Engine Control System (Diagnostic Codes (P0010-P0339)): Other Lexus ES XV40 facelift

Testing & Diagnostics 33 illustrations ~11913 words

MONITOR STRATEGY

Related DTCsP0010: VVT OCV (bank 1) range check P0020: VVT OCV (bank 2) range check
Required sensors/components (Main)VVT OCV (Variable Valve Timing oil control valve)
Required sensors/components (Related)
Frequency of operationContinuous
Duration1 second
MIL operationImmediately
Sequence of operationNone

TYPICAL ENABLING CONDITIONS

Monitor runs whenever following DTCs are not presentNone
All of the following conditions are met
StarterOFF
Engine switchOn (IG)
Time after turning engine switch off to on (IG)0.5 seconds or more

TYPICAL MALFUNCTION THRESHOLDS

One of the following conditions is metCondition A, B or C
A. All of the following conditions are met
Battery voltage11 V or more, and less than 13 V
Target duty ratioLess than 70%
Output signal duty ratio100% or more
B. All of the following conditions are met
Battery voltage13 V or more
Target duty ratioLess than 80%
Output signal duty ratio100% or more
C. All of the following conditions are met
Current cut statusNot cut
Output signal duty ratio3% or less

COMPONENT OPERATING RANGE

Output signal duty ratioMore than 3%, and Less than 100%

Scheme 267

Scheme 267: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on.
  6. Wait 5 seconds [A].
  7. Enter the following menus: Powertrain / Engine / Trouble Codes.
  8. Read the DTC [B].
  9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  11. Input the DTC: P0010 or P0020.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
  13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 268

Scheme 268: WIRING DIAGRAM
Related DTCsP0011: Advanced camshaft timing (bank 1) P0012: Retard camshaft timing (bank 1) P0021: Advanced camshaft timing (bank 2) P0022: Retard camshaft timing (bank 2)
Required sensors/components (Main)VVT OCV and VVT Actuator
Required sensors/components (Related)Crankshaft position sensor, VVT sensor and Engine coolant temperature sensor
Frequency of operationOnce per drive cycle
DurationWithin 10 seconds
MIL operationAdvanced camshaft timing (bank 1): Immediately Advanced camshaft timing (bank 2): Immediately Retard camshaft timing (bank 1): 2 driving cycles Retard camshaft timing (bank 2): 2 driving cycles
Sequence of operationNone
Monitor runs whenever following DTCs are not presentP0010, P0020 (OCV bank 1, 2) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor)
Battery voltage11 V or more
Engine500 to 4,000 rpm
ECT75 to 100°C (167 to 212°F)
All of the following conditions are met
Deviation of actual valve timing and target valve timingMore than 5°CA
Valve timingNo change at advanced valve timing

ADVANCED CAMSHAFT TIMING

All of the following conditions are met
Deviation of between actual valve timing and target valve timingMore than 5°CA
Valve timingNo change at retarded valve timing

RETARD CAMSHAFT TIMING

MONITOR RESULT

Refer to CHECKING MONITOR STATUS. Refer to CHECKING MONITOR STATUS .

Scheme 269

Scheme 269: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on [A].
  6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B].
  7. Drive the vehicle for 5 minutes or more [C].
  8. Idle the engine for 30 seconds or more [D].
  9. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
  10. Read the pending DTC [E].
  11. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  13. Input the DTC: P0011, P0012, P0021 or P0022.
  14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
  15. Drive the vehicle for 5 minutes or more [F].
  16. Idle the engine for 30 seconds or more [G].
  17. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  18. Input the DTC: P0011, P0012, P0021 or P0022.
  19. Check the DTC judgment result again [H]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  20. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. If the difference between the target and actual camshaft timings is greater than the specified value, the ECM operates the VVT actuator.
  2. Then, the ECM monitors the camshaft timing change for 5 seconds.
Related DTCsP0013: VVT OCV (bank 1) range check P0023: VVT OCV (bank 2) range check
Required sensors/components (Main)VVT OCV (Variable Valve Timing oil control valve)
Required sensors/components (Related)
Frequency of operationContinuous
Duration1 second
MIL operationImmediately
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
All of the following conditions are met
StarterOFF
Engine switchOn (IG)
Time after turning engine switch off to on (IG)0.5 seconds or more
One of the following conditions is metCondition A, B or C
A. All of the following conditions are met
Battery voltage11 V or more, and less than 13 V
Target duty ratioLess than 70%
Output signal duty ratio100% or more
B. All of the following conditions are met
Battery voltage13V or more
Target duty ratioLess than 80%
Output duty ratio100% or more
C. All of the following conditions are met
Current cut statusNot cut
Output signal duty ratio3% or less
Output signal duty ratioMore than 3%, and less than 100%

Scheme 270

Scheme 270: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on.
  6. Wait 5 seconds [A].
  7. Enter the following menus: Powertrain / Engine / Trouble Codes.
  8. Read the DTC [B].
  9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  11. Input the DTC: P0013 or P0023.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
  13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 271

Scheme 271: WIRING DIAGRAM

PROCEDURE

  1. PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE OCV) Connect the Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the Exhaust Linear (Bank 1) or Control the Exhaust Linear (Bank 2). Check the engine speed while operating the Oil Control Valve (OCV) using the Techstream. OK Techstream Operation Specified Condition 0% (OFF) Normal engine speed 127% (ON) Engine idles roughly or stalls (soon after OCV switched from OFF to ON) OK --> CHECK FOR INTERMITTENT PROBLEMS NG: Go to next step
  2. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Disconnect the B7 or B5 OCV connector. Measure the resistance between the terminals of the OCV. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Reconnect the OCV connector. OK --> See step 4 NG: Go to next step
  3. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «COMPONENTS»(ref-396635-S15366317692011050900000)
  4. CHECK HARNESS AND CONNECTOR (OCV - ECM) Disconnect the B7 or B5 OCV connector. Disconnect the B12 ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Tester Connection Specified Condition OE1+ (B12-16) - B7-1 Below 1 ohms OE1- (B12-17) - B7-2 Below 1 ohms OE2+ (B12-14) - B5-1 Below 1 ohms OE2- (B12-15) - B5-2 Below 1 ohms Standard resistance (Check for short) Tester Connection Specified Condition OE1+ (B12-16) or B7-1 - Body ground 10 kohms or higher OE1- (B12-17) or B7-2 - Body ground 10 kohms or higher OE2+ (B12-14) or B5-1 - Body ground 10 kohms or higher OE2- (B12-15) or B5-2 - Body ground 10 kohms or higher Reconnect the ECM connector. Reconnect the OCV connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  5. REPLACE ECM. Refer to «REMOVAL»(ref-396635-S35871318042011050900000)
Related DTCsP0014: Advanced camshaft timing (bank 1) P0015: Retarded camshaft timing (bank 1) P0024: Advanced camshaft timing (bank 2) P0025: Retarded camshaft timing (bank 2)
Required sensors/components (Main)VVT OCV and VVT Actuator
Required sensors/components (Related)Crankshaft position sensor, VVT sensor and Engine coolant temperature sensor
Frequency of operationOnce per driving cycle
DurationWithin 10 seconds
MIL operationAdvanced camshaft timing (bank 1): 2 driving cycles Advanced camshaft timing (bank 2): 2 driving cycles Retarded camshaft timing (bank 1): Immediately Retarded camshaft timing (bank 2): Immediately
Sequence of operationNone
Monitor runs whenever following DTCs are not presentP0013, P0023 (Exhaust OCV bank 1, 2) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor)
Battery voltage11 V or more
Engine RPM500 to 4000 rpm
Engine coolant temperature75 to 100°C (167 to 212°F)
Valve timingNo change
Valve timingAdvanced position

ADVANCED CAMSHAFT TIMING

Valve timingNo change
Valve timingRetard position

RETARDED CAMSHAFT TIMING

Refer to CHECKING MONITOR STATUS. Refer to CHECKING MONITOR STATUS .

