HOW TO PROCEED WITH TROUBLESHOOTING
HINT
- Use these procedures to troubleshoot the audio and visual system.
- *: Use Techstream.
- VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
- INSPECT BATTERY VOLTAGE Standard voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding. NEXT: Go to next step
- BASIC INSPECTION Turn the power switch ON (ACC). Check whether or not the display appears on the multi-display. RESULT Result Proceed to Display appears A Display does not appear B B --> Go to step 7 A: Go to next step
- INSPECT COMMUNICATION FUNCTION OF MULTIPLEX COMMUNICATION SYSTEM (BEAN)* Use Techstream to check if the Multiplex Communication System (MPX) is functioning normally. RESULT Result Proceed to MPX DTC is not output A MPX DTC is output B B --> Go to MULTIPLEX COMMUNICATION SYSTEM A: Go to next step
- CHECK FOR DTC Check for DTCs and note any codes that are output. Delete for DTC. Recheck for DTCs. Based on the DTC output in the first step, try to force output of the audio system DTC by simulating the operation indicated by the DTC. HINT: If the system cannot enter the diagnosis mode, inspect each AVC-LAN communication signal and repair or replace problem parts. Even if the malfunction symptom is not confirmed, check for DTCs. This is because the system stores past DTCs. Refer to the detailed description on the diagnostic screen, as necessary. «DIAGNOSIS DISPLAY DETAILED DESCRIPTION»(ref-387171-S02976621102011022400000) . Check and clear past diagnostic trouble codes. Check the diagnostic trouble code and inspect the area the code indicates. RESULT Result Proceed to DTC does not reoccur A DTC reoccurs B B --> Go to step 8 A: Go to next step
- PROBLEM SYMPTOMS TABLE RESULT Result Proceed to Fault is not listed in problem symptoms table A Fault is listed in problem symptoms table B B --> Go to step 8 A: Go to next step
- OVERALL ANALYSIS AND TROUBLESHOOTING Terminals of ECU. Refer to «TERMINALS OF ECU»(ref-387171-S34649818612011022400000) . Inspect the front No. 1 speaker. Refer to «INSPECTION»(ref-387134-S39028062482011022400000) . Inspect the front No. 2 speaker. Refer to «INSPECTION»(ref-387134-S41609404252011022400000) . Inspect the front stereo component speaker. Refer to «INSPECTION»(ref-387134-S41609404252011022400000) . Inspect the stereo component speaker. Refer to «INSPECTION»(ref-387134-S30875395342011022400000) . Inspect the rear No. 1 speaker. Refer to «INSPECTION»(ref-387134-S11362715582011022400000) . Inspect the rear No. 2 speaker. Refer to «INSPECTION»(ref-387134-S11362715582011022400000) . Inspect the rear header speaker. Refer to «INSPECTION»(ref-387134-S30875395342011022400000) . NEXT: Go to next step
- ADJUST, REPAIR OR REPLACE NEXT --> END
PROBLEM SYMPTOMS TABLE
HINT
Use the table to help determine the cause of the problem symptom. The potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
| Symptom | Suspected Area | Refer to |
|---|---|---|
| Pressing power switch does not turn on system. | 1. Radio receiver power source circuit | Refer to Radio Receiver Power Source Circuit |
| 2. Multi-display power source circuit | Refer to Multi-display Power Source Circuit | |
| 3. AVC-LAN circuit | Refer to AVC-LAN Circuit | |
| 4. Radio receiver | ||
| 5. Multi-display | ||
| Panel switch does not function. | 1. Steering pad switch circuit | Refer to Steering Pad Switch Circuit |
| 2. AVC-LAN circuit | Refer to AVC-LAN Circuit | |
| 3. Radio receiver | ||
| No sound can be heard from speakers (audio is mute). | 1. AVC-LAN circuit | Refer to AVC-LAN Circuit |
| 2. Radio receiver power source circuit | Refer to Radio Receiver Power Source Circuit | |
| 3. Multi-display power source circuit | Refer to Multi-display Power Source Circuit | |
| 4. Proceed to "No sound can be Heard from Speakers" | Refer to No Sound can be Heard from Speakers | |
| 5. Stereo component amplifier power source circuit | Refer to Stereo Component Amplifier Power Source Circuit | |
| 6. Proceed to "Sound Signal Circuit between Radio Receiver and Stereo Component Amplifier" | Refer to Sound Signal Circuit between Radio Receiver and Stereo Component Amplifier | |
| 7. Speaker circuit | Refer to Speaker Circuit | |
| 8. Proceed to "Mute Signal Circuit between Radio Receiver and Stereo Component Amplifier" | Refer to Mute Signal Circuit between Radio Receiver and Stereo Component Amplifier | |
| 9. Stereo component amplifier | ||
| 10. Radio receiver | ||
| 11. Multi-display | ||
| Only DVD sound cannot be heard or sound quality is bad*1. | 1. Proceed to "DVD Sound Signal Circuit between Radio receiver and Stereo Component Amplifier" | Refer to DVD Sound Signal Circuit between Radio Receiver and Stereo Component Amplifier |
| 2. Stereo component amplifier | ||
| 3. Radio receiver | ||
| Sound quality is bad in all modes (volume is too low). | 1. Proceed to "Poor Sound Quality in All Modes (Low Volume)" | Refer to Poor Sound Quality in All Modes (Low Volume) |
| 2. Speaker circuit | Refer to Speaker Circuit | |
| 3. Proceed to "Sound Signal Circuit between Radio Receiver and Stereo Component Amplifier" | Refer to Sound Signal Circuit between Radio Receiver and Stereo Component Amplifier | |
| 4. Proceed to "Mute Signal Circuit between Radio Receiver and Stereo Component Amplifier" | Refer to Mute Signal Circuit between Radio Receiver and Stereo Component Amplifier | |
| 5. Stereo component amplifier | ||
| 6. Radio receiver | ||
| External device sound cannot be heard or sound quality is bad. (Stereo jack adapter is used.) | 1. Radio receiver power source circuit | Refer to Radio Receiver Power Source Circuit |
| 2. Proceed to "Sound Signal Circuit between Radio Receiver and Stereo Jack Adapter" | Refer to Sound Signal Circuit between Radio Receiver and Stereo Jack Adapter | |
| 3. Stereo jack adapter | ||
| 4. Radio receiver | ||
| ASL does not function. | Proceed to "Vehicle Speed Signal Circuit between Stereo Component Amplifier and Component Meter" | Refer to Vehicle Speed Signal Circuit between Stereo Component Amplifier and Combination Meter |
| Noise occurs. | 1. Proceed to "Noise Occurs" | Refer to Noise Occurs |
