Automatic Transaxle - Service, Removal & Installation [AY6A-EL]: Specifications Mazda 6 GH рестайлинг

Line pressure specification (while idling)

LINE PRESSURE SPECIFICATION CHART

Scheme 829

Scheme 830

Scheme 831

Scheme 832

Scheme 833

1. (6) Stop the engine.
2. 3. Measure the line pressure while stalling in D position. Replace the oil pressure gauge as following: When using the oil pressure gauge set (49 0378 400C) , replace the SST (49 B019 901B) with SST (49 B019 902A) . When using the oil pressure gauge set (49 D019 9A2) , replace the SST (49 D019 908) with SST (49 D019 907) . Connect the M-MDS to the DLC-2. Monitor the pressure control solenoid current (LPS) using the M-MDS data monitor function. Start the engine. Firmly depress the brake pedal with the left foot. Shift the selector lever to the D position. CAUTION: If the accelerator pedal is pressed for longer than 5 s while the brake pedal is pressed, the transaxle could be damaged. Therefore, perform Steps (7)-(8) within 5 s. Gradually depress the accelerator pedal with the right foot. When the engine speed no longer increases, quickly read the line pressure and release the accelerator pedal. Verify that the pressure control solenoid current changes as shown in the illustration depending on the throttle opening angle. NOTE: The line pressure standard other than when the engine is idling cannot be determined because the maximum line pressure for this transaxle is controlled by vehicle conditions. Shift the selector fever to the N position and idle the engine for 1 min or more to coot the ATF. Remove the SSTs. WARNING: Removing the SSTs when the ATF is hot can be dangerous. Hot ATF can come out of the opening and badly burn you. Before removing the SSTs, allow the ATF to cool. Install the test plug and new O-ring in the inspection port. Tightening torque 5.9-8.8 N.m {61-89 kgf.cm, 53-77 in.lbf} Stop the engine.
3. 4. Measure the line pressure while idling in R position. Remove the test plug (for the R position line) and the O-ring. Connect the SSTs as following: When using the oil pressure gauge set (49 0378 400C) , connect the SSTs (49 HD64 406A, 49 0378 400C, 49 B019 901B) to the line pressure inspection port as shown in the illustration. When using the oil pressure gauge set (49 D019 9A2) , connect the SSTs (49 D019 910,49 D019 911, 49 D019 912,49 D019 909, 49 D019 308) to the line pressure inspection port as shown in the illustration. Start the engine and warm it up until the ATF reaches 60-70 °C {140-158 °F}. Shift the selector lever to the R position. Read the line pressure while the engine is idling.

LINE PRESSURE SPECIFICATION CHART

1. (6) Stop the engine.

Scheme 834

Scheme 835

Scheme 836

1. 5. Measure the line pressure while stalling in R position. Replace the oil pressure gauge as following: When using the oil pressure gauge set (49 0378 400C) , replace the SST (49 B019 901B) with SST (49 B019 902A) . When using the oil pressure gauge set (49 D019 9A2) , replace the SST (49 D019 908) with SST (49 D019 907) . Connect the M-MDS to the DLC-2. Monitor the pressure control solenoid current (LPS) using the M-MDS data monitor function. Start the engine. Firmly depress the brake pedal with the left foot. Shift the selector lever to the R position. CAUTION: If the accelerator pedal is pressed for longer than 5 s white the brake pedal is pressed, the transaxle could be damaged. Therefore, perform Steps (7)-(8) within 5 s. Gradually depress the accelerator pedal with the right foot. When the engine speed no longer increases, quickly read the line pressure and release the accelerator pedal. Verify that the pressure control solenoid current changes as shown in the illustration depending on the throttle opening angle. NOTE: The line pressure standard other than when the engine is idling cannot be determined because the maximum line pressure for this transaxle is controlled by vehicle conditions. Shift the selector lever to the N position and idle the engine for 1 min or more to cool the ATF. Remove the SSTs. WARNING: Removing the SSTs when the ATF is hot can be dangerous. Hot ATF can come out of the opening and badly burn you. Before removing the SSTs, allow the ATF to cool. Install the test plug and new O-ring in the inspection port. Tightening torque 5.9-8.8 N.m {61-89 kgf.cm, 53-77 in.lbf}
2. 6. Stop the engine. If there is any malfunction, inspect the following "Possible Cause" according to the condition. POSSIBLE CAUSE CONDITION REFERENCE CHART Condition Possible cause Lower than specification in R, D positions Line pressure control solenoid malfunction Primary regulator valve malfunction Oil pump malfunction Oil leaking from D position or R position hydraulic circuit Constant pressure without fluctuation in hydraulic pressure to throttle in R, D positions Line pressure control solenoid malfunction Control valve body internal malfunction Current to throttle does not change in R, D positions TCM internal malfunction Connector malfunction Hydraulic pressure in R position is not higher than D position Primary regulator valve malfunction