Scheme 272

Scheme 272: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on [A].
  6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B].
  7. Drive the vehicle for 5 minutes or more [C].
  8. Idle the engine for 30 seconds or more [D].
  9. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
  10. Read the pending DTC [E].
  11. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  13. Input the DTC: P0014, P0015, P0024 or P0025.
  14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
  15. Drive the vehicle for 5 minutes or more [F].
  16. Idle the engine for 30 seconds or more [G].
  17. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  18. Input the DTC: P0014, P0015, P0024 or P0025.
  19. Check the DTC judgment result again [H]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  20. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0014, P0015, P0024 OR P0025) Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Code. Read the DTCs. Result Display (DTC output) Proceed to P0014, P0015, P0024 and/or P0025 A P0014, P0015, P0024 and/or P0025 and other DTCs B HINT: If any DTCs other than P0014, P0015, P0024 or P0025 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
  2. PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE OCV) Connect the Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the Exhaust Linear (Bank 1) or Control the Exhaust Linear (Bank 2). Check the engine speed while operating the Oil Control Valve (OCV) using the Techstream. OK Techstream Operation Specified Condition 0% (OFF) Normal engine speed 127% (ON) Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 5 OK: Go to next step
  3. CHECK WHETHER DTC OUTPUT RECURS (DTC P0014, P0015, P0024 OR P0025) Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. NG --> See step 5 OK: CHECK FOR INTERMITTENT PROBLEMS
  4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-396630-S19862863392011050900000)
  5. CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMPED TEETH ON TIMING CHAIN) Remove the cylinder head covers RH and LH. Turn the crankshaft pulley, and align its groove with the timing mark "0" of the timing chain cover. Check that the timing marks of the camshaft timing gears are aligned with the timing marks of the bearing cap as shown in the illustration. If not, turn the crankshaft 1 revolution (360°), then align the marks as above. OK The timing marks on the crankshaft timing gears are aligned as shown in the illustration. Reinstall the cylinder head covers. NG --> ADJUST VALVE TIMING OK: Go to next step
  6. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (OCV FOR EXHAUST CAMSHAFT) Remove the OCV. Measure the resistance between the terminals of the OCV. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Connect the positive battery terminal to terminal 1 and connect the negative battery terminal to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the OCV. NG --> See step 10 OK: Go to next step
  7. INSPECT OIL CONTROL VALVE FILTER AND PIPE Remove the oil pipe No. 1 or No. 2. Remove the oil control valve filter. Check that the filter and pipe are not clogged. OK Filter is not clogged. NG --> REPLACE OIL CONTROL VALVE FILTER OR PIPE OK: Go to next step
  8. REPLACE EXHAUST CAMSHAFT TIMING GEAR ASSEMBLY NEXT: Go to next step
  9. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Clear the DTCs. Start the engine and warm up the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. HINT: DTC P0014, P0015, P0024 or P0025 may be stored when foreign objects in the engine oil are caught in some parts of the system. The DTC will remain stored even system returns to normal after a short time. Foreign objects are filtered out by the oil filter. NG --> See step 11 OK: END
  10. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT). Refer to «COMPONENTS»(ref-396635-S15366317692011050900000)
  11. REPLACE ECM. Refer to «REMOVAL»(ref-396635-S35871318042011050900000)
Related DTCsP0016: Crankshaft position - Camshaft position misaligned at idling (bank 1) P0018: Crankshaft position - Camshaft position misaligned at idling (bank 2)
Required Sensors / Components (Main)VVT actuator
Required Sensors / Components (Related)VVT sensor, Crankshaft position sensor
Frequency of OperationOnce per driving cycle
DurationLess than 60 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentP0010, P0020 (OCV bank 1, 2) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor)

ALL

Engine RPM500 to 1000 rpm
One of the following conditions is met
VVT learning value at maximum retarded valve timing (Bank 1)Less than 18.5°CA (Crankshaft Angle)
VVT learning value at maximum retarded valve timing (Bank 2)Less than 18.5°CA (Crankshaft Angle)
VVT learning value at maximum retarded valve timing (Bank 1)More than 43.5°CA (Crankshaft Angle)
VVT learning value at maximum retarded valve timing (Bank 2)More than 43.5°CA (Crankshaft Angle)

Refer to CHECKING MONITOR STATUS. Refer to CHECKING MONITOR STATUS .

Scheme 273

Scheme 273: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on [A].
  6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
  7. Idle the engine for 5 minutes or more [C].
  8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
  9. Read the pending DTC [D].
  10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  12. Input the DTC: P0016 or P0018.
  13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
  14. Drive the vehicle for 2 to 3 minutes [E].
  15. Idle the engine for 5 minutes or more [F].
  16. Check the DTC judgment result [G]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  17. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP0017: Exhaust valve timing misalignment at idling (bank 1) P0019: Exhaust valve timing misalignment at idling (bank 2)
Required Sensors / Components (Main)Timing chain/belt
Required Sensors / Components (Related)None
Frequency of OperationOnce per driving cycle
DurationLess than 60 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
The monitor will run whenever these DTCs are not presentP0013, P0023 (Exhaust OCV bank 1, 2) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor)
Engine RPM500 to 1000 rpm
One of the following conditions is metCondition A, B, C or D
A. VVT learning value at maximum advanced valve timing (bank 1)Less than 77°CA (Crankshaft angle)
B. VVT learning value at maximum advanced valve timing (bank 2)Less than 77°CA (Crankshaft angle)
C. VVT learning value at maximum advanced valve timing (bank 1)More than 102°CA (Crankshaft angle)
D. VVT learning value at maximum advanced valve timing (bank 2)More than 102°CA (Crankshaft angle)

Refer to CHECKING MONITOR STATUS. Refer to CHECKING MONITOR STATUS .

Scheme 274

Scheme 274: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on [A].
  6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
  7. Idle the engine for 5 minutes or more [C].
  8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
  9. Read the pending DTC [D].
  10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  12. Input the DTC: P0017 or P0019.
  13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
  14. Drive the vehicle for 2 to 3 minutes [E].
  15. Idle the engine for 5 minutes or more [F].
  16. Check the DTC judgment result [G]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  17. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0017 AND P0019) Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Select the following menu items: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Display (DTC Output) Proceed to P0017 or P0019 A P0017 or P0019 and other DTCs B HINT: If any DTCs other than P0017 or P0019 are output, troubleshoot those DTCs first. B --> GO TO «DIAGNOSTIC TROUBLE CODE CHART»(ref-396630-S19862863392011050900000) A: Go to next step
  2. PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE OIL CONTROL VALVE FOR EXHAUST CAMSHAFT) Connect the Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine. Select the following menu items: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 2). Check the engine speed while operating the oil control valve using the Techstream. OK Techstream Operation Specified Condition 0% (OFF) Normal engine idle speed 127% (ON) Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 4 OK: Go to next step
  3. CHECK WHETHER DTC OUTPUT RECURS (DTC P0017 OR P0019) Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the pending DTCs using the Techstream. OK No pending DTC output. OK --> CHECK FOR INTERMITTENT PROBLEMS NG: Go to next step
  4. CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMP TEETH ON TIMING CHAIN) Remove the cylinder head covers RH and LH. Turn the crankshaft to align the matchmarks of the crankshaft. Align the notch of the crankshaft pulley to the "0" position. Check if the matchmarks of the camshaft pulley and camshaft bearing cap align. Turn the crankshaft clockwise by 360° if the matchmarks do not align. Check if they align once again. OK The matchmarks of the camshaft pulley and the camshaft bearing cap align when the notch of the crankshaft pulley is in the "0" position. NG --> ADJUST VALVE TIMING OK: Go to next step
  5. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Remove the exhaust camshaft timing oil control valve. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Connect the positive battery terminal to terminal 1 and connect the negative battery terminal to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the camshaft timing oil control valve. NG --> REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY OK: Go to next step
  6. INSPECT OIL CONTROL VALVE FILTER AND PIPE Remove the oil pipe No. 1 or oil pipe assembly. Remove the oil control valve filter. Check that the filter and pipe are not clogged. OK The filter and pipe are not clogged. NG --> REPLACE OIL CONTROL VALVE FILTER OR PIPE OK: Go to next step
  7. REPLACE EXHAUST CAMSHAFT TIMING GEAR ASSEMBLY NEXT: Go to next step
  8. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTC. OK No pending DTC output. HINT: DTC P0017 or P0019 may be stored when foreign objects in the engine oil are caught in some parts of the system. The DTC will remain stored even system returns to normal after a short time. Foreign objects are filtered out by the oil filter. OK --> END NG: Go to next step
  9. REPLACE ECM. Refer to «REMOVAL»(ref-396635-S35871318042011050900000)
Related DTCsP0031: A/F sensor heater (bank 1) range check (Low current) P0032: A/F sensor heater (bank 1) range check (High current) P0051: A/F sensor heater (bank 2) range check (Low current) P0052: A/F sensor heater (bank 2) range check (High current)
Required sensors/components (Main)A/F sensor heater (bank 1 and bank 2)
Required sensors/components (Related)
Frequency of operationContinuous
Duration10 seconds: P0031 and P0051 10.24 seconds: P0032 and P0052
MIL operationImmediately
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone

ALL

Battery voltage10.5 V or more
Heater output duty50% or more
Time after engine start10 seconds or more
Active heater off controlNot operating
Active heater on controlNot operating

P0031 AND P0051

Battery voltage10.5 V or more
Heater output dutyMore than 0%
Time after engine start10 seconds or more
Active heater off controlNot operating
Active heater on controlNot operating

P0032 AND P0052

Heater on currentLess than 0.8 A

P0031 AND P0051

Both of the following conditions are metConditions A and B
A. Hybrid IC high current limiter monitor inputFail
B. Heater outputON

P0032 AND P0052

Heater on current0.8 A or more

P0031 AND P0051

Heater outputON
Hybrid IC high current limiter portPass

P0032 AND P0052

Scheme 275

Scheme 275: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on [A].
  6. Start the engine and idle it for 5 minutes or more [B].
  7. With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 rpm for 1 minute [C].
  8. Idle the engine for 5 minutes or more [D].
  9. Enter the following menus: Powertrain / Engine / Trouble Codes.
  10. Read the DTC [E].
  11. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  13. Input the DTC: P0031, P0032, P0051 or P0058.
  14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] through [D] again.
  15. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  16. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  17. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP0037: Heated oxygen sensor heater (bank 1 sensor 2) open/short (Low electrical current) P0038: Heated oxygen sensor heater (bank 1 sensor 2) open/short (High electrical current) P0057: Heated oxygen sensor heater (bank 2 sensor 2) open/short (Low electrical current) P0058: Heated oxygen sensor heater (bank 2 sensor 2) open/short (High electrical current) P0141: Heated oxygen sensor heater performance (bank 1 sensor 2) P0161: Heated oxygen sensor heater performance (bank 2 sensor 2)
Required sensors/components (Main)Heated oxygen sensor heater (bank 1 sensor 2) Heated oxygen sensor heater (bank 2 sensor 2)
Required sensors/components (Related)Vehicle speed sensor
Frequency of operationContinuous
Duration0.5 second: P0037 and P0057 1 second: P0057 and P0058 10 seconds: P0141 and P0161
MIL operationImmediate: P0037, P0038, P0057 and P0058 2 driving cycles: P0141 and P0161
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone

ALL

Battery voltage10.5 to 20 V

P0037 AND P0057

Battery voltage10.5 V or more
EngineRunning
StarterOFF

P0038 AND P0058 (CASE 1)

Battery voltage10.5 to 20 V

P0038 AND P0058 (CASE 2)

One of the following conditions is metCondition A or B
A. All of the following conditions are metConditions 1, 2, 3, 4 and 5
1. Battery voltage10.5 V or more
2. Fuel cutOFF
3. Time after fuel cut ON to OFF30 seconds or more
4. Accumulated heater ON time100 seconds or more
5. Learned heater OFF current operationCompleted
B. Duration that rear heated oxygen sensor impedance is less than 15 kohms2 seconds or more

P0141 AND P0161

Heater current - Learned heater OFF currentLess than 0.3 A

P0037 AND P0057

One of the following conditions is metCondition A or B
A. Learned heater OFF currentMore than 2 A
B. Hybrid IC high current limiter portFail

P0038 AND P0058

Accumulated heater resistanceVaries with sensor element temperature (Example: More than 23 ohm)

P0141 AND P0161 (HEATER PERFORMANCE MONITOR CHECK)

Heated Oxygen (HO2) sensor heater current0.3 to 2 A (when engine idles, HO2 sensor warmed up and battery voltage 11 to 14 V)
  1. Refer to CHECKING MONITOR STATUS. Refer to «CHECKING MONITOR STATUS»(ref-396630-S39381445522011050900000) .

Scheme 276

Scheme 276: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on [A].
  6. Start the engine and idle it for 5 minutes or more [B].
  7. With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 rpm for 1 minute [C].
  8. Idle the engine for 5 minutes or more [D].
  9. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
  10. Read the pending DTC [E].
  11. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  13. Input the DTC: P0037, P0038, P0057, P0058, P0141 or P0161.
  14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] through [D] again.
  15. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  16. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  17. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP0101: Mass air flow meter rationality
Required Sensors/Components (Main)Mass air flow meter
Required Sensors/Components (Related)Crankshaft Position (CKP) sensor, Engine Coolant Temperature (ECT) sensor and Throttle Position (TP) sensor
Frequency of OperationContinuous
Duration10 times
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
TP (Throttle position) sensor voltage0.2 to 2 V
EngineRunning
Battery voltage10.5 V or more
ECT70°C (158°F) or more
Estimated load30 to 70%
IAT sensor circuit (P0112, P0113)OK
ECT sensor circuit (P0115, P0117, P0118)OK
CKP sensor circuit (P0335)OK
TP sensor circuit (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135)OK
Fuel tank pressure sensor circuit (P0452, P0453)OK
Leak detection pump (P2401, P2402)OK
Vent valve (P2419, P2420)OK
Average engine loadLess than 0.85%, or more than 1.33%
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Select the following menu items: Powertrain / Engine / Trouble Codes. Read DTCs. Result Display (DTC Output) Proceed to P0101 A P0101 and other DTCs B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> GO TO «DIAGNOSTIC TROUBLE CODE CHART»(ref-396630-S19862863392011050900000) A: Go to next step
  2. CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leakage. OK No leakage from air induction system. NG --> REPAIR OR REPLACE AIR INDUCTION SYSTEM OK: Go to next step
  3. CHECK PCV HOSE CONNECTIONS OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK --> REPLACE MASS AIR FLOW METER
Related DTCsP0102: Mass air flow meter range check (Low voltage) P0103: Mass air flow meter range check (High voltage)
Required Sensors/Components (Main)MAF meter
Required sensors/components (Related)Crankshaft position sensor
Frequency of OperationContinuous
Duration3 seconds
MIL OperationImmediately: Engine RPM less than 4000 rpm 2 driving cycles: Engine RPM 4000 rpm or more
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
Mass air flow meter voltageLess than 0.2 V