| 2. Stereo component amplifier | ||
| 3. Radio receiver | ||
| Radio broadcast cannot be received (poor reception). | Proceed to "Radio Broadcast cannot be Received (Poor reception)" | Refer to Radio Broadcast cannot be Received (Bad Reception) |
| Cassette tape cannot be inserted or played. | Proceed to "Cassette tape cannot be Inserted or Played" | Refer to Cassette Tape cannot be Inserted or Played |
| Cassette tape cannot be ejected. | Proceed to "Cassette Tape cannot be Ejected" | Refer to Cassette Tape cannot be Ejected |
| Sound quality is bad only when playing tape. | Proceed to "Sound Quality is Bad Only when Playing Tape" | Refer to Sound Quality is Bad Only when Playing Tape |
| Tape is tangled due to incorrect tape speed or auto-reverse malfunction. | Proceed to "Tape is Tangled due to Incorrect Tape Speed or Auto-Reverse Malfunction" | Refer to Tape is Tangled due to Incorrect Tape Speed or Auto-Reverse Malfunction |
| Disc cannot be inserted or is ejected right after insertion. | 1. Radio receiver power source circuit | Refer to Radio Receiver Power Source Circuit |
| 2. Proceed to "Disc cannot be Inserted or is Ejected Right After Insertion" | Refer to Disc cannot be Inserted or is Ejected Right After Insertion | |
| 3. Radio receiver | ||
| Disc cannot be ejected. | 1. Radio receiver power source circuit | Refer to Radio Receiver Power Source Circuit |
| 2. Proceed to "Disc cannot be ejected" | Refer to Disc cannot be Ejected | |
| 3. Radio receiver | ||
| Sound quality is bad only when CD is played (volume is too low). | Proceed to "Sound Quality is Bad Only when CD is Played (Volume is Too Low)" | Refer to Sound Quality is Bad Only when CD is Played (Volume is Too Low) |
| CD / DVD sound skips. | 1. Proceed to "CD / DVD Sound Skips" | Refer to CD/DVD Sound Skips |
| 2. Radio receiver | ||
| Illumination for radio receiver does not come on with light control switch on. | 1. Illumination circuit | Refer to Illumination Circuit |
| 2. Radio receiver |
AUDIO FUNCTION
*1: for DVD changer models
| Symptom | Suspected Area | Refer to |
|---|---|---|
| Pressing power switch does not turn on system. | 1. Multi-display power source circuit | Refer to Multi-display Power Source Circuit |
| 2. AVC-LAN circuit | Refer to AVC-LAN Circuit | |
| 3. Multi-display | ||
| Back screen (no image appears on audio screen). | 1. Proceed to "No Image Appears on Multi-display" | Refer to No Image Appears on Multi-display |
| 2. Multi-display power source circuit | Refer to Multi-display Power Source Circuit | |
| 3. Illumination circuit | Refer to Illumination Circuit | |
| 4. AVC-LAN circuit | Refer to AVC-LAN Circuit | |
| 5. Multi-display | ||
| Illumination for panel switch does not come on with light control switch on. | 1. Proceed to "Illumination for Panel Switch does not Come on with Light Control Switch ON" | Refer to Illumination for Panel Switch does not Come on with Tail Switch ON |
| 2. Illumination circuit | Refer to Illumination Circuit | |
| 3. Multi-display | ||
| Display does not dim (night screen) when light control switch is turned on. | 1. Proceed to "Display does not Dim when Light Control Switch is Turned ON" | Refer to Display does not Dim when Light Control Switch is Turned ON |
| 2. Illumination circuit | Refer to Illumination Circuit | |
| 3. Multi-display | ||
| Power does not turn off (screen remains on). | 1. Multi-display power source circuit | Refer to Multi-display Power Source Circuit |
| 2. Multi-display | ||
| Panel switches do not function. | 1. Proceed to "Panel Switches do not Function" | Refer to Panel Switches do not Function |
| 2. Steering pad switch circuit | Refer to Steering Pad Switch Circuit | |
| 3. Multi-display power source circuit | Refer to Multi-display Power Source Circuit | |
| 4. Multi-display | ||
| Touch panel switch does not function. | 1. Proceed to "Touch Panel Switch does not Function" | Refer to Touch Panel Switch does not Function |
| 2. Steering pad switch circuit | Refer to Steering Pad Switch Circuit | |
| 3. Multi-display power source circuit | ||
| 4. Multi-display | ||
| DVD image cannot be displayed on multi-display (parking brake is on)*1. | 1. Proceed to "Display Signal Circuit between Multi-display and Radio Receiver" | Refer to Display Signal Circuit between Multi-display and Radio Receiver |
| 2. Parking brake switch circuit | Refer to Parking Brake Switch Circuit | |
| 3. Radio receiver | ||
| 4. Multi-display |
DISPLAY FUNCTION
*1: for DVD changer models
| Symptom | Suspected Area | Refer to |
|---|---|---|
| System cannot be operated by steering pad switch. | 1. Steering pad switch circuit | Refer to Steering Pad Switch Circuit |
| 2. Radio receiver | ||
| Illumination for steering pad switch does not come on with light control switch on. | 1. Illumination circuit | Refer to Illumination Circuit |
| 2. Steering pad switch |
STEERING PAD SWITCH FUNCTION
| Symptom | Suspected Area | Refer to |
|---|---|---|
| Cellular phone registration failure, phone directory transfer failure. | Proceed to "Cellular Phone Registration Failure, Phone Directory Transfer Failure" | Refer to Cellular Phone Registration Failure, Phone Directory Transfer Failure |
| Cellular phone cannot send / receive. | 1. Proceed to "Cellular Phone cannot Send / Receive" | Refer to Cellular Phone cannot Send/Receive |
| 2. Steering pad switch circuit | Refer to Steering Pad Switch Circuit | |
| 3. Radio receiver | ||
| Cannot call in a certain place. | Proceed to "Cannot Call in a Certain Place" | Refer to Cannot Call in a Certain Place |
| The other caller's voice cannot be heard, is too quiet, or distorted. | 1. Proceed to "The Other Caller's Voice cannot be Heard, is too Quiet, or Distorted" | Refer to The Other Caller's Voice cannot be Heard, is too Quiet, or Distorted |
| 2. Multi-display | ||
| The other caller cannot hear your voice, or your voice is too quiet or distorted. | 1. Proceed to "The Other Caller cannot Hear Your Voice, or Your Voice is too Quiet or Distorted." | Refer to The Other Caller cannot Hear Your Voice, or Your Voice is too Quiet or Distorted |
