Cellular Communication (Service Information): Overview Lexus GS III рестайлинг

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT Remove the floor mat.
3. REMOVE LUGGAGE COMPARTMENT NO. 1 LIGHT ASSEMBLY Using a screwdriver, detach the claw and remove the light. HINT: Tape the screwdriver tip before use. Disconnect the connector.
4. REMOVE LUGGAGE COMPARTMENT TRIM SIDE COVER RH
5. REMOVE LUGGAGE COMPARTMENT TRIM SIDE COVER LH Remove the 2 clips and compartment trim side cover LH.
6. REMOVE TOOL BOX Remove the tool box.
7. REMOVE REAR FLOOR FINISH PLATE Remove the 2 bolts and 2 hooks. Remove the 3 clips labeled A. Detach the 4 clips to remove the finish plate.
8. REMOVE LUGGAGE COMPARTMENT TRIM COVER FRONT Detach the hook. Remove the rope hook. Remove the 3 clips. Detach the 4 claws and remove the trim cover.
9. REMOVE LUGGAGE COMPARTMENT TRIM COVER INNER LH Remove the 5 clips and trim cover.
10. REMOVE LUGGAGE COMPARTMENT TRIM COVER INNER RH Remove the 5 clips and trim cover.
11. REMOVE MAYDAY ASSEMBLY Remove the 2 bolts and mayday assembly with wire harness. Disconnect the 5 connectors and 2 clamps and mayday assembly.

Scheme 96

Scheme 97

Scheme 98

1. REMOVE NO. 2 MOBILE PHONE BRACKET Remove the 2 bolts and bracket.
2. REMOVE MAYDAY ECU Remove the 4 bolts and ECU.
3. REMOVE MAYDAY BATTERY Remove the bolt, No. 4 mobile phone bracket and battery.
