1. SET RADIO RECEIVER ASSEMBLY TO SHIPMENT MODE Remove all discs and tape. NOTE: If the discs or tape cannot be removed, do not attempt to remove them forcibly. Send the unit to a repair shop. Turn the power switch OFF. While simultaneously pressing the "SEEK UP" and "DISC" switches, turn the power switch ON (ACC). HINT: The CD loading door indicator light blinks during mode setting and it remains lit after the setting is completed. Turn the power switch OFF.
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
3. REMOVE FRONT CONSOLE UPPER PANEL GARNISH . Refer to «REMOVAL - Step 17»(ref-387101-S14326776632011022400000)
4. REMOVE CONSOLE UPPER PANEL ASSEMBLY . Refer to «REMOVAL - Step 18»(ref-387101-S14326776632011022400000)
5. REMOVE INSTRUMENT PANEL FINISH PANEL END LH . Refer to «REMOVAL - Step 20»(ref-387101-S14326776632011022400000)
6. REMOVE INSTRUMENT PANEL FINISH PANEL END RH . Refer to «REMOVAL - Step 19»(ref-387101-S14326776632011022400000)
7. REMOVE MULTI-DISPLAY WITH RADIO RECEIVER ASSEMBLY Remove the 4 bolts. Pull the multi-display with radio receiver to detach the 2 clips on the backside of the multi-display. Disconnect the connectors and remove the multi-display with radio receiver.
8. CONFIRM RADIO RECEIVER ASSEMBLY SHIPMENT MODE SETTING Look at the backside of the radio receiver and check that a metal plate can be seen through the hole near the "SHIP" mark. NOTE: If a metal plate cannot be seen, perform the shipment mode setting again.
9. REMOVE NO. 2 RADIO BRACKET Remove the 5 bolts and bracket.
10. REMOVE NO. 1 RADIO BRACKET Remove the 5 bolts and bracket.
