HVAC - Climate Control System: Component Locations Lincoln MKZ I рестайлинг

Special Tool(s)

SPECIAL TOOL(S) SPECIFICATION TABLE Holding Fixture, Compressor Clutch Disc and Hub 412-134

Scheme 194

Scheme 195

ITEM DESCRIPTION TABLE

Scheme 196

Scheme 197

Scheme 198

1. Remove the A/C compressor. For additional information, refer to «Removal and Installation»(ref-355973-S14780606502010013000000) or «Removal and Installation»(ref-355973-S31292067872010013000000) .
2. Remove the 3 screws and the A/C clutch shield (if equipped).
3. Remove the A/C clutch disc and hub bolt. Hold the A/C clutch disc and hub with the Compressor Clutch Disc and Hub Holding Fixture. Remove the A/C clutch disc and hub bolt.
4. Remove the A/C clutch disc and hub.
5. Remove the A/C compressor pulley snap ring.
6. Remove the A/C compressor pulley.
7. Remove the A/C clutch field coil electrical connector clip screw.
8. Remove the A/C clutch field coil snap ring.
9. Remove the A/C clutch field coil.

Scheme 199

1. Visually inspect the A/C clutch disc and hub, A/C compressor pulley and A/C clutch field coil for damage. Inspect for physical damage, including cracked or melted components or discoloration due to excessive heat. Inspect for excessive wear, including grooving in the A/C clutch disc and hub or A/C compressor pulley that is more than fingernail depth. Inspect for roughness in the A/C compressor pulley bearing.
2. Clean the A/C clutch field coil and pulley mounting surfaces.
3. Install the A/C clutch field coil.
4. Install the A/C clutch field coil snap ring.
5. Install the A/C clutch field coil electrical connector clip screw.
6. Install the A/C clutch pulley. NOTE: The A/C clutch pulley is a tight fit on the A/C compressor head. It must be correctly aligned during installation.
7. Install the A/C clutch pulley snap ring.
8. Place one nominal thickness A/C clutch disc and hub spacer inside the clutch hub spline opening.
9. Install the A/C clutch disc and hub assembly.
10. Install the A/C clutch disc and hub bolt. Hold the A/C clutch disc and hub with the Compressor Clutch Disc and Hub Holding Fixture. Install the A/C clutch disc and hub bolt. Tighten to 14 Nm (124 lb-in).
11. Install the A/C clutch shield and the 3 screws (if equipped).
12. Measure and adjust the clutch air gap by removing or adding A/C clutch hub spacers.
13. Install the A/C compressor. For additional information, refer to «Removal and Installation»(ref-355973-S14780606502010013000000) or «Removal and Installation»(ref-355973-S31292067872010013000000) .