M position switch specification

CONTINUITY REFERENCE CHART

Scheme 837

Up switch specification

CONTINUITY REFERENCE CHART

Scheme 838

Down switch specification

CONTINUITY REFERENCE CHART

Scheme 839

TFT sensor specification

TFT SENSOR SPECIFICATIONS CHART

Scheme 840

Scheme 841

1. Place the TFT sensor and a thermometer in ATF as shown in the illustration, and heat the ATF gradually. WARNING: A hot ATF and beaker can cause severe burns. Do not touch them.
2. Measure the resistance between coupler component terminals B7 and B8. If there is any malfunction, replace the coupler component.

TFT SENSOR REFERENCE CHART

Scheme 842

Input/turbine speed sensor specification

INPUT/TURBINE SPEED SENSOR SPECIFICATIONS CHART

Scheme 843

Scheme 844

1. 5. Measure the continuity between coupler component terminals B12 and B13. If there is any malfunction, inspect the coupler component for continuity. (See «COUPLER COMPONENT INSPECTION [AY6A-EL]».) If the coupler component is normal, perform an off-vehicle inspection of input/turbine speed sensor. (See «OFF-VEHICLE INSPECTION».)

INPUT/TURBINE SPEED SENSOR SPECIFICATIONS CHART

Scheme 845

Scheme 846

1. Connect the input/turbine speed sensor terminal 2 to the battery positive terminal, connect the battery negative terminal to input/turbine speed sensor terminal 1 through an ammeter set to a resistance of 100 ohm. NOTE: Inspect with a tester that can indicate more than 10 megohms and confirm that the value is more than 1 megohm.
2. Measure the current white waving a magnet back and forth over the top of the input/turbine speed sensor (less than 5 mm {0.2 in}). If there is any malfunction, replace the input/turbine speed sensor.

INPUT/TURBINE SPEED SENSOR SPECIFICATIONS CHART

Scheme 847

VSS specification

CONTINUITY REFERENCE CHART

Scheme 848

Scheme 849

1. 5. Measure the continuity between coupler component terminals B19 and B20. If there is any malfunction, inspect the coupler component for continuity. (See «COUPLER COMPONENT INSPECTION [AY6A-EL]».) If the coupler component is normal, perform an off-vehicle inspection of VSS. (See «OFF-VEHICLE INSPECTION».)

CONTINUITY REFERENCE CHART

Scheme 850

Scheme 851

1. Connect the VSS terminal 2 to the battery positive terminal, connect the battery negative terminal to VSS terminal 1 through an ammeter set to a resistance of 100 ohm. NOTE: Inspect with a tester that can indicate more than 10 megohms and confirm that the value is more than 1 megohm.
2. Measure the current while waving a magnet back and forth over the top of the VSS (less than 5 mm {0.2 in}) . If there is any malfunction, replace the VSS.

