Symptom Troubleshooting - Automatic Transaxle (FS5A-EL): Diagnosis Mazda 3 BL

Automatic Trans 2 illustrations

BASIC INSPECTION [FS5A-EL]

STEPINSPECTIONACTION
1Perform the mechanical system test. (See MECHANICAL SYSTEM TEST [FS5A-EL] .) Is the mechanical system normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts according to the inspection result.
2Turn the ignition switch to the ON position. When the selector lever is moved, does the gear position indicator light indication correspond to the selector lever position? Also, when other ranges are selected from N or P during idling, does the vehicle move within 1-2 s?YesGo to the next step.
NoInspect the selector lever and TR switch. Repair or replace malfunctioning parts. (See SELECTOR LEVER INSPECTION .) (See TRANSAXLE RANGE (TR) SWITCH INSPECTION [FS5A-EL] .) If the selector lever and TR switch are normal, go to the next step.
3Inspect the ATF color and condition. (See AUTOMATIC TRANSAXLE FLUID (ATF) INSPECTION [FS5A-EL] .) Are the ATF color and odor normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts according to the inspection result. Flush the ATX and cooler line if necessary.
4Perform the line pressure test. (See MECHANICAL SYSTEM TEST [FS5A-EL] .) Is the line pressure normal?YesGo to the next step.
NoAdjust the accelerator cable if necessary. Repair or replace any malfunctioning parts according to the inspection result.
5Perform the stall test. (See MECHANICAL SYSTEM TEST [FS5A-EL] .) Is the stall speed normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts according to the inspection result.
6Inspect the value at the following PCM and TCM PIDs using the M-MDS. (See PCM INSPECTION [LF, L3] .) (See TCM INSPECTION [FS5A-EL] .) PCM PIDs: APP TP REL ECT RPM VPWR TCM PIDs: TFT TFTV TR TR_SENS MNL SW DWN SW UP SW THOP TSS OSS VPWR TCM Are the PID values normal?YesPerform the symptom troubleshooting and follow the procedures.
NoRepair or replace any malfunctioning parts according to the inspection result.

INSPECTION CHART

SYMPTOM TROUBLESHOOTING ITEM TABLE [FS5A-EL]

