Automatic Transaxle Features & Operation (FS5A-EL): Specifications Mazda 3 BL

Automatic Trans 3 illustrations ~154 words

AUTOMATIC TRANSAXLE SPECIFICATIONS

ItemSpecification
Engine typeL3
Automatic transaxle typeFS5A-EL
Gear ratio1GR3.620
2GR1.925
3GR1.285
4GR0.939
5GR0.692
Reverse3.405
Final gear ratio3.863
ATFTypeATF M-V
Capacity (Approx. quantity)(L {US qt, IMP qt})8.14 {8.60, 7.16}
Torque converter stall torque ratio1.84
Hydraulic system (Number of drive/driven gear plates)Forward clutch4/4
3-4 clutch3/3
Reverse clutch2/2
Direct clutch2/3
Low and reverse brake5/5
Reduction brake3/5
Band servoServo diameter (Piston outer dia.)(mm {in})64.6 {2.54}
Front planetary gear (Number of teeth)Front sun gear49
Front pinion gear20
Front internal gear89
Rear planetary gear (Number of teeth)Rear sun gear37
Rear pinion gear30
Rear internal gear98
Primary gear (number of teeth)86
Secondary gear (number of teeth)82
Secondary planetary gear (Number of teeth)Secondary sun gear31
Secondary pinion gear29
Secondary internal gear89
Output gear (number of teeth)22
Ring gear (number of teeth)85

AUTOMATIC TRANSAXLE SPECIFICATIONS

Scheme 506

Scheme 506: AUTOMATIC TRANSAXLE CROSS-SECTIONAL VIEW

TORQUE CONVERTER OUTLINE

  1. The torque converter clutch mechanism mechanically engages the pump impeller and the turbine runner under a specified condition, and transmits the power, not through the fluid, but directly, preventing the slip loss of the torque converter.
  2. The torque converter has obtained sufficient transaxle efficiency and torque converting ratio that matches the output characteristic of each engine.

Scheme 507

Scheme 507

TORQUE CONVERTER STRUCTURE

  1. The torque converter with the TCC control consists of the turbine runner, pump impeller, stator, and the TCC piston as shown in the figure. The TCC piston engages with the turbine runner and slides on the turbine hub to be pushed and contacts with the torque converter cover during the TCC control operation. In the TCC piston, a spring for torsion damper is installed to absorb the engine torque fluctuation during TCC control.

Scheme 508

Scheme 508