| 2. Microphone circuit between overhead J/B and multi-display | Refer to Microphone Circuit between Overhead J/B and Multi-display | |
| 3. Microphone | ||
| 4. Microphone amplifier | ||
| 5. Multi-display |
BLUETOOTH FUNCTION
Scheme 126
Scheme 127
Scheme 128
Scheme 129
Scheme 130
Scheme 131
- CHECK MULTI-DISPLAY Disconnect the K46 display connector. Measure the resistance and voltage of the wire harness side connector. Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition +B1 (K46-1) - GND1 (K46-10) BE - W-B Battery Always 10 to 14 V ACC (K46-2) - GND1 (K46-10) GR - W-B Accessory (ON) Power switch OFF Below 1 V ACC (K46-2) - GND1 (K46-10) GR - W-B Accessory (ON) Power switch ON (ACC) 10 to 14 V IG (K46-3) - GND1 (K46-10) B - W-B Ignition (ON) Power switch OFF Below 1 V IG (K46-3) - GND1 (K46-10) B - W-B Ignition (ON) Power switch ON (IG) 10 to 14 V GND1 (K46-10) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the K46 display connector. Measure the voltage of the connector. Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition TC (K46-7) - GND1 (K46-10) BR - W-B Diagnosis ON signal Power switch ON (IG) 9 to 14 V ILL- (K46-11) - GND1 (K46-10) L - W-B Illumination signal Light control switch OFF Below 1 V ILL- (K46-11) - GND1 (K46-10) L - W-B Illumination signal Light control switch ON 10 to 14 V ILL+ (K46-12) - GND1 (K46-10) G - W-B Illumination signal Light control switch OFF Below 1 V ILL+ (K46-12) - GND1 (K46-10) G - W-B Illumination signal Light control switch ON 10 to 14 V REV (K46-13) - GND1 (K46-10) R - W-B Reverse signal See "Vehicle Signal Check" Mode - SPD (K46-14) - GND1 (K46-10) V - W-B Speed signal from combination meter See "Vehicle Signal Check" Mode - PKB (K46-23) - GND1 (K46-10) Y - W-B Parking brake signal See "Vehicle Signal Check" Mode - TX- (K47-1) - TX+ (K47-2) LG - L AVC-LAN communication signal Power switch ON (ACC) 2 to 3 V TSW- (K47-5) - GND1 (K46-10) W-B - W-B Telephone relation switch signal Always Below 1 V MACC (K47-9) - GND1 (K46-10)*2 BE - W-B Microphone amplifier power supply Power switch OFF Below 1 V MACC (K47-9) - GND1 (K46-10)*2 BE - W-B Microphone amplifier power supply Power switch ON (IG) 5 V MIN- (K47-10) - GND1 (K46-10) R(*2), W(*3) - W-B Microphone voice signal See "Microphone & Voice Recognition Check" - MIN+ (K47-11) - GND1 (K46-10) G(*2), B(*3) - W-B Microphone voice signal See "Microphone & Voice Recognition Check" - SGND (K47-12) - Body ground W-B - Body ground Ground Always Below 1 V IVO- (K47-21) - GND1 (K46-10) BR - W-B Voice guidance signal Voice guidance is provided Waveform synchronized with sounds is output IVO+ (K47-22) - GND1 (K46-10) Y - W-B Voice guidance signal Voice guidance is provided Waveform synchronized with sounds is output SLD (K47-23) - GND1 (K46-10) Shielded - W-B Shielded ground Always Below 1 V VV+ (z17-1) - GND1 (K46-10)*1 W - W-B DVD image signal DVD is played on radio receiver Pulse generation VV- (z17-4) - GND1 (K46-10)*1 B - W-B Signal ground Always Below 1 V CA+ (K47-13) - GND1 (K46-10) B - W-B Television camera power supply Power switch ON (IG), shift lever reverse position Approx. 6 V CGND (K47-14) - Body ground W - Body ground Ground Always Below 1 V V+ (K47-27) - CGND (K47-14) R - W Television camera image signal Power switch ON (IG), shift lever reverse position Pulse generation (refer to waveform 1 (Scheme 128) ) V- (K47-28) - CGND (K47-14) Shielded - W Shielded ground Always Below 1 V HINT: *1: for DVD changer models *2: w/o LEXUS Link System *3: w/ LEXUS Link System If the result is not as specified, the multi-display may have a malfunction.
- CHECK RADIO RECEIVER Disconnect the K54 receiver connector. Measure the resistance and voltage of the wire harness side connector. Symbols (Terminal No.) Wiring Color Terminal Description Condition Specification B (K54-1) - GND (K54-20) SB - BR Battery Always 10 to 14 V GND (K54-20) - Body ground BR - Body ground Ground Always Below 1 ohms ACC (K54-11) - GND (K54-20) GR - BR Accessory (ON) Power switch OFF Below 1 V ACC (K54-11) - GND (K54-20) GR - BR Accessory (ON) Power switch ON (ACC) 10 to 14 V If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the K54 receiver connector. Measure the voltage on the connectors. Symbols (Terminal No.) Wiring Color Terminal Description Condition Specification TXM+ (K53-9) - TXM- (K53-10) L - LG AVC-LAN communication signal Power switch ON (ACC) 2 to 3 V ILL+ (K54-2) - GND (K54-20) G - BR Illumination signal Power switch ON (IG), light control switch OFF Below 1 V ILL+ (K54-2) - GND (K54-20) G - BR Illumination signal Power switch ON (IG), light control switch TAIL or ON 10 to 14 V MUTE (K54-7) - GND (K54-20) SB - BR Mute signal Audio system is playing --> changing mode Above 3.5 V --> Below 1 V R+ (K54-8) - GND (K54-20) R - BR Sound signal (right) Audio system is playing Waveform synchronized with sound is output L+ (K54-9) - GND (K54-20) B - BR Sound signal (left) Audio system is playing Waveform synchronized with sound is output R- (K54-18) - GND (K54-20) G - BR Sound signal (right) Audio system is playing Waveform synchronized with sound is output L- (K54-19) - GND (K54-20) W - BR Sound signal (left) Audio system is playing Waveform synchronized with sound is output ILL- (K54-12) - GND (K54-20) W - BR Illumination signal Power switch OFF Below 1 V ILL- (K54-12) - GND (K54-20) W - BR Illumination signal Power switch ON (IG) Pulse generation TX+ (K56-9) - TX- (K56-10) L - LG AVC-LAN communication signal Power switch ON (ACC) 2 to 3 V ATX+ (K54-5) - ATX- (K54-15) L - LG AVC-LAN communication signal Power switch ON (ACC) 2 to 3 V ANT (K54-13) - GND (K54-20) BE - BR Power source of antenna Radio switch is ON and AM or FM 10 to 14 V SWG (K56-6) - GND (K54-20) LG - BR Steering pad switch ground Always Below 1 V SW1 (K56-7) - GND (K54-20) Y - BR Steering pad switch signal Steering pad switch not pushed 4.5 to 5.5 V SW1 (K56-7) - GND (K54-20) Y - BR Steering pad switch signal Steering pad switch SEEK+ switch pushed Below 0.5 V SW1 (K56-7) - GND (K54-20) Y - BR Steering pad switch signal Steering pad switch SEEK- switch