Automatic Transaxle External Controls (Hybrid): Removal & Installation Lincoln MKZ I рестайлинг

Installation

Scheme 203

PART NUMBER REFERENCE

Scheme 204

Scheme 205

Scheme 206

Scheme 207

1. Remove the center console. For additional information, refer to «REMOVAL AND INSTALLATION»(ref-355963-S26424224192010013000000) .
2. Disconnect the selector lever cable end from the selector lever.
3. Release the tab on the selector lever cable and remove it from the selector lever housing.
4. Disconnect the electrical connector.
5. Remove the 4 nuts and remove the selector lever.

1. Install the selector lever and the 4 nuts. Tighten to 20 Nm (177 lb-in).
2. Connect the electrical connector.
3. Install the selector lever cable in the selector lever housing. NOTE: When installing the selector lever cable, make sure that the selector lever cable locking tabs are locked in place and the selector lever cable end is snapped onto the ball stud. Press the selector lever cable into the bracket and listen for the selector lever cable to click in place. Pull back on the selector lever cable to make sure that it is locked into the selector lever cable bracket. Also make sure that the selector lever cable end is correctly installed onto the ball stud. Pull back on the selector lever cable end to make sure that the selector lever cable end is correctly installed.
4. Connect the selector lever cable end to the selector lever.
5. Install the center console. For additional information, refer to «REMOVAL AND INSTALLATION»(ref-355963-S26424224192010013000000) .
6. Adjust the selector lever cable. For additional information, refer to «SELECTOR LEVER CABLE ADJUSTMENT»(ref-355980-S31996908222010013000000) .

Scheme 208

PART NUMBER REFERENCE TABLE

Scheme 209

Scheme 210

1. Slide the selector lever knob bezel downward to gain access to the 2 selector lever knob screws.
2. Remove the 2 screws from the selector lever knob. Remove the selector lever knob and the selector lever knob bezel.

Scheme 211

1. Install the selector lever knob on the selector lever and install the screws.
2. Slide the selector lever knob bezel up and install it on the selector lever knob.

Scheme 212

PART NUMBER REFERENCE TABLE

Scheme 213

Scheme 214

Scheme 215

Scheme 216

1. Remove the selector lever trim ring.
2. Remove the center console trim panel.
3. Remove the utility tray from the center console.
4. Disconnect the electrical connector and remove the utility tray.
5. Slide the selector lever knob bezel downward to gain access to the 2 selector lever knob screws.
6. Remove the 2 screws from the selector lever knob. Remove the selector lever knob and the selector lever knob bezel.
7. Disconnect the selector lever bezel electrical connector.
8. Release the 3 tabs and remove the selector lever knob bezel. NOTE: Selector lever removed for clarity.

Scheme 217

Scheme 218

1. Install the selector lever bezel on the selector lever. Position the override lever in the override lever guide. Make sure that the 3 locking tabs are locked in place. NOTE: Be sure that the override lever is inserted in the override lever guide or the shift interlock override button will not work correctly. NOTE: Selector lever removed for clarity.
2. Connect selector lever bezel electrical connector.
3. Install the selector lever knob on the selector lever and install the screws.
4. Slide the selector lever knob bezel up and install it on the selector lever knob.
5. Position the utility tray in place and connect the electrical connector.
6. Install the utility tray on the center console.
7. Install the center console trim panel.
8. Install the selector lever trim ring.