P0102

Mass air flow meter voltageMore than 4.9 V

P0103

Mass air flow meter voltageBetween 0.2 V and 4.9 V

Scheme 277

Scheme 277: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for at least 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on [A].
  6. Start the engine.
  7. Idle the engine for 5 seconds [B].
  8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending [C].
  9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  10. Run the engine at an engine speed of 4000 rpm for 5 seconds [D].
  11. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending [E].
  12. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  14. Input the DTC: P0102 or P0103.
  15. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
  16. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 278

Scheme 278: WIRING DIAGRAM
Related DTCsP0111: Intake air temperature sensor rationality (After engine stop) P0111: Intake air temperature sensor rationality (After cold engine start)
Required Sensors/Components (Main)Intake Air Temperature (IAT) sensor
Required sensors/components (Related)
Frequency of OperationOnce per driving cycle
Duration10 seconds or more
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone

ALL

Time after engine start10 seconds or more
Battery voltage10.5 V or more
IAT sensor circuit (P0112, P0113)OK
ECT sensor circuit (P0115, P0117, P0118)OK
MAF meter circuit (P0102, P0103)OK
ECT change since engine stop40°C (-40°F) or more
Accumulated MAF amount before engine stop2033 g or more
Key-off duration30 minutes

AFTER ENGINE STOP

Key-off duration5 hours
Time after engine start10 seconds or more
IAT sensor circuit (P0112, P0113)OK
ECT sensor circuit (P0115, P0117, P0118)OK
MAF meter circuit (P0102, P0103)OK
ECT70°C (158°F) or more
Accumulated MAF amount2033 g or more
One of the following conditions 1 or 2 is met
1. Duration while engine load is low120 seconds or more
2. Duration while engine load is high10 seconds or more

AFTER COLD ENGINE START

IAT changeLess than 1°C (2°F)

AFTER ENGINE STOP

IAT changeLess than 1°C (2°F)

AFTER COLD ENGINE START

Scheme 279

Scheme 279: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on [A].
  6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
  7. Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is below 1°C (2°F), the intake air temperature sensor (mass air flow meter sub-assembly) is malfunctioning. It is not necessary to continue this procedure.
  8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
  9. Read the pending DTC [D].
  10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  12. Input the DTC: P0111.
  13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F].
  14. Drive the vehicle at 25 mph (40 km/h) or more for a total of 5 minutes or more [E].
  15. Check the DTC judgment result again [F].
  16. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  17. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  18. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Display (DTC Output) Proceed to P0111 and other DTCs A P0111 B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> See step 3 A: Go to next step
  2. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-396630-S19862863392011050900000)
  3. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-396635-S17842337612011050900000)
Related DTCsP0112: Intake air temperature sensor range check (Low voltage) P0113: Intake air temperature sensor range check (High voltage)
Required Sensors/Components (Main)Intake Air Temperature (IAT) sensor
Required sensors/components (Related)
Frequency of OperationContinuous
Duration0.5 seconds
MIL OperationImmediately
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
Battery voltage8 V or more
Engine switchOn (IG)
StarterOFF
Intake air temperature sensor voltageLess than 0.18 V

P0112

Intake air temperature sensor voltageMore than 4.91 V

P0113

Intake air temperature sensor voltage0.18 to 4.91 V

Scheme 280

Scheme 280: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on.
  6. Wait 0.5 seconds or more [A].
  7. Enter the following menus: Powertrain / Engine / Trouble Codes.
  8. Read the DTC [B].
  9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  11. Input the DTC: P0112 or P0113.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
  13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 281

Scheme 281: WIRING DIAGRAM
Related DTCsP0115: Engine coolant temperature sensor range check (Chattering) P0117: Engine coolant temperature sensor range check (Low voltage) P0118: Engine coolant temperature sensor range check (High voltage)
Required Sensors/Components (Main)Engine coolant temperature sensor
Required sensors/components (Related)
Frequency of OperationContinuous
Duration0.5 seconds
MIL OperationImmediately
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
Engine coolant temperature sensor voltageLess than 0.14 V, or more than 4.91 V

P0115

Engine coolant temperature sensor voltageLess than 0.14 V

P0117

Engine coolant temperature sensor voltageMore than 4.91 V

P0118

Engine coolant temperature sensor voltage0.14 to 4.91 V

Scheme 282

Scheme 282: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on.
  6. Wait 0.5 seconds or more [A].
  7. Enter the following menus: Powertrain / Engine / Trouble Codes.
  8. Read the DTC [B].
  9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  11. Input the DTC: P0115, P0117 or P0118.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
  13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 283

Scheme 283: WIRING DIAGRAM
Related DTCsP0116: Engine coolant temperature sensor rationality (ECT sensor cold start monitor) P0116: Engine coolant temperature sensor rationality (ECT sensor soak monitor)
Required Sensors/Components (Main)Engine coolant temperature (ECT) sensor
Required sensors/components (Related)
Frequency of OperationOnce per driving cycle
Duration10 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone

ALL

Battery voltage10.5 V or more
Time after engine start1 second or more
ECT at engine startLess than 60°C (140°F)
ECT sensor circuit (P0115, P0117, P0118, P0125)OK
IAT sensor circuit (P0112, P0113)OK
Soak time0 second
Accumulated MAF1241 g or more
Fuel cutOFF
Difference between ECT at engine start and IATLess than 40°C (104°F)

ECT SENSOR COLD START MONITOR

Battery voltage10.5 V or more
EngineRunning
Soak time5 hours or more
ECT at engine start60°C (140°F) or more
Accumulated MAF2334 g or more

ECT SENSOR SOAK MONITOR

ECT sensor value changeLess than 5°C (41°F)

ECT SENSOR COLD START MONITOR

Difference between current ECT sensor value and previous ECT sensor value when engine stoppedLess than 5°C (41°F)

ECT SENSOR SOAK MONITOR

Engine coolant temperatureVaries with actual engine coolant temperature

Scheme 284

Scheme 284: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
  4. Check that the engine coolant temperature is 60°C (140°F) or less.
  5. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  6. Turn the engine switch off and wait for 30 seconds.
  7. Turn the engine switch on (IG) and turn the Techstream on [A].
  8. Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or higher, the engine coolant temperature sensor is malfunctioning. It is not necessary to continue this procedure.
  9. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
  10. Read the pending DTC [C].
  11. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  13. Input the DTC: P0116.
  14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E].
  15. Drive the vehicle at 25 mph (40 km/h) or more for a total of 5 minutes or more [D]. HINT: In the event of the drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed.
  16. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  17. Check the DTC judgment result again [E]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  18. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC P0116) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Display (DTC output) Proceed to P0116 A P0116 and other DTCs B B --> See step 3 A: Go to next step
  2. INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-396642-S29806719702011050900000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-396642-S40928798302011050900000) . NG --> See step 4 OK --> See step 5
  3. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-396630-S19862863392011050900000)
  4. REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-396642-S29806719702011050900000)
  5. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-396635-S33992661182011050900000)
Related DTCsP011B: Engine Coolant Temperature (ECT) / Intake Air Temperature (IAT) sensor correlation
Required Sensors / Components (Main)ECT / IAT sensor
Required Sensors / Components (Related)
Frequency of OperationOnce per driving cycle
Duration7 hours or more
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
All of following conditions metConditions 1 and 2
1. All of the following conditions are metConditions (a), (b), (c) and (d)
(a) After engine switch on (IG) and engine not running timeLess than 20 seconds
(b) Soak Time7 hours or more
(c) Battery voltage10.5 V or more
(d) Time after engine start15 seconds or more
2. Either of the following conditions are metCondition (a) and (b)
(a) Minimum IAT after engine start10°C (14°F) or more
(b) ECT before engine start10°C (14°F) or more
ECT sensor circuit fail (P0115, P0117, P0118, P0125)OK
IAT sensor circuit fail (P0112, P0113)OK
Soak timer circuit fail (P2610)OK
Deviated ECT and IATLess than -20°C (-36°F) or more than 20°C (36°F)