VSS SPECIFICATIONS CHART

Scheme 852

Coupler component specification

CONTINUITY REFERENCE CHART

Scheme 853

Off-Vehicle Inspection

1. Measure the coupler component continuity. If there is any malfunction, replace the coupler component.

CONTINUITY REFERENCE CHART

Scheme 854

CONTINUITY REFERENCE CHART

CONTINUITY REFERENCE CHART

Line pressure control solenoid specification

CONTINUITY REFERENCE CHART

Shift solenoid A specification

CONTINUITY REFERENCE CHART

Shift solenoid B specification

CONTINUITY REFERENCE CHART

Shift solenoid C specification

CONTINUITY REFERENCE CHART

Shift solenoid D specification

CONTINUITY REFERENCE CHART

Shift solenoid E specification

CONTINUITY REFERENCE CHART

Shift solenoid F specification

CONTINUITY REFERENCE CHART

TCC control solenoid specification

CONTINUITY REFERENCE CHART

LINE PRESSURE CONTROL SOLENOID SPECIFICATIONS CHART

Scheme 855

LINE PRESSURE CONTROL SOLENOID SPECIFICATIONS CHART

Scheme 856

SHIFT SOLENOID A SPECIFICATION CHART

Scheme 857

SHIFT SOLENOID SPECIFICATIONS CHART

Scheme 858

SHIFT SOLENOID SPECIFICATIONS CHART

Scheme 859

SHIFT SOLENOID SPECIFICATIONS CHART

Scheme 860

SHIFT SOLENOID SPECIFICATIONS CHART

Scheme 861

SHIFT SOLENOID SPECIFICATIONS CHART

Scheme 862

SHIFT SOLENOID SPECIFICATIONS CHART

Scheme 863

SHIFT SOLENOID SPECIFICATIONS CHART

Scheme 864

SHIFT SOLENOID SPECIFICATIONS CHART

Scheme 865

SHIFT SOLENOID SPECIFICATIONS CHART

Scheme 866

SHIFT SOLENOID SPECIFICATIONS CHART

Scheme 867

SHIFT SOLENOID SPECIFICATIONS CHART

Scheme 868

TORQUE CONVERTER CLUTCH (TCC) CONTROL SOLENOID INSPECTION [AY6A-EL]

On-Vehicle Inspection

1. Disconnect the negative battery cable.
2. Remove the fresh-air duct and air cleaner component as a single unit. (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [MZI 3.7 V6]».)
3. Remove the TCM. (See «TCM REMOVAL/INSTALLATION [AY6A-EL]».)
4. Measure the resistance between coupler component terminals B4 and B9.

Scheme 869

1. If there is any malfunction, inspect the coupler component for continuity. (See «COUPLER COMPONENT INSPECTION [AY6A-EL]».)
2. If coupler component has no malfunction, perform the "Off-vehicle inspection". (See «OFF-VEHICLE INSPECTION».)

TCC CONTROL SOLENOID SPECIFICATIONS CHART

Scheme 870

TCC CONTROL SOLENOID SPECIFICATIONS CHART

Scheme 871

TORQUE CONVERTER CLUTCH (TCC) CONTROL SOLENOID REMOVAL/INSTALLATION [AY6A-EL]

Note. TCC control solenoid is not available (shipped) as a single part.

1. If the TCC control solenoid is replaced, replace the control valve body. (See «CONTROL VALVE BODY REMOVAL/INSTALLATION [AY6A-EL]».)

TORQUE CONVERTER REMOVAL/INSTALLATION [AY6A-EL]

Scheme 872

Scheme 873

Scheme 874

1. Remove the transaxle. (See «AUTOMATIC TRANSAXLE REMOVAL/INSTALLATION [AY6A-EL]».)
2. Clean the transaxle. (See «AUTOMATIC TRANSAXLE CLEANING [AY6A-EL]».)
3. Remove the torque converter, and immediately turn it so that the hole faces upward. This will help to keep any remaining fluid from spilling. CAUTION: Do not damage the oil seal. Do not drop the torque converter. Clean oil off between the converter housing and torque converter. Completely remove ATF with white gasoline or equivalent.
4. Drain any ATF remaining in the torque converter.
5. Using a flathead screwdriver, position the drive gear on the oil pump component in the center.
6. Install the torque converter to the transaxle. CAUTION: Do not damage the oil seal. Do not drop the torque converter. Do not pinch fingers.
7. To ensure that the torque converter is installed accurately, measure distance A between the end of the torque converter and the end of the converter housing. Distance A (between the end of the torque converter and the end of the converter housing) 20 mm {0.79 in}
8. Install the transaxle. (See «AUTOMATIC TRANSAXLE REMOVAL/INSTALLATION [AY6A-EL]».)
9. Add ATF. (See «AUTOMATIC TRANSAXLE FLUID (ATF) LEVEL ADJUSTMENT [AY6A-EL]».)
10. Adjust the ATF level. (See «AUTOMATIC TRANSAXLE FLUID (ATF) LEVEL ADJUSTMENT [AY6A-EL]».)
11. Perform the "Mechanical System Test". (See «MECHANICAL SYSTEM TEST [AY6A-EL]».)