  1. Use the chart below to verify the symptoms of the trouble in order to diagnose the appropriate area.
No.TROUBLESHOOTING ITEMDESCRIPTIONPAGE
1Vehicle does not move in D, M ranges, or in R positionVehicle does not move when accelerator pedal is depressed.(See NO.1 VEHICLE DOES NOT MOVE IN D, M RANGES, OR IN R POSITION [FS5A-EL] ).
2Vehicle moves in N positionVehicle creeps in N position. Vehicle creeps if brake pedal is not depressed in N position.(See NO.2 VEHICLE MOVES IN N POSITION [FS5A-EL] ).
3Vehicle moves in P position, or parking gear does not disengage when P position is disengagedVehicle rolls when on a downward slope and tires do not lock in P position. Tires locked when P position is disengaged, vehicle does not move in D, M ranges, and R position when accelerator pedal is depressed, and engine remains in stalled condition.(See NO.3 VEHICLE MOVES IN P POSITION, OR PARKING GEAR DOES NOT DISENGAGE WHEN P IS DISENGAGED [FS5A-EL] ).
4Excessive creepVehicle accelerates in D, M ranges and R position when accelerator pedal is not depressed.(See NO.4 EXCESSIVE CREEP [FS5A-EL] ).
5No creep at allVehicle does not move in D, M ranges, or R position when idling on flat paved road.(See NO.5 NO CREEP AT ALL [FS5A-EL] ).
6Low maximum speed and poor accelerationVehicle acceleration is poor at start. Delayed acceleration when accelerator pedal is depressed while driving.(See NO.6 LOW MAXIMUM SPEED AND POOR ACCELERATION [FS5A-EL] ).
7No shiftingSingle shift range only. Sometimes shifts correctly.(See NO.7 NO SHIFTING [FS5A-EL] ).
8Does not shift to 5GRVehicle does not upshift from 4GR to 5GR even though vehicle speed is increased. Vehicle does not shift to 5GR even though accelerator pedal is released in D range at 60 km/h {37 mph} .(See NO.8 DOES NOT SHIFT TO 5GR [FS5A-EL] ).
9Abnormal shiftingShifts incorrectly (incorrect shift pattern).(See NO.9 ABNORMAL SHIFTING [FS5A-EL] ).
10Frequent shiftingDownshifting occurs suddenly even when accelerator pedal is depressed slightly in D range.(See NO.10 FREQUENT SHIFTING [FS5A-EL] ).
11Shift point is high or lowShift point considerably different from automatic shift diagram. Shift delays when accelerating. Shift occurs suddenly when accelerating and engine speed does not increase.(See NO.11 SHIFT POINT IS HIGH OR LOW [FS5A-EL] ).
12Torque converter clutch (TCC) non-operationTCC does not operate when vehicle reaches TCC operation range.(See NO.12 TORQUE CONVERTER CLUTCH (TCC) NON-OPERATION [FS5A-EL] ).
13No kickdownDoes not downshift when accelerator pedal is fully depressed within kickdown range.(See NO.13 NO KICKDOWN [FS5A-EL] ).
14Engine flares up or slips when upshifting or downshiftingWhen accelerator pedal is depressed, engine speed increases normally but vehicle speed increases slowly. When accelerator pedal is depressed while driving, engine speed increases but vehicle speed does not.(See NO.14 ENGINE FLARES UP OR SLIPS WHEN UPSHIFTING OR DOWNSHIFTING [FS5A-EL] ).
15Engine flares up or slips when accelerating vehicleEngine flares up when accelerator pedal is depressed for upshifting. Engine flares up suddenly when accelerator pedal is depressed for downshifting.(See NO.15 ENGINE FLARES UP OR SLIPS WHEN ACCELERATING VEHICLE [FS5A-EL] ).
16Judder upon torque converter clutch (TCC) operationVehicle jolts when TCC is engaged.(See NO.16 JUDDER UPON TORQUE CONVERTER CLUTCH (TCC) OPERATION [FS5A-EL] ).