Scheme 285

Scheme 285: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) [A].
  4. Turn the engine switch off and wait for 30 seconds.
  5. With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
  6. Turn the engine switch on (IG) and turn the Techstream on.
  7. Start the engine and wait 60 seconds or more [C].
  8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
  9. Read the pending DTC [D].
  10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  12. Input the DTC: P011B.
  13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [C] again.
  14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  16. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P011B) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream ON. Select the following menu items: Powertrain / Engine / Trouble Codes. Read DTCs. Result Result Proceed to P011B A P011B and other DTCs B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
  2. READ VALUE USING TECHSTREAM (INTAKE AIR TEMPERATURE) Leave the vehicle for 7 hours or more. HINT: It is necessary leave the vehicle for 7 hours or more to allow conditions similar to the DTC detection conditions. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream ON. Select the following menu items: Powertrain / Engine / Intake Air. Read the value displayed on the Techstream. OK Difference between the intake air temperature and the actual outside air temperature is within 10°C (50°F). HINT: Temperature readings on the vehicle's outside temperature gauge (if equipped) are not suitable for comparing to the IAT reading. The outside temperature gauge has a significant delay built in to prevent temperature swings from being displayed on its display. Use an accurate thermometer to determine the outside air temperature. NG --> See step 5 OK: Go to next step
  3. READ VALUE USING TECHSTREAM (COOLANT TEMPERATURE) Connect the Techstream to the DLC3. Turn the engine switch to on (IG). Turn the Techstream ON. Select the following menu items: Powertrain / Engine / Coolant Temp. Read the value displayed on the Techstream. OK The difference between the coolant temperature and the actual outside air temperature is within 10°C (50°F). HINT: If the result is not as specified, check that there are heat sources such as a block heater in the engine compartment. NG --> See step 7 OK --> See step 6
  4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-396630-S19862863392011050900000)
  5. REPLACE MASS AIR FLOW METER. Refer to «COMPONENTS»(ref-396635-S32329080362011050900000)
  6. REPLACE ECM. Refer to «COMPONENTS»(ref-396635-S32341521312011050900000)
  7. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «COMPONENTS»(ref-396635-S25387023352011050900000)
Related DTCsP0120: Throttle position sensor 1 range check (Chattering) P0121: Throttle position sensor rationality P0122: Throttle position sensor 1 range check (Low voltage) P0123: Throttle position sensor 1 range check (High voltage) P0220: Throttle position sensor 2 range check (Chattering) P0222: Throttle position sensor 2 range check (Low voltage) P0223: Throttle position sensor 2 range check (High voltage) P2135: Throttle position sensor range check (Correlation)
Required Sensors/Components (Main)Throttle position sensor
Required Sensors/Components (Related)
Frequency of OperationContinuous
Duration2 seconds: P0120, P0122, P0123, P0220, P0222 and P0223 Within 2 seconds: P0121 0.5 seconds: P2135 (Condition A) 0.4 seconds: P2135 (Condition B)
MIL OperationImmediately
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
Either of the following conditions A or B is met
A. Engine switch on (IG)0.012 seconds or more
B. Electronic throttle actuator powerON

P0120, P0122, P0123, P0220, P0222, P0223, P02135

Monitor runs whenever following DTCs are not presentNone
Either of the following conditions A or B is met
A. Engine switchOn (IG)
B. Electric throttle motor powerON
Throttle position sensor malfunction (P0120, P0122, P0123, P0220, P0222, P0223, P2135)Not detected

P0121

VTA1 voltage0.2 V or less, or 4.535 V or higher

P0120

Either of the following conditions is met
Difference of throttle position sensor voltage between VTA1 and VTA2 x 0.8Higher than 1.6 V
Difference of throttle position sensor voltage between VTA1 and VTA2 x 0.8Lower than 0.8 V

P0121

VTA1 voltage0.2 V or less

P0122

VTA1 voltage4.535 V or higher

P0123

Either of the following conditions A or B is met
A. VTA2 voltage1.75 V or less
B. VTA2 voltage when VTA1 0.2 V or higher, and 2.02 V or less4.8 V or higher

P0220

VTA2 voltage1.75 V or less

P0222

VTA2 voltage when VTA1 0.2 V or higher, and 2.02 V or less4.8 V or higher

P0223

Difference between VTA1 and VTA2 voltages0.02 V or less

P2135 CASE 1

VTA1 voltage0.2 V or less
VTA2 voltage1.75 V or less

P2135 CASE 2

VTA1 voltage0.69 to 4.05 V
VTA2 voltage2.25 to 4.8 V

Scheme 286

Scheme 286: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on [A].
  6. Start the engine.
  7. With the vehicle stationary, fully depress and release the accelerator pedal [B].
  8. Idle the engine for 2 seconds or more [C].
  9. Enter the following menus: Powertrain / Engine / Trouble Codes.
  10. Read the DTC [D].
  11. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  13. Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
  14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
  15. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  16. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  17. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

FAIL-SAFE

When any of these DTCs, as well as other DTCs relating to electronic throttle control system malfunctions are set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the engine switch is then turned off.

Scheme 287

Scheme 287: WIRING DIAGRAM
Related DTCsP0125: Insufficient engine coolant temperature for closed-loop fuel control
Required Sensors/Components (Main)Thermostat, cooling system
Required Sensors/Components (Related)Engine coolant temperature sensor and mass air flow meter
Frequency of OperationOnce per driving cycle
Duration64 seconds: Closed-loop engine coolant temperature - 8.33°C (46.99°F) or more 111 seconds: Closed-loop engine coolant temperature - 19.44°C (66.99°F) or more to less than closed-loop engine coolant temperature - 8.33°C (46.99°F) 1200 seconds: Less than closed-loop engine coolant temperature - 19.44°C (66.99°F)
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
MAF sensor circuit fail (P0102, P0103)Not detected
IAT sensor circuit fail (P0112, P0113)Not detected
ECT sensor circuit fail (P0115, P0117, P0118)Not detected
Thermostat fail (P0128)Not detected
Time until actual engine coolant temperature reaches closed-loop fuel control enabling temperature64 seconds: Closed-loop engine coolant temperature - 8.33°C (46.99°F) or more 111 seconds: Closed-loop engine coolant temperature - 19.44°C (66.99°F) or more to less than closed-loop engine coolant temperature - 8.33°C (44.99°F) 1200 seconds: Less than closed-loop engine coolant temperature - 19.44°C (66.99°F)

