Smart Access System (Keyless Entry) (Diagnostics & Symptom Tests): Overview Lexus GS III рестайлинг

SYSTEM DESCRIPTION

Scheme 44

Scheme 45

1. SMART ACCESS SYSTEM WITH PUSH-BUTTON START DESCRIPTION In addition to conventional mechanical key and wireless door lock control functions, the smart access system with push-button start enables door locking/unlocking, steering lock releasing, HV control system starting and luggage compartment door opening without operating the key. The only requirement is that the key is in the user's possession. This system is controlled by the certification ECU. When the certification ECU detects the presence of the key in one of the detection areas, it identifies and checks the ID code, and outputs operation signals to the related ECU in accordance with their functions. The detection areas are formed by 4 oscillators and 4 antennas (4 door oscillators, 2 luggage compartment antennas, and 2 indoor antennas).
2. DETECTION AREA Precautions for the entire system: Be sure to carry the key during inspection of the smart access system with push-button start. As weak radio waves are used to detect the key, the key detection area may decrease, or the key may not be detected correctly in the following situations: The key battery is depleted. Any facilities that generate strong radio waves, such as a TV tower, power plant, broadcast station or gas station, are located near the inspection site. A wireless device, such as a cellular phone, is carried with the key. The key is in contact with or covered with metal. Another wireless door lock control function is operated near the vehicle. The key is located near a device that generates high voltage or noise. The key may be difficult to operate for a reason relating to the vehicle body shape. The key may not be detected correctly if it is around the vehicle's windows, the door handle or center of the bumper even when it is in the detection area outside the vehicle. The key may not be detected correctly if it is on the instrument panel, rear package tray or floor, or in the glove box even when it is in the detection area inside the vehicle. The hybrid system cannot be started even when the key is in the detection area inside the luggage compartment. The key may not operate if the key is not held properly. The smart access system with push-button start does not operate in the following conditions: The smart access system with push-button start is canceled. The key battery is completely depleted (the indicator does not blink when pushing any of the buttons on the key).
3. FUNCTION OF MAIN COMPONENTS Components Function Key Consists of mechanical key, transmitter for wireless door lock control and transceiver for smart access system with push-button start Certification ECU Controls smart access system with push-button start in accordance with signals from each oscillator, various switches, ECUs and key Judges and certifies ID code from entry door control receiver Transmits engine immobiliser unset signal to ID code box Transmits steering unlock signals to steering lock ECU Power Source Control ECU Controls push-button start function in accordance with signals from various switches, ECUs and combination meter Transmits key verification request signal to certification ECU in accordance with power switch signal, and turns relays ON and OFF ID Code Box Receives steering unlock or engine immobiliser unset signals from certification ECU, certifies them, and transmits unset signals to steering lock ECU or ECM Main Body ECU RH Receives request signal from certification ECU and sends request signal to door ECUs to lock or unlock doors Transmits each door condition to certification ECU Outside Door Handle (for driver, front passenger, rear doors) (antenna) Transmits request signals Outside Door Handle (for driver, front passenger, rear doors) (touch sensor) Detects when person touches inside of outside handle The signal transmits from door ECU to certification ECU Outside Door Handle (for driver, front passenger, rear doors) (lock switch) Transmits door lock request signals from door ECU to certification ECU Door Electrical Key Oscillator (for driver, front passenger, rear doors) Receives request signal from certification ECU, and forms detection area around each door Indoor Electrical Key Antenna (for front, rear) Receives request signal from certification ECU, and forms detection area in vehicle interior Luggage Compartment Electrical Key Antenna (for inner) Receives request signal from certification ECU, and forms detection area in luggage room Luggage Compartment Electrical Key Antenna (for outer) Receives request signal from certification ECU, and forms detection area around luggage compartment door Door Control Receiver Receives ID code from key in detection area and transmits it to certification ECU Receives ID code from key in luggage room and transmits it to certification ECU Rear Glass Antenna Receives ID code from key and transmits it to entry door control receiver Outside Rear View Mirror Foot Light When key enters exterior detection area, foot light is illuminated in accordance with request signal of certification ECU Power Luggage Door Open Switch Transmits luggage compartment door open request signal to certification ECU Stop Light Switch Outputs state of brake pedal to power source control ECU Wireless Door Lock Buzzer Combination Meter Multi-information Display Buzzer When certification ECU detects human errors such as those below, it warns driver by sounding wireless door lock buzzer, displays information and sounds buzzer in accordance with request signal from ECU Example: Key is taken outside vehicle Driver leaves vehicle while hybrid system is still running Driver leaves vehicle while shift lever is in position other than P
4. CONSTRUCTION AND OPERATION Key: The key consists of a mechanical key, a transmitter function for the wireless door lock control and a transceiver for the smart access system with push-button start. The transceiver function for the smart access system with push-button start receives the signals from the oscillators and sends the ID code to the tuner. The transmitter function for the wireless door lock control has a LOCK switch, UNLOCK switch, LUGGAGE COMPARTMENT switch and PANIC switch. This mechanical key works for the driver door, luggage compartment door and glove box, but cannot start the hybrid system. A total of 7 keys can be registered. Oscillator (each door oscillator, front and rear indoor antenna, luggage compartment inner antenna, luggage compartment outer antenna) Each oscillator transmits the request signal received from the certification ECU, and forms a key detection area to detect the presence of a key. The detection area formed by each door oscillator and luggage compartment outer antenna is approximately 0.7 to 1.0 m (2.3 to 3.3 ft.) from the outside handle of each door or the center of the rear bumper. The detection area of each door oscillator is formed by transmitting a request signal every 0.25 seconds while the power switch is OFF and each door is locked. In this way, it detects the proximity of a key. During entry lock, the detection area is formed with the lock switch ON. The detection area of the luggage compartment outer antenna is formed when the power luggage door open switch is ON. The detection area of the indoor antenna (for front and rear) is formed when the driver door is opened or closed, during start ignition, when a warning is activated, or when the lock switch is ON. The detection area of the luggage compartment inner antenna is formed when the luggage compartment door is closed or the luggage compartment open switch is pressed.
5. ENTRY FUNCTION OPERATION The smart access system with push-button start has the following functions. Function Outline Mechanical Key Operation is same as conventional mechanical key. Wireless Door Lock Control This function remotely locks and unlocks all doors or luggage compartment. Operation is same as wireless door lock control system. However, the receiver in certification ECU uses entry door control receiver to control locking and unlocking. Entry Illumination When person carrying key enters detection area, door will enter unlock standby mode and front map light and door mirror foot light will illuminate. Entry Unlock When key is located in detection area of door oscillator, door will unlock by touching inside of outside door handle. Entry Unlock Mode Switching . Refer to «CUSTOMIZE PARAMETERS»(ref-387107-S19649216352011022400000) Changes doors that can be unlocked with entry unlock function between 4 modes. Driver door unlock mode Doors on one side unlock mode One door unlock mode All door unlock mode Entry Lock When key is located in detection area of door oscillator and power switch is OFF, door can be locked by pressing lock switch on outside door handle. Entry Luggage Compartment Open When key is in detection area of luggage compartment outer oscillator, luggage compartment opens by pressing luggage compartment open switch. Memory Call This function operates driving position memory system in accordance with key ID code. Entry Power Window Function Pressing door handle entry lock switch for approx. 3 seconds or more causes all power windows to close while sounding wireless buzzer. Key Lock-in Prevention Prevents confinement of key if door is locked using outside door handle while key is still inside vehicle. If all doors locked and luggage compartment door is closed while key is still in luggage compartment, warning buzzer sounds. If luggage compartment open switch is operated, luggage compartment door can be opened. Warning When any of situations below occur, smart access system with push-button start causes certification ECU to sound buzzer in combination meter and wireless door lock buzzer, and illuminate information in order to alert driver. Shift lever not on P (power source cut reminder) vehicle exit warning Key reminder warning Shift lever on P (power source cut reminder) vehicle exit warning Entry door ajar warning Passenger has brought key out of vehicle warning Key is not within detection area warning Key lock-in prevention function buzzer (for cabin) Key lock-in prevention function buzzer (for luggage compartment) Key battery low warning Battery Saving If key is constantly located within actuation area of door oscillator, system maintains periodic communication with key. Therefore, if vehicle remains parked in that state for long time, key battery and vehicle battery could be drained. Key Cancel . Refer to «CUSTOMIZE PARAMETERS»(ref-387107-S19649216352011022400000) Following key functions can be canceled. Entry Unlock/Lock Entry Ignition Memory Call Entry Luggage Compartment Open Key Lock-in Prevention Warning
6. WIRELESS DOOR LOCK AND UNLOCK AND LUGGAGE COMPARTMENT OPEN FUNCTION Push the LOCK/UNLOCK/PANIC/LUGGAGE COMPARTMENT switch on the key to operate each function.
7. ENTRY UNLOCK FUNCTION The detection area is formed by communication between a door oscillator and tuner when the door is locked in order to detect the person carrying the key. When the person carrying the key enters the detection area around the vehicle, the matching of the ID codes for a door oscillator and key will automatically be performed. After the matching is completed, the door will enter unlock standby mode. In unlock standby mode, the antenna built into the outside handle starts sensing. If the outside handle is held (the back side of the handle is touched), the door unlock operation will be performed. At this time, the hazard warning light blinks twice and the wireless door lock buzzer sounds twice. If any of the doors are not opened after a door unlock operation, all doors will automatically lock after 30 seconds.
8. ENTRY LOCK FUNCTION After leaving the vehicle carrying the key, push the lock switch on the outside handle when all the doors are closed. The certification ECU determines whether the key is located inside or outside of the cabin based on the information from a door oscillator and room oscillator. Then matching of the ID codes is performed. When the matching result shows that the ID codes of the key and indoor antenna do not match and the ID codes of the key and door oscillator match, the door lock function will operate. At this time, the hazard warning lights blink once and the wireless door lock buzzer sounds once. If the key is located inside of the cabin, the door lock function will not operate and the alarm buzzer (beep sound) will sound for 2 seconds.
9. ENTRY LUGGAGE COMPARTMENT OPEN FUNCTION Stand in front of the luggage compartment with the key and push the power luggage door open switch to start the matching of the ID codes for the luggage compartment antenna (for outer). If the ID codes match, luggage compartment door open operation will be performed.
10. PREVENTION OF KEY CONFINEMENT FUNCTION If you attempt to lock the door through keyless operation (move the lock knob to the lock position and then close the door) with the key in the cabin, the system determines that the key is located in the cabin and unlocks the door. If the luggage compartment is closed with the key in it, the alarm will sound and the luggage compartment can be opened only when all the doors are locked in order to prevent key confinement in the vehicle.
11. ENTRY ILLUMINATION FUNCTION In order to improve ease of entering and exiting the vehicle at night, the vehicle interior front dome light and door mirror foot area light illuminate when the key is brought near the vehicle. Control Information: Holding the key and bringing it within the vehicle exterior detection area causes the door to enter unlock standby. At this time, the vehicle interior front dome light and door mirror foot area light illuminate. Precaution: The entry illumination function operates when the key is outside the vehicle exterior detection area for 3 seconds or more, and is then brought within the vehicle exterior detection area. If the key is not first brought outside the vehicle exterior detection area, the entry illumination function will not operate.
