Audio / Visual (Service Information): Removal & Installation Lexus GS III рестайлинг

INSTALLATION

HINT

A bolt without a torque specification is shown in the standard bolt chart. Refer to SPECIFIED TORQUE FOR STANDARD BOLTS .

Scheme 12

1. INSTALL NO. 2 RADIO BRACKET Install the bracket with the 5 bolts.
2. INSTALL NO. 1 RADIO BRACKET Install the bracket with the 5 bolts.
3. INSTALL MULTI-DISPLAY WITH RADIO RECEIVER ASSEMBLY Connect the connectors. Insert the multi-display with radio receiver and attach the 2 clips on its backside. Install the multi-display with radio receiver with the 4 bolts.
4. INSTALL INSTRUMENT PANEL FINISH PANEL END LH . Refer to «INSTALLATION - Step 19»(ref-387101-S06767646592011022400000)
5. INSTALL INSTRUMENT PANEL FINISH PANEL END RH . Refer to «INSTALLATION - Step 20»(ref-387101-S06767646592011022400000)
6. INSTALL CONSOLE UPPER PANEL ASSEMBLY . Refer to «INSTALLATION - Step 21»(ref-387101-S06767646592011022400000)
7. INSTALL FRONT CONSOLE UPPER PANEL GARNISH . Refer to «INSTALLATION - Step 22»(ref-387101-S06767646592011022400000)
8. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
9. PERFORM INITIALIZATION Perform initialization. Refer to «INITIALIZATION»(ref-386951-S21829001392011022400000) . NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

REMOVAL

1. SET RADIO RECEIVER ASSEMBLY TO SHIPMENT MODE See step 1
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
3. REMOVE FRONT CONSOLE UPPER PANEL GARNISH . Refer to «REMOVAL - Step 17»(ref-387101-S14326776632011022400000)
4. REMOVE CONSOLE UPPER PANEL ASSEMBLY . Refer to «REMOVAL - Step 18»(ref-387101-S14326776632011022400000)
5. REMOVE INSTRUMENT PANEL FINISH PANEL END LH . Refer to «REMOVAL - Step 20»(ref-387101-S14326776632011022400000)
6. REMOVE INSTRUMENT PANEL FINISH PANEL END RH . Refer to «REMOVAL - Step 19»(ref-387101-S14326776632011022400000)
7. REMOVE MULTI-DISPLAY WITH RADIO RECEIVER ASSEMBLY See step 7
8. CONFIRM RADIO RECEIVER ASSEMBLY SHIPMENT MODE SETTING See step 8
9. REMOVE NO. 2 RADIO BRACKET See step 9
10. REMOVE NO. 1 RADIO BRACKET See step 10

HINT

A bolt without a torque specification is shown in the standard bolt chart. Refer to SPECIFIED TORQUE FOR STANDARD BOLTS .

1. INSTALL NO. 2 RADIO BRACKET See step 1
2. INSTALL NO. 1 RADIO BRACKET See step 2
3. INSTALL MULTI-DISPLAY WITH RADIO RECEIVER ASSEMBLY See step 3
4. INSTALL INSTRUMENT PANEL FINISH PANEL END LH . Refer to «INSTALLATION - Step 19»(ref-387101-S06767646592011022400000)
5. INSTALL INSTRUMENT PANEL FINISH PANEL END RH . Refer to «INSTALLATION - Step 20»(ref-387101-S06767646592011022400000)
6. INSTALL CONSOLE UPPER PANEL ASSEMBLY . Refer to «INSTALLATION - Step 21»(ref-387101-S06767646592011022400000)
7. INSTALL FRONT CONSOLE UPPER PANEL GARNISH . Refer to «INSTALLATION - Step 22»(ref-387101-S06767646592011022400000)
8. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
9. PERFORM INITIALIZATION Perform initialization. Refer to «INITIALIZATION»(ref-386951-S21829001392011022400000) . NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL - Step 14»(ref-387104-S08102091462011022400000)
3. REMOVE LUGGAGE COMPARTMENT COVER RH
4. REMOVE STEREO COMPONENT AMPLIFIER ASSEMBLY WITH AMPLIFIER BRACKET Disconnect the connectors. Remove the 3 nuts and amplifier with bracket.
5. REMOVE NO. 2 AMPLIFIER BRACKET Remove the 2 screws and bracket.
6. REMOVE NO. 1 AMPLIFIER BRACKET Remove the 2 screws and bracket.
7. REMOVE STEREO COMPONENT AMPLIFIER ASSEMBLY

HINT

A bolt without a torque specification is shown in the standard bolt chart. Refer to SPECIFIED TORQUE FOR STANDARD BOLTS .

Scheme 17

Scheme 18

Scheme 19

1. INSTALL NO. 2 AMPLIFIER BRACKET Set the bracket's aligning protrusions labeled A into the amplifier's holes. Install the bracket with the 2 screws labeled B
2. INSTALL NO. 1 AMPLIFIER BRACKET Set the bracket's aligning protrusions labeled A into the amplifier's holes. Install the bracket with the 2 screws labeled B.
3. INSTALL STEREO COMPONENT AMPLIFIER ASSEMBLY WITH AMPLIFIER BRACKET Install the amplifier with the 3 nuts. HINT: Tighten the nuts in the order shown in the illustration.
4. INSTALL LUGGAGE COMPARTMENT COVER RH
5. INSTALL LUGGAGE COMPARTMENT FLOOR MAT . Refer to «INSTALLATION - Step 9»(ref-387104-S11194699402011022400000)
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
7. PERFORM INITIALIZATION Perform initialization. Refer to «INITIALIZATION»(ref-386951-S21829001392011022400000) . NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 20

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.

Scheme 21

1. REMOVE DOOR INSIDE HANDLE BEZEL . Refer to «REMOVAL - Step 1»(ref-387104-S13389567862011022400000)
2. REMOVE FRONT DOOR TRIM PANEL ASSEMBLY . Refer to «REMOVAL - Step 2»(ref-387104-S13389567862011022400000)
3. REMOVE FRONT NO. 1 SPEAKER ASSEMBLY Disconnect the speaker connector. Remove the 3 screws and speaker. NOTE: Do not touch the cone part of the speaker.