pushed 0.86 to 0.95 V SW1 (K56-7) - GND (K54-20) Y - BR Steering pad switch signal Steering pad switch VOL+ switch pushed 1.91 to 2.01 V SW1 (K56-7) - GND (K54-20) Y - BR Steering pad switch signal Steering pad switch VOL- switch pushed 3.23 to 3.57 V SW2 (K56-8) - GND (K54-20) O - BR Steering pad switch signal Steering pad switch not pushed 4.5 to 5.5 V SW2 (K56-8) - GND (K54-20) O - BR Steering pad switch signal Steering pad switch MODE switch pushed Below 0.5 V SW2 (K56-8) - GND (K54-20) O - BR Steering pad switch signal Steering pad switch ON HOOK switch pushed 0.86 to 0.95 V SW2 (K56-8) - GND (K54-20) O - BR Steering pad switch signal Steering pad switch OFF HOOK switch pushed 1.91 to 2.01 V SW2 (K56-8) - GND (K54-20) O - BR Steering pad switch signal Steering pad switch VOICE switch pushed 3.23 to 3.57 V ARI (K56-15) - GND (K54-20) (*2) W - BR Sound signal (Right) External device is playing (When stereo jack adapter is used) Waveform synchronized with sound is output ASGN (K56-16) - GND (K54-20) (*2) R - BR Ground Always Below 1 V ALI (K56-17) - GND (K54-20) (*2) B - BR Sound signal (Left) External device is playing (When stereo jack adapter is used) Waveform synchronized with sound is output AGND (K56-18) - GND (K54-20) (*2) Shielded - BR Shielded ground Always Below 1 V AUXI (K56-19) - GND (K54-20) (*2) L - BR External device connection detection signal External device is connected Below 1 V NTSC (z16-1) - GND (K54-20) (*1) W - BR DVD image signal DVD played Pulse generation (see waveform1 (Scheme 128) ) GND (z16-2) - GND (K54-20) (*1) B - BR Ground Always Below 1 V SLD (z16-3) - GND (K54-20) (*1) Shielded - BR Shielded ground Always Below 1 V DVD (z14-1) - GND (K54-20) (*1) B - BR Digital sound signal DVD played on multi-display Pulse generation HINT: *1: for DVD changer models *2: For models with a DVD changer, the radio receiver assembly consists of a sub wire harness and radio receiver. The sub wire harness is supplied as part of the radio receiver assembly. If the result is not as specified, the receiver may have a malfunction. Using an oscilloscope, check the waveform. WAVEFORM 1 (REFERENCE) Item Content Symbols (Terminal No.) NTSC (z16-1) - Body ground Tool 200 mV/DIV., 10 μs/DIV. Condition DVD displayed on multi-display
- CHECK STEREO COMPONENT AMPLIFIER (for CD Changer Models) Disconnect the U29 and U42 amplifier connectors. Measure the resistance and voltage of the connectors. Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition GND (U42-2) - Body ground W-B - Body ground Ground Always Below 1 ohms GND2 (U42-6) - Body ground W-B - Body ground Ground Always Below 1 ohms +B (U42-1) - GND (U42-2) SB - W-B Battery Always 10 to 14 V +B2 (U42-3) - GND (U42-2) SB - W-B Battery Always 10 to 14 V ACC (U29-12) - GND (U42-2) GR - W-B Accessory (ON) Power switch OFF Below 1 V ACC (U29-12) - GND (U42-2) GR - W-B Accessory (ON) Power switch ON (ACC) 10 to 14 V If the result is not as specified, there may be a malfunction on the wire harness. Reconnect the U29 and U42 amplifier connectors. Measure the voltage of the connectors. Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition CTR+ (U44-3) - GND (U42-2) Y - W-B Sound signal Audio system is playing Waveform synchronized with sound is output CTR- (U44-9) - GND (U42-2) B - W-B Sound signal Audio system is playing Waveform synchronized with sound is output FL+ (U30-2) - GND (U42-2) P - W-B Sound signal Audio system is playing Waveform synchronized with sound is output FL- (U30-6) - GND (U42-2) V - W-B Sound signal Audio system is playing Waveform synchronized with sound is output FR+ (U30-8) - GND (U42-2) LG - W-B Sound signal Audio system is playing Waveform synchronized with sound is output FR- (U30-7) - GND (U42-2) L - W-B Sound signal Audio system is playing Waveform synchronized with sound is output RL+ (U30-3) - GND (U42-2) B - W-B Sound signal Audio system is playing Waveform synchronized with sound is output RL- (U30-9) - GND (U42-2) Y - W-B Sound signal Audio system is playing Waveform synchronized with sound is output RR+ (U30-4) - GND (U42-2) R - W-B Sound signal Audio system is playing Waveform synchronized with sound is output RR- (U30-10) - GND (U42-2) W - W-B Sound signal Audio system is playing Waveform synchronized with sound is output WF1+ (U44-1) - GND (U42-2) P - W-B Sound signal Audio system is playing Waveform synchronized with sound is output WF1- (U44-5) - GND (U42-2) V - W-B Sound signal Audio system is playing Waveform synchronized with sound is output WF2+ (U44-2) - GND (U42-2) L - W-B Sound signal Audio system is playing Waveform synchronized with sound is output WF2- (U44-6) - GND (U42-2) LG - W-B Sound signal Audio system is playing Waveform synchronized with sound is output II1+ (U29-15) - GND (U42-2) Y - W-B Voice guidance signal Voice guidance is proved Waveform synchronized with sound is output II1- (U29-14) - GND (U42-2) BR - W-B Voice guidance signal Voice guidance is proved Waveform synchronized with sound is output SPD (U29-11) - GND (U42-2) V - W-B Speed signal Power switch ON (IG), drive wheels are turned slowly Pulse generation MUTE (U29-1) - GND (U42-2) BE - W-B Mute signal Audio system is playing --> change mode Above 3.5 V --> Below 1 V TX+ (U29-8) - TX- (U29-7) LG - L AVC-LAN communication signal Power switch ON (ACC) 2 to 3 V R+ (U29-5) - GND (U42-2) R - W-B Sound signal (right) Audio system playing Waveform synchronized with sound is output R- (U29-4) - GND (U42-2) G - W-B Sound signal (right) Audio system playing Waveform synchronized with sound is output L+ (U29-3) - GND (U42-2) B - W-B Sound signal (left) Audio system playing Waveform synchronized with sound is output L- (U29-2) - GND (U42-2) W - W-B Sound signal (left) Audio system playing Waveform synchronized with sound is output SLD (U29-6) - GND (U42-2) Shielded - W-B Shielded ground Always Below 1 V TMUT (U29-24) - GND (U42-2) (*1) W - W-B Mute signal Audio system is playing --> LEXUS link system operating Above 3.5 V --> Below 1 V HINT: *1: w/ LEXUS Link System If the result is not as specified, the amplifier may have a malfunction.