12. ENTRY POWER WINDOW FUNCTION (DOOR WINDOW AND SLIDING ROOF CLOSE OPERATION ONLY) After locking all the doors through the wireless lock operation or entry lock operation, pressing the door handle lock switch for 3 seconds or more operates the door window close operation of all of the windows and the sliding roof close operation. If the entry power window function is operating and the door handle lock switch is released, the entry power window operation will stop. The wireless buzzer sounds while the entry power window function is operating. HINT: For more information about the entry power window function, refer to the power window control system.
13. MEMORY CALL FUNCTION (for MEMORY SEAT VEHICLES ONLY) After unlocking the driver door using the key ID and opening the driver door, the seat automatically moves to the position associated with the key ID. HINT: For more information about the memory call function, refer to the front power seat control system. Key ID registration method: With the power switch OFF and the driver door closed, press and hold the seat memory switch to be registered. (Releasing the seat memory switch will end the key ID registration mode.) Press the lock or unlock switch of the key to be registered. If the key has not been registered previously, the key ID will be registered. During the registration, the wireless buzzer will sound. Memory call cancel method: With the power switch OFF, press and hold the SET switch. (Releasing the SET switch will end the memory call cancel mode.) Press the lock or unlock switch of the key to be canceled. If the key has been registered previously, the memory call operation of the key ID will be canceled. The key ID can be reactivated by pressing the lock or unlock switch of the key again. During the memory call cancel and reactivation operation, the wireless buzzer will sound.
14. WARNING FUNCTION General: When any of the situations below occur, the smart access system with push-button start responds to alert the driver. Warning Function Operation Condition Situation Shift lever not on P (power source cut reminder) vehicle exit warning A Key reminder warning B Shift lever on P (power source cut reminder) vehicle exit warning C Entry door ajar warning D Passenger has brought key out of vehicle warning E Key is not within detection area warning F Key lock-in prevention function buzzer (for cabin) G Key lock-in prevention function buzzer (for luggage compartment) H Key battery low warning I Situation A: Shift lever not on P (power source cut reminder) vehicle exit warning With shift lever in position other than P, door is opened and vehicle exit (while holding key) is attempted Reason for warning: Sudden vehicle start prevention, vehicle theft prevention, vehicle roll-away prevention Warning start condition: Shift lever position is not P, power switch is ON (ACC or IG), driver side door is opened and vehicle speed is 0 km/h (0 mph) Warning stop condition: Power switch is ON (ACC or IG), shift lever position is P, vehicle speed is above 0 km/h (0 mph), or driver side door is closed Warning description Combination meter buzzer Multi-buzzer Sounds continuously ("pon" sound) Combination meter display Combination meter information None Wireless buzzer Sounds for 3 seconds (long beep) Recommended user action Move shift lever to P position With shift lever in position other than P, door is opened, key is brought out of vehicle, door is closed, and move away from vehicle is attempted Reason for warning: Sudden vehicle start prevention, vehicle theft prevention, vehicle roll-away prevention Warning start condition: Shift lever position is not P, power switch is ON (ACC or IG), opened driver side door is closed, vehicle speed is 0 km/h (0 mph) and key is not in detected in vehicle interior and luggage interior Warning stop condition: Key is detected in vehicle interior and luggage interior: Buzzer stops and "SHIFT TO P RANGE" is displayed on combination meter Vehicle speed is above 0 km/h (0 mph): Buzzer stops, "KEY IS NOT DETECTED" is displayed on combination meter Power switch ON (ACC) or OFF: All warnings are turned off Warning description Combination meter buzzer Multi-buzzer Sounds continuously ("pon" sound) Combination meter display Combination meter information Information below is displayed alternately on combination meter "SHIFT TO P RANGE" "KEY IS NOT DETECTED" Wireless buzzer Sounds continuously (beep) Recommended user action Move shift lever to P position Situation B: Key reminder warning Steering lock / unlock set, driver door is opened and move away from vehicle is attempted Reason for warning: Vehicle theft prevention, required by law Precondition: Remote start is not operating Warning start condition: One of following conditions is met Power switch ON (ACC) or OFF, and driver door opened Power switch ON (ACC) or OFF, steering lock / unlock set and driver door opened Warning stop condition: One of following conditions is met Power switch is ON (IG) or driver door is closed Power switch ON (ACC) or OFF, and steering lock / unlock is set Warning description Combination meter buzzer Multi-buzzer Sounds intermittently (several "pon" sounds) Combination meter display Combination meter information None Wireless buzzer None Recommended user action If power switch is ON (ACC or IG), turn power switch OFF and close driver door Situation C: Shift lever on P (power source cut reminder) vehicle exit warning Pattern 1: With shift lever on P, driver door is opened, key is brought out of vehicle, driver door is closed, and move away from vehicle is attempted Reason for warning: Vehicle theft prevention, "Hybrid system cannot be restarted" prevention, battery depletion prevention Warning start condition: Shift lever position is P, power switch is ON (ACC or IG), opened driver side door is closed and key is not in detected in vehicle interior and luggage interior Warning stop condition: Power switch ON (ACC) or OFF, or key is detected in vehicle interior and luggage interior Warning description Combination meter buzzer Multi-buzzer Sounds once (1 "pon" sound) (when key is not detected continuously, sounds again when vehicle is first driven) Combination meter display Combination meter information "KEY IS NOT DETECTED" Wireless buzzer Sounds 3 times (short beeps) Recommended user action Turn power switch OFF and exit vehicle while holding key With shift lever on P and either power switch ON (ACC) or steering lock / unlock set, driver door is opened, move away from vehicle is performed, and door handle lock switch is pressed in an attempt to perform entry lock operation Reason for warning: Vehicle theft prevention, battery depletion prevention Precondition: Change door control lock switch from off to on Warning start condition: Shift lever position is P, power switch is ON (ACC or IG), all doors closed and key is detected in vehicle exterior. Warning stop condition: One of following conditions is met Power switch ON (ACC) or OFF, or key is detected in vehicle exterior Key is detected in vehicle interior and luggage interior and key is not detected in vehicle exterior. Warning description Combination meter buzzer Multi-buzzer None Combination meter display Combination meter information None Wireless buzzer Sounds for 2 seconds (long beep) Recommended user action Turn power switch OFF and perform entry lock operation Situation D: Entry door ajar warning With one of vehicle's doors open, entry lock operation is attempted Reason for warning: Vehicle theft prevention Precondition: Power switch ON (ACC) or OFF, and one of doors open Warning stop condition: After preconditions are met, entry lock operation is performed Warning stop condition: Power switch is ON (ACC or IG), all doors are closed, wireless unlock is performed, entry unlock operation is performed or 10 seconds have passed after warning start Warning description Combination meter buzzer Multi-buzzer None Combination meter display Combination meter information None Wireless buzzer Sounds continuously (beep) Recommended user action Close all doors and perform entry lock operation Situation E: Passenger has brought key out of vehicle warning With power switch in position other than OFF, key is brought out of vehicle by passenger Reason for warning: "Hybrid system cannot be started" prevention Warning start condition: Power switch is ON (ACC or IG), opened door other than driver side door is closed, vehicle speed is 0 km/h (0 mph) and key is not in detected in vehicle interior and luggage interior Warning stop condition: Power switch ON (ACC) or OFF, or key is detected in vehicle interior and luggage interior or vehicle speed is above 0 km/h (0 mph) Warning description Combination meter buzzer Multi-buzzer Sounds once (1 "pon" sound) (when key is not detected continuously, sounds again when vehicle is first driven) Combination meter display Combination meter information "KEY IS NOT DETECTED" Wireless buzzer Sounds 3 times (short beeps) Recommended user action Check if the passenger who exited the vehicle has the key or not Situation F: Key is not within detection area warning With key not in vehicle cabin or key battery depleted, hybrid system start is attempted or power switch ON (ACC or IG) operation is attempted Reason for warning: User confusion prevention Warning condition: Power switch is not OFF and key is not detected in vehicle interior Warning description Combination meter buzzer Multi-buzzer Sounds once (1 "pon" sound) Combination meter display Combination meter information "KEY IS NOT DETECTED" is displayed for 8 seconds, then display ends Wireless buzzer None Recommended user action Check if the key is within the detection area of the vehicle cabin If key is within the vehicle interior, built-in battery may be depleted If key's wireless door lock switch is pressed, check if key's indicator illuminates If indicator does not illuminate, replace the built-in battery It is recommended that battery be bought at dealer, but battery can be replaced according to user preference Situation G: Key lock-in prevention function buzzer (for cabin) With key in vehicle cabin, vehicle is exited and door handle lock switch is pressed in an attempt to perform entry lock operation. Reason for warning: Key reminder vehicle theft warning prevention Warning condition: Power switch ON (ACC) or OFF, all doors closed, door handle lock switch ON and key is detected in vehicle interior (key is not in luggage) Warning description Combination meter buzzer Multi-buzzer None Combination meter display Combination meter information None Wireless buzzer Sounds for 2 seconds (long beep) Recommended user action Pick up key that is in vehicle interior and perform entry lock operation again Situation H: Key lock-in prevention function buzzer (for luggage compartment) Key is put into luggage compartment and luggage compartment door is accidentally closed Reason for warning: Key confinement Precondition: Vehicle speed is 0 km/h (0 mph) and entry luggage function is operating (not set to off through customization) Warning start condition: After preconditions are met, all doors are closed, key is put into luggage and luggage compartment door is closed Warning description Combination meter buzzer Multi-buzzer None Combination meter display Combination meter information None Wireless buzzer Sounds for 2 seconds (short beep) Recommended user action Using entry luggage function, open luggage compartment door and remove key. Situation I: Key battery low warning Key with almost depleted battery is used to drive vehicle Reason for warning: Helpful function Warning condition: After power switch not OFF condition continues for 20 minutes or more, power switch is changed from not OFF to OFF position, key battery is low and key is detected in vehicle interior and luggage interior Warning description Combination meter buzzer Multi-buzzer Sound once (1 "pon" sound) Combination meter display Combination meter information "LOW KEY BATTERY" Wireless buzzer None Recommended user action Replace key's built-in battery with new one It is recommended that battery be bought at dealer, but battery can be replaced according to user preference
15. BATTERY SAVING Vehicle battery saving function: In the smart access system with push-button start, signals are emitted outside of the vehicle at a prescribed interval (0.25 seconds) when the doors are locked. Therefore, the vehicle battery could be drained if the vehicle remains parked for a long time. For this reason, the controls listed below exist. Condition Control Both conditions below are met for 5 days: Key is not in detection area Touch sensor or lock switch operation is not performed Signal transmission interval is extended from 0.25 to 0.75 seconds Both conditions below are met for 14 days: Key is not in detection area Touch sensor or lock switch operation is not performed Automatically deactivates the smart access system with push-button start Reinstatement Conditions: A wireless door lock control signal (lock, unlock) is input and the ID matches. A user carries the key and pushes a lock switch on an outside door handle. The driver door is locked or unlocked by the mechanical key. Key battery and vehicle battery saving function: In the smart access system with push-button start, if the key is constantly located within the vehicle exterior detection area of the doors, the system maintains periodic communication with the key. Therefore, if the vehicle remains parked in that state for a long time, the key battery and the vehicle battery could be drained. For this reason, if this state continues longer than 10 minutes, the smart access system with push-button start automatically becomes deactivated. Reinstatement Conditions A wireless door lock control signal (lock, unlock) is input and the ID code matches. A user carries the key and pushes a lock switch on an outside handle. The driver door is locked or unlocked by the mechanical key.