Scheme 22

1. INSPECT FRONT NO. 1 SPEAKER ASSEMBLY With the speaker installed, check that there is no looseness or other abnormalities. Check that there is no foreign matter in the speaker, no tears on the speaker's cone part, or other abnormalities. Measure the resistance of the speaker. Standard resistance (Standard models) Tester Connection Specified Condition 1 - 2 4 ohms Standard resistance (Mark Levinson models) Tester Connection Specified Condition 1 - 2 8 ohms If the result is not as specified, replace the speaker assembly.

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.

Scheme 23

1. INSTALL FRONT NO. 1 SPEAKER ASSEMBLY Temporarily install the speaker by attaching the claws of the speaker to the door panel. Install the speaker with the 3 screws. HINT: Install the screws in the order shown in the illustration. NOTE: Do not touch the cone part of the speaker. Connect the speaker connector.
2. INSTALL FRONT DOOR TRIM PANEL ASSEMBLY . Refer to «INSTALLATION - Step 30»(ref-387104-S05304920912011022400000)
3. INSTALL DOOR INSIDE HANDLE BEZEL . Refer to «INSTALLATION - Step 31»(ref-387104-S05304920912011022400000)

Scheme 24

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.

Scheme 25

Scheme 26

1. REMOVE REAR DOOR INSIDE HANDLE BEZEL . Refer to «REMOVAL - Step 2»(ref-387104-S06605344692011022400000)
2. REMOVE REAR DOOR TRIM PANEL ASSEMBLY . Refer to «REMOVAL - Step 4»(ref-387104-S06605344692011022400000)
3. REMOVE REAR SPEAKER ASSEMBLY Disconnect the speaker connector. Remove the 3 screws and speaker. NOTE: Do not touch the cone part of the speaker.
4. REMOVE REAR NO. 2 SPEAKER ASSEMBLY Disconnect the speaker connector. Remove the 2 screws and speaker. NOTE: Do not touch the cone part of the speaker.

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.

Scheme 27

Scheme 28

1. INSTALL REAR SPEAKER ASSEMBLY Temporarily install the speaker by attaching the claws of the speaker to the door panel. Install the speaker with the 3 screws. HINT: Install the screws in the order shown in the illustration. NOTE: Do not touch the cone part of the speaker. Connect the speaker connector.
2. INSTALL REAR NO. 2 SPEAKER ASSEMBLY Align the speaker with the door position pin labeled A. Install the speaker with the 2 screws. HINT: Install the screws in the order shown in the illustration. NOTE: Do not touch the cone part of the speaker. Connect the speaker connector.
3. INSTALL REAR DOOR TRIM PANEL ASSEMBLY . Refer to «INSTALLATION - Step 28»(ref-387104-S10619042932011022400000)
4. INSTALL REAR DOOR INSIDE HANDLE BEZEL . Refer to «INSTALLATION - Step 30»(ref-387104-S10619042932011022400000)

Scheme 29

Scheme 30

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. REMOVE SPEAKER HOLE COVER Using a screwdriver, detach the 4 clips and remove the hole cover. HINT: Tape the screwdriver tip before use.
2. REMOVE FRONT STEREO COMPONENT SPEAKER ASSEMBLY Remove the 2 bolts. Disconnect the speaker connector and remove the speaker. NOTE: Do not touch the cone part of the speaker.
3. REMOVE NO. 2 INSTRUMENT PANEL SPEAKER PANEL SUB-ASSEMBLY Using a screwdriver, detach the 2 clips and 2 claws. HINT: Tape the screwdriver tip before use. Remove the speaker panel.
4. REMOVE FRONT NO. 2 SPEAKER ASSEMBLY Remove the 2 bolts. Disconnect the speaker connector and remove the speaker. NOTE: Do not touch the cone part of the speaker.

Scheme 35

1. INSPECT FRONT STEREO COMPONENT SPEAKER ASSEMBLY With the speaker installed, check that there is no looseness or other abnormalities. Check that there is no foreign matter in the speaker, no tears on the speaker's cone part, or other abnormalities. Measure the resistance of the speaker. Standard resistance (Standard models) Tester Connection Specified Condition 1 - 2 10 ohms Standard resistance (Mark Levinson models) Tester Connection Specified Condition 1 - 2 8 ohms If the result is not as specified, replace the speaker assembly.
2. INSPECT FRONT NO. 2 SPEAKER ASSEMBLY With the speaker installed, check that there is no looseness or other abnormalities. Check that there is no foreign matter in the speaker, no tears on the speaker's cone part, or other abnormalities. When there is a possibility that either the right or left speaker is malfunctioning, interchange the speakers and perform an inspection. If the malfunction disappears after interchanging the speakers, replace the malfunctioning speaker. HINT: Connect all connectors to the speakers when performing an inspection. If the result is not as specified, replace the speaker assembly.

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.

Scheme 36

Scheme 37

Scheme 38

1. INSTALL FRONT STEREO COMPONENT SPEAKER ASSEMBLY Connect the speaker connector. Temporarily install the speaker by aligning the positioning pins of the speaker with the instrument panel. Install the speaker with the 2 bolts. NOTE: Do not touch the cone part of the speaker.
2. INSTALL SPEAKER HOLE COVER Attach the 4 clips to install the hole cover.
3. INSTALL FRONT NO. 2 SPEAKER ASSEMBLY Connect the speaker connector. Temporarily install the speaker by aligning the positioning pins of the speaker with the instrument panel. Install the speaker with the 2 bolts. NOTE: Do not touch the cone part of the speaker.
4. INSTALL NO. 2 INSTRUMENT PANEL SPEAKER PANEL SUB-ASSEMBLY Attach the 2 clips and 2 claws to install the panel.