17Excessive shift shock from N to D or N to R position/rangeStrong shock is felt when shifting from N to D or N to R position/range at idle.(See NO.17 EXCESSIVE SHIFT SHOCK FROM N TO D OR N TO R POSITION/RANGE [FS5A-EL] ).
18Excessive shift shock is felt when upshifting and downshiftingExcessive shift shock is felt when depressing accelerator pedal to accelerate at upshifting. During cruising, excessive shift shock is felt when depressing accelerator pedal at downshifting.(See NO.18 EXCESSIVE SHIFT SHOCK IS FELT WHEN UPSHIFTING AND DOWNSHIFTING [FS5A-EL] ).
19Excessive shift shock on torque converter clutch (TCC)Strong shock is felt when TCC is engaged.(See NO.19 EXCESSIVE SHIFT SHOCK ON TORQUE CONVERTER CLUTCH (TCC)[FS5A-EL] ).
20Noise occurs at idle when vehicle is stopped in all positions/rangesTransaxle is noisy in all positions and ranges when vehicle idling.(See NO.20 NOISE OCCURS AT IDLE WHEN VEHICLE IS STOPPED IN ALL POSITIONS/RANGES [FS5A-EL] ).
21Noise occurs at idle when vehicle is stopped in D, M ranges, or in R positionTransaxle is noisy in driving ranges when vehicle is idling.(See NO.21 NOISE OCCURS AT IDLE WHEN VEHICLE IS STOPPED IN D, M RANGES, OR IN R POSITION [FS5A-EL] ).
22No engine braking in 1GR position of M rangeEngine speed drops to idle but vehicle coasts when accelerator pedal is released when in M range (1GR) at low vehicle speed.(See NO.22 NO ENGINE BRAKING IN 1GR POSITION OF M RANGE [FS5A-EL] ).
23Transaxle overheatsBurnt smell emitted from the transaxle. Smoke is emitted from the transaxle.(See NO.23 TRANSAXLE OVERHEATS [FS5A-EL] ).
24Engine stalls when shifted to D, M ranges, or in R positionEngine stalls when shifting from N or P position to D, M ranges or R position at idle.(See NO.24 ENGINE STALLS WHEN SHIFTED TO D, M RANGES, OR IN R POSITION [FS5A-EL] ).
25Engine stalls when driving at slow speeds or stoppingEngine stalls when brake pedal is depressed while driving at low speed or stopping.(See NO.25 ENGINE STALLS WHEN DRIVING AT SLOW SPEEDS OR STOPPING [FS5A-EL] ).
26Starter does not workStarter does not work even when in P or N position.(See NO.26 STARTER DOES NOT WORK [FS5A-EL] ).
27Gear position indicator light does not illuminate in D or M rangeGear position indicator light in instrument cluster does not illuminate in D or M range with ignition switch at ON.(See NO.27 GEAR POSITION INDICATOR LIGHT DOES NOT ILLUMINATE IN D OR M RANGE [FS5A-EL] ).
28Gear position indicator light illuminates in P, R and N positionGear position indicator light in instrument cluster illuminates in P, R and N position with ignition switch at ON.(See NO.28 GEAR POSITION INDICATOR LIGHT ILLUMINATE IN P, R AND N POSITION [FS5A-EL] ).
29Does not upshift in M rangeGear position indicator light in instrument cluster illuminates but vehicle does not upshift when selector lever is pushed to "+" side.(See NO.29 DOES NOT UPSHIFT IN M RANGE [FS5A-EL] ).
30Does not downshift in M rangeGear position indicator light in instrument cluster illuminates but vehicle does not downshift when selector lever is pushed to "-" side.(See NO.30 DOES NOT DOWNSHIFT IN M RANGE [FS5A-EL] ).
31M range position indicator light does not illuminate in M range/M range position indicator light illuminate in D rangeM range position indicator light in instrument cluster does not illuminate in M range or M range position indicator light illuminates in D range with the ignition switch at ON position.(See NO.31 M RANGE POSITION INDICATOR LIGHT DOES NOT ILLUMINATE IN M RANGE/M RANGE POSITION INDICATOR LIGHT ILLUMINATE IN D RANGE [FS5A-EL] .)