DESCRIPTION

When the key cancel function is ON, all entry functions will stop operating. If the key cancel function is operated but all entry functions stop operating, one of the following is malfunctioning: 1) key cancel function, 2) certification ECU, or 3) wire harness.

When an ID code from the door electrical key oscillator front LH matches an ID code from the key, the certification ECU outputs a SEL signal (Lo when output) to the door electrical key oscillator front LH, activates the touch sensor inside the outside door handle, and enters unlock standby mode. When the touch sensor is touched, the door electrical key oscillator front LH sends a SENS signal (Lo when output) to the certification ECU and the certification ECU sends an unlock signal to the driver side door lock.

Scheme 46

Scheme 47

Scheme 48

Scheme 49

1. CHECK MANUAL DOOR UNLOCK OPERATION Check that the manual door unlock function operates normally. OK Manual door unlock function operates normally. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM OK: Go to next step
2. READ VALUE USING TECHSTREAM (DOOR COURTESY SWITCH) Check the DATA LIST for proper functioning of the driver side door courtesy switch. MAIN BODY ECU RH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door Courtesy SW Driver side door courtesy switch / ON or OFF ON: Courtesy switch is pushed OFF: Courtesy switch is not pushed - OK ON (door courtesy switch is pushed) appears on the screen. NG --> GO TO LIGHTING SYSTEM OK: Go to next step
3. READ VALUE USING TECHSTREAM (DOOR LOCK POSITION SWITCH) Check the DATA LIST for proper functioning of the door lock position switch. MULTIPLEX NETWORK MASTER SWITCH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Door Unlock Detection Switch Door unlock detection switch / ON or OFF ON: Door is unlocked OFF: Door is locked - OK On the Techstream screen, the display changes between ON and OFF as shown in the chart above. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM (Proceed to Only Driver Door LOCK / UNLOCK Functions do not Operate) OK: Go to next step
4. PERFORM ACTIVE TEST USING TECHSTREAM (DRIVER SIDE SELECT) Select the ACTIVE TEST, use the Techstream to generate a control command, and then check that the oscillator operates. CERTIFICATION ECU: Tester Display Test Part Control Range Diagnostic Note D-Seat Select Driver side select ON/OFF - OK ON (D-Seat Select is on) appears on the screen. NG --> REPLACE CERTIFICATION ECU OK: Go to next step
5. READ VALUE USING TECHSTREAM (DRIVER SIDE TOUCH SENSOR) With "D-Seat Select" ON, check the DATA LIST for proper functioning of the touch sensor. CERTIFICATION ECU: Tester Display Measurement Item/Range Normal Condition Diagnostic Note D-Touch Sensor Driver side door touch sensor / ON or OFF ON: Sensor is touched OFF: Sensor is not touched - OK When driver side door touch sensor is touched, ON (Sensor is touched) appears on the screen. NG --> See step 7 OK: Go to next step
6. CHECK OPERATION OF MULTIPLEX NETWORK MASTER SWITCH After replacing the multiplex network master switch with a normal one, check that the entry unlock function operates normally. OK Entry unlock function operates normally. NG --> REPLACE CERTIFICATION ECU OK --> END (MULTIPLEX NETWORK MASTER SWITCH IS DEFECTIVE)
7. CHECK DOOR ELECTRICAL KEY OSCILLATOR FRONT LH Measure the voltage of the oscillator connector. Standard voltage Tester Connection Condition Specified Condition 4 (SEL) - Body ground During Active Test Below 1 V 6 (SENS) - Body ground Touch sensor is touched during Active Test Below 1 V OK --> REPLACE CERTIFICATION ECU NG: Go to next step
8. CHECK WIRE HARNESS (OSCILLATOR - ANTENNA) Disconnect the q2 oscillator connector. Disconnect the q1 antenna connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition q2-2 (SGT) - q1-6 (SGT2) Below 1 ohms q2-3 (ANT1) - q1-5 (ANT1) Below 1 ohms q2-8 (ANT2) - q1-2 (ANT2) Below 1 ohms q2-9 (TRG-) - q1-1 (TRG-) Below 1 ohms q2-2 (SGT) or q1-6 (SGT2) - Body ground 10 kohms or higher q2-3 (ANT1) or q1-5 (ANT1) - Body ground 10 kohms or higher q2-8 (ANT2) or q1-2 (ANT2) - Body ground 10 kohms or higher q2-9 (TRG-) or q1-1 (TRG-) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
9. CHECK WIRE HARNESS (ECU - OSCILLATOR) Disconnect the U28 ECU connector. Disconnect the q2 oscillator connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition U28-5 (SEL1) - q2-4 (SEL) Below 1 ohms U28-22 (SEN1) - q2-6 (SENS) Below 1 ohms U28-33 (CLG1) - q2-10 (CLG) Below 1 ohms U28-34 (CG1B) - q2-5 (CLGB) Below 1 ohms U28-5 (SEL1) or q2-4 (SEL) - Body ground 10 kohms or higher U28-22 (SEN1) or q2-6 (SENS) - Body ground 10 kohms or higher U28-33 (CLG1) or q2-10 (CLG) - Body ground 10 kohms or higher U28-34 (CG1B) or q2-5 (CLGB) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE DOOR ELECTRICAL KEY OSCILLATOR FRONT LH

When an ID code from the door electrical key oscillator front RH matches an ID code from the key, the certification ECU outputs a SEL signal (Lo when output) to the door electrical key oscillator front RH, activates the touch sensor inside the outside door handle, and enters unlock standby mode. When the touch sensor is touched, the door electrical key oscillator front RH sends a SENS signal (Lo when output) to the certification ECU and the certification ECU sends an unlock signal to the front passenger side door lock.