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. REMOVE REAR SEAT CUSHION ASSEMBLY . Refer to «REMOVAL - Step 1»(ref-386977-S11477294662011022400000)
2. REMOVE REAR SEAT HEADREST ASSEMBLY
3. REMOVE CENTER REAR SEAT HEADREST ASSEMBLY
4. REMOVE REAR SEATBACK ASSEMBLY . Refer to «REMOVAL - Step 4»(ref-386977-S11477294662011022400000)
5. REMOVE REAR SEAT OUTER BELT ASSEMBLY . Refer to «REMOVAL - Step 8»(ref-387151-S28244569492011022400000)
6. REMOVE REAR SEAT INNER WITH CENTER BELT ASSEMBLY RH . Refer to «REMOVAL - Step 9»(ref-387151-S28244569492011022400000)
7. REMOVE REAR DOOR SCUFF PLATE LH . Refer to «REMOVAL - Step 15»(ref-387112-S08813470752011022400000)
8. REMOVE REAR DOOR SCUFF PLATE RH . Refer to «REMOVAL - Step 16»(ref-387112-S08813470752011022400000)
9. REMOVE REAR SEAT SIDE GARNISH LH . Refer to «REMOVAL - Step 21»(ref-387112-S08813470752011022400000)
10. REMOVE REAR SEAT SIDE GARNISH RH . Refer to «REMOVAL - Step 22»(ref-387112-S08813470752011022400000)
11. REMOVE ROOF SIDE GARNISH INNER LH . Refer to «REMOVAL - Step 23»(ref-387112-S08813470752011022400000)
12. REMOVE ROOF SIDE GARNISH INNER RH . Refer to «REMOVAL - Step 24»(ref-387112-S08813470752011022400000)
13. REMOVE HIGH MOUNTED STOP LIGHT ASSEMBLY . Refer to «REMOVAL - Step 2»(ref-387111-S20442389652011022400000)
14. REMOVE AUTOMATIC LIGHT CONTROL SENSOR . Refer to «REMOVAL - Step 3»(ref-387111-S20442389652011022400000)
15. REMOVE PACKAGE TRAY TRIM PANEL ASSEMBLY (w/o Rear Sunshade) . Refer to «REMOVAL - Step 12»(ref-387151-S29971367972011022400000)
16. REMOVE PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade) . Refer to «REMOVAL - Step 11»(ref-387151-S29971367972011022400000)
17. REMOVE NO. 2 PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade) . Refer to «REMOVAL - Step 16»(ref-387112-S33158236132011022400000)
18. REMOVE STEREO COMPONENT SPEAKER ASSEMBLY Disconnect the speaker connector. Remove the 4 bolts and speaker. NOTE: Do not touch the cone part of the speaker.
19. REMOVE REAR HEADER SPEAKER ASSEMBLY Remove the bolt. Detach the clip, disconnect the speaker connector and remove the speaker. WARNING: Do not touch the cone part of the speaker.

Scheme 43

1. INSPECT STEREO COMPONENT SPEAKER ASSEMBLY With the speaker installed, check that there is no looseness or other abnormalities. Check that there is no foreign matter in the speaker, no tears on the speaker's cone part, or other abnormalities. Measure the resistance of the speaker. Standard resistance (Standard models) Tester Connection Specified Condition 4 (WF1+) - 3 (WF1-) Approximately 2.5 ohms 2 (WF2+) - 1 (WF2-) Approximately 2.5 ohms Standard resistance (Mark Levinson models) Tester Connection Specified Condition 4 (WF1+) - 2 (WF2+) 12.5 to 16.5 ohms If the result is not as specified, replace the speaker assembly.
2. INSPECT REAR HEADER SPEAKER ASSEMBLY With the speaker installed, check that there is no looseness or other abnormalities. Check that there is no foreign matter in the speaker, no tears on the speaker's cone part, or other abnormalities. When there is a possibility that either the right or left speaker is malfunctioning, interchange the speakers and perform an inspection. If the malfunction disappears after interchanging the speakers, replace the malfunctioning speaker. HINT: Connect all connectors to the speakers when performing an inspection. If the result is not as specified, replace the speaker assembly.

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.

Scheme 44

1. INSTALL STEREO COMPONENT SPEAKER ASSEMBLY Install the speaker with the 4 bolts. HINT: Install the bolts in the order shown in the illustration. NOTE: Do not touch the cone part of the speaker. Connect the speaker connector.
2. INSTALL REAR HEADER SPEAKER ASSEMBLY Connect the speaker connector. Install the speaker and attach the clip. Install the bolt. NOTE: Do not touch the cone part of the speaker.
3. INSTALL NO. 2 PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade) . Refer to «INSTALLATION - Step 3»(ref-387112-S40931681392011022400000)
4. INSTALL PACKAGE TRAY TRIM PANEL ASSEMBLY (w/o Rear Sunshade) . Refer to «INSTALLATION - Step 3»(ref-387151-S21399536462011022400000)
5. INSTALL PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade) . Refer to «INSTALLATION - Step 2»(ref-387151-S21399536462011022400000)
6. INSTALL AUTOMATIC LIGHT CONTROL SENSOR . Refer to «INSTALLATION - Step 1»(ref-387111-S01289727162011022400000)
7. INSTALL HIGH MOUNTED STOP LIGHT ASSEMBLY . Refer to «INSTALLATION - Step 2»(ref-387111-S01289727162011022400000)
8. INSTALL ROOF SIDE GARNISH INNER LH . Refer to «INSTALLATION - Step 15»(ref-387112-S34119271062011022400000)
9. INSTALL ROOF SIDE GARNISH INNER RH . Refer to «INSTALLATION - Step 16»(ref-387112-S34119271062011022400000)
10. INSTALL REAR SEAT SIDE GARNISH LH . Refer to «INSTALLATION - Step 17»(ref-387112-S34119271062011022400000)
11. INSTALL REAR SEAT SIDE GARNISH RH . Refer to «INSTALLATION - Step 18»(ref-387112-S34119271062011022400000)
12. INSTALL REAR DOOR SCUFF PLATE LH . Refer to «INSTALLATION - Step 23»(ref-387112-S34119271062011022400000)
13. INSTALL REAR DOOR SCUFF PLATE RH . Refer to «INSTALLATION - Step 24»(ref-387112-S34119271062011022400000)
14. INSTALL REAR SEAT OUTER BELT ASSEMBLY . Refer to «INSTALLATION - Step 9»(ref-387151-S21399536462011022400000)
15. INSTALL REAR SEAT INNER WITH CENTER BELT ASSEMBLY RH . Refer to «INSTALLATION - Step 8»(ref-387151-S21399536462011022400000)
16. INSTALL REAR SEATBACK ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-386977-S42246080722011022400000)
17. INSTALL REAR SEAT HEADREST ASSEMBLY
18. INSTALL CENTER REAR SEAT HEADREST ASSEMBLY
19. INSTALL REAR SEAT CUSHION ASSEMBLY . Refer to «INSTALLATION - Step 4»(ref-386977-S42246080722011022400000)

