Automatic Transaxle System: Wiring Kia Sedona II

Automatic Trans 12 illustrations ~646 words

SCHEMATIC DIAGRAM

Refer to DTC P0707 .

Refer to DTC P0712 .

Refer to DTC P0743 .

Scheme 105

Scheme 105: SIGNAL WAVEFORM

Scheme 106

Scheme 106: MONITOR SCANTOOL DATA
  1. Connect scantool to data link connector (DLC).
  2. Engine "ON".
  3. Monitor the "PRESS CONTROL SOL. VALVE" parameter on the scantool.
  4. Shift gear at each position.
  5. Does "PRESS CONTROL SOL DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269576-S01020118602007110100000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-269576-S24322784172007110100000) " procedure.

Refer to DTC P0743 .

Scheme 107

Scheme 107: SIGNAL WAVEFORM

Scheme 108

Scheme 108: MONITOR SCANTOOL DATA
  1. Connect scantool to data link connector (DLC).
  2. Engine "ON".
  3. Monitor the "LR SOL. VALVE" parameter on the scantool.
  4. Shift gear at each position.
  5. Does "LR SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269576-S41293745372007110100000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-269576-S25355503162007110100000) " procedure.

Refer to DTC P0750 .

Scheme 109

Scheme 109: SIGNAL WAVEFORM

Scheme 110

Scheme 110: MONITOR SCANTOOL DATA
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "UD SOL. VALVE" parameter on the scantool.
  4. Shift gear at each position.
  5. Does "UD SOLENOID DUTY" follow the reference data?

YES

  1. Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269576-S21307648742007110100000) " procedure.

NO

  1. Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-269576-S22954269732007110100000) " procedure.

Refer to DTC P0750 .

Scheme 111

Scheme 111: SIGNAL WAVEFORM

Scheme 112

Scheme 112: MONITOR SCANTOOL DATA
  1. Connect scantool to data link connector (DLC).
  2. Engine "ON".
  3. Monitor the "2nd SOL. VALVE" parameter on the scantool.
  4. Shift gear at each position.
  5. Does "2nd SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269576-S27697581442007110100000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-269576-S32524416922007110100000) " procedure.

Refer to DTC P0750 .

Scheme 113

Scheme 113: SIGNAL WAVEFORM

Scheme 114

Scheme 114: MONITOR SCANTOOL DATA
  1. Connect scantool to data link connector (DLC).
  2. Engine "ON".
  3. Monitor the "OD SOL. VALVE" parameter on the scantool.
  4. Shift gear at each position.
  5. Does "OD SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269576-S42340918572007110100000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-269576-S25122874152007110100000) " procedure.

Refer to DTC P0750 .

Scheme 115

Scheme 115: SIGNAL WAVEFORM

Scheme 116

Scheme 116: MONITOR SCANTOOL DATA
  1. Connect scantool to data link connector (DLC).
  2. Engine "ON".
  3. Monitor the "RED SOL. VALVE" parameter on the scantool.
  4. Shift gear at each position.
  5. Does "RED SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269576-S08556135062007110100000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-269576-S34868932162007110100000) " procedure.

Refer to DTC P0885 .

Refer to DTC P0885 .