Scheme 50

Scheme 51

Scheme 52

1. CHECK MANUAL DOOR UNLOCK OPERATION Check that the manual door unlock function operates normally. OK Manual door unlock function operates normally. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM OK: Go to next step
2. READ VALUE USING TECHSTREAM (DOOR COURTESY SWITCH) Check the DATA LIST for proper functioning of the front passenger side door courtesy switches. MAIN BODY ECU RH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note P Door Courtesy SW Front passenger side courtesy switch / ON or OFF ON: Courtesy switch is pushed OFF: Courtesy switch is not pushed - OK ON (door courtesy switch is pushed) appears on the screen. NG --> GO TO LIGHTING SYSTEM OK: Go to next step
3. READ VALUE USING TECHSTREAM (DOOR LOCK POSITION SWITCH) Check the DATA LIST for proper functioning of the door lock position switch. MULTIPLEX NETWORK DOOR ECU FRONT RH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Door Unlock Detection Switch Door unlock detection switch / ON or OFF ON: Door is unlocked OFF: Door is locked - OK On the Techstream screen, the display changes between ON and OFF as shown in the chart above. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM (Proceed to Only Passenger Door LOCK / UNLOCK Functions do not Operate) OK: Go to next step
4. PERFORM ACTIVE TEST USING TECHSTREAM (FRONT PASSENGER SIDE SELECT) Select the ACTIVE TEST, use the Techstream to generate a control command, and then check that the oscillator operates. CERTIFICATION ECU: Tester Display Test Part Control Range Diagnostic Note P-Seat Select Front passenger side select ON / OFF - OK ON (P-Seat Select is on) appears on the screen. NG --> REPLACE CERTIFICATION ECU OK: Go to next step
5. READ VALUE USING TECHSTREAM (FRONT PASSENGER SIDE TOUCH SENSOR) With "P-Seat Select" ON, check the DATA LIST for proper functioning of the touch sensor. CERTIFICATION ECU: Tester Display Measurement Item/Range Normal Condition Diagnostic Note P-Touch Sensor Front passenger side door touch sensor / ON or OFF ON: Sensor is touched OFF: Sensor is not touched - OK When front passenger side door touch sensor is touched, ON (Sensor is touched) appears on the screen. NG --> See step 7 OK: Go to next step
6. CHECK OPERATION OF MULTIPLEX NETWORK DOOR ECU FRONT RH After replacing the multiplex network door ECU front RH with a normal one, check that the entry unlock function operates normally. OK Entry unlock function operates normally. NG --> REPLACE CERTIFICATION ECU OK --> END (MULTIPLEX NETWORK DOOR ECU FRONT RH IS DEFECTIVE)
7. CHECK DOOR ELECTRICAL KEY OSCILLATOR FRONT RH Measure the voltage of the oscillator connector. Standard voltage Tester Connection Condition Specified Condition 4 (SEL) - Body ground During Active Test Below 1 V 6 (SENS) - Body ground Touch sensor is touched during Active Test Below 1 V OK --> REPLACE CERTIFICATION ECU NG: Go to next step
8. CHECK WIRE HARNESS (OSCILLATOR - ANTENNA) Disconnect the p2 oscillator connector. Disconnect the p1 antenna connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition p2-2 (SGT) - p1-6 (SGT2) Below 1 ohms p2-3 (ANT1) - p1-5 (ANT1) Below 1 ohms p2-8 (ANT2) - p1-2 (ANT2) Below 1 ohms p2-9 (TRG-) - p1-1 (TRG-) Below 1 ohms p2-2 (SGT) or p1-6 (SGT2) - Body ground 10 kohms or higher p2-3 (ANT1) or p1-5 (ANT1) - Body ground 10 kohms or higher p2-8 (ANT2) or p1-2 (ANT2) - Body ground 10 kohms or higher p2-9 (TRG-) or p1-1 (TRG-) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
9. CHECK WIRE HARNESS (ECU - OSCILLATOR) Disconnect the U28 ECU connector. Disconnect the p2 oscillator connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition U28-6 (SEL2) - p2-4 (SEL) Below 1 ohms U28-23 (SEN2) - p2-6 (SENS) Below 1 ohms U28-35 (CLG2) - p2-10 (CLG) Below 1 ohms U28-36 (CG2B) - p2-5 (CLGB) Below 1 ohms U28-6 (SEL2) or p2-4 (SEL) - Body ground 10 kohms or higher U28-23 (SEN2) or p2-6 (SENS) - Body ground 10 kohms or higher U28-35 (CLG2) or p2-10 (CLG) - Body ground 10 kohms or higher U28-36 (CG2B) or p2-5 (CLGB) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE DOOR ELECTRICAL KEY OSCILLATOR FRONT RH

When an ID code from the door electrical key oscillator rear LH matches an ID code from the key, the certification ECU outputs a SEL signal (Lo when output) to the door electrical key oscillator rear LH, activates the touch sensor inside the outside door handle, and enters unlock standby mode. When the touch sensor is touched, the door electrical key oscillator rear LH sends a SENS signal (Lo when output) to the certification ECU and the certification ECU sends an unlock signal to the rear door LH lock.

Scheme 53

Scheme 54

Scheme 55

1. CHECK MANUAL DOOR UNLOCK OPERATION Check that the manual door unlock function operates normally. OK Manual door unlock function operates normally. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM OK: Go to next step
2. READ VALUE USING TECHSTREAM (DOOR COURTESY SWITCH) Check the DATA LIST for proper functioning of the rear LH side door courtesy switches. MAIN BODY ECU RH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Rr Door Courtesy SW Rear door courtesy switch / ON or OFF ON: Courtesy switch is pushed OFF: Courtesy switch is not pushed - OK ON (door courtesy switch is pushed) appears on the screen. NG --> GO TO LIGHTING SYSTEM OK: Go to next step
3. READ VALUE USING TECHSTREAM (DOOR LOCK POSITION SWITCH) Check the DATA LIST for proper functioning of the door lock position switch. MULTIPLEX NETWORK DOOR ECU REAR LH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Door Unlock Detection Switch Door unlock detection switch / ON or OFF ON: Door is unlocked OFF: Door is locked - OK On the Techstream screen, the display changes between ON and OFF as shown in the chart above. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM (Proceed to Only Rear Door LH LOCK / UNLOCK Functions do not Operate) OK: Go to next step
4. PERFORM ACTIVE TEST USING TECHSTREAM (DRIVER SIDE REAR SELECT) Select the ACTIVE TEST, use the Techstream to generate a control command, and then check that the oscillator operates. CERTIFICATION ECU: Tester Display Test Part Control Range Diagnostic Note Dr-Seat Select Driver side rear select ON / OFF - OK ON (Dr-Seat Select is on) appears on the screen. NG --> REPLACE CERTIFICATION ECU OK: Go to next step
5. READ VALUE USING TECHSTREAM (DRIVER SIDE REAR TOUCH SENSOR) With "Dr-Seat Select" ON, check the DATA LIST for proper functioning of the touch sensor. CERTIFICATION ECU: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Dr-Touch Sensor Driver side rear door touch sensor / ON or OFF ON: Sensor is touched OFF: Sensor is not touched - OK When driver side rear door touch sensor is touched, ON (Sensor is touched) appears on the screen. NG --> See step 7 OK: Go to next step
6. CHECK OPERATION OF MULTIPLEX NETWORK DOOR ECU REAR LH After replacing the multiplex network door ECU rear LH with a normal one, check that the entry unlock function operates normally. OK Entry unlock function operates normally. NG --> REPLACE CERTIFICATION ECU OK --> END (MULTIPLEX NETWORK DOOR ECU REAR LH IS DEFECTIVE)
7. CHECK DOOR ELECTRICAL KEY OSCILLATOR REAR LH Measure the voltage of the oscillator connector. Standard voltage Tester Connection Condition Specified Condition 4 (SEL) - Body ground During Active Test Below 1 V 6 (SENS) - Body ground Touch sensor is touched during Active Test Below 1 V OK --> REPLACE CERTIFICATION ECU NG: Go to next step
8. CHECK WIRE HARNESS (OSCILLATOR - ANTENNA) Disconnect the s2 oscillator connector. Disconnect the s1 antenna connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition s2-2 (SGT) - s1-6 (SGT2) Below 1 ohms s2-3 (ANT1) - s1-5 (ANT1) Below 1 ohms s2-8 (ANT2) - s1-2 (ANT2) Below 1 ohms s2-9 (TRG-) - s1-1 (TRG-) Below 1 ohms s2-2 (SGT) or s1-6 (SGT2) - Body ground 10 kohms or higher s2-3 (ANT1) or s1-5 (ANT1) - Body ground 10 kohms or higher s2-8 (ANT2) or s1-2 (ANT2) - Body ground 10 kohms or higher s2-9 (TRG-) or s1-1 (TRG-) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
9. CHECK WIRE HARNESS (ECU - OSCILLATOR) Disconnect the U33 ECU connector. Disconnect the s2 oscillator connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition U33-1 (SEL3) - s2-4 (SEL) Below 1 ohms U33-28 (SEN3) - s2-6 (SENS) Below 1 ohms U33-8 (CLG3) - s2-10 (CLG) Below 1 ohms U33-9 (CG3B) - s2-5 (CLGB) Below 1 ohms U33-1 (SEL3) or s2-4 (SEL) - Body ground 10 kohms or higher U33-28 (SEN3) or s2-6 (SENS) - Body ground 10 kohms or higher U33-8 (CLG3) or s2-10 (CLG) - Body ground 10 kohms or higher U33-9 (CG3B) or s2-5 (CLGB) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE DOOR ELECTRICAL KEY OSCILLATOR REAR LH

When an ID code from the door electrical key oscillator rear RH matches an ID code from the key, the certification ECU outputs a SEL signal (Lo when output) to the door electrical key oscillator rear RH, activates the touch sensor inside the outside door handle, and enters unlock standby mode. When the touch sensor is touched, the door electrical key oscillator rear RH sends a SENS signal (Lo when output)) to the certification ECU and the certification ECU sends an unlock signal to the rear door RH lock.