Scheme 288

Scheme 288: CONFIRMATION DRIVING PATTERN
  1. Leave the vehicle outside overnight.
  2. Connect the Techstream to the DLC3.
  3. Turn the engine switch on (IG) and turn the Techstream on.
  4. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp.
  5. Check that the engine coolant temperature is 5°C (41°F) or less.
  6. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  7. Turn the engine switch off and wait for 30 seconds.
  8. Turn the engine switch on (IG) and turn the Techstream on [A].
  9. Start the engine.
  10. After starting the engine, wait 21 minutes or more [B].
  11. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
  12. Read the pending DTC [C].
  13. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  15. Input the DTC: P0125.
  16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
  17. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  18. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  19. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Display (DTC Output) Proceed to P0125 A P0125 and other DTCs B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
  2. INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-396642-S29806719702011050900000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-396642-S40928798302011050900000) . NG --> See step 5 OK: Go to next step
  3. CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. OK --> See step 6 NG: REPAIR OR REPLACE COOLING SYSTEM
  4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-396630-S19862863392011050900000)
  5. REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-396642-S29806719702011050900000)
  6. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-396635-S33992661182011050900000)
Related DTCsP0128: Coolant Thermostat
Required Sensors/Components (Main)Thermostat
Required sensors/components (Related)Engine Coolant Temperature (ECT) sensor, Intake Air Temperature (IAT) sensor, Vehicle speed sensor
Frequency of OperationOnce per driving cycle
Duration540 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor will run whenever this DTC is not presentP0010, P0020 (OCV bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0013, P0023 (Exhaust OCV bank 1, 2) P0014, P0024 (Exhaust VVT system bank 1, 2 - advance) P0015, P0025 (Exhaust VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052 (A/F sensor heater) P0102, P0103 (MAF meter) P0112, P0113 (IAT sensor) P0115, P0117, P0118 (ECT sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (TP sensor) P014C, P014D, P014E, P014F (Air fuel ratio sensor - slow response) P015A, P015B, P015C, P015D (Air fuel ratio sensor - delayed response) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (CKP sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0500 (Vehicle speed sensor) P2195, P2196, P2197, P2198 (A/F sensor - rationality) P2237, P2240 (A/F sensor - open) P2238, P2241, P2252, P2255 (A/F sensor - low impedance) P2239, P2242, P2253, P2256 (A/F sensor - high impedance)
Battery voltage11 V or more
Either following condition 1 or 2 is met
1. All of following conditions are met
ECT at engine start - IAT at engine start15 to 7°C (5 to 44.6°F)
ECT at engine start10 to 56°C (14 to 132.8°F)
IAT at engine start10 to 56°C (14 to 132.8°F)
2. All of following conditions are met
ECT at engine start - IAT at engine startMore than 7°C (44.6°F)
ECT at engine start56°C (132.8°F) or less
IAT at engine start10°C (14°F) or more
Accumulated time that vehicle speed is 80 mph (128 km/h) or more speedLess than 20 seconds
Duration that both of the following conditions 1 and 2 are met5 seconds or more
1. Estimated ECT75°C (167°F) or more
2. ECT sensor outputLess than 75°C (167°F)

Scheme 289

Scheme 289: CONFIRMATION DRIVING PATTERN
  1. Stop the engine and allow it to cool down.
  2. Connect the Techstream to the DLC3.
  3. Turn the engine switch on (IG) and turn the Techstream on [A].
  4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  5. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp and Intake Air.
  6. Check if "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (32 and 95°F).
  7. Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
  8. Start the engine and drive the vehicle at 50 mph (80 km/h) for 15 minutes [B]. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menus: Data List / Function / Snap-shot configuration / Record time / 5 min. Data capture can be started by using the target point. For example, setting the target point to an Accel of 90% and then racing the engine, etc. to raise the engine speed to a speed of 2500 rpm or more will cause data capture to start.
  9. After driving the vehicle at 50 mph (80 kmh) and "Coolant Temp" stabilizes, check that "Coolant Temp" is 75°C (167°F) or higher [C]. HINT: If "Coolant Temp" is below 75°C (167°F) while driving the vehicle at 50 mph (80 km/h), inspect the cooling system and thermostat.
  1. CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC P0128) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTC. Result Display (DTC Output) Proceed to P0128 A P0128 and other DTCs B HINT: If any DTC other than P0128 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
  2. CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
  3. INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-396642-S29806719702011050900000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-396642-S40928798302011050900000) . NG --> See step 5 OK --> See step 6
  4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-396630-S19862863392011050900000)
  5. REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-396642-S29806719702011050900000)
  6. REPLACE ECM. Refer to «REMOVAL»(ref-396635-S35871318042011050900000)
Related DTCsP0136: HO2S voltage (Bank 1) P0136: HO2S low impedance (Bank 1) P0137: HO2S high impedance (Bank 1) P0137: HO2S low voltage (Bank 1) P0138: HO2S high voltage (Bank 1) P0138: HO2S high voltage (Extremely high) (Bank 1) P0139: HO2 sensor output voltage during fuel cut (Bank 1) P0156: HO2S voltage (Bank 2) P0156: HO2S low impedance (Bank 2) P0157: HO2S high impedance (Bank 2) P0157: HO2S low voltage (Bank 2) P0158: HO2S high voltage (Bank 2) P0158: HO2S high voltage (Extremely high) (Bank 2) P0159: HO2 sensor output voltage during fuel cut (Bank 2)
Required Sensors/Components (Main)HO2S
Required sensors/components (Related)Crankshaft position sensor, Engine coolant temperature sensor, Mass air flow meter, Throttle position sensor
Frequency of OperationOnce per driving cycle: Active air fuel ratio control detection, abnormal voltage during fuel cut Continuous: Others
Duration20 seconds: HO2S voltage (P0136, P0156), HO2S low voltage (P0137, P0157), HO2S high voltage (P0138, P0158) 30 seconds: HO2S low impedance (P0136, P0156) 90 seconds: HO2S high impedance (P0137, P0157) 10 seconds: HO2S high voltage (Extremely high) (P0138, P0158) 7 seconds: HO2S output voltage during fuel cut (P0139, P0159)
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentP0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052 (A/F sensor heater) P0037, P0038, P0057, P0058 (HO2S heater) P0102, P0103 (MAF meter) P0112, P0113 (IAT sensor) P0115, P0117, P0118 (ECT sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (TP sensor) P0125 (Insufficient ECT for closed loop) P0128 (Thermostat) P014C, P014D, P014E, P014F (Air fuel ratio sensor - slow response) P015A, P015B, P015C, P015D (Air fuel ratio sensor - delayed response) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (CKP sensor) P0451, P0452, P0452 (EVAP system) P0500 (Vehicle speed sensor) P2195, P2196, P2197, P2198 (A/F sensor - rationality) P2237, P2240 (A./F sensor - open) P2238, P2241, P2252, P2255 (A/F sensor - low impedance) P2239, P2242, P2253, P2256 (A/F sensor - high impedance)

ALL

Active A/F controlPerforming
Battery voltage11 V or more
ECT75°C (167°F) or more
IdleOFF
Engine rpmLess than 3200 rpm
A/F sensor statusActivated
Fuel system statusClosed loop
Fuel-cutOFF
Engine load10 to 70%
Shift position4rd or more

HO2S VOLTAGE (P0136, P0156), HO2S LOW VOLTAGE (P0137, P0157), HO2S HIGH VOLTAGE (P0138, P0158)

Battery voltage11 V or more
Estimated rear HO2S temperatureLess than 700°C (1292°F)
ECM monitorCompleted
P0607Not set

HO2S LOW IMPEDANCE (P0136, P0156)

Battery voltage11 V or more
Estimated rear HO2S temperature450 to 750°C (842 to 1382°F)
P0607Not preset

HO2S HIGH IMPEDANCE (P0137, P0157)

Battery voltage11 V or more
Time after engine start2 seconds or more

HO2S HIGH VOLTAGE (EXTREMELY HIGH) (P0138, P0158)

ECT75°C (167°F) or more
Estimated catalyst temperature400°C (752°F) or more
Fuel cutON

HO2 SENSOR VOLTAGE (DURING FUEL CUT) (P0139, P0159)

Either of the following condition 1 or 2 is met
1. All of the following conditions (a), (b) and (c) are met
(a) Commanded air-fuel ratio14.3 or less
(b) Rear HO2S voltage0.21 to 0.59 V
(c) OSC (Oxygen capacity of catalyst)1.8 g or more
2. All of the following conditions (d), (e) and (f) are met
(d) Commanded air-fuel ratio14.9 or more
(e) Rear HO2S voltage0.21 to 0.59 V
(f) OSC (Oxygen capacity of catalyst)1.8 g or more

HO2S VOLTAGE (P0136, P0156)

Duration that following condition is met30 seconds or more
Rear HO2S impedanceLess than 5 ohms

HO2S LOW IMPEDANCE (P0136, P0156)

