A-EL] .) (See AUTOMATIC TRANSAXLE FLUID (ATF) REPLACEMENT [FS5A-EL] .) (See AUTOMATIC TRANSAXLE REMOVAL/INSTALLATION [FS5A-EL] .) |
| 14 | Oil cooler (See OIL COOLER REMOVAL/INSTALLATION [FS5A-EL] .) (See OIL COOLER FLUSHING [FS5A-EL] .) |
| 15 | TCM (See TCM INSPECTION [FS5A-EL] .) (See TCM REMOVAL/INSTALLATION [FS5A-EL] .) |
| 16 | M position switch, up position, down position switch (See M POSITION SWITCH INSPECTION [FS5A-EL] .) (See M POSITION SWITCH REMOVAL/INSTALLATION [FS5A-EL] .) (See UP SWITCH INSPECTION [FS5A-EL] .) (See UP SWITCH REMOVAL/INSTALLATION [FS5A-EL] .) (See DOWN SWITCH INSPECTION [FS5A-EL] .) (See DOWN SWITCH REMOVAL/INSTALLATION [FS5A-EL] .) |
PARTS DESCRIPTION CHART
Operation Inspection
- Verily that the starter operates only when the ignition is switched to START with the selector lever in P or N position.
- Verify that the back-up lights illuminate when selected to R position with the ignition at ON.
- Verify that the positions of the selector lever and the selector indicator light are aligned. If there is any malfunction, adjust the TR switch. (See «TRANSAXLE RANGE (TR) SWITCH ADJUSTMENT [FS5A-EL]»(ref-448615-S37024457402012012000000) .)
Scheme 688
Scheme 689
- Engage the parking brake and use wheel chocks at the front and rear of the wheels.
- Disconnect the TR switch connector. Disconnect the negative battery cable. Remove the air cleaner component. (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [MZR 2.5]»(ref-448579-S21051015612012012000000) .) Disconnect the TR switch connector.
- Inspect continuity as indicated in the table. If there is any malfunction, adjust the TR switch. (See «TRANSAXLE RANGE (TR) SWITCH ADJUSTMENT [FS5A-EL]»(ref-448615-S37024457402012012000000) .) If a malfunction occurs after performing adjustments, replace the TR switch. (See «TRANSAXLE RANGE (TR) SWITCH REMOVAL/INSTALLATION [FS5A-EL]»(ref-448615-S14981256492012012000000) .)