Scheme 56

Scheme 57

Scheme 58

1. CHECK MANUAL DOOR UNLOCK OPERATION Check that the manual door unlock function operates normally. OK Manual door unlock function operates normally. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM OK: Go to next step
2. READ VALUE USING TECHSTREAM (DOOR COURTESY SWITCH) Check the DATA LIST for proper functioning of the rear RH side door courtesy switches. MAIN BODY ECU RH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Rr Door Courtesy SW Rear door courtesy switch / ON or OFF ON: Courtesy switch is pushed OFF: Courtesy switch is not pushed - OK ON (door courtesy switch is pushed) appears on the screen. NG --> GO TO LIGHTING SYSTEM OK: Go to next step
3. READ VALUE USING TECHSTREAM (DOOR LOCK POSITION SWITCH) Check the DATA LIST for proper functioning of the door lock position switch. MULTIPLEX NETWORK DOOR ECU REAR RH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Door Unlock Detection Switch Door unlock detection switch / ON or OFF ON: Door is unlocked OFF: Door is locked - OK On the Techstream screen, the display changes between ON and OFF as shown in the chart above. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM (Proceed to Only Rear Door RH LOCK / UNLOCK Functions do not Operate) OK: Go to next step
4. PERFORM ACTIVE TEST USING TECHSTREAM (PASSENGER SIDE REAR SELECT) Select the ACTIVE TEST, use the Techstream to generate a control command, and then check that the oscillator operates. CERTIFICATION ECU: Tester Display Test Part Control Range Diagnostic Note Pr-Seat Select Passenger side rear select ON / OFF - OK ON (Pr-Seat Select is on) appears on the screen. NG --> REPLACE CERTIFICATION ECU OK: Go to next step
5. READ VALUE USING TECHSTREAM (PR TOUCH SENSOR) With "Pr-Seat Select" ON, check the DATA LIST for proper functioning of the touch sensor. CERTIFICATION ECU: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Pr-Touch Sensor Passenger side rear door touch sensor / ON or OFF ON: Sensor is touched OFF: Sensor is not touched - OK When passenger side rear door touch sensor is touched, OK (Sensor is touched) appears on the screen. NG --> See step 7 OK: Go to next step
6. CHECK OPERATION OF MULTIPLEX NETWORK DOOR ECU REAR RH After replacing the multiplex network door ECU rear RH with a normal one, check that the entry unlock function operates normally. OK Entry unlock function operates normally. NG --> REPLACE CERTIFICATION ECU OK --> END (MULTIPLEX NETWORK DOOR ECU REAR RH IS DEFECTIVE)
7. CHECK DOOR ELECTRICAL KEY OSCILLATOR REAR RH Measure the voltage of the oscillator connector. Standard voltage Tester Connection Condition Specified Condition 4 (SEL) - Body ground During Active Test Below 1 V 6 (SENS) - Body ground Touch sensor is touched during Active Test Below 1 V OK --> REPLACE CERTIFICATION ECU NG: Go to next step
8. CHECK WIRE HARNESS (OSCILLATOR - ANTENNA) Disconnect the r2 oscillator connector. Disconnect the r1 antenna connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition r2-2 (SGT) - r1-6 (SGT2) Below 1 ohms r2-3 (ANT1) - r1-5 (ANT1) Below 1 ohms r2-8 (ANT2) - r1-2 (ANT2) Below 1 ohms r2-9 (TRG-) - r1-1 (TRG-) Below 1 ohms r2-2 (SGT) or r1-6 (SGT2) - Body ground 10 kohms or higher r2-3 (ANT1) or r1-5 (ANT1) - Body ground 10 kohms or higher r2-8 (ANT2) or r1-2 (ANT2) - Body ground 10 kohms or higher r2-9 (TRG-) or r1-1 (TRG-) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
9. CHECK WIRE HARNESS (ECU - OSCILLATOR) Disconnect the U33 ECU connector. Disconnect the r2 oscillator connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition U33-2 (SEL4) - r2-4 (SEL) Below 1 ohms U33-27 (SEN4) - r2-6 (SENS) Below 1 ohms U33-10 (CLG4) - r2-10 (CLG) Below 1 ohms U33-11 (CG4B) - r2-5 (CLGB) Below 1 ohms U33-2 (SEL4) or r2-4 (SEL) - Body ground 10 kohms or higher U33-27 (SEN4) or r2-6 (SENS) - Body ground 10 kohms or higher U33-10 (CLG4) or r2-10 (CLG) - Body ground 10 kohms or higher U33-11 (CG4B) or r2-5 (CLGB) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE DOOR ELECTRICAL KEY OSCILLATOR REAR RH

Both the entry lock and unlock functions do not operate when: 1) nothing is output from the door electrical key oscillator front LH, 2) the smart access system with push-button start is disabled through customization, or 3) the entire power door lock control system is malfunctioning.

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

1. CHECK MANUAL DOOR LOCK AND UNLOCK OPERATION Check that the manual door lock and unlock function operates normally. OK Manual door lock and unlock function operates normally. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM OK: Go to next step
2. READ VALUE USING TECHSTREAM (DOOR LOCK POSITION SWITCH) Check the DATA LIST for proper functioning of the door lock position switch. MULTIPLEX NETWORK MASTER SWITCH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Door Unlock Detection Switch Door unlock detection switch / ON or OFF ON: Door is unlocked OFF: Door is locked - OK On the Techstream screen, the display changes between ON and OFF as shown in the chart above. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM (Proceed to Only Driver Door LOCK / UNLOCK Functions do not Operate) OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (DOOR ELECTRICAL KEY OSCILLATOR FRONT LH) Select the ACTIVE TEST, use the Techstream to generate a control command, and then check that the oscillator operates. CERTIFICATION ECU: Tester Display Test Part Control Range Diagnostic Note D-Seat Outside Transmitter Driver side oscillator ON / OFF - OK When key is brought close to door oscillator that is OFF, indicator light on key illuminates. OK --> REPLACE CERTIFICATION ECU NG: Go to next step
4. CHECK WIRE HARNESS (ECU - OSCILLATOR) Disconnect the U28 ECU connector. Disconnect the q2 oscillator connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition U28-33 (CLG1) - q2-10 (CLG) Below 1 ohms U28-34 (CG1B) - q2-5 (CLGB) Below 1 ohms U28-33 (CLG1) or q2-10 (CLG) - Body ground 10 kohms or higher U28-34 (CG1B) or q2-5 (CLGB) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. CHECK WIRE HARNESS (OSCILLATOR - ANTENNA) Disconnect the q2 oscillator connector. Disconnect the q1 antenna connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition q2-2 (SGT) - q1-6 (SGT2) Below 1 ohms q2-3 (ANT1) - q1-5 (ANT1) Below 1 ohms q2-8 (ANT2) - q1-2 (ANT2) Below 1 ohms q2-9 (TRG-) - q1-1 (TRG-) Below 1 ohms q2-2 (SGT) or q1-6 (SGT2) - Body ground 10 kohms or higher q2-3 (ANT1) or q1-5 (ANT1) - Body ground 10 kohms or higher q2-8 (ANT2) or q1-2 (ANT2) - Body ground 10 kohms or higher q2-9 (TRG-) or q1-1 (TRG-) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
6. CHECK WIRE HARNESS (OSCILLATOR - ECU) Disconnect the q2 oscillator connector. Disconnect the M10 ECU connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition q2-1 (+B) - M10-7 (OSCB) Below 1 ohms q2-7 (GND) - M10-20 (OSCE) Below 1 ohms q2-1 (+B) or M10-7 (OSCB) - Body ground 10 kohms or higher q2-7 (GND) or M10-20 (OSCE) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
7. CHECK WIRE HARNESS (ANTENNA - ECU) Disconnect the q1 oscillator connector. Disconnect the M10 ECU connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition q1-3 (TRG+) - M10-18 (TRG+) Below 1 ohms q1-3 (TRG+) or M10-18 (TRG+) - Body ground 10 kohmsor higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
8. CHECK OPERATION OF ELECTRICAL KEY ANTENNA FRONT LH After replacing the electrical key antenna front LH with a normal one, check that the entry lock and unlock functions operate normally. OK Entry lock and unlock functions operate normally. OK --> END (ELECTRICAL KEY ANTENNA FRONT LH IS DEFECTIVE) NG: Go to next step
9. CHECK OPERATION OF DOOR ELECTRICAL KEY OSCILLATOR FRONT LH After replacing the door electrical key oscillator front LH with a normal one, check that the entry lock and unlock functions operate normally. OK Entry lock and unlock functions operate normally. NG --> REPLACE CERTIFICATION ECU OK --> END (DOOR ELECTRICAL KEY OSCILLATOR FRONT LH IS DEFECTIVE)

Both the entry lock and unlock functions do not operate when: 1) nothing is output from the door electrical key oscillator front RH, 2) the smart access system with push-button start is disabled through customization, or 3) the entire power door lock control system is malfunctioning.