Duration that following condition is met90 seconds or more
Rear HO2S impedance15 kohms or more

HO2S HIGH IMPEDANCE (P0137, P0157)

All of the following conditions 1, 2 and 3 are met
1. Commanded air-fuel ratio14.3 or less
2. Rear HO2S voltageLess than 0.21 V
3. OSC (Oxygen capacity of catalyst)1.8 g or more

HO2S LOW VOLTAGE (P0137, P0157)

All of the following conditions 1, 2 and 3 are met
1. Commanded air-fuel ratio14.9 or more
2. Rear HO2S voltageMore than 0.59 V
3. OSC (Oxygen capacity of catalyst)1.8 g or more

HO2S HIGH VOLTAGE (P0138, P0158)

Duration that following condition is met10 seconds or more
Rear HO2S voltage1.2 V or more

HO2S HIGH VOLTAGE (EXTREMELY HIGH) (P0138, P0158)

One of the following conditions is met
Duration until HO2 sensor voltage drops to 0.2 V during fuel cut7 seconds or more
Duration that HO2 sensor voltage drops from 0.35 V to 0.2 V during fuel-cut1 second or more

HO2 SENSOR VOLTAGE (DURING FUEL-CUT) (P0139, P0159)

Duration of following condition30 seconds or more
Heated oxygen sensor voltageVaries between 0.1 and 0.9 V

Refer to CHECKING MONITOR STATUS. Refer to CHECKING MONITOR STATUS .

Scheme 290

Scheme 290: WIRING DIAGRAM

CONFIRMATION DRIVING PATTERN

P0136, P0137, P0138, P0156, P0157 and P0158

Scheme 291

Scheme 291: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on [A].
  6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
  7. With the transmission in 4th gear or more, drive the vehicle at 40 to 75 mph (60 to 120 km/h) for 10 minutes or more [C].
  8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
  9. Read the pending DTC [D].
  10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  12. Input the DTC: P0136, P0137, P0138, P0156, P0157 or P0158.
  13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [C] again.
  14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  16. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

P0139 and P0159

Scheme 292

Scheme 292
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on [A].
  6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
  7. Drive the vehicle at 40 mph (60 km/h), and then decelerate the vehicle by releasing the accelerator pedal for 7 seconds or more to perform the fuel-cut [C].
  8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
  9. Read the pending DTC [D].
  10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  12. Input the DTC: P0139 or P0159.
  13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, move the shift lever to 2nd and then perform step [C] again.
  14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  16. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP014C: Air fuel ratio sensor (bank 1) slow response (rich to lean) P014D: Air fuel ratio sensor (bank 1) slow response (lean to rich) P014E: Air fuel ratio sensor (bank 2) slow response (rich to lean) P014F: Air fuel ratio sensor (bank 2) slow response (lean to rich) P015A: Air fuel ratio sensor (bank 1) delayed response (rich to lean) P015B: Air fuel ratio sensor (bank 1) delayed response (lean to rich) P015C: Air fuel ratio sensor (bank 2) delayed response (rich to lean) P015D: Air fuel ratio sensor (bank 2) delayed response (lean to rich)
Required Sensors/Components (Main)Air fuel ratio sensor
Required Sensors/Components (Related)Vehicle speed sensor, crankshaft position sensor
Frequency of OperationOnce per driving cycle
Duration10 to 15 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not storedNone
Active air fuel ratio controlPerforming
Active air fuel ratio control is performed when the following conditions are met
Battery voltage11 V or higher
Engine coolant temperature75°C (167°F) or more
IdleOFF
Engine speed1000 to 4000 rpm
Air fuel ratio sensor statusActivated
Fuel-cutOFF
Engine load10 to 70%
Shift position2nd or higher
Catalyst monitorNot yet
Mass air flow5 to 15 g/sec.
Rich to Lean Response rate deterioration level0.035 V or less

AIR FUEL RATIO SENSOR (BANK 1, 2) SLOW RESPONSE (RICH TO LEAN)

Lean to Rich Response rate deterioration level0.038 V or higher

AIR FUEL RATIO SENSOR (BANK 1, 2) SLOW RESPONSE (LEAN TO RICH)

Rich to Lean delay level230 msec or more

AIR FUEL RATIO SENSOR (BANK 1, 2) DELAYED RESPONSE (RICH TO LEAN)

Lean to Rich delay level230 msec or more

AIR FUEL RATIO SENSOR (BANK 1, 2) DELAYED RESPONSE (LEAN TO RICH)

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

HINT

Performing this confirmation pattern will activate the air fuel ratio sensor response monitor.

Scheme 293

Scheme 293: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG).
  3. Turn the Techstream on.
  4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  5. Turn the engine switch off.
  6. Turn the engine switch on (IG) and turn the Techstream on.
  7. Enter the following menus: Powertrain / Engine / Monitor / O2 Sensor / Details.
  8. Check that the RES RATE B1S1 and RES RATE B2S1 are Incomplete.
  9. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
  10. Drive the vehicle at a constant speed of between 47 and 62 mph (75 and 100 km/h) for 10 minutes [B].
  11. Check the monitor result values on Techstream by entering the following menus: Powertrain / Engine / Monitor / O2 Sensor / Details / RES RATE B1S1 and RES RATE B2S1.
  12. If the values indicated on the Techstream do not change, perform Readiness Monitor Drive Pattern for the air fuel ratio sensor and heated oxygen sensor. Refer to «READINESS MONITOR DRIVE PATTERN»(ref-396630-S10402633792011050900000) .
  13. Note the value of the Monitor Result.
  14. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
  15. Read the pending DTC [C].
  16. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  17. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  18. Input the DTC: P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D.
  19. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
  20. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  21. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  22. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK ANY OTHER DTCS OUTPUT (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D and other DTCs are output B HINT: If any DTCs other than P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
  2. INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) See step 1 NG --> See step 11 OK: Go to next step
  3. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM). Refer to «PROCEDURE - Step 4»(ref-396633-S15417437012011050900000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  4. INSPECT AIR FUEL RATIO SENSOR Check that the proper air fuel ratio sensors are installed to the vehicle. NG --> See step 12 OK: Go to next step
  5. PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
  6. CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C and/or P015D are output A DTC is not output B B --> See step 13 A: Go to next step
  7. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-396640-S01703233552011050900000) . NEXT: Go to next step
  8. PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
  9. CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. RESULT Result Proceed to DTC is not output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C and/or P015D are output B B --> See step 14 A: END
  10. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-396630-S19862863392011050900000)
  11. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-396640-S01703233552011050900000)
  12. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-396640-S01703233552011050900000)
  13. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-396630-S16310885982011050900000)
  14. CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1); DTC P0174: System Too Lean (Bank 2); DTC P0175: System Too Rich (Bank 2)»(ref-396637-S00136583312011050900000)
Related DTCsP0171: Fuel trim Lean (Bank 1) P0172: Fuel trim Rich (Bank 1) P0174: Fuel trim Lean (Bank 2) P0175: Fuel trim Rich (Bank 2)
Required Sensors/Components (Main)Fuel system
Required Sensors/Components (Related)A/F sensor, Mass air flow meter, Crankshaft position sensor
Frequency of OperationContinuous
DurationLess than 10 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentP0010, P0020 (OCV bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0013, P0023 (Exhaust OCV bank 1, 2) P0014, P0024 (Exhaust VVT system bank 1, 2 - advance) P0015, P0025 (Exhaust VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052 (A/F sensor heater) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (TP sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0500 (Vehicle speed sensor)
Fuel system statusClosed-loop
Battery voltage11 V or more
Either following condition is metCondition 1 or 2
1. Engine RPMLess than 1100 rpm
2. Intake air amount per revolution0.22 g/rev or more
Catalyst monitorNot executed

