Servicing - RX330: Removal & Installation Lexus RX II

Automatic Trans 15 illustrations ~1482 words

FILTER REPLACEMENT

This procedure is included in valve body removal and installation. See VALVE BODY ASSEMBLY under REMOVAL & INSTALLATION.

REMOVAL & INSTALLATION

WARNINGVehicle is equipped with Supplemental Inflatable Restraint (SIR) system. When servicing vehicle, use care to avoid accidental air bag deployment. SIR system related components are located in various locations throughout interior and exterior of vehicle, depending on application. Do not use electrical test equipment on or near these circuits. If necessary, deactivate SIR system before servicing components. See AIR BAG SAFETY PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM in AIRBAG article in RESTRAINTS.
CAUTIONWhen battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery.

Note. For component locations. see scheme 4

  1. Remove engine undercover No. 1 and 2, or undercover assembly. (Scheme 2)
  2. Drain ATF. See «DRAINING & REFILLING»(ref-168021-S40944435512004102800000) under LUBRICATION.
  3. Remove bolts, and carefully remove oil pan assembly, discard gasket. Examine particles in pan by Removing magnets using them to collect any steel chips. Look carefully at chips and particles in pan and on magnet to anticipate what type of wear you may find in transaxle. Steel is magnetic indicating bearing, gear and plate wear. Brass is non-magnetic indicating bearing wear.
  4. Disconnect transaxle wire: Disconnect shift solenoid connectors and remove bolt and lock plate from ATF temperature sensor. Disconnect the ATF temperature sensor. (Scheme 3) Disconnect the solenoid wire connector and remove the solenoid connector wire bolt. (Scheme 4) Remove solenoid connector wire. Discard the "O" ring.

Installation

  1. Install transaxle wire: Coat a NEW "O" ring with ATF and place on solenoid wire connector. (Scheme 5) Install the solenoid connector wire and bolt. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000). Connect solenoid connector. Coat a new "O" ring with ATF and install it on ATF temperature sensor. Install ATF temperature sensor with lock plate and bolt. (Scheme 3) Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000). Connect the shift solenoid valve connectors.
  2. Place magnets in oil pan. see scheme 3 Apply seal packing or equivalent to bolts (Manufacture recommends THREE BOND 1344). Install oil pan and a NEW gasket. Hand tighten bolts. Within 10 minutes of application of seal packing, tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000).
  3. Install a NEW gasket and drain plug. Tighten drain plug to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000).
  4. Fill transaxle with ATF and check ATF level. See «DRAINING & REFILLING»(ref-168021-S40944435512004102800000).
  5. Install engine undercover No. 1 and 2, or undercover assembly. (Scheme 2)
  6. Reset memory. See «COMPUTER RELEARN PROCEDURES»(ref-162030) in GENERAL INFORMATION.

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Removal & Installation FWD

  1. Remove front wheels.
  2. Remove engine undercover No. 1 and 2, or undercover assembly. (Scheme 2)
  3. Drain ATF. See «DRAINING & REFILLING»(ref-168021-S40944435512004102800000).
  4. Remove front axle shafts. See «AXLE SHAFTS - FRONT»(ref-164258) article in DRIVELINES/AXLES.
  5. Remove left and right hand side gear shaft differential oil seals using Special Tool. (Scheme 6)
  6. Install left side gear shaft oil seal: Using oil seal and bearing adapter and a hammer, drive in a NEW oil seal flush plus or minus 0.02 in. (0.5 mm). (Scheme 7) Coat lip of oil seal with multipurpose (MP) grease.
  7. Install right side gear shaft oil seal: Using oil seal and bearing adapter and a hammer, drive in a NEW oil seal flush plus or minus 0.02 in. (0.5 mm). (Scheme 8) Coat lip of oil seal with MP grease.
  8. Install front axle shafts. See «AXLE SHAFTS - FRONT»(ref-164258) article in DRIVELINES/AXLES.
  9. Install front wheels.
  10. Fill transaxle with ATF. See «DRAINING & REFILLING»(ref-168021-S40944435512004102800000).
  11. Install engine undercover No. 1 and 2, or undercover assembly. (Scheme 2)
  12. Check ABS sensor signal. See ANTILOCK/TRACTON CONTROL article in BRAKES.