SYMPTOM TROUBLESHOOTING CHART

Scheme 987

Scheme 987: QUICK DIAGNOSIS CHART [FS5A-EL]

Scheme 988

Scheme 988

Diagnostic procedure

STEPINSPECTIONACTION
1When the vehicle is stopped on a flat, level road and the engine is off, does the vehicle move when pushed? (in D range or N, R positions with the brake pedal released)YesGo to the next step.
NoInspect for parking mechanism. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
2Disconnect the TCM connector. Is the resistance between the ground terminal at the TCM connector and the body ground less than 5.0 ohms?YesGo to the next step.
NoRepair open ground circuit.
3Inspect the value at the following TCM PID using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) LPS Is the LPS PID value normal?YesOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
NoRepair or replace any malfunctioning parts.
4Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Does the vehicle creep when the selector lever is moved slightly in N position?YesGo to the next step.
NoAdjust the selector lever. (See SELECTOR CABLE ADJUSTMENT .)
2Disconnect the TCM connector. Is the resistance between the ground terminal at the TCM connector and the body ground less than 5.0 ohms?YesGo to the next step.
NoRepair open ground circuit. Reconnect the TCM.
3Inspect the value at the following TCM PID using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) LPS Is the LPS PID value normal?YesOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
NoRepair or replace any malfunctioning parts.
4Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Does the vehicle creep in any range/position?YesGo to the next step.
NoInspect or adjust the selector lever. (See SELECTOR LEVER INSPECTION .) (See SELECTOR CABLE ADJUSTMENT .)
2Inspect the value at the following TCM PID using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) THOP Is the PID value normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts.
3Disconnect the TCM connector. Is the resistance between the ground terminal at the TCM connector and the body ground less than 5.0 ohms?YesGo to the next step.
NoRepair open ground circuit.
4Inspect the value at the following TCM PID using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) LPS Is the LPS PID value normal?YesOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
NoRepair or replace any malfunctioning parts.
5Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1With the ignition switch at the ON position, does the gear position indicator light indication correspond to the selector lever position?YesGo to the next step.
NoGo to No.27 " GEAR POSITION INDICATOR LIGHT DOES NOT ILLUMINATE IN M RANGE " or No.28 " GEAR POSITION INDICATOR LIGHT ILLUMINATES IN D RANGE OR P, N, R POSITIONS "
2Go to No.12 "LACK/LOSS OF POWER". (See NO.12 LACK/LOSS OF POWER-ACCELERATION/CRUISE [LF, L3] .) Is the CIS system normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts.
3Disconnect the solenoid connector. Does the vehicle operate as follows? D range: 3GR (fixed) R position: ReverseYesGo to the next step.
NoOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) . If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
4Drive the vehicle in D range. Does the vehicle start from stop in first gear?YesGo to the next step.
NoInspect the value at the following PCM and TCM PIDs using the M-MDS. (See PCM INSPECTION [LF, L3] .) (See TCM INSPECTION [FS5A-EL] .) PCM PIDs: APP TP REL TCM PIDs: THOP OSS TSS TR Repair or replace any malfunctioning parts.
5Inspect the value at the following TCM PIDs using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) SSA/SS1 SSB/SS2 SSC/SS3 SSF_SS6 Are the PID values normal?YesGo to the next step.
NoInspect the value at the following PCM and TCM PIDs using the M-MDS. (See PCM INSPECTION [LF, L3] .) (See TCM INSPECTION [FS5A-EL] .) PCM PIDs: APP TP REL TCM PIDs: THOP OSS TSS Repair or replace any malfunctioning parts.
6Perform the stall test. (See MECHANICAL SYSTEM TEST [FS5A-EL] .) Is stall speed normal?YesReverify symptoms of malfunction.
NoOverhaul the transaxle and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
7Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1With the ignition switch at the ON position, does the gear position indicator light indication correspond to the selector lever position?YesGo to the next step.
NoGo to No.27 " GEAR POSITION INDICATOR LIGHT DOES NOT ILLUMINATE IN M RANGE " or No. 28 " GEAR POSITION INDICATOR LIGHT ILLUMINATES IN D RANGE OR P, N, R POSITIONS "
2Inspect the value at the following TCM PIDs using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) TFT TFTV Are the PID values normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts.
3Inspect the value at the following TCM PIDs using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) SSA/SS1 SSB/SS2 SSD/SS4 SSF_SS6 Are the PID values normal?YesOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) . If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
NoGo to the next step.
4Disconnect the TCM connector. Is the resistance between the ground terminal at the TCM connector and the body ground less than 5.0 ohms?YesInspect the value at the following TCM PIDs using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) TR TSS OSS Repair or replace any malfunctioning parts.
