Automatic Transaxle Control System: Overview Kia Sedona II

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

1. Remove the console upper cover (A), (see «INTERIOR»(ref-269624) ).
2. Remove the front console cover (A), (see «INTERIOR»(ref-269624) ).
3. Disconnect the connector (A).
4. Remove the shift lever assembly mounting nuts (A).
5. Remove the shift cable mounting nut (A) and cap (B).

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

1. Remove the adjusting pedal relay (A) from the bracket.
2. Remove both sides of the brackets.
3. Remove the shift lever knob (A) by removing the two screws.
4. Disconnect the solenoid connector (A) and remove the indicator panel (B).
5. Remove the switch assembly (A) and "P" position switch assembly.
6. Remove the solenoid (B) and solenoid lever (A).
7. Remove the lever assembly (B) by the mounting bolt (A).
8. Remove the lever (A) and tube (B) by removing the bolt (C).