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

1. SET RADIO RECEIVER ASSEMBLY TO SHIPMENT MODE See step 1
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
3. REMOVE FRONT CONSOLE UPPER PANEL GARNISH . Refer to «REMOVAL - Step 17»(ref-387101-S14326776632011022400000)
4. REMOVE CONSOLE UPPER PANEL ASSEMBLY . Refer to «REMOVAL - Step 18»(ref-387101-S14326776632011022400000)
5. REMOVE INSTRUMENT PANEL FINISH PANEL END LH . Refer to «REMOVAL - Step 20»(ref-387101-S14326776632011022400000)
6. REMOVE INSTRUMENT PANEL FINISH PANEL END RH . Refer to «REMOVAL - Step 19»(ref-387101-S14326776632011022400000)
7. REMOVE CONSOLE BOX PLATE . Refer to «REMOVAL - Step 21»(ref-387101-S14326776632011022400000)
8. REMOVE CONSOLE BOX REGISTER ASSEMBLY . Refer to «REMOVAL - Step 22»(ref-387101-S14326776632011022400000)
9. REMOVE CONSOLE BOX . Refer to «REMOVAL - Step 23»(ref-387101-S14326776632011022400000)
10. REMOVE MULTI-DISPLAY WITH RADIO RECEIVER ASSEMBLY See step 7
11. CONFIRM RADIO RECEIVER ASSEMBLY SHIPMENT MODE See step 8
12. REMOVE ANTENNA CORD SUB-ASSEMBLY Disconnect the connector labeled A. Detach the clip labeled B and remove the antenna cord.
13. REMOVE REAR SEAT CUSHION ASSEMBLY . Refer to «REMOVAL - Step 1»(ref-386977-S11477294662011022400000)
14. REMOVE REAR SEAT HEADREST ASSEMBLY LH AND RH
15. REMOVE REAR SEAT HEADREST ASSEMBLY CENTER
16. REMOVE REAR SEATBACK ASSEMBLY . Refer to «REMOVAL - Step 4»(ref-386977-S11477294662011022400000)
17. REMOVE REAR DOOR SCUFF PLATE RH . Refer to «REMOVAL - Step 16»(ref-387112-S08813470752011022400000)
18. REMOVE REAR SEAT SIDE GARNISH RH . Refer to «REMOVAL - Step 22»(ref-387112-S08813470752011022400000)
19. REMOVE NO. 2 ANTENNA CORD SUB-ASSEMBLY Standard Models: Disconnect the connector labeled A. Mark Levinson Models: Disconnect the 2 connectors labeled A. Remove the 3 bolts labeled B. Detach the antenna cord protector's 3 clips labeled C from the floor stud bolts. Detach the 6 clips labeled D and remove the antenna cord.

HINT

A bolt without a torque specification is shown in the standard bolt chart. Refer to SPECIFIED TORQUE FOR STANDARD BOLTS .