NoRepair open ground circuit. Reconnect the TCM.
5Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Disconnect the TCM connector. Is the resistance between the ground terminal at the TCM connector and the body ground less than 5.0 ohms?YesGo to the next step.
NoRepair open ground circuit. Reconnect the TCM.
2Inspect the value at the following PCM and TCM PIDs using the M-MDS. (See PCM INSPECTION [LF, L3] .) (See TCM INSPECTION [FS5A-EL] .) PCM PIDs: APP TP REL TCM PIDs: THOP TSS OSS VSS Are the PID values normal?YesOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) .) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts.
NoRepair or replace any malfunctioning parts.
3Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1With the ignition switch at the ON position, does the gear position indicator light indication correspond to the selector lever position?YesGo to the next step.
NoGo to No.27 " GEAR POSITION INDICATOR LIGHT DOES NOT ILLUMINATE IN M RANGE " or No.28 " GEAR POSITION INDICATOR LIGHT ILLUMINATES IN D RANGE OR P, N, R POSITIONS "
2Inspect the value at the following PCM and TCM PIDs using the M-MDS. (See PCM INSPECTION [LF, L3] .) (See TCM INSPECTION [FS5A-EL] .) PCM PIDs: APP TP REL TCM PIDs: THOP OSS TSS Are the PID values normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts.
3Disconnect the TCM connector. Is the resistance between the ground terminal at the TCM connector and the body ground less than 5.0 ohms?YesGo to the next step.
NoRepair the open ground circuit.
4Inspect the resistance between shift solenoid A and E control circuit at the TCM connector and control valve body connector. Inspect resistance between shift solenoid A and E circuit at the TCM connector and control valve body connector. Are the resistances less than 5.0 ohms?YesGo to the next step.
NoRepair the shift solenoid A or E control. Reconnect the TCM.
5Inspect the shift solenoid A and E. (See SOLENOID VALVE INSPECTION (PRIMARY CONTROL VALVE BODY)[FS5A-EL] .) Are the shift solenoids operating properly?YesReplace the TCM.
NoOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) . If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
6Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Is shift point normal?YesGo to the next step.
NoGo to No.9 " ABNORMAL SHIFTING ".
2Inspect the value at the following TCM PID using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) THOP Is the PID value normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts.
3Disconnect the TCM connector. Is the resistance between the ground terminal at the TCM connector and the body ground less than 5.0 ohms?YesGo to the next step.
NoRepair the open ground circuit. Reconnect the TCM.
4Inspect the value at the following TCM PID using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) LPS Is the LPS PID value normal?YesOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) . If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
NoRepair or replace any malfunctioning parts.
5Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Inspect the value at the following TCM PID using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) TSS Is the PID value normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts.
2Disconnect the TCM connector. Is the resistance between the ground terminal at the TCM connector and the body ground less than 5.0 ohms?YesGo to the next step.
NoRepair the open ground circuit.
3Inspect the resistance between shift solenoid A and E control circuit at the TCM connector and control valve body connector. Inspect the resistance between shift solenoid A/E circuit at the TCM connector and control valve body connector. Are the resistances less than 5.0 ohms?YesGo to the next step.
NoRepair the shift solenoid A and/or E circuit.
4Inspect the shift solenoid. (See SOLENOID VALVE INSPECTION (PRIMARY CONTROL VALVE BODY)[FS5A-EL] .) Is the solenoid valve operating properly?YesGo to the next step.
NoOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) . If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
5Inspect the value at the following TCM PID using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) LPS Is the LPS PID value normal?YesOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
NoReplace the TCM.
6Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Does the shift shock occur only when the engine is cold?YesGo to the next step.
NoGo to Step 3.
2Disconnect the TCM connector. Is the resistance between the ground terminal at the TCM connector and the body ground less than 5.0 ohms?YesInspect the value at the following PCM and TCM PIDs using the M-MDS. (See PCM INSPECTION [LF, L3] .) (See TCM INSPECTION [FS5A-EL] .) PCM PIDs: APP TP REL TCM PIDs: THOP TFT TFTV Repair or replace any malfunctioning parts.
NoRepair the open ground circuit. Reconnect the TCM.
3Perform the stall test. (See MECHANICAL SYSTEM TEST [FS5A-EL] .) Is the stall speed normal?YesGo to the next step.
NoGo to Step 5.