- CHECK STEREO COMPONENT AMPLIFIER (for DVD Changer Models) Disconnect the U31 amplifier connector. Measure the resistance and voltage of the connector. Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition GND (U31-16) - Body ground W-B - Body ground Ground Always Below 1 ohms GND2 (U31-15) - Body ground W-B - Body ground Ground Always Below 1 ohms +B (U31-1) - GND (U31-16) SB - W-B Battery Always 10 to 14 V +B2 (U31-10) - GND (U31-16) SB - W-B Battery Always 10 to 14 V ACC (U29-12) - GND (U31-16) GR - W-B Accessory (ON) Power switch OFF Below 1 V ACC (U29-12) - GND (U31-16) GR - W-B Accessory (ON) Power switch ON (ACC) 10 to 14 V If the result is not as specified, there may be a malfunction on the wire harness. Reconnect the U31 amplifier connector. Measure the voltage of the connectors. Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition MUTE (U29-1) - GND (U31-16) BE - W-B Mute signal Audio system is sounding --> Changing mode Above 3.5 V --> Below 1 V L- (U29-2) - GND (U31-16) W - W-B Sound signal (left) Audio system is playing Waveform synchronized with sounds is output L+ (U29-3) - GND (U31-16) B - W-B Sound signal (left) Audio system is playing Waveform synchronized with sounds is output R- (U29-4) - GND (U31-16) G - W-B Sound signal (right) Audio system is playing Waveform synchronized with sounds is output R+ (U29-5) - GND (U31-16) R - W-B Sound signal (right) Audio system is playing Waveform synchronized with sounds is output SLD (U29-6) - GND (U31-16) Shielded - W-B Shielded ground Always Below 1 V TX- (U29-7) - TX+ (U29-8) L - LG AVC-LAN communication signal Power switch is ON (ACC) 2 to 3 V SPD (U29-11) - GND (U31-16) V - W-B Speed signal Power switch is ON (IG), drive wheels are turned slowly Pulse generation II1- (U29-22) - GND (U31-16) BR - W-B Voice guidance signal Voice guidance is provided Waveform synchronized with sounds is output II1+ (U29-23) - GND (U31-16) Y - W-B Voice guidance signal Voice guidance is provided Waveform synchronized with sounds is output TMUT (U29-24) - GND (31-16) (*1) W - W-B Mute signal Audio system is sounding --> LEXUS link system operating Above 3.5 V --> Below 1 V FL+ (U31-8) - GND (U31-16) P - W-B Sound signal Audio system is playing Waveform synchronized with sounds is output FR- (U31-20) - GND (U31-16) L - W-B Sound signal Audio system is playing Waveform synchronized with sounds is output RL- (U31-17) - GND (U31-16) Y - W-B Sound signal Audio system is playing Waveform synchronized with sounds is output RR- (U31-18) - GND (U31-16) W - W-B Sound signal Audio system is playing Waveform synchronized with sounds is output FL- (U31-19) - GND (U31-16) V - W-B Sound signal Audio system is playing Waveform synchronized with sounds is output FR+ (U31-9) - GND (U31-16) LG - W-B Sound signal Audio system is playing Waveform synchronized with sounds is output RL+ (U31-6) - GND (U31-16) B - W-B Sound signal Audio system is playing Waveform synchronized with sounds is output RR+ (U31-7) - GND (U31-16) R - W-B Sound signal Audio system is playing Waveform synchronized with sounds is output WF1+ (U31-5) - GND (U31-16) P - W-B Sound signal Audio system is playing Waveform synchronized with sounds is output WF2+ (U31-4) - GND (U31-16) V - W-B Sound signal Audio system is playing Waveform synchronized with sounds is output CTR+ (U31-3) - GND (U31-16) Y - W-B Sound signal Audio system is playing Waveform synchronized with sounds is output CTR- (U31-12) - GND (U31-16) B - W-B Sound signal Audio system is playing Waveform synchronized with sounds is output SL+ (U30-1) - GND (U31-16) LG - W-B Sound signal Audio system is playing Waveform synchronized with sound is output SL- (U30-5) - GND (U31-16) L - W-B Sound signal Audio system is playing Waveform synchronized with sound is output SR+ (U30-2) - GND (U31-16) B - W-B Sound signal Audio system is playing Waveform synchronized with sound is output SR- (U30-6) - GND (U31-16) Y - W-B Sound signal Audio system is playing Waveform synchronized with sound is output WFL+ (U30-3) - GND (U31-16) W - W-B Sound signal Audio system is playing Waveform synchronized with sound is output WFL- (U30-9) - GND (U31-16) R - W-B Sound signal Audio system is playing Waveform synchronized with sound is output WFR+ (U30-4) - GND (U31-16) G - W-B Sound signal Audio system is playing Waveform synchronized with sound is output WFR- (U30-10) - GND (U31-16) W - W-B Sound signal Audio system is playing Waveform synchronized with sound is output HINT: *1: w/ LEXUS Link System If the result is not as specified, the amplifier may have a malfunction.
- CHECK NETWORK GATEWAY ECU Measure the voltage of the connector. Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition GTX+ (K66-6) - GTX- (K66-21) L - LG AVC-LAN communication signal Power switch ON (ACC) 2 to 3 V
- CHECK MAYDAY ECU
DTC CHECK / CLEAR
HINT
- Illustrations may differ from the actual vehicle depending on the device settings and options. Therefore, some detailed areas may not be exactly the same as on the actual vehicle.
- If the system cannot enter the diagnostic mode, inspect all AVC-LAN communication components and repair or replace problem parts. Refer to «AVC-LAN Circuit»(ref-387172-S15573264402011022400000) .
- After the power switch is turned ON (IG), check that the map is displayed before starting the diagnostic mode. Otherwise, some items cannot be checked.
Scheme 132
Scheme 133
Scheme 134
Scheme 135
Scheme 136
Scheme 137
Scheme 138
Scheme 139
Scheme 140
Scheme 141
Scheme 142
Scheme 143
- START DIAGNOSTIC MODE There are 2 methods to start diagnostic mode. Start the mode by using one of them. Method 1 Start the hybrid system. While pressing and holding the "INFO" switch, operate the light control switch: OFF --> Turn ON --> Turn OFF --> Turn ON --> Turn OFF --> Turn ON --> Turn OFF. The diagnostic mode starts and the "System Check Mode" screen will be displayed. Service inspection starts automatically and the result will be displayed. Method 2 Start the hybrid system. Press the "DISP" switch. From the display quality adjustment screen, touch the corners of the screen in the following order: upper left --> lower left --> upper left --> lower left --> upper left --> lower left. The diagnostic mode starts and the "System Check Mode" screen will be displayed. Service inspection starts automatically and the result will be displayed.