Scheme 51

Scheme 52

1. INSTALL NO. 2 ANTENNA CORD SUB-ASSEMBLY Attach the 6 clips labeled A. Attach the antenna cord protector's 3 clips labeled B to the floor stud bolts. Install the 3 bolts labeled C. Standard Models: Connect the connector labeled D. Mark Levinson Models: Connect the 2 connectors labeled D.
2. INSTALL REAR SEAT SIDE GARNISH RH . Refer to «INSTALLATION - Step 18»(ref-387112-S34119271062011022400000)
3. INSTALL REAR DOOR SCUFF PLATE RH . Refer to «INSTALLATION - Step 24»(ref-387112-S34119271062011022400000)
4. INSTALL REAR SEATBACK ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-386977-S42246080722011022400000)
5. INSTALL REAR SEAT HEADREST ASSEMBLY LH AND RH
6. INSTALL REAR SEAT HEADREST ASSEMBLY CENTER
7. INSTALL REAR SEAT CUSHION ASSEMBLY . Refer to «INSTALLATION - Step 4»(ref-386977-S42246080722011022400000)
8. INSTALL ANTENNA CORD SUB-ASSEMBLY Attach the clip labeled A. Connect the connector labeled B.
9. INSTALL MULTI-DISPLAY WITH RADIO RECEIVER ASSEMBLY See step 3
10. INSTALL CONSOLE BOX . Refer to «INSTALLATION - Step 16»(ref-387101-S06767646592011022400000)
11. INSTALL CONSOLE BOX REGISTER ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-387101-S06767646592011022400000)
12. INSTALL CONSOLE BOX PLATE . Refer to «INSTALLATION - Step 18»(ref-387101-S06767646592011022400000)
13. INSTALL INSTRUMENT PANEL FINISH PANEL END LH . Refer to «INSTALLATION - Step 19»(ref-387101-S06767646592011022400000)
14. INSTALL INSTRUMENT PANEL FINISH PANEL END RH . Refer to «INSTALLATION - Step 20»(ref-387101-S06767646592011022400000)
15. INSTALL CONSOLE UPPER PANEL ASSEMBLY . Refer to «INSTALLATION - Step 21»(ref-387101-S06767646592011022400000)
16. INSTALL FRONT CONSOLE UPPER PANEL GARNISH . Refer to «INSTALLATION - Step 22»(ref-387101-S06767646592011022400000)
17. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
18. PERFORM INITIALIZATION Perform initialization. Refer to «INITIALIZATION»(ref-386951-S21829001392011022400000) . NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY LH . Refer to «REMOVAL - Step 2»(ref-386977-S30597171782011022400000)
3. REMOVE FRONT SEAT ASSEMBLY . Refer to «REMOVAL - Step 6»(ref-386977-S30597171782011022400000)
4. REMOVE REAR SEAT CUSHION ASSEMBLY . Refer to «REMOVAL - Step 1»(ref-386977-S11477294662011022400000)
5. REMOVE REAR SEAT HEADREST ASSEMBLY LH AND RH
6. REMOVE REAR SEAT HEADREST ASSEMBLY CENTER
7. REMOVE REAR SEATBACK ASSEMBLY . Refer to «REMOVAL - Step 4»(ref-386977-S11477294662011022400000)
8. REMOVE FRONT CONSOLE UPPER PANEL GARNISH . Refer to «REMOVAL - Step 17»(ref-387101-S14326776632011022400000)
9. REMOVE CONSOLE UPPER PANEL ASSEMBLY . Refer to «REMOVAL - Step 18»(ref-387101-S14326776632011022400000)
10. REMOVE INSTRUMENT PANEL FINISH PANEL END LH . Refer to «REMOVAL - Step 20»(ref-387101-S14326776632011022400000)
11. REMOVE INSTRUMENT PANEL FINISH PANEL END RH . Refer to «REMOVAL - Step 19»(ref-387101-S14326776632011022400000)
12. REMOVE CONSOLE BOX PLATE . Refer to «REMOVAL - Step 21»(ref-387101-S14326776632011022400000)
13. REMOVE CONSOLE BOX REGISTER ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-387101-S06767646592011022400000)
14. REMOVE CONSOLE BOX . Refer to «REMOVAL - Step 23»(ref-387101-S14326776632011022400000)
15. REMOVE FRONT DOOR SCUFF PLATE LH . Refer to «REMOVAL - Step 9»(ref-387112-S08813470752011022400000)
16. REMOVE FRONT DOOR SCUFF PLATE RH . Refer to «REMOVAL - Step 10»(ref-387112-S08813470752011022400000)
17. REMOVE FRONT DOOR OPENING TRIM COVER LH . Refer to «REMOVAL - Step 11»(ref-387112-S08813470752011022400000)
18. REMOVE FRONT DOOR OPENING TRIM COVER RH . Refer to «REMOVAL - Step 12»(ref-387112-S08813470752011022400000)
19. REMOVE FRONT PILLAR GARNISH LH . Refer to «REMOVAL - Step 13»(ref-387112-S08813470752011022400000)
20. REMOVE FRONT PILLAR GARNISH RH . Refer to «REMOVAL - Step 14»(ref-387112-S08813470752011022400000)
21. REMOVE REAR DOOR SCUFF PLATE LH . Refer to «REMOVAL - Step 15»(ref-387112-S08813470752011022400000)
22. REMOVE REAR DOOR SCUFF PLATE RH . Refer to «REMOVAL - Step 16»(ref-387112-S08813470752011022400000)
23. REMOVE CENTER PILLAR GARNISH LOWER LH . Refer to «REMOVAL - Step 17»(ref-387112-S08813470752011022400000)
24. REMOVE CENTER PILLAR GARNISH LOWER RH . Refer to «REMOVAL - Step 18»(ref-387112-S08813470752011022400000)
25. REMOVE CENTER PILLAR GARNISH LH . Refer to «REMOVAL - Step 19»(ref-387112-S08813470752011022400000)
26. REMOVE CENTER PILLAR GARNISH RH . Refer to «REMOVAL - Step 20»(ref-387112-S08813470752011022400000)
27. REMOVE REAR SEAT SIDE GARNISH LH . Refer to «REMOVAL - Step 21»(ref-387112-S08813470752011022400000)
28. REMOVE REAR SEAT SIDE GARNISH RH . Refer to «REMOVAL - Step 22»(ref-387112-S08813470752011022400000)
29. REMOVE ROOF SIDE GARNISH INNER LH . Refer to «REMOVAL - Step 23»(ref-387112-S08813470752011022400000)
30. REMOVE ROOF SIDE GARNISH INNER RH . Refer to «REMOVAL - Step 24»(ref-387112-S08813470752011022400000)
31. REMOVE INNER REAR VIEW MIRROR COVER . Refer to «REMOVAL - Step 25»(ref-387112-S08813470752011022400000)
32. REMOVE FRONT ROOFTOP GARNISH . Refer to «REMOVAL - Step 26»(ref-387112-S08813470752011022400000)
33. REMOVE PERSONAL LIGHT ASSEMBLY . Refer to «REMOVAL - Step 27»(ref-387112-S08813470752011022400000)
34. REMOVE INNER REAR VIEW MIRROR ASSEMBLY . Refer to «REMOVAL - Step 28»(ref-387112-S08813470752011022400000)
35. REMOVE REAR ROOM LIGHT ASSEMBLY . Refer to «REMOVAL - Step 29»(ref-387112-S08813470752011022400000)
36. REMOVE STEERING SPOT LIGHT ASSEMBLY . Refer to «REMOVAL - Step 30»(ref-387112-S08813470752011022400000)
37. REMOVE ASSIST GRIP ASSEMBLY . Refer to «REMOVAL - Step 31»(ref-387112-S08813470752011022400000)
38. REMOVE VISOR BRACKET COVER . Refer to «REMOVAL - Step 32»(ref-387112-S08813470752011022400000)
39. REMOVE VISOR ASSEMBLY LH . Refer to «REMOVAL - Step 33»(ref-387112-S08813470752011022400000)
40. REMOVE VISOR ASSEMBLY RH . Refer to «REMOVAL - Step 34»(ref-387112-S08813470752011022400000)
41. REMOVE VISOR HOLDER . Refer to «REMOVAL - Step 35»(ref-387112-S08813470752011022400000)
42. REMOVE ROOF HEADLINING ASSEMBLY . Refer to «REMOVAL - Step 36»(ref-387112-S08813470752011022400000)
43. REMOVE AMPLIFIER ANTENNA ASSEMBLY Disconnect the antenna connectors. Detach the 3 clips labeled A and remove the 2 nuts labeled B. Detach the clip labeled C and remove the amplifier antenna.