4Inspect the value at the following TCM PID using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) TR Is the PID value normal?YesOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
NoRepair or replace any malfunctioning parts.
5Inspect the value at the following TCM PID using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) THOP Is the PID value normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts.
6Disconnect the TCM connector. Is the resistance between the ground terminal at the TCM connector and the body ground less than 5.0 ohms?YesGo to the next step.
NoRepair the open ground circuit. Reconnect the TCM.
7Inspect the value at the following TCM PID using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) LPS Is the LPS PID value normal?YesOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
NoRepair or replace any malfunctioning parts.
8Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Inspect the engine mounts for loose tightening bolts or worn parts. Are all engine mounts normal?YesGo to the next step.
NoReadjust, retighten or replace engine mounts.
2Perform the stall test. (See MECHANICAL SYSTEM TEST [FS5A-EL] .) Is the stall speed normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts.
3Inspect the value at the following PCM PID using the M-MDS. (See PCM INSPECTION [LF, L3] .) APP TP REL Is the PID value normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts.
4Disconnect the TCM connector. Is the resistance between the ground terminal at the TCM connector and the body ground less than 5.0 ohms?YesGo to the next step.
NoRepair the open ground circuit. Reconnect the TCM.
5Inspect the value at the following TCM PID using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) LPS Is the LPS PID value normal?YesOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
NoRepair or replace any malfunctioning parts.
6Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Inspect engine condition. Is there any engine concern (i. e. rough idle)?YesGo to appropriate symptom troubleshooting. (See ENGINE SYMPTOM TROUBLESHOOTING [LF, L3] .)
NoGo to the next step.
2Does the noise stop when the solenoid connector is disconnected?YesGo to the next step.
NoOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
3Inspect the value at the following PCM and TCM PIDs using the M-MDS. (See PCM INSPECTION [LF, L3] .) (See TCM INSPECTION [FS5A-EL] .) PCM PIDs: APP TP REL TCM PIDs: THOP OSS TSS Are the PID values normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts.
4Disconnect the TCM connector. Is the resistance between the ground terminal at the TCM connector and the body ground less than 5.0 ohms?YesGo to the next step.
NoRepair the open ground circuit. Reconnect the TCM.
5Inspect the value at the following TCM PID using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) LPS Is the LPS PID value normal?YesOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
NoRepair or replace any malfunctioning parts.
6Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Do the following symptoms occur concurrently? Engine flares up or slips during acceleration. Engine flares up or slips when shifting.YesGo to symptom troubleshooting NO. 14 " ENGINE FLARES UP OR SLIPS WHEN UPSHIFTING OR DOWNSHIFTING " or No.15 " ENGINE FLARES UP OR SLIPS WHEN ACCELERATING VEHICLE ".
NoRepeat basic inspection and repair or replace any malfunctioning parts according to the inspection result. (See BASIC INSPECTION [FS5A-EL] ).
2Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Inspect for bending, damage, corrosion or kinks of the oil cooler pipes. Are oil cooler pipes normal?YesGo to the next step.
NoReplace any malfunctioning parts.
2Perform the stall test. (See MECHANICAL SYSTEM TEST [FS5A-EL] .) Is the stall speed normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts.
3Inspect the value at the following PCM PID using the M-MDS. (See PCM INSPECTION [LF, L3] .) APP TP REL Is the PID value normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts.
4Disconnect the TCM connector. Is the resistance between the ground terminal at the TCM connector and the body ground less than 5.0 ohms?YesGo to the next step.
NoRepair the open ground circuit. Reconnect the TCM.
5Inspect the value at the following TCM PID using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) LPS Is the LPS PID value normal?YesOverhaul the control valve body and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL) If any problem remains, overhaul the transaxle and repair or replace any malfunctioning parts. (See AUTOMATIC TRANSAXLE OVERHAUL (FS5A-EL)
NoRepair or replace any malfunctioning parts.
6Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Go to symptom troubleshooting No. 10 "LOW IDLE/STALLS DURING DECELERATION". (See NO.10 LOW IDLE/STALLS DURING DECELERATION [LF, L3] .) Is the engine control system normal?YesRepeat the basic inspection and repair or replace any malfunctioning parts according to the inspection result. (See BASIC INSPECTION [FS5A-EL] ).
NoRepair or replace any malfunctioning parts according to the inspection results.
2Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Go to symptom troubleshooting No. 10 "LOW IDLE/STALLS DURING DECELERATION". (See NO.10 LOW IDLE/STALLS DURING DECELERATION [LF, L3] .) (See PCM INSPECTION [LF, L3] .) Is the engine control system normal?YesGo to the next step.
