GEAR AND SOLENOID OPERATION TABLE
| Gear | SSC | SSD | SSE | SSF | SSA | SSB |
|---|---|---|---|---|---|---|
| 1st | OFF | ON | ON | ON | OFF | ON |
| 1st Engine Braking | OFF | ON | ON | ON | ON | ON |
| 2nd | OFF | ON | ON | OFF | OFF | OFF |
| 3rd | OFF | ON | OFF | ON | OFF | OFF |
| 4th | OFF | OFF | ON | ON | OFF | OFF |
| 5th | ON | OFF | OFF | ON | OFF | OFF |
| 6th | ON | OFF | ON | OFF | OFF | OFF |
GEAR AND SOLENOID OPERATION TABLE
Transaxle Description
This transaxle is a compact, lightweight, next generation electronically controlled, 6-speed automatic transaxle that employs Ravigeneaux-type and one single planetary gear set.
This transaxle contains a high-precision clutch hydraulic control system for a smooth, highly responsive gear shift feel.
All hydraulic functions are directed by electronic solenoids to control
- engagement feel.
- shift feel.
- shift scheduling.
- modulated Torque Converter Clutch (TCC) applications.
- engine braking, utilizing the coast clutch.
Scheme 3
When servicing the automatic transaxle, use the bar code identification label located on side of the transaxle case.