Scheme 62

1. INSTALL AMPLIFIER ANTENNA ASSEMBLY Use non-residue solvent to clean the area on the glass where the antenna will be installed. NOTE: Do not use non-residue solvent to clean the antenna's contact points. Doing so may cause improper contact between the antenna and glass. Temporarily install the antenna with the clip labeled A, and then install the antenna with the 2 nuts labeled B. Torque: 14 N*m (143 kgf*cm, 10 ft.*lbf) NOTE: Just before installing the antenna to the glass, remove the protective cover of the antenna's contact points. When removing the protective cover of the antenna's contact points, make sure the cover does not touch the contact points. Never touch the contact points after removing the protective cover. After removing the protective cover, return it to the manufacturer for recycling. Do not reuse the clip labeled A. Attach the 3 clips labeled C. Connect the antenna connectors.
2. INSTALL ROOF HEADLINING ASSEMBLY . Refer to «INSTALLATION - Step 3»(ref-387112-S34119271062011022400000)
3. INSTALL VISOR HOLDER
4. INSTALL VISOR ASSEMBLY LH . Refer to «INSTALLATION - Step 5»(ref-387112-S34119271062011022400000)
5. INSTALL VISOR ASSEMBLY RH . Refer to «INSTALLATION - Step 6»(ref-387112-S34119271062011022400000)
6. INSTALL VISOR BRACKET COVER . Refer to «INSTALLATION - Step 7»(ref-387112-S34119271062011022400000)
7. INSTALL STEERING SPOT LIGHT ASSEMBLY . Refer to «INSTALLATION - Step 8»(ref-387112-S34119271062011022400000)
8. INSTALL ASSIST GRIP ASSEMBLY
9. INSTALL REAR ROOM LIGHT ASSEMBLY . Refer to «INSTALLATION - Step 10»(ref-387112-S34119271062011022400000)
10. INSTALL INNER REAR VIEW MIRROR ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-387163-S03588694022011022400000)
11. INSTALL PERSONAL LIGHT ASSEMBLY . Refer to «INSTALLATION - Step 12»(ref-387112-S34119271062011022400000)
12. INSTALL FRONT ROOF TOP GARNISH . Refer to «INSTALLATION - Step 13»(ref-387112-S34119271062011022400000)
13. INSTALL INNER REAR VIEW MIRROR COVER
14. INSTALL ROOF SIDE GARNISH INNER LH . Refer to «INSTALLATION - Step 15»(ref-387112-S34119271062011022400000)
15. INSTALL ROOF SIDE GARNISH INNER RH . Refer to «INSTALLATION - Step 16»(ref-387112-S34119271062011022400000)
16. INSTALL REAR SEAT SIDE GARNISH LH . Refer to «INSTALLATION - Step 15»(ref-387112-S34119271062011022400000)
17. INSTALL REAR SEAT SIDE GARNISH RH . Refer to «INSTALLATION - Step 18»(ref-387112-S34119271062011022400000)
18. INSTALL CENTER PILLAR GARNISH LH . Refer to «INSTALLATION - Step 19»(ref-387112-S34119271062011022400000)
19. INSTALL CENTER PILLAR GARNISH RH . Refer to «INSTALLATION - Step 20»(ref-387112-S34119271062011022400000)
20. INSTALL CENTER PILLAR GARNISH LOWER LH . Refer to «INSTALLATION - Step 21»(ref-387112-S34119271062011022400000)
21. INSTALL CENTER PILLAR GARNISH LOWER RH . Refer to «INSTALLATION - Step 22»(ref-387112-S34119271062011022400000)
22. INSTALL REAR DOOR SCUFF PLATE LH . Refer to «INSTALLATION - Step 23»(ref-387112-S34119271062011022400000)
23. INSTALL REAR DOOR SCUFF PLATE RH . Refer to «INSTALLATION - Step 24»(ref-387112-S34119271062011022400000)
24. INSTALL FRONT PILLAR GARNISH LH . Refer to «INSTALLATION - Step 25»(ref-387112-S34119271062011022400000)
25. INSTALL FRONT PILLAR GARNISH RH . Refer to «INSTALLATION - Step 26»(ref-387112-S34119271062011022400000)
26. INSTALL FRONT DOOR OPENING TRIM COVER LH . Refer to «INSTALLATION - Step 27»(ref-387112-S34119271062011022400000)
27. INSTALL FRONT DOOR OPENING TRIM COVER RH . Refer to «INSTALLATION - Step 28»(ref-387112-S34119271062011022400000)
28. INSTALL FRONT DOOR SCUFF PLATE LH . Refer to «INSTALLATION - Step 29»(ref-387112-S34119271062011022400000)
29. INSTALL FRONT DOOR SCUFF PLATE RH . Refer to «INSTALLATION - Step 30»(ref-387112-S34119271062011022400000)
30. INSTALL CONSOLE BOX . Refer to «INSTALLATION - Step 16»(ref-387101-S06767646592011022400000)
31. INSTALL CONSOLE BOX REGISTER ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-387101-S06767646592011022400000)
32. INSTALL CONSOLE BOX PLATE . Refer to «INSTALLATION - Step 18»(ref-387101-S06767646592011022400000)
33. INSTALL INSTRUMENT PANEL FINISH PANEL END LH . Refer to «INSTALLATION - Step 19»(ref-387101-S06767646592011022400000)
34. INSTALL INSTRUMENT PANEL FINISH PANEL END RH . Refer to «INSTALLATION - Step 20»(ref-387101-S06767646592011022400000)
35. INSTALL CONSOLE UPPER PANEL ASSEMBLY . Refer to «INSTALLATION - Step 21»(ref-387101-S06767646592011022400000)
36. INSTALL FRONT CONSOLE UPPER PANEL GARNISH . Refer to «INSTALLATION - Step 22»(ref-387101-S06767646592011022400000)
37. INSTALL REAR SEATBACK ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-386977-S42246080722011022400000)
38. INSTALL REAR SEAT HEADREST ASSEMBLY CENTER
39. INSTALL REAR SEAT HEADREST ASSEMBLY LH AND RH
40. INSTALL REAR SEAT CUSHION ASSEMBLY . Refer to «INSTALLATION - Step 4»(ref-386977-S42246080722011022400000)
41. INSTALL FRONT SEAT ASSEMBLY . Refer to «INSTALLATION - Step 37»(ref-387112-S34119271062011022400000)
42. CONNECT FRONT SEAT OUTER BELT ASSEMBLY LH . Refer to «INSTALLATION - Step 2»(ref-387151-S33576064432011022400000)
43. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
44. PERFORM INITIALIZATION Perform initialization. Refer to «INITIALIZATION»(ref-386951-S21829001392011022400000) . NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
45. INSPECT FRONT POWER SEAT CONTROL SYSTEM Inspect the front power seat control system. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-386970-S28743518142011022400000) . Inspect the front power seat control system (w/ seat position memory system). Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-386970-S28743518142011022400000) .
46. INSPECT SEAT HEATER CONTROL Inspect the seat heater control. Refer to «INSTALLATION - Step 41»(ref-387112-S34119271062011022400000) .
47. INSPECT CLIMATE CONTROL SEAT SYSTEM Inspect the climate control seat system. Refer to «OPERATION CHECK»(ref-387174-S37745058812011022400000) .
48. INSPECT SEAT BELT WARNING SYSTEM Inspect the seat belt warning system. Refer to «ON-VEHICLE INSPECTION»(ref-387153-S42184942632011022400000) .