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Removal & Installation AWD

Note. Procedure for right side requires transaxle removal.

  1. Remove left front wheel.
  2. Remove engine undercover No. 1 and 2, or undercover assembly. (Scheme 2)
  3. Drain ATF. See «DRAINING & REFILLING»(ref-168021-S40944435512004102800000).
  4. Remove front axle shafts. See «AXLE SHAFTS - FRONT»(ref-164258) article in DRIVELINES/AXLES.
  5. Remove left side gear shaft differential oil seal using Special Tool. (Scheme 6)
  6. Install left side gear shaft oil seal: Using oil seal and bearing adapter and a hammer, drive in a NEW oil seal flush plus or minus 0.02 in. (0.5 mm). (Scheme 7) Coat lip of oil seal with multipurpose (MP) grease.
  7. Install left front axle shaft. See «AXLE SHAFTS - FRONT»(ref-164258) article in DRIVELINES/AXLES.
  8. Install left front wheel.
  9. Fill transaxle with ATF. See «DRAINING & REFILLING»(ref-168021-S40944435512004102800000).
  10. Install engine undercover No. 1 and 2, or undercover assembly. (Scheme 2)

Remove

  1. Remove front bumper cover. see scheme 19
  2. Drain automatic transaxle fluid. See «DRAINING & REFILLING»(ref-168021-S40944435512004102800000) in LUBRICATION.
  3. Disconnect oil cooler hoses and Remove bolt "A", nut "B" and oil cooler. see scheme 18

Removal

  1. Remove battery. (Scheme 9)
  2. Remove air cleaner assembly.
  3. Remove air cleaner hose No. 1.
  4. Remove air cleaner inlet No. 2.
  5. Remove air cleaner bracket.
  6. Remove air cleaner inlet No. 1.
  7. Noting manufacturer, disconnect sensor connector, remove bolt and sensor.
  8. Remove and discard "O" ring from sensor.
  1. Coat a NEW "O" ring with ATF and install it on sensor.
  2. Install sensor with bolt. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000). Connect sensor connector.
  3. Install air cleaner inlet No. 1. (Scheme 9)
  4. Install air cleaner bracket.
  5. Install air cleaner inlet No. 2.
  6. Install air cleaner hose No. 1.
  7. Install air cleaner assembly.
  8. Install battery.

Scheme 9

Scheme 9
Scheme 9
  1. Remove battery. (Scheme 9)
  2. Remove air cleaner assembly.
  3. Remove air cleaner hose No. 1.
  4. Remove air cleaner inlet No. 2.
  5. Remove air cleaner bracket.
  6. Remove air cleaner inlet No. 1.
  7. Remove intake air resonator sub-assembly.
  8. Disconnecting transaxle control cable: Remove nut from control shaft lever. see scheme 8 Disconnect control cable from lever. Remove clip and disconnect control cable from bracket.
  9. Removing park/neutral position switch: Disconnect park/neutral position switch connector. Remove nut washer and control shaft lever. Using a screwdriver, pry off lock plate. (Scheme 10) Remove lock nut and lock plate. Remove 2 bolts and pull out park/neutral position switch. see scheme 5
  1. Installing park/neutral position switch: Install park/neutral position switch on manual valve shaft hand tighten 2 retaining bolts. see scheme 5 Install a new lock plate and nut. Tighten nut to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000). Adjust park/neutral position switch. See «PARK/NEUTRAL POSITION SWITCH»(ref-168021-S22626808392004102800000) under ADJUSTMENTS. Bend claws on lock plate to stake nut. (Scheme 10) Install nut and washer to transaxle control shaft lever. (Scheme 11) Tighten nut to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000). Install transaxle control shift cable and nut. see scheme 8 Tighten nut to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000). Install control cable and a NEW clip to bracket. Connect park/neutral position switch connector.
  2. Inspect and adjust shift lever position. See «SHIFT LEVER POSITION»(ref-168021-S30780865792004102800000) under ADJUSTMENTS.
  3. Verify correct park/neutral position switch operation. See «PARK/NEUTRAL POSITION SWITCH»(ref-168021-S22626808392004102800000) under ADJUSTMENTS.
  4. Install air intake resonator sub-assembly.
  5. Install air cleaner inlet No. 1. (Scheme 9) Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000).
  6. Install air cleaner bracket. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000).
  7. Install air cleaner inlet No. 2. (Scheme 9) Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000).
  8. Install air cleaner hose No. 1.
  9. Install air cleaner assembly. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000).
  10. Install battery. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000).