- FINISH DIAGNOSTIC MODE There are 2 methods to end diagnostic mode. Use one of them. Turn the power switch OFF. Press and hold the "DISP" switch for 3 seconds.
- DIAGNOSIS MENU The "Diagnosis MENU" screen will be displayed by pressing the menu switch on the "System Check Mode" screen.
- CHECK DTC Read the system check result. If the check result is "EXCH", "CHEK" or "Old", touch the displayed check result to view the results on the "Unit Check Mode" screen and record them. HINT: If all check results are "OK", go to the communication DTC check. If a device name is not known, its physical address is displayed. HINT: When proceeding to view the results of another device, press the service switch to return to the "System Check Mode" screen. Repeat this step. Read the communication diagnostic check result. Return to the "System Check Mode" screen, and press the "LAN Mon" switch to enter the "LAN Monitor" screen. If the check result is "CHEK" or "Old", touch the displayed check result to view the results on the individual communication diagnostic screen and record them. HINT: If all check results are "No Err", the system judges that no DTC exists. The sub-code (relevant device) will be indicated by its physical address. When proceeding to view the results of another device, press the "Service" switch to return to the original "LAN Monitor" screen. Repeat this step.
- DTC CLEAR/RECHECK Clear DTC Press the "Code CLR" switch for 3 seconds. The check results are cleared. Recheck Press the "Recheck" switch. Confirm that all diagnostic codes are "OK" when the check results are displayed. If a code other than "OK" is displayed, troubleshoot again. Press the "LAN Mon" switch to change to the "LAN Monitor" screen. Confirm that all diagnostic codes are "No Err". If a code other than "No Err" is displayed, troubleshoot again.
DIAGNOSTIC TROUBLE CODE CHART
HINT
If a trouble code is displayed during the DTC check, inspect the trouble areas listed for that code. For details of the code, refer to the table below.
| DTC Code | Detection Item | Trouble Area | Refer to |
|---|---|---|---|
| 01-21 | ROM Error | Multi-display | Refer to DTC 01-21: ROM Error; DTC 01-22: RAM Error |
| 01-22 | RAM Error | Multi-display | Refer to DTC 01-21: ROM Error; DTC 01-22: RAM Error |
| 01-D5 | Absence of Registration Unit | 1. Power source circuit of component shown by sub-code 2. AVC-LAN circuit between multi-display and component shown by sub-code 3. Component shown by sub-code | Refer to DTC 01-D5: Absence of Registration Unit; DTC 01-D8: No Response for Connection Check; DTC 01-D9: Last Mode Error; DTC 01-DA: No Response Against ON / OFF Command; DTC 01-DB: Mode Status Error; DTC 01-DE: Slave Reset |
| 01-D6 | No Master | 1. Multi-display power source circuit 2. Power source circuit of the component which has stored this code 3. AVC-LAN circuit between the multi-display and the component which has stored this code 4. Component which has stored this code 5. Multi-display | Refer to DTC 01-D6: No Master; DTC 01-D7: Connection Check Error |
| 01-D7 | Connection Check Error | 1. Multi-display power source circuit 2. Power source circuit of the component which has stored this code 3. AVC-LAN circuit between the multi-display and the component which has stored this code 4. Component which has stored this code 5. Multi-display | Refer to DTC 01-D6: No Master; DTC 01-D7: Connection Check Error |
| 01-D8 | No Response for Connection Check | 1. Power source circuit of component shown by sub-code 2. AVC-LAN circuit between multi-display and component shown by sub-code 3. Component shown by sub-code | Refer to DTC 01-D5: Absence of Registration Unit; DTC 01-D8: No Response for Connection Check; DTC 01-D9: Last Mode Error; DTC 01-DA: No Response Against ON / OFF Command; DTC 01-DB: Mode Status Error; DTC 01-DE: Slave Reset |
| 01-D9 | Last Mode Error | 1. Power source circuit of component shown by sub-code 2. AVC-LAN circuit between multi-display and component shown by sub-code 3. Component shown by sub-code | Refer to DTC 01-D5: Absence of Registration Unit; DTC 01-D8: No Response for Connection Check; DTC 01-D9: Last Mode Error; DTC 01-DA: No Response Against ON / OFF Command; DTC 01-DB: Mode Status Error; DTC 01-DE: Slave Reset |
| 01-DA | No Response Against ON / OFF Command | 1. Power source circuit of component shown by sub-code 2. AVC-LAN circuit between multi-display and component shown by sub-code 3. Component shown by sub-code | Refer to DTC 01-D5: Absence of Registration Unit; DTC 01-D8: No Response for Connection Check; DTC 01-D9: Last Mode Error; DTC 01-DA: No Response Against ON / OFF Command; DTC 01-DB: Mode Status Error; DTC 01-DE: Slave Reset |
| 01-DB | Mode Status Error | 1. Power source circuit of component shown by sub-code 2. AVC-LAN circuit between multi-display and component shown by sub-code 3. Component shown by sub-code | Refer to DTC 01-D5: Absence of Registration Unit; DTC 01-D8: No Response for Connection Check; DTC 01-D9: Last Mode Error; DTC 01-DA: No Response Against ON / OFF Command; DTC 01-DB: Mode Status Error; DTC 01-DE: Slave Reset |
| 01-DC | Transmission Error | If same sub-code is recorded in other components, check harness for power supply and communication system of all components shown by code | Refer to DTC 01-DC: Transmission Error |
| 01-DD | Master Reset | 1. Multi-display power source circuit 2. AVC-LAN circuit between multi-display and component which has stored this code 3. Multi-display 4. Component which has stored this code | Refer to DTC 01-DD: Master Reset; DTC 01-E1: Voice Processing Device ON Error |