Scheme 63

Scheme 64

1. REMOVE CONSOLE BOX REGISTER ASSEMBLY . Refer to «REMOVAL - Step 6»(ref-387101-S25865537512011022400000)
2. REMOVE STEREO JACK ADAPTER ASSEMBLY Disconnect the connector. Disengage the 2 claws and remove the stereo jack adapter assembly.

1. INSTALL STEREO JACK ADAPTER ASSEMBLY Engage the 2 claws and install the stereo jack adapter assembly. Connect the connector.
2. INSTALL CONSOLE BOX REGISTER ASSEMBLY . Refer to «INSTALLATION - Step 2»(ref-387101-S30221634372011022400000)

Scheme 65

Scheme 66

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE FRONT CONSOLE UPPER PANEL GARNISH . Refer to «REMOVAL - Step 17»(ref-387101-S14326776632011022400000)
3. REMOVE CONSOLE UPPER PANEL ASSEMBLY . Refer to «REMOVAL - Step 18»(ref-387101-S14326776632011022400000)
4. REMOVE INSTRUMENT PANEL FINISH PANEL END RH . Refer to «REMOVAL - Step 19»(ref-387101-S14326776632011022400000)
5. REMOVE FRONT DOOR SCUFF PLATE RH . Refer to «REMOVAL - Step 10»(ref-387112-S08813470752011022400000)
6. REMOVE FRONT DOOR OPENING TRIM COVER RH . Refer to «REMOVAL - Step 12»(ref-387112-S08813470752011022400000)
7. REMOVE INSTRUMENT SIDE PANEL RH . Refer to «REMOVAL - Step 26»(ref-387101-S14326776632011022400000)
8. REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 32»(ref-387101-S14326776632011022400000)
9. REMOVE FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY . Refer to «REMOVAL - Step 9»(ref-386976-S06366199182011022400000)
10. REMOVE GLOVE COMPARTMENT DOOR SUB-ASSEMBLY . Refer to «REMOVAL - Step 34»(ref-387101-S14326776632011022400000)
11. REMOVE NETWORK GATEWAY ECU Disconnect the ECU connector. Detach the 2 claws and remove the cover. Remove the ECU.

1. INSTALL NETWORK GATEWAY ECU Install the ECU. Attach the 2 claws to install the cover. Connect the ECU connector.
2. INSTALL GLOVE COMPARTMENT DOOR SUB-ASSEMBLY . Refer to «INSTALLATION - Step 5»(ref-387101-S06767646592011022400000)
3. INSTALL FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-386976-S40157070732011022400000)
4. INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 7»(ref-387101-S06767646592011022400000)
5. INSTALL INSTRUMENT SIDE PANEL RH . Refer to «INSTALLATION - Step 13»(ref-387101-S06767646592011022400000)
6. INSTALL FRONT DOOR OPENING TRIM COVER RH . Refer to «INSTALLATION - Step 28»(ref-387112-S34119271062011022400000)
7. INSTALL FRONT DOOR SCUFF PLATE RH . Refer to «INSTALLATION - Step 30»(ref-387112-S34119271062011022400000)
8. INSTALL INSTRUMENT PANEL FINISH PANEL END RH . Refer to «INSTALLATION - Step 20»(ref-387101-S06767646592011022400000)
9. INSTALL CONSOLE UPPER PANEL ASSEMBLY . Refer to «INSTALLATION - Step 21»(ref-387101-S06767646592011022400000)
10. INSTALL FRONT CONSOLE UPPER PANEL GARNISH . Refer to «INSTALLATION - Step 22»(ref-387101-S06767646592011022400000)
11. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
12. INSPECT STEERING PAD . Refer to «INSTALLATION - Step 5»(ref-386976-S09305533722011022400000)
13. PERFORM INITIALIZATION Perform initialization. Refer to «INITIALIZATION»(ref-386951-S21829001392011022400000) . NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
14. CHECK SRS WARNING LIGHT Check the SRS warning light. Refer to «DIAGNOSIS SYSTEM»(ref-387113-S03380841082011022400000) .

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

1. PLACE FRONT WHEELS FACING STRAIGHT AHEAD
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION»(ref-387113-S14173589052011022400000) . NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-386951-S21829001392011022400000) .
3. REMOVE LOWER NO. 3 STEERING WHEEL COVER . Refer to «REMOVAL - Step 3»(ref-386976-S33383103072011022400000)
4. REMOVE LOWER NO. 2 STEERING WHEEL COVER . Refer to «REMOVAL - Step 4»(ref-386976-S33383103072011022400000)
5. REMOVE STEERING PAD . Refer to «REMOVAL - Step 5»(ref-386976-S33383103072011022400000)
6. REMOVE STEERING WHEEL ASSEMBLY . Refer to «REMOVAL - Step 8»(ref-387138-S18872529122011022400000)
7. REMOVE CRUISE CONTROL MAIN SWITCH . Refer to «REMOVAL - Step 6»(ref-387103-S05405695412011022400000)
8. REMOVE STEERING SHAKE DAMPER Remove the 2 screws and steering shake damper.
9. REMOVE LOWER STEERING WHEEL BOSS COVER Remove the 2 screws. Disengage the 2 claws and remove the lower steering wheel boss cover.
10. REMOVE STEERING PAD SWITCH ASSEMBLY Remove the screw. Disengage the 2 claws and pin and remove the steering pad switch assembly. NOTE: Be sure to disengage the claws to prevent breaking them. Remove the screw. Disengage the 2 claws and pin and remove the steering pad switch assembly. NOTE: Be sure to disengage the claws to prevent breaking them.