NoRepair or replace any malfunctioning parts according to the inspection results.
2Go to symptom troubleshooting No.5 "ENGINE STALLS-AFTER START/AT IDLE" (See NO.5 ENGINE STALLS-AFTER START/AT IDLE [LF, L3] .) (See PCM INSPECTION [LF, L3] .) Is the engine control system normal?YesRepeat the basic inspection and repair or replace any malfunctioning parts according to the inspection result. (See BASIC INSPECTION [FS5A-EL] ).
NoRepair or replace any malfunctioning parts according to the inspection results.
3Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1With the ignition switch at ON, When selector lever is moved, does selector illumination indicate synchronized position to lever location?YesGo to the next step.
NoCheck value at the following. TCM terminal voltage: 1U (TR switch) Repair or replace any defective parts.
2Inspect the voltage at TCM terminal 1K (M range switch). (See TCM INSPECTION [FS5A-EL] .) Is voltage normal?YesGo to the next step.
NoRepair or replace any defective part.
3Inspect the instrument cluster. (See INSTRUMENT CLUSTER INSPECTION .) Is instrument cluster normal?YesGo to the next step.
NoRepair or replace any defective part.
4Disconnect the TCM and instrument cluster connector. Turn the ignition switch off. Check continuity between the following circuits: TCM terminal 1B and body GND TCM terminal 1E and body GND Instrument cluster terminal 11 and body GND Instrument cluster terminal 1K and body GND Is there continuity?YesRepair or replace harness for short to GND, then go to the next step.
NoGo to the next step.
5Disconnect the TCM and instrument cluster connector. Turn the ignition switch off. Check continuity between the following circuits: TCM terminal 1B and instrument cluster terminal 11 TCM terminal 1E and instrument cluster terminal 1K Is there continuity?YesGo to the next step.
NoRepair or replace harness for open circuit, then go to the next step.
6Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1With the ignition switch at ON, When selector lever is moved, does selector illumination indicate synchronized position to lever location?YesGo to the next step.
NoCheck value at the following. TCM terminal voltage: 1U (TR switch) Repair or replace any defective parts.
2Inspect the voltage at TCM terminal 1K (M range switch). (See TCM INSPECTION [FS5A-EL] .) Is voltage normal?YesGo to the next step.
NoRepair or replace any defective part.
3Inspect the instrument cluster. (See INSTRUMENT CLUSTER INSPECTION .) Is instrument cluster normal?YesGo to the next step.
NoRepair or replace any defective part.
4Disconnect the TCM and instrument cluster connector. Turn the ignition switch off. Check continuity between the following circuits: TCM terminal 1B and body GND TCM terminal 1E and body GND Instrument cluster terminal 11 and body GND Instrument cluster terminal 1K and body GND Is there continuity?YesRepair or replace harness for short to GND, then go to the next step.
NoGo to the next step.
5Disconnect the TCM and instrument cluster connector. Turn the ignition switch off. Check continuity between the following circuits: TCM terminal 1B and instrument cluster terminal 11 TCM terminal 1E and instrument cluster terminal 1K Is there continuity?YesGo to the next step.
NoRepair or replace harness for open circuit, then go to the next step.
6Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line Repair information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Inspect the UP SW PID value using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) Is the UP SW PID value normal?YesInspect the instrument cluster.
NoInspect the up switch. If the up switch is normal, inspect for continuity between the up switch and TCM terminal G.
2Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Inspect the DWN SW PID value using the M-MDS. (See TCM INSPECTION [FS5A-EL] .) Is the DWN SW PID value normal?YesInspect the instrument cluster.
NoInspect the down switch. If the down switch is normal, inspect for continuity between the down switch and TCM terminal F.
2Verify the test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE

STEPINSPECTIONACTION
1Access the TCM PID MNL SW using the M-MDS. (see PID/DATA MONITOR INSPECTION [FS5A-EL] .) Monitor the MNL SW PID with move the selector lever to all positions and range. Does the PID indicate properly?YesInspect the instrument cluster using the input/output test mode. (See INSTRUMENT CLUSTER INSPECTION .)
NoInspect the M range switch. (See SELECTOR LEVER COMPONENT INSPECTION .) If the M range switch is normal, inspect and repair wiring harness between manual switch terminal A and TCM terminal K.
2Verify test results. If normal, return to the diagnostic index to service any additional symptoms. If the malfunction remains, inspect the related Service Bulletins and/or On-line repair information and perform repair or diagnosis. If the vehicle is repaired, troubleshooting is completed. If the vehicle is not repaired or additional diagnostic information is not available, replace the TCM.

DIAGNOSTIC PROCEDURE