| 01-DE | Slave Reset | 1. Power source circuit of component shown by sub-code 2. AVC-LAN circuit between multi-display and component shown by sub-code 3. Component shown by sub-code | Refer to DTC 01-D5: Absence of Registration Unit; DTC 01-D8: No Response for Connection Check; DTC 01-D9: Last Mode Error; DTC 01-DA: No Response Against ON / OFF Command; DTC 01-DB: Mode Status Error; DTC 01-DE: Slave Reset |
| 01-DF | Master Error | 1. Multi-display power source circuit 2. AVC-LAN circuit between multi-display and component which has stored this code 3. AVC-LAN circuit between multi-display and radio receiver 4. Multi-display 5. Component which has stored this code | Refer to DTC 01-DF: Master Error |
| 01-E0 | Registration Complete Indication Error | Refer to DTC 01-E0: Registration Complete Indication Error; DTC 01-E3: Registration Demand Transmission; DTC 01-E4: Multiple Frame Incomplete | |
| 01-E1 | Voice Processing Device ON Error | 1. Multi-display power source circuit 2. AVC-LAN circuit between multi-display and component which has stored this code 3. Multi-display 4. Component which has stored this code | Refer to DTC 01-DD: Master Reset; DTC 01-E1: Voice Processing Device ON Error |
| 01-E2 | ON / OFF Indication Parameter Error | Multi-display | Refer to DTC 01-E2: ON / OFF Indication Parameter Error |
| 01-E3 | Registration Demand Transmission | Refer to DTC 01-E0: Registration Complete Indication Error; DTC 01-E3: Registration Demand Transmission; DTC 01-E4: Multiple Frame Incomplete | |
| 01-E4 | Multiple Frame Incomplete | Refer to DTC 01-E0: Registration Complete Indication Error; DTC 01-E3: Registration Demand Transmission; DTC 01-E4: Multiple Frame Incomplete | |
| 21-10 | Panel Switch Error | Multi-display | Refer to DTC 21-10: Panel Switch Error; DTC 21-11: Touch Switch Error; DTC 23-10: Panel Switch Error; DTC 23-11: Touch Switch Error; DTC 24-10: Panel Switch Error; DTC 24-11: Touch Switch Error; DTC 25-10: Panel Switch Error; DTC 25-11: Touch Switch Error |
| 21-11 | Touch Switch Error | Multi-display | Refer to DTC 21-10: Panel Switch Error; DTC 21-11: Touch Switch Error; DTC 23-10: Panel Switch Error; DTC 23-11: Touch Switch Error; DTC 24-10: Panel Switch Error; DTC 24-11: Touch Switch Error; DTC 25-10: Panel Switch Error; DTC 25-11: Touch Switch Error |
| 23-10 | Panel Switch Error | Multi-display | Refer to DTC 21-10: Panel Switch Error; DTC 21-11: Touch Switch Error; DTC 23-10: Panel Switch Error; DTC 23-11: Touch Switch Error; DTC 24-10: Panel Switch Error; DTC 24-11: Touch Switch Error; DTC 25-10: Panel Switch Error; DTC 25-11: Touch Switch Error |
| 23-11 | Touch Switch Error | Multi-display | Refer to DTC 21-10: Panel Switch Error; DTC 21-11: Touch Switch Error; DTC 23-10: Panel Switch Error; DTC 23-11: Touch Switch Error; DTC 24-10: Panel Switch Error; DTC 24-11: Touch Switch Error; DTC 25-10: Panel Switch Error; DTC 25-11: Touch Switch Error |
| 24-10 | Panel Switch Error | Multi-display | Refer to DTC 21-10: Panel Switch Error; DTC 21-11: Touch Switch Error; DTC 23-10: Panel Switch Error; DTC 23-11: Touch Switch Error; DTC 24-10: Panel Switch Error; DTC 24-11: Touch Switch Error; DTC 25-10: Panel Switch Error; DTC 25-11: Touch Switch Error |
| 24-11 | Touch Switch Error | Multi-display | Refer to DTC 21-10: Panel Switch Error; DTC 21-11: Touch Switch Error; DTC 23-10: Panel Switch Error; DTC 23-11: Touch Switch Error; DTC 24-10: Panel Switch Error; DTC 24-11: Touch Switch Error; DTC 25-10: Panel Switch Error; DTC 25-11: Touch Switch Error |
| 25-10 | Panel Switch Error | Multi-display | Refer to DTC 21-10: Panel Switch Error; DTC 21-11: Touch Switch Error; DTC 23-10: Panel Switch Error; DTC 23-11: Touch Switch Error; DTC 24-10: Panel Switch Error; DTC 24-11: Touch Switch Error; DTC 25-10: Panel Switch Error; DTC 25-11: Touch Switch Error |
| 25-11 | Touch Switch Error | Multi-display | Refer to DTC 21-10: Panel Switch Error; DTC 21-11: Touch Switch Error; DTC 23-10: Panel Switch Error; DTC 23-11: Touch Switch Error; DTC 24-10: Panel Switch Error; DTC 24-11: Touch Switch Error; DTC 25-10: Panel Switch Error; DTC 25-11: Touch Switch Error |
| 34-10 | Error in Picture Circuit | Multi-display | Refer to DTC 34-10: Error in Picture Circuit; DTC 34-11: No Current in Back-light; DTC 34-12: Excess Current in Back-light |
| 34-11 | No Current in Back-light | Multi-display | Refer to DTC 34-10: Error in Picture Circuit; DTC 34-11: No Current in Back-light; DTC 34-12: Excess Current in Back-light |
| 34-12 | Excess Current in Back-light | Multi-display | Refer to DTC 34-10: Error in Picture Circuit; DTC 34-11: No Current in Back-light; DTC 34-12: Excess Current in Back-light |
| 45-10 | DVD Changer Mechanical Error | Radio receiver | Refer to DTC 45-10: DVD Changer Mechanical Error; DTC 45-11: DVD Insertion and Ejection Error; DTC 45-12: DVD Reading Abnormal |
| 45-11 | DVD Insertion and Ejection Error | Radio receiver | Refer to DTC 45-10: DVD Changer Mechanical Error; DTC 45-11: DVD Insertion and Ejection Error; DTC 45-12: DVD Reading Abnormal |
| 45-12 | DVD Reading Abnormal | Radio receiver | Refer to DTC 45-10: DVD Changer Mechanical Error; DTC 45-11: DVD Insertion and Ejection Error; DTC 45-12: DVD Reading Abnormal |
| 45-41 | Wrong Disc | 1. Disc 2. Radio receiver | Refer to DTC 45-41: Wrong Disc; DTC 45-42: Disc cannot be Read |
| 45-42 | Disc cannot be Read | 1. Disc 2. Radio receiver | Refer to DTC 45-41: Wrong Disc; DTC 45-42: Disc cannot be Read |
| 45-43 | DVD-ROM Abnormal | 1. Disc 2. Radio receiver | Refer to DTC 45-43: DVD-ROM Abnormal |