Scheme 72

1. INSPECT STEERING PAD SWITCH ASSEMBLY Measure the resistance of the switch connector. Standard resistance Tester Connection Switch Condition Specified Condition A-10 (AU1) - A-8 (EAU) Not pushed 95 to 105 kohms A-10 (AU1) - A-8 (EAU) Pushed (SEEK+) Below 2.5 ohms A-10 (AU1) - A-8 (EAU) Pushed (SEEK-) 313.5 to 346.5 ohms A-10 (AU1) - A-8 (EAU) Pushed (VOL+) 959.5 to 1060.5 ohms A-10 (AU1) - A-8 (EAU) Pushed (VOL-) 3049.5 to 3370.5 ohms A-9 (AU2) - A-8 (EAU) Not pushed 95 to 105 kohms A-9 (AU2) - A-8 (EAU) Pushed (MODE) Below 2.5 ohms A-9 (AU2) - A-8 (EAU) Pushed (ON HOOK) 313.5 to 346.5 ohms A-9 (AU2) - A-8 (EAU) Pushed (OFF HOOK) 959.5 to 1060.5 ohms A-9 (AU2) - A-8 (EAU) Pushed (VOICE) 3049.5 to 3370.5 ohms If the result is not as specified, replace the switch.

Scheme 73

1. INSTALL STEERING PAD SWITCH ASSEMBLY Engage the 2 claws and pin and install the steering pad switch assembly. Install the screw. Torque: 2.4 N*m (24 kgf*cm, 21 in.*lbf) Engage the 2 claws and pin and install the steering pad switch assembly. Install the screw. Torque: 2.4 N*m (24 kgf*cm, 21 in.*lbf)
2. INSTALL LOWER STEERING WHEEL BOSS COVER Engage the 2 claws. Install the lower steering wheel boss cover with the 2 screws.
3. INSTALL STEERING SHAKE DAMPER Install the steering shake damper with the 2 screws. Engage the 2 harness clamps.
4. INSTALL CRUISE CONTROL MAIN SWITCH . Refer to «INSTALLATION - Step 1»(ref-387103-S32381371302011022400000)
5. ADJUST SPIRAL CABLE WITH STEERING SENSOR . Refer to «INSTALLATION - Step 4»(ref-386976-S15365252272011022400000)
6. INSTALL STEERING WHEEL ASSEMBLY . Refer to «INSTALLATION - Step 13»(ref-387138-S36241184272011022400000)
7. INSTALL STEERING PAD . Refer to «INSTALLATION - Step 1»(ref-386976-S09305533722011022400000)
8. INSTALL LOWER NO. 3 STEERING WHEEL COVER
9. INSTALL LOWER NO. 2 STEERING WHEEL COVER
10. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-386951-S21829001392011022400000) .
11. INSPECT STEERING PAD . Refer to «INSTALLATION - Step 5»(ref-386976-S09305533722011022400000)
12. INSPECT SRS WARNING LIGHT Refer to «DIAGNOSIS SYSTEM»(ref-387113-S03380841082011022400000)

Scheme 74

Scheme 75

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE INNER REAR VIEW MIRROR COVER . Refer to «REMOVAL - Step 25»(ref-387112-S08813470752011022400000)
3. REMOVE FRONT ROOF TOP GARNISH . Refer to «REMOVAL - Step 26»(ref-387112-S08813470752011022400000)
4. REMOVE PERSONAL LIGHT ASSEMBLY . Refer to «REMOVAL - Step 27»(ref-387112-S08813470752011022400000)
5. REMOVE MICROPHONE AMPLIFIER ASSEMBLY Remove the microphone amplifier cord from the cover labeled A. Disconnect the connector labeled B. Remove the 9 screws labeled C and cover. Remove the microphone amplifier.

Scheme 76

1. INSTALL MICROPHONE AMPLIFIER ASSEMBLY Install the microphone amplifier to the map light. Install the cover to the map light with the 9 screws labeled A. Connect the connector labeled B. Install the microphone amplifier cord to the cover labeled C.
2. INSTALL PERSONAL LIGHT ASSEMBLY . Refer to «INSTALLATION - Step 8»(ref-387112-S34119271062011022400000)
3. INSTALL FRONT ROOF TOP GARNISH . Refer to «INSTALLATION - Step 13»(ref-387112-S34119271062011022400000)
4. INSTALL INNER REAR VIEW MIRROR COVER
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
6. PERFORM INITIALIZATION Perform initialization. Refer to «INITIALIZATION»(ref-386951-S21829001392011022400000) . NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 77

Scheme 78

Scheme 79

Scheme 80

1. INSPECT WINDOW GLASS ANTENNA WIRE NOTE: When cleaning the glass, use a soft, dry cloth, and wipe the glass in the direction of the wire. Take care not to damage the wires. Do not use detergents or glass cleaners with abrasive ingredients. When measuring voltage, wind a piece of tin foil around the top of the negative probe and press the foil against the wire with your finger, as shown in the illustration. Check the voltage at the center of each wire, as shown in the illustration.
2. REPAIR WINDOW GLASS ANTENNA WIRE Clean the broken wire tips with the grease, wax and silicone remover. Place the masking tape along both sides of the wire to be repaired. Thoroughly mix the repair agent (Dupont paste No. 4817). Using a fine tip brush, apply a small amount of the repair agent to the wire. After a few minutes, remove the masking tape. Do not repair the antenna wire for at least 24 hours.
