Special Tool(s)
SPECIAL TOOL REFERENCE TABLE Installer, Drive Pinion Oil Seal 205-115 Remover, Input Shaft Oil Seal 308-375 Slide Hammer 100-001 (T50T-100-A)
Scheme 97
Scheme 98
Scheme 99
SPECIAL TOOL SPECIFICATION TABLE Installer, Output Shaft Oil Seal (4X2) 308-382 Remover, RH Halfshaft Fluid Seal 307-429 Slide Hammer 100-001 (T50T-100-A)
Scheme 100
SPECIAL TOOL SPECIFICATION TABLE Support Bar, Engine 303-F072
Scheme 101
Scheme 102
| Item | Part Number | Description |
|---|---|---|
| 1 | W520214 | Transaxle support insulator nuts |
| 2 | 14A464 | Transaxle support insulator |
PART NUMBER REFERENCE TABLE
Scheme 103
Scheme 104
Scheme 105
Scheme 106
- Remove the Air Cleaner (ACL) assembly. For additional information, refer to «REMOVAL AND INSTALLATION»(ref-355999-S27106258062010013000000) .
- Install the Engine Support Bar and support the engine and transaxle.
- Disconnect the hood ajar electrical connector.
- Remove the bolt and the nut and position aside the Battery Junction Box (BJB). To install, tighten to 10 Nm (89 lb-in).
- Remove the 5 nuts and remove the transaxle support insulator and the bracket. To install, tighten to 90 Nm (66 lb-ft).
- To install, reverse the removal procedure.
Scheme 107
| Item | Part Number | Description |
|---|---|---|
| 1 | W706674 | Rear roll restrictor bolt |
| 2 | W500545 | Front roll restrictor bolt |
| 3 | 6P082 | Roll restrictor assembly |
PART NUMBER REFERENCE TABLE
Scheme 108
- With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-355922) .
- Remove the 7 screws and the underbody cover.
- Remove the 2 bolts and remove the roll restrictor.