FUEL TRIM

EVAP purge-cutExecuting
Either of the following condition is metCondition 1 or 2
1. Average between short-term fuel trim and long-term fuel trim35% or more (varies with ECT)
2. Average between short-term fuel trim and long-term fuel trim35% or less (varies with ECT)

FUEL TRIM

Scheme 294

Scheme 294: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on [A].
  6. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) with all the accessories switched off [B].
  7. With the engine warmed up, idle the engine for 2 minutes or more [C].
  8. Drive the vehicle at between 38 and 75 mph (60 and 120 km/h) and at an engine speed of between 1400 and 3200 rpm for 5 minutes or more [D].
  9. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
  10. Read the pending DTC [E].
  11. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
  12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  13. Input the DTC: P0171, P0172, P0174 or P0175.
  14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [C] through [D] again.
  15. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  16. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  17. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP0300: Multiple cylinder misfire P0301: Cylinder 1 misfire P0302: Cylinder 2 misfire P0303: Cylinder 3 misfire P0304: Cylinder 4 misfire P0305: Cylinder 5 misfire P0306: Cylinder 6 misfire
Required Sensors/Components (Main)Injector, Ignition coil and spark plug
Required Sensors/Components (Related)Crankshaft position, VVT Engine coolant temperature and intake air temperature sensors and Mass air flow meter
Frequency of OperationContinuous
Duration1000 to 4000 crankshaft revolutions: Emission related misfire 200 to 600 crankshaft revolutions: Catalyst damaged misfire
MIL Operation2 driving cycles: (MIL illuminates when misfire detected) MIL flashes immediately: When catalyst damaged misfire occur
Sequence of OperationNone
Monitor runs whenever following DTCs not presentP0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0102, P0103 (MAF meter) P0112, P0113 (IAT sensor) P0115, P0117, P0118 (ECT sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (TP sensor) P0125 (Insufficient ECT for closed loop) P0327, P0328, P0332, P0333 (Knock sensor) P0335 (CKP sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0500 (Vehicle speed sensor) P0705 (Shift lever position switch)
Battery voltage8 V or more
VVT systemNot operated by scan tool
Engine RPM450 to 6500 rpm
Either of the following conditions (a) or (b) is met
(a) Engine coolant temperature at engine startMore than -7°C (19.4°F)
(b) Engine coolant temperatureMore than 20°C (68°F)
Fuel cutOFF

MISFIRE

First 1000 revolutions after engine start, or Check ModeCrankshaft 1000 revolutions
Except aboveCrankshaft 1000 revolutions x 4

MONITOR PERIOD OF EMISSION-RELATED-MISFIRE

All of the following conditions 1, 2 and 3 are metCrankshaft 200 revolutions
1. Driving cycles1st
2. Check modeOFF
3. Engine RPMLess than 2300 rpm
Except aboveCrankshaft 200 revolutions x 3

MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)

Misfire rate1 % or more

MONITOR PERIOD OF EMISSION-RELATED-MISFIRE

Number of misfire per 200 revolutions94 or more (varies with intake air amount and RPM)
Paired cylinder misfire (MIL blinks immediately)Detected

MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)

Refer to CHECKING MONITOR STATUS. Refer to CHECKING MONITOR STATUS .

Scheme 295

Scheme 295: WIRING DIAGRAM
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG).
  3. Turn the Techstream on.
  4. Record the DTC(s) and freeze frame data.
  5. Using the Techstream, switch the ECM from normal mode to check mode. Refer to «CHECK MODE PROCEDURE»(ref-396630-S36473134852011050900000) .
  6. Read the misfire counts of each cylinder (Cylinder #1 Misfire Count to Cylinder #6 Misfire Count) with the engine in an idling condition. If any misfire count is displayed, skip the following confirmation driving pattern.
  7. Drive the vehicle several times with the conditions, such as engine rpm and engine load, shown in, Misfire RPM and Misfire Load in the Data List. HINT: In order to store misfire DTCs, it is necessary to operate the vehicle for the period of time shown in the table below, using the Misfire RPM and Misfire Load in the Data List. Engine RPM Duration Idling 5 minutes or more 1000 4 minutes or more 2000 3 minutes or more 3000 2 minute or more
  8. Check whether misfires have occurred by checking DTCs and freeze frame data. HINT: Do not turn the engine switch off until the stored DTC(s) and freeze frame data have been recorded. When the ECM returns to normal mode (default), the stored DTC(s), freeze frame data and other data will be erased.
  9. Record the DTC(s), freeze frame data and misfire counts.
  10. Turn the engine switch off and wait for at least 5 seconds.
Related DTCsP0327: Knock sensor (Bank 1) range check (Low voltage) P0328: Knock sensor (Bank 1) range check (High voltage) P0332: Knock sensor (Bank 2) range check (Low voltage) P0333: Knock sensor (Bank 2) range check (High voltage)
Required Sensors/Components (Main)Knock sensor (Bank 1 and 2)
Required Sensors/Components (Related)
Frequency of OperationContinuous
Duration1 second
MIL OperationImmediately
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
Battery voltage10.5 V or more
Time after engine start5 seconds or more
Engine switchOn (IG)
StarterOFF
Knock sensor voltageLess than 0.5 V

KNOCK SENSOR RANGE CHECK (LOW VOLTAGE) P0327 AND P0332

Knock sensor voltageMore than 4.5 V

KNOCK SENSOR RANGE CHECK (HIGH VOLTAGE) P0328 AND P0333

Scheme 296

Scheme 296: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on [A].
  6. Start the engine and wait 10 seconds.
  7. Enter the following menus: Powertrain / Engine / Trouble Codes.
  8. Read the DTC [B].
  9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  11. Input the DTC: P0327, P0328, P0332 or P0333.
  12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 5 minutes.
  13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  14. Check the judgment result [C]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 297

Scheme 297: WIRING DIAGRAM
Related DTCsP0335: CKP sensor verify pulse input P0335: CKP sensor range check/rationality
Required Sensors/Components (Main)Crankshaft Position (CKP) sensor
Required Sensors/components (Related)
Frequency of OperationContinuous
Duration4.7 seconds
MIL OperationImmediately
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone

ALL

Time after starter OFF to ON3 seconds or more
Battery voltage7 V or more
Minimum battery voltage while starter ONLess than 11 V
Number of VVT sensor signal pulse6 times
Camshaft position sensor circuit fail (P0340,P0342,P0343)Not detected

P0335: CKP SENSOR RANGE CHECK/RATIONALITY

Engine speed600 rpm or less
StarterOFF
Time after starter ON to OFF3 seconds or more

P0335: CKP SENSOR VERIFY PULSE INPUT (CASE 1)

StarterON
Minimum battery voltage starter ONBelow 11 V

P0335: CKP SENSOR VERIFY PULSE INPUT (CASE 2)

Number of crankshaft position sensor signal pulse132 or less, or 174 or more

P0335: CKP SENSOR RANGE CHECK/RATIONALITY

Crankshaft position sensor signalNo signal

P0335: CKP SENSOR VERIFY PULSE INPUT

CKP sensorCKP sensor output voltage fluctuates while crankshaft is revolving 34 CKP sensor signals per crankshaft revolution

Scheme 298

Scheme 298: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the engine switch on (IG) and turn the Techstream on.
  3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) .
  4. Turn the engine switch off and wait for 30 seconds.
  5. Turn the engine switch on (IG) and turn the Techstream on [A].
  6. Start the engine.
  7. Idle the engine for 20 seconds or more [B].
  8. Enter the following menus: Powertrain / Engine / Trouble Codes.
  9. Read the DTC [C].
  10. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
  11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  12. Input the DTC: P0335 or P0039.
  13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
  14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
  16. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-396630-S12048003312011050900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 299

Scheme 299: WIRING DIAGRAM
