Multiplex Control Systems: Diagnosis Lexus LS III

Communication Devices 1 illustration ~282 words

SELF-DIAGNOSTICS

WARNINGDeactivate air bag system before performing any service operation. See AIR BAG RESTRAINT SYSTEMS article. DO NOT apply electrical power to any component on steering column without first deactivating air bag system. Air bag may deploy.

When diagnosing multiplex control system, perform BODY CONTROL ECU and OPEN DOOR INDICATOR LIGHT inspection procedures first to ensure DTCs can be retrieved. See PRELIMINARY INSPECTION .

Scheme 1

Scheme 1: Body ECU
  1. Check if Diagnostic Trouble Codes (DTCs) can be retrieved from body ECU. See «RETRIEVING DIAGNOSTIC TROUBLE CODES»(ref-27213-S19311377262001010800000). If DTCs can be accessed, perform appropriate self-diagnostics. If DTCs cannot be accessed, go to next step.
  2. Turn ignition off. Disconnect body ECU connector. (Scheme 1) Measure voltage between connector terminals No. 12 (Blue/Yellow wire) and No. 22 (White/Black wire). Battery voltage should be present. Check continuity between ground and connector terminals No. 22 (White/Black wire) and No. 11 (White/Black wire). Continuity should be present. Turn ignition on. Measure voltage between ground and connector terminals No. 2 (Red/Blue wire) and No. 13 (Gray wire). Battery voltage should be present. If voltages and continuity are to specification, go to next step. If voltages and continuity are not to specification, repair open or short circuit in wiring as necessary.
  3. Check White/Green wire between body ECU connector terminal No. 7 and Data Link Connector 3. Repair wiring as necessary. If wiring is okay, replace body ECU.

Scan Tool Method

Multiplex self-diagnostic system DTCs are retrieved through Data Link Connector 3 (DLC3). DLC3 is located under left side of instrument panel. Connect scan tool to DLC3. Turn ignition on. Follow LEXUS or scan tool instructions to retrieve DTCs. See MULTIPLEX DIAGNOSTIC TROUBLE CODE (DTC) DEFINITION table. If DTC(s) is present, perform appropriate test. See DIAGNOSTIC TESTS .

DIAGNOSTIC TROUBLE CODE DEFINITIONS

OBD-II DTCDescription
B1211Driver Door ECU To Body ECU Communication
B1212Passenger Front Door ECU To Body ECU Communication
B1213Tilt/Telescopic ECU To Body ECU Communication
B1214Door System Bus Communication Circuit Is Short To Power
B1215Door System Bus Communication Circuit Short To Ground
B1216Right Rear Door ECU To Body ECU Communication
B1217Left Rear Door ECU To Body ECU Communication
B1219Rear Seat Switch Communication Stop
B1248AVC-LAN Communication Impossible
B1261ECM To Body ECU Communication
B1262A/C Control Assembly To Body ECU Communication
B1263Luggage Room Junction Block ECU Communication Stop
B1266Instrument Panel System Bus Communication Circuit Short To Power
B1267Instrument Panel System Bus Communication Circuit Short To Ground
B1269Theft Deterrent ECU Communication Stop
B1271Combination Meter ECU To Body ECU Communication
B1272Power Seat ECU Communication
B1273Sliding Roof Control Relay To Body ECU Communication
B1275Accessory Bus Buffer To Body ECU Communication
B1277Center Cluster Integration Panel Communication Stop
B1278Combination Switch ECU Communication Stop
B1279Rain Sensor Communication Stop
B1281Air Bag ECU Communication Stop
B1282Skid Control ECU Communication Stop
B1283Driver Side Junction Block ECU Communication Stop
B1284Passenger Side Junction Block ECU Communication Stop
B1285Steering Pad Switch Communication Stop
B1291Light Control System Communication Bus Malfunction To Power
B1292Light Control System Communication Bus Malfunction To Ground
B1294Immobilizer ECU Communication Stop
B1296Front Light ECU Communication Stop
B1297Clearance Sonar ECU Communication Stop
B1298Right Rear Seat ECU Communication Stop
B1299Left Rear Seat ECU Communication Stop

MULTIPLEX DIAGNOSTIC TROUBLE CODE (DTC) DEFINITION

CLEARING DIAGNOSTIC TROUBLE CODES

Note. DTCs will be cleared from memory when DTC is normally retrieved.

DIAGNOSTIC TESTS

WARNINGDeactivate air bag system before performing any service operation. See AIR BAG RESTRAINT SYSTEMS article. DO NOT apply electrical power to any component on steering column without first deactivating air bag system. Air bag may deploy.