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

1. CHECK MANUAL DOOR LOCK AND UNLOCK OPERATION Check that the manual door lock and unlock function operates normally. OK Manual door lock and unlock function operates normally. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM OK: Go to next step
2. READ VALUE USING TECHSTREAM (DOOR LOCK POSITION SWITCH) Check the DATA LIST for proper functioning of the door lock position switch. MULTIPLEX NETWORK DOOR ECU FRONT RH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Door Unlock Detection Switch Door unlock detection switch / ON or OFF ON: Door is unlocked OFF: Door is locked - OK On the Techstream screen, the display changes between ON and OFF as shown in the chart above. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM (Proceed to Only Passenger Door LOCK / UNLOCK Functions do not Operate) OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (DOOR ELECTRICAL KEY OSCILLATOR FRONT RH) Select the ACTIVE TEST, use the Techstream to generate a control command, and then check that the oscillator operates. CERTIFICATION ECU: Tester Display Test Part Control Range Diagnostic Note P-Seat Outside Transmitter Front passenger side oscillator ON / OFF - OK When key is brought close to door oscillator that is OFF, indicator light on key illuminates. OK --> REPLACE CERTIFICATION ECU NG: Go to next step
4. CHECK WIRE HARNESS (ECU - OSCILLATOR) Disconnect the U28 ECU connector. Disconnect the p2 oscillator connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition U28-35 (CLG2) - p2-10 (CLG) Below 1 ohms U28-36 (CG2B) - p2-5 (CLGB) Below 1 ohms U28-35 (CLG2) or p2-10 (CLG) - Body ground 10 kohms or higher U28-36 (CG2B) or p2-5 (CLGB) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. CHECK WIRE HARNESS (OSCILLATOR - ANTENNA) Disconnect the p2 oscillator connector. Disconnect the p1 antenna connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition p2-2 (SGT) - p1-6 (SGT2) Below 1 ohms p2-3 (ANT1) - p1-5 (ANT1) Below 1 ohms p2-8 (ANT2) - p1-2 (ANT2) Below 1 ohms p2-9 (TRG-) - p1-1 (TRG-) Below 1 ohms p2-2 (SGT) or p1-6 (SGT2) - Body ground 10 kohms or higher p2-3 (ANT1) or p1-5 (ANT1) - Body ground 10 kohms or higher p2-8 (ANT2) or p1-2 (ANT2) - Body ground 10 kohms or higher p2-9 (TRG-) or p1-1 (TRG-) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
6. CHECK WIRE HARNESS (OSCILLATOR - ECU) Disconnect the p2 oscillator connector. Disconnect the M3 ECU connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition p2-1 (+B) - M3-7 (OSCB) Below 1 ohms p2-7 (GND) - M3-20 (OSCE) Below 1 ohms p2-1 (+B) or M3-7 (OSCB) - Body ground 10 kohms or higher p2-7 (GND) or M3-20 (OSCE) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
7. CHECK WIRE HARNESS (ANTENNA - ECU) Disconnect the p1 antenna connector. Disconnect the M3 ECU connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition p1-3 (TRG+) - M3-18 (TRG+) Below 1 ohms p1-3 (TRG+) or M3-18 (TRG+) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
8. CHECK OPERATION OF ELECTRICAL KEY ANTENNA FRONT RH After replacing the electrical key antenna front RH with a normal one, check that the entry lock and unlock functions operate normally. OK Entry lock and unlock functions operate normally. OK --> END (ELECTRICAL KEY ANTENNA FRONT RH IS DEFECTIVE) NG: Go to next step
9. CHECK OPERATION OF DOOR ELECTRICAL KEY OSCILLATOR FRONT RH After replacing the door electrical key oscillator front RH with a normal one, check that the entry lock and unlock functions operate normally. OK Entry lock and unlock functions operate normally. NG --> REPLACE CERTIFICATION ECU OK --> END (DOOR ELECTRICAL KEY OSCILLATOR FRONT RH IS DEFECTIVE)

Both the entry lock and unlock functions do not operate when: 1) nothing is output from the door electrical key oscillator rear LH, 2) the smart access system with push-button start is disabled through customization, or 3) the entire power door lock control system is malfunctioning.

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

1. CHECK MANUAL DOOR LOCK AND UNLOCK OPERATION Check that the manual door lock and unlock function operates normally. OK Manual door lock and unlock function operates normally. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM OK: Go to next step
2. READ VALUE USING TECHSTREAM (DOOR LOCK POSITION SWITCH) Check the DATA LIST for proper functioning of the door lock position switch. MULTIPLEX NETWORK DOOR ECU REAR LH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Door Unlock Detection Switch Door unlock detection switch / ON or OFF ON: Door is unlocked OFF: Door is locked - OK On the Techstream screen, the display changes between ON and OFF as shown in the chart above. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM (Proceed to Only Rear Door LH LOCK / UNLOCK Functions do not Operate) OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (DOOR ELECTRICAL KEY OSCILLATOR REAR LH) Select the ACTIVE TEST, use the Techstream to generate a control command, and then check that the oscillator operates. CERTIFICATION ECU: Tester Display Test Part Control Range Diagnostic Note Dr-Seat Outside Transmitter Rear LH side oscillator ON / OFF - OK When key is brought close to door oscillator that is OFF, indicator light on key illuminates. OK --> REPLACE CERTIFICATION ECU NG: Go to next step
4. CHECK WIRE HARNESS (ECU - OSCILLATOR) Disconnect the U33 ECU connector. Disconnect the s2 oscillator connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition U33-8 (CLG3) - s2-10 (CLG) Below 1 ohms U33-9 (CG3B) - s2-5 (CLGB) Below 1 ohms U33-8 (CLG3) or s2-10 (CLG) - Body ground 10 kohms or higher U33-9 (CG3B) or s2-5 (CLGB) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. CHECK WIRE HARNESS (OSCILLATOR - ANTENNA) Disconnect the s2 oscillator connector. Disconnect the s1 antenna connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition s2-2 (SGT) - s1-6 (SGT2) Below 1 ohms s2-3 (ANT1) - s1-5 (ANT1) Below 1 ohms s2-8 (ANT2) - s1-2 (ANT2) Below 1 ohms s2-9 (TRG-) - s1-1 (TRG-) Below 1 ohms s2-2 (SGT) or s1-6 (SGT2) - Body ground 10 kohms or higher s2-3 (ANT1) or s1-5 (ANT1) - Body ground 10 kohms or higher s2-8 (ANT2) or s1-2 (ANT2) - Body ground 10 kohms or higher s2-9 (TRG-) or s1-1 (TRG-) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
6. CHECK WIRE HARNESS (OSCILLATOR - ECU) Disconnect the s2 oscillator connector. Disconnect the O8 ECU connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition s2-1 (+B) - O8-7 (OSCB) Below 1 ohms s2-7 (GND) - O8-20 (OSCE) Below 1 ohms s2-1 (+B) or O8-7 (OSCB) - Body ground 10 kohms or higher s2-7 (GND) or O8-20 (OSCE) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
7. CHECK WIRE HARNESS (ANTENNA - ECU) Disconnect the s1 antenna connector. Disconnect the O8 ECU connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition s1-3 (TRG+) - O8-18 (TRG+) Below 1 ohms s1-3 (TRG+) or O8-18 (TRG+) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
8. CHECK OPERATION OF ELECTRICAL KEY ANTENNA REAR LH After replacing the electrical key antenna rear LH with a normal one, check that the entry lock and unlock functions operate normally. OK Entry lock and unlock functions operate normally. OK --> END (ELECTRICAL KEY ANTENNA REAR LH IS DEFECTIVE) NG: Go to next step
9. CHECK OPERATION OF DOOR ELECTRICAL KEY OSCILLATOR REAR LH After replacing the door electrical key oscillator rear LH with a normal one, check that the entry lock and unlock functions operate normally. OK Entry lock and unlock functions operate normally. NG --> REPLACE CERTIFICATION ECU OK --> END (DOOR ELECTRICAL KEY OSCILLATOR REAR LH IS DEFECTIVE)

Both the entry lock and unlock functions do not operate when: 1) nothing is output from the door electrical key oscillator rear RH, 2) the smart access system with push-button start is disabled through customization, or 3) the entire power door lock control system is malfunctioning.

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

1. CHECK MANUAL DOOR LOCK AND UNLOCK OPERATION Check that the manual door lock and unlock function operates normally. OK Manual door lock and unlock function operates normally. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM OK: Go to next step
2. READ VALUE USING TECHSTREAM (DOOR LOCK POSITION SWITCH) Check the DATA LIST for proper functioning of the door lock position switch. MULTIPLEX NETWORK DOOR ECU REAR RH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Door Unlock Detection Switch Door unlock detection switch / ON or OFF ON: Door is unlocked OFF: Door is locked - OK On the Techstream screen, the display changes between ON and OFF as shown in the chart above. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM (Proceed to Only Rear Door RH LOCK / UNLOCK Functions do not Operate) OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (DOOR ELECTRICAL KEY OSCILLATOR REAR RH) Select the ACTIVE TEST, use the Techstream to generate a control command, and then check that the oscillator operates. CERTIFICATION ECU: Tester Display Test Part Control Range Diagnostic Note Pr-Seat Outside Transmitter Rear RH side oscillator ON / OFF - OK When key is brought close to door oscillator that is OFF, indicator light on key illuminates. OK --> REPLACE CERTIFICATION ECU NG: Go to next step
4. CHECK WIRE HARNESS (ECU - OSCILLATOR) Disconnect the U33 ECU connector. Disconnect the r2 oscillator connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition U33-10 (CLG4) - r2-10 (CLG) Below 1 ohms U33-11 (CG4B) - r2-5 (CLGB) Below 1 ohms U33-10 (CLG4) or r2-10 (CLG) - Body ground 10 kohms or higher U33-11 (CG4B) or r2-5 (CLGB) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. CHECK WIRE HARNESS (OSCILLATOR - ANTENNA) Disconnect the r2 oscillator connector. Disconnect the r1 antenna connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition r2-2 (SGT) - r1-6 (SGT2) Below 1 ohms r2-3 (ANT1) - r1-5 (ANT1) Below 1 ohms r2-8 (ANT2) - r1-2 (ANT2) Below 1 ohms r2-9 (TRG-) - r1-1 (TRG-) Below 1 ohms r2-2 (SGT) or r1-6 (SGT2) - Body ground 10 kohms or higher r2-3 (ANT1) or r1-5 (ANT1) - Body ground 10 kohms or higher r2-8 (ANT2) or r1-2 (ANT2) - Body ground 10 kohms or higher r2-9 (TRG-) or r1-1 (TRG-) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
6. CHECK WIRE HARNESS (OSCILLATOR - ECU) Disconnect the r2 oscillator connector. Disconnect the O2 ECU connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition r2-1 (+B) - O2-7 (OSCB) Below 1 ohms r2-7 (GND) - O2-20 (OSCE) Below 1 ohms r2-1 (+B) or O2-7 (OSCB) - Body ground 10 kohms or higher r2-7 (GND) or O2-20 (OSCE) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
7. CHECK WIRE HARNESS (ANTENNA - ECU) Disconnect the r1 antenna connector. Disconnect the O2 ECU connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition r1-3 (TRG+) - O2-18 (TRG+) Below 1 ohms r1-3 (TRG+) or O2-18 (TRG+) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
8. CHECK OPERATION OF ELECTRICAL KEY ANTENNA REAR RH After replacing the electrical key antenna rear RH with a normal one, check that the entry lock and unlock functions operate normally. OK Entry lock and unlock functions operate normally. OK --> END (ELECTRICAL KEY ANTENNA REAR RH IS DEFECTIVE) NG: Go to next step
9. CHECK OPERATION OF DOOR ELECTRICAL KEY OSCILLATOR REAR RH After replacing the door electrical key oscillator rear RH with a normal one, check that the entry lock and unlock functions operate normally. OK Entry lock and unlock functions operate normally. NG --> REPLACE CERTIFICATION ECU OK --> END (DOOR ELECTRICAL KEY OSCILLATOR REAR RH IS DEFECTIVE)

When the touch sensor inside the outside door handle front LH is touched, the certification ECU sends a request signal to the door electrical key oscillator front LH. The key receives this request and transmits its ID code. Upon receiving the ID code, the certification ECU determines that the key is outside the vehicle and sends a lock signal to the driver side door lock through the main body ECU RH.