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11
CAUTIONA large amount of material debris including steel (magnetic) and non magnetic (brass, aluminum or clutch fiber particles) may indicate excessive transaxle wear or damage. Check magnets in oil pan for steel particles which indicate bearing, plate or hardware damage.
CAUTIONWhen removing transaxle oil pan, filter and valve body components, note bolt size, location and length for reassembly reference.
  1. Raise and support vehicle.
  2. Remove engine undercover No. 1 and 2, or undercover assembly. (Scheme 2)
  3. Drain transaxle fluid. See «DRAINING & REFILLING»(ref-168021-S40944435512004102800000) under LUBRICATION.
  4. Removing oil pan: Noting placement, remove oil pan bolts, and carefully remove pan assembly and gasket. Discard gasket. see scheme 3 Remove magnets and examine chips and particles in pan and magnets carefully to anticipate what type of wear you will find in transaxle: Steel (magnetic): indicate bearing, gear and plate wear. Brass (non-magnetic): indicate bushing wear.
  5. Disconnect shift solenoid connectors. (Scheme 3) Remove bolt and lock plate. Remove ATF temperature sensor.
  6. Remove 3 bolts and oil strainer. (Scheme 12) Remove "O" ring from oil strainer. (Scheme 13)
  7. Removing valve body: Support valve body and remove bolts and valve body assembly. (Scheme 14) Remove check ball body and spring. (Scheme 15). Remove bolts and shift solenoid valves. (Scheme 16)
  1. Install valve body: Install spring and check ball body. (Scheme 15) Install shift solenoid valves hand tighten bolts. (Scheme 16) Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000). Align groove of manual valve with pin of manual valve lever. Hand tighten 2 alignment bolts. Hand tighten valve body bolts. Tighten valve body bolts to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000).
  2. Install oil strainer. (Scheme 12): Coat a new "O" ring with ATF. Install "O" ring on oil strainer. Install oil strainer with 3 bolts. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000).
  3. Install Transaxle wire: Coat a NEW "O" ring with ATF. Install ATF temperature sensor with lock plate and bolt. (Scheme 3) Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000). Connect shift solenoid valve connectors.
  4. Place magnets in oil pan. see scheme 3 Apply seal packing or equivalent to bolts (Manufacture recommends THREE BOND 1344). Hand tighten 18 bolts. Install oil pan and a NEW gasket. Within 10 minutes of application of seal packing, tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000).
  5. Install a NEW oil drain plug gasket and drain plug. Tighten drain plug to specification. See «TORQUE SPECIFICATIONS»(ref-168021-S37518742892004102800000).
  6. Fill transaxle with ATF and check fluid level. See «DRAINING & REFILLING»(ref-168021-S40944435512004102800000) in LUBRICATION.
  7. Install engine undercover No. 1 and 2, or undercover assembly. (Scheme 2)
  8. Reset memory. See «COMPUTER RELEARN PROCEDURES»(ref-162030) in GENERAL INFORMATION.
  9. Lower vehicle.

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