| 45-44 | DVD Malfunction | Radio receiver | Refer to DTC 45-44: DVD Malfunction; DTC 45-48: Excess Current; DTC 45-50: Tray Insertion / Ejection Error |
| 45-45 | Eject Error | Radio receiver | Refer to DTC 45-45: Eject Error; DTC 45-51: Elevator Error; DTC 45-52: Clamp Error |
| 45-46 | Scratched/Reversed Disc | 1. Disc 2. Radio receiver | Refer to DTC 45-46: Scratched/Reversed Disc |
| 45-47 | High Temperature | Radio receiver | Refer to DTC 45-47: High Temperature |
| 45-48 | Excess Current | Radio receiver | Refer to DTC 45-44: DVD Malfunction; DTC 45-48: Excess Current; DTC 45-50: Tray Insertion / Ejection Error |
| 45-50 | Tray Insertion / Ejection Error | Radio receiver | Refer to DTC 45-44: DVD Malfunction; DTC 45-48: Excess Current; DTC 45-50: Tray Insertion / Ejection Error |
| 45-51 | Elevator Error | Radio receiver | Refer to DTC 45-45: Eject Error; DTC 45-51: Elevator Error; DTC 45-52: Clamp Error |
| 45-52 | Clamp Error | Radio receiver | Refer to DTC 45-45: Eject Error; DTC 45-51: Elevator Error; DTC 45-52: Clamp Error |
| 45-78 | DSP Error | Radio receiver | Refer to DTC 45-78: DSP Error |
| 45-7D | Disc cannot be Played | 1. Disc 2. Radio receiver | Refer to DTC 45-7D: Disc cannot be Played; DTC 45-7E: No Playable Files; DTC 45-7F: Copyright Protection Error |
| 45-7E | No Playable Files | 1. Disc 2. Radio receiver | Refer to DTC 45-7D: Disc cannot be Played; DTC 45-7E: No Playable Files; DTC 45-7F: Copyright Protection Error |
| 45-7F | Copyright Protection Error | 1. Disc 2. Radio receiver | Refer to DTC 45-7D: Disc cannot be Played; DTC 45-7E: No Playable Files; DTC 45-7F: Copyright Protection Error |
| 57-47 | Bluetooth Module Initialization Failed | Multi-display | Refer to DTC 57-47: Bluetooth Module Initialization Failed |
| 5C-40 | Camera Picture Error | 1. Wire harness 2. Television camera 3. Multi-display | Refer to DTC 5C-40: Camera Picture Error |
| 60-10 | AM Tuner PLL does not Lock | Radio receiver | Refer to DTC 60-10: AM Tuner PLL does not Lock; DTC 60-11: FM Tuner PLL does not Lock |
| 60-11 | FM Tuner PLL does not Lock | Radio receiver | Refer to DTC 60-10: AM Tuner PLL does not Lock; DTC 60-11: FM Tuner PLL does not Lock |
| 60-42 | Tuner Power Source Error | Radio receiver | Refer to DTC 60-42: Tuner Power Source Error; DTC 60-43: AM Tuner Error; DTC 60-44: FM Tuner Error; DTC 60-50: Malfunction in Internal IC |
| 60-43 | AM Tuner Error | Radio receiver | Refer to DTC 60-42: Tuner Power Source Error; DTC 60-43: AM Tuner Error; DTC 60-44: FM Tuner Error; DTC 60-50: Malfunction in Internal IC |
| 60-44 | FM Tuner Error | Radio receiver | Refer to DTC 60-42: Tuner Power Source Error; DTC 60-43: AM Tuner Error; DTC 60-44: FM Tuner Error; DTC 60-50: Malfunction in Internal IC |
| 60-50 | Malfunction in Internal IC | Radio receiver | Refer to DTC 60-42: Tuner Power Source Error; DTC 60-43: AM Tuner Error; DTC 60-44: FM Tuner Error; DTC 60-50: Malfunction in Internal IC |
| 63-10 | CD Changer Mechanical Error | Radio receiver | Refer to DTC 63-10: CD Changer Mechanical Error; DTC 63-11: CD Insertion and Ejection Error; DTC 63-12: CD Reading Abnormal |
| 63-11 | CD Insertion and Ejection Error | Radio receiver | Refer to DTC 63-10: CD Changer Mechanical Error; DTC 63-11: CD Insertion and Ejection Error; DTC 63-12: CD Reading Abnormal |
| 63-12 | CD Reading Abnormal | Radio receiver | Refer to DTC 63-10: CD Changer Mechanical Error; DTC 63-11: CD Insertion and Ejection Error; DTC 63-12: CD Reading Abnormal |
| 63-41 | Wrong Disc | 1. CD 2. Radio receiver | Refer to DTC 63-41: Wrong Disc; DTC 63-42: Disc cannot be Read |
| 63-42 | Disc cannot be Read | 1. CD 2. Radio receiver | Refer to DTC 63-41: Wrong Disc; DTC 63-42: Disc cannot be Read |
| 63-43 | CD-ROM Abnormal | 1. CD 2. Radio receiver | Refer to DTC 63-43: CD-ROM Abnormal |
| 63-44 | CD Abnormal | Radio receiver | Refer to DTC 63-44: CD Abnormal; DTC 63-48: Excess Current; DTC 63-50: Tray Insertion / Ejection Error |
| 63-45 | Eject Error | Radio receiver | Refer to DTC 63-45: Eject Error; DTC 63-51: Elevator Error; DTC 63-52: Clamp Error |
| 63-46 | Scratched / Reversed Disc | 1. CD 2. Radio receiver | Refer to DTC 63-46: Scratched / Reversed Disc |
| 63-47 | High Temperature | Radio receiver | Refer to DTC 63-47: High Temperature |
| 63-48 | Excess Current | Radio receiver | Refer to DTC 63-44: CD Abnormal; DTC 63-48: Excess Current; DTC 63-50: Tray Insertion / Ejection Error |
| 63-50 | Tray Insertion / Ejection Error | Radio receiver | Refer to DTC 63-44: CD Abnormal; DTC 63-48: Excess Current; DTC 63-50: Tray Insertion / Ejection Error |
| 63-51 | Elevator Error | Radio receiver | Refer to DTC 63-45: Eject Error; DTC 63-51: Elevator Error; DTC 63-52: Clamp Error |
| 63-52 | Clamp Error | Radio receiver | Refer to DTC 63-45: Eject Error; DTC 63-51: Elevator Error; DTC 63-52: Clamp Error |
| 63-78 | DSP Error | Radio receiver | Refer to DTC 63-78: DSP Error |
| 63-7D | Disc cannot be Played | 1. CD 2. Radio receiver | Refer to DTC 63-7D: Disc cannot be Played; DTC 63-7E: No Playable Files; DTC 63-7F: Copyright Protection Error |
| 63-7E | No Playable Files | 1. CD 2. Radio receiver | Refer to DTC 63-7D: Disc cannot be Played; DTC 63-7E: No Playable Files; DTC 63-7F: Copyright Protection Error |
| 63-7F | Copyright Protection Error | 1. CD 2. Radio receiver | Refer to DTC 63-7D: Disc cannot be Played; DTC 63-7E: No Playable Files; DTC 63-7F: Copyright Protection Error |
| 74-40 | Short in Speaker Circuit | 1. Wire harness 2. Speaker 3. Stereo component amplifier | Refer to DTC 74-40: Short in Speaker Circuit |
AUDIO AND VISUAL SYSTEM