When the touch sensor inside the outside door handle front RH is touched, the certification ECU sends a request signal to the door electrical key oscillator front RH. The key receives this request and transmits its ID code. Upon receiving the ID code, the certification ECU determines that the key is outside the vehicle and sends a lock signal to the front passenger side door lock through the main body ECU RH.

When the touch sensor inside the outside door handle rear LH is touched, the certification ECU sends a request signal to the door electrical key oscillator rear LH. The key receives this request and transmits its ID code. Upon receiving the ID code, the certification ECU determines that the key is outside the vehicle and sends a lock signal to the rear door LH lock through the main body ECU RH.

When the touch sensor inside the outside door handle rear RH is touched, the certification ECU sends a request signal to the door electrical key oscillator rear RH. The key receives this request and transmits its ID code. Upon receiving the ID code, the certification ECU determines that the key is outside the vehicle and sends a lock signal to the rear door RH lock through the main body ECU RH.

If the entry ignition function does not operate, place the key in the vehicle and check if the hybrid vehicle control system starts. If the hybrid vehicle control system starts (the ID code box outputs a start permission to the hybrid vehicle control system and the hybrid vehicle control system starts), it can be assumed that only the entry ignition system is malfunctioning.

The certification ECU uses the indoor electrical key antenna to send a request signal to the key when: 1) the driver's door is opened and closed, or 2) the power switch is turned from ON (ACC) to OFF or OFF to ON (IG). Then, the key transmits its ID code to the entry door control receiver. The ID code, which is then sent to the certification ECU, is verified by the certification ECU and the verification result is sent to the ID code box. Turning the power switch from ON (ACC) to OFF stops the hybrid vehicle control system.

The ID code box and the certification ECU communicate encryption codes to each other using the multiplex communication line. When the return code from the certification ECU matches the ID code in memory, the ID code box sends an hybrid vehicle control system start permission signal to the ECM. With the brake pedal depressed, pressing the power switch starts the hybrid vehicle control system. With the hybrid vehicle control system running, pressing the power switch stops the hybrid vehicle control system.

Scheme 79

Scheme 80

1. CHECK WIRELESS DOOR LOCK AND UNLOCK OPERATION Check that the wireless door lock and unlock functions operate normally. OK Wireless door lock functions operate normally. NG --> GO TO WIRELESS DOOR LOCK CONTROL FUNCTION OK: Go to next step
2. CHECK OPERATION OF KEY After replacing the key with a normally functioning one, check that the wireless lock and unlock functions operate normally. OK Wireless lock and unlock functions operate normally. OK --> END (KEY IS DEFECTIVE) NG: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (INDOOR ELECTRICAL KEY ANTENNA) Select the ACTIVE TEST, use the Techstream to generate a control command, and then check that the antenna operates. CERTIFICATION ECU: Tester Display Test Part Control Range Diagnostic Note Fr-Seat Outside Transmitter Indoor electrical key antenna (for front) ON / OFF - Rr-Seat Outside Transmitter Indoor electrical key antenna (for rear) ON / OFF - Inside Trunk/Back Door Transmitter Indoor electrical key antenna (for luggage) ON / OFF - OK When key is brought close to indoor electrical key antenna, antenna is turned OFF and indicator on key illuminates. OK --> REPLACE CERTIFICATION ECU NG: Go to next step
4. CHECK WIRE HARNESS (INDOOR ELECTRICAL KEY ANTENNA - CERTIFICATION ECU ASSEMBLY) Disconnect the U35, V32 and V33 antenna connectors. Disconnect the U28 ECU connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition U35-1 (CLG3) - U28-11 (CLG5)*1 Below 1 ohms U35-1 (CLG3) or U28-11 (CLG5)*1 - Body ground 10 kohms or higher V32-1 (CLG4) - U28-13 (CLG6)*2 Below 1 ohms V32-1 (CLG4) or U28-13 (CLG6)*2 - Body ground 10 kohms or higher V33-1 (CLG6) - U28-15 (CLG7)*3 Below 1 ohms V33-1 (CLG6) or U28-15 (CLG7)*3 - Body ground 10 kohms or higher U35-3 (CLGB) - U28-12 (CG5B)*1 Below 1 ohms U35-3 (CLGB) or U28-12 (CG5B)*1 - Body ground 10 kohms or higher V32-3 (CLGB) - U28-14 (CG6B)*2 Below 1 ohms V32-3 (CLGB) or U28-14 (CG6B)*2 - Body ground 10 kohms or higher V33-3 (CLGB) - U28-16 (CG7B)*3 Below 1 ohms V33-3 (CLGB) or U28-16 (CG7B)*3 - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. CHECK INDOOR ELECTRICAL KEY ANTENNA Carry the key into the vehicle. Replace the indoor electrical key antenna with a new one. Depress the brake pedal and check that the power switch indicator illuminates in green. OK Power switch indicator illuminates in green. OK --> END (INDOOR ELECTRICAL KEY ANTENNA IS DEFECTIVE) NG --> REPLACE CERTIFICATION ECU

When the power luggage door open switch is turned ON, the certification ECU uses the luggage electrical key antenna (for outer) and antenna to output a request signal to the outside of the vehicle for a distance of approximately 1.0 m (3.3 ft.) from the luggage compartment door. A key near the luggage compartment door detects this request and transmits its ID code. The entry door control receiver receives the ID code and sends this ID code to the certification ECU. The certification ECU checks if the ID code is valid. When the ID code is valid, the certification ECU sends a luggage compartment door open signal to the main body ECU LH using the multiplex communication line and stops outputting request signals. The luggage room junction block then unlocks the luggage compartment door.

Scheme 81

Scheme 82

Scheme 83

1. CHECK LUGGAGE DOOR OPENING SWITCH ASSEMBLY Turn the luggage door opening switch OFF and check that the entry luggage compartment door opener function operates normally. OK Entry luggage compartment door opener function operates normally. OK --> END NG: Go to next step
2. CHECK MANUAL LUGGAGE COMPARTMENT DOOR OPENER OPERATION Check that the manual luggage compartment door opener function operates normally. OK Manual luggage compartment door opener function operates normally. NG --> GO TO LUGGAGE COMPARTMENT DOOR OPENER SYSTEM OK: Go to next step
3. CHECK WIRELESS LUGGAGE COMPARTMENT DOOR OPENER OPERATION Check that the wireless luggage compartment door opener function operates normally. OK Wireless luggage compartment door opener function operates normally NG --> GO TO WIRELESS DOOR LOCK CONTROL FUNCTION OK: Go to next step
4. CHECK OPERATION OF KEY After replacing the key with a normally functioning one, check that the wireless luggage compartment door opener function operates normally. OK Wireless luggage compartment door opener function operates normally. OK --> END (KEY IS DEFECTIVE) NG: Go to next step
5. PERFORM ACTIVE TEST USING TECHSTREAM (LUGGAGE ELECTRICAL KEY ANTENNA [for Outer]) Select the ACTIVE TEST, use the Techstream to generate a control command, and then check that the antenna (for outer) operates. CERTIFICATION ECU: Tester Display Test Part Control Range Diagnostic Note Outside Trunk/Back Door Transmitter Luggage compartment door outer antenna ON / OFF - OK When key is brought close to luggage compartment door, antenna (for outer) is turned OFF and indicator on key illuminates. NG --> See step 8 OK: Go to next step
6. READ VALUE USING TECHSTREAM (LUGGAGE COMPARTMENT DOOR LOCK SWITCH) Check the DATA LIST for proper functioning of the door lock switch. CERTIFICATION ECU: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Luggage Door Lock/Unlock Switch Luggage compartment door lock / unlock switch / ON or OFF ON: Luggage compartment door lock switch is pushed OFF: Luggage compartment door lock switch is not pushed - OK ON (luggage compartment door lock is pushed) appears on the screen. NG --> REPLACE LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY OK: Go to next step
7. CHECK OPERATION OF CERTIFICATION ECU After replacing the certification ECU with a normal one, check that the entry luggage compartment door lock functions operates normally. OK Entry luggage compartment door lock function operates normally. NG --> REPLACE MAIN BODY ECU LH OK --> END (CERTIFICATION ECU IS DEFECTIVE)
8. CHECK WIRE HARNESS (ECU - ANTENNA) Disconnect the U28 ECU connector. Disconnect the U32 antenna connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition U28-31 (CLG8) - U32-1 (CLG5) Below 1 ohms U28-32 (CG8B) - U32-2 (CLGB) Below 1 ohms U28-31 (CLG8) or U32-1 (CLG5) - Body ground 10 kohms or higher U28-32 (CG8B) or U32-2 (CLGB) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
9. CHECK LUGGAGE ELECTRICAL KEY ANTENNA (for Outer) After replacing the luggage electrical key antenna (for outer) with a normal one, check that the luggage entry unlock functions operates normally. OK Luggage entry unlock function operates normally. OK --> END (LUGGAGE ELECTRICAL KEY ANTENNA IS DEFECTIVE [for Outer]) NG --> REPLACE CERTIFICATION ECU

If the key is locked into the luggage compartment, the closing of the luggage door will cause the multiplex network rear ECU to send a luggage courtesy switch OFF signal to the certification ECU via the BEAN. The certification ECU then sends a request signal through the indoor electrical key antenna (for luggage). The key receives the request signal, and then sends its ID code to the door control receiver. The door control receiver then sends the ID code to the certification ECU, which confirms the ID code. If the ID code is verified, the following occurs: 1) the vehicle exterior warning (wireless door buzzer) sounds for 10 seconds; 2) a trunk open signal is sent to the luggage room junction block ECU via the BEAN; 3) the request signal is stopped; and 4) the multiplex network rear ECU unlocks the luggage door lock.

HINT

*: The key luggage compartment lock-in prevention function does not operate for 100% of the luggage compartment . Refer to ON-VEHICLE INSPECTION .

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

1. CHECK LUGGAGE DOOR OPENING MAIN SWITCH Turn the luggage door opening switch OFF and check that the entry luggage compartment door opener function operates normally. OK Entry luggage compartment door opener function operates normally. OK --> END NG: Go to next step
2. CHECK MANUAL LUGGAGE COMPARTMENT DOOR OPENER OPERATION Check that the manual luggage compartment door operates function operates normally. OK Manual luggage compartment door opener function operates normally. NG --> GO TO LUGGAGE COMPARTMENT DOOR OPENER SYSTEM OK: Go to next step
3. READ VALUE USING TECHSTREAM (DOOR COURTESY SWITCH) Check the DATA LIST for proper functioning of each door courtesy switch. MAIN BODY ECU RH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door Courtesy SW Driver side door courtesy switch / ON or OFF ON: Courtesy switch is pushed OFF: Courtesy switch is not pushed - P Door Courtesy SW Front passenger side door courtesy switch / ON or OFF ON: Courtesy switch is pushed OFF: Courtesy switch is not pushed - Rr Door Courtesy SW Rear door courtesy switch / ON or OFF ON: Courtesy switch is pushed OFF: Courtesy switch is not pushed - MULTIPLEX NETWORK REAR ECU: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Luggage Courtesy Switch Luggage compartment door switch / ON or OFF ON: Courtesy switch is pushed OFF: Courtesy switch is not pushed - OK ON (door courtesy switch is pushed) appears on the screen. NG --> GO TO LIGHTING SYSTEM OK: Go to next step
4. READ VALUE USING TECHSTREAM (LOCK POSITION SWITCH) Check the DATA LIST for proper functioning of the door lock position switch. MULTIPLEX NETWORK MASTER SWITCH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Door Unlock Detection Switch Door unlock detection switch signal / ON or OFF ON: Door is unlocked OFF: Door is locked - MULTIPLEX NETWORK DOOR ECU FRONT RH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Door Unlock Detection Switch Door unlock detection switch signal / ON or OFF ON: Door is unlocked OFF: Door is locked - MULTIPLEX NETWORK DOOR ECU REAR LH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Door Unlock Detection Switch Door unlock detection switch signal / ON or OFF ON: Door is unlocked OFF: Door is locked - MULTIPLEX NETWORK DOOR ECU REAR RH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Door Unlock Detection Switch Door unlock detection switch signal / ON or OFF ON: Door is unlocked OFF: Door is locked - OK ON (Door is unlocked) appears on the screen. NG --> GO TO POWER DOOR LOCK CONTROL SYSTEM OK: Go to next step
5. PERFORM ACTIVE TEST USING TECHSTREAM (LUGGAGE ELECTRICAL KEY ANTENNA [for Inner]) Select the ACTIVE TEST, use the Techstream to generate a control command, and then check that the antenna (for inner) operates. CERTIFICATION ECU: Tester Display Test Part Control Range Diagnostic Note Inside Trunk/Back Door Transmitter Luggage compartment door inner antenna ON / OFF - OK When key is brought close to luggage compartment door antenna (for inner) is turned OFF and indicator on key illuminates. NG --> See step 11 OK: Go to next step
6. CHECK WIRE HARNESS (DOOR CONTROL RECEIVER - BATTERY AND BODY GROUND) Disconnect the U36 receiver connector. Measure the voltage and resistance of the wire harness side connector. Standard voltage Standard resistance Tester Connection Specified Condition U36-2 (+5) - Body ground 5 V Tester Connection Specified Condition U36-6 (GND) - Body ground Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
7. CHECK WIRE HARNESS (DOOR CONTROL RECEIVER - CERTIFICATION ECU) Disconnect the U36 receiver connector. Disconnect the U28 ECU connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition U36-3 (DATA) - U28-38 (RDA) Below 1 ohms U36-5 (RSSI) - U28-39 (RSSI) Below 1 ohms U36-4 (ASEL) - U28-37 (ASEL) Below 1 ohms U36-3 (DATA) or U28-38 (RDA) - Body ground 10 kohms or higher U36-5 (RSSI) or U28-39 (RSSI) - Body ground 10 kohms or higher U36-4 (ASEL) or U28-37 (ASEL) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
8. CHECK DOOR CONTROL RECEIVER Measure the frequency of the receiver connector. Standard frequency Tester Connection Condition Specified Condition 7 (ANT) - 6 (GND) Key is placed near center of luggage compartment and luggage compartment door is closed Above 0 Hz NG --> REPLACE DOOR CONTROL RECEIVER OK: Go to next step
9. CHECK LUGGAGE ELECTRICAL KEY ANTENNA (for Inner) Disconnect the V33 connector. Measure the voltage and resistance of the wire harness side connectors. Standard voltage Tester Connection Specified Condition V33-3 (CLGB) - Body ground 10 to 14 V Standard resistance Tester Connection Specified Condition V33-1 (CLG6) - Body ground Below 1 ohms NG --> See step 12 OK: Go to next step
10. READ VALUE USING TECHSTREAM (POWER LUGGAGE DOOR OPEN SWITCH) Check the DATA LIST for proper functioning of the power luggage door open switch. COWL SIDE JUNCTION BLOCK ECU LH: Tester Display Measurement Item/Range Normal Condition Diagnostic Note Luggage Push Switch Power luggage door open switch / ON or OFF ON: Power luggage door open switch is pushed OFF: Power luggage door open switch is not pushed - OK ON (power luggage door open switch is pushed) appears on the screen. NG --> REPLACE LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY OK: Go to next step
11. CHECK OPERATION OF CERTIFICATION ECU After replacing the certification ECU with a normal one, check that the key luggage lock-in prevention function operates normally. OK Key luggage lock-in prevention function operates normally. NG --> REPLACE MAIN BODY ECU LH OK --> END (CERTIFICATION ECU IS DEFECTIVE)
12. CHECK WIRE HARNESS (ANTENNA - ECU) Disconnect the V33 antenna connector. Disconnect the U28 ECU connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition V33-1 (CLG6) - U28-15 (CLG7) Below 1 ohms V33-1 (CLG6) or U28-15 (CLG7) - Body ground 10 kohms or higher V33-3 (CLGB) - U28-16 (CG7B) Below 1 ohms V33-3 (CLGB) or U28-16 (CG7B) - Body ground 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
13. CHECK OPERATION OF LUGGAGE ELECTRICAL KEY ANTENNA (for Inner) After replacing the luggage electrical key antenna (for inner) with a normal one, check that the key luggage lock-in prevention function operates normally. OK Key luggage lock-in prevention function operates normally. NG --> REPLACE CERTIFICATION ECU OK --> END (LUGGAGE ELECTRICAL KEY ANTENNA IS DEFECTIVE [for INNER])

Each of the smart access system with push-button start's warnings uses the key reminder warning buzzer to alert the driver.

The combination meter repeatedly sounds the key reminder warning buzzer when one of the following occurs: 1) the activation conditions for the smart access system with push-button start warning is met, or 2) the certification ECU sends a key reminder warning buzzer signal via the BEAN line to the combination meter.

Scheme 90

When the entry functions do not operate at all, it is possible that the certification ECU is malfunctioning or that the wire harness leading to the certification ECU is short-circuited.

Scheme 91

Scheme 92

1. CHECK KEY CANCEL FUNCTION Check that the key cancel function is set. OK Key cancel function is set. OK --> END (UNSET KEY CANCEL FUNCTION) NG: Go to next step
2. INSPECT FUSE (SECURITY, ECU-IG RH) Remove the SECURITY and ECU-IG RH fuses from the main body ECU RH. Measure the resistance of the fuse. Standard resistance Below 1 ohms NG --> REPLACE FUSE OK: Go to next step
3. CHECK WIRE HARNESS (CERTIFICATION ECU - BATTERY AND BODY GROUND) Disconnect the U28 ECU connector. Measure the voltage and resistance of the wire harness side connector. Standard voltage Standard resistance Tester Connection Condition Specified Condition U28-18 (IG) - Body ground Power switch OFF Below 1 V U28-18 (IG) - Body ground Power switch ON (IG) 10 to 14 V U28-1 (+B1) - Body ground Always 10 to 14 V Tester Connection Specified Condition U28-17 (E) - Body ground Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE CERTIFICATION ECU
