Automatic Transaxle System: Removal & Installation Kia Sedona II

Automatic Trans 23 illustrations ~1028 words

REPLACEMENT

If you have a fluid changer, use this changer to replace the fluid. If you do not, replace it using the following procedure.

Scheme 82

Scheme 82: REPLACEMENT
Scheme 82: REPLACEMENT
  1. Disconnect the hose which connects the transmission and the oil cooler.
  2. Start the engine and let the fluid drain out. Running conditions: "N" range with engine idling. CAUTION: The engine should be stopped within one minute after it is started. If the fluid has all drained out before then, the engine should be stopped at that point.
  3. Remove the drain plug (A) from the bottom of the transmission case to drain the fluid.
  4. Install the drain plug via the gasket, and tighten it to the specified torque. TORQUE: 40 ~ 50Nm (400 ~ 500 kgf.cm, 29 ~ 36 Lb-ft)
  5. Pour the new fluid in through the oil filler tube. CAUTION: Stop pouring if the full volume of fluid cannot be poured in.
  6. Repeat the procedure in step (2). NOTE: Check the old fluid for contamination. If it has been contaminated, repeat the steps (5) and (6).
  7. Pour the new fluid in through the oil filler tube.
  8. Reconnect the hose which was disconnected in step (1) above and firmly replace the oil level gauge. (In case of this "replace", this means after wiping off any dirt around the oil level gauge, insert it into the filler tube.)
  9. Start the engine and run it at idle for 1~2 minutes.
  10. Move the select lever through all positions, and then move it to the "N" position.
  11. Drive the vehicle until the fluid temperature rises to the normal temperature (70~80°C), and then check the fluid level again. The fluid level must be at the HOT mark.
  12. Firmly insert the oil level gauge into the oil filler tube.

Scheme 83

Scheme 83: COMPONENT LOCATION
Scheme 83: COMPONENT LOCATION

REMOVAL

CAUTIONUse a cover not to damage the vehicle surface. Disconnect connectors carefully not to be damaged.

Note. Mark wires or hoses for identification.

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85
Scheme 85

Scheme 86

Scheme 86
Scheme 86

Scheme 87

Scheme 87
Scheme 87

Scheme 88

Scheme 88
Scheme 88

Scheme 89

Scheme 89
Scheme 89

Scheme 90

Scheme 90
Scheme 90

Scheme 91

Scheme 91
Scheme 91

Scheme 92

Scheme 92
Scheme 92

Scheme 93

Scheme 93
Scheme 93

Scheme 94

Scheme 94
Scheme 94

Scheme 95

Scheme 95
Scheme 95

Scheme 96

Scheme 96
Scheme 96

Scheme 97

Scheme 97
Scheme 97

Scheme 98

Scheme 98
Scheme 98

Scheme 99

Scheme 99
Scheme 99

Scheme 100

Scheme 100
Scheme 100

Scheme 101

Scheme 101
Scheme 101

Scheme 102

Scheme 102
Scheme 102

Scheme 103

Scheme 103
Scheme 103

Scheme 104

Scheme 104
Scheme 104
  1. Remove the battery (A).
  2. Disconnect the AFS connector (A).
  3. Remove the air cleaner upper cover (B) by loosening the clips (A).
  4. Remove the air cleaner assembly (A).
  5. Disconnect the air cleaner hose (B) by loosening the clamp (A).
  6. Remove the battery tray (B) by removing the four mounting bolts (A).
  7. Disconnect the transaxle wire harness connectors. Remove the inhibitor switch connector (A). Remove the solenoid valve connector (A). Remove the input speed sensor connector (A). Remove the output speed sensor connector (A). Remove the vehicle speed sensor connector (A). Remove the CKP sensor connector (A).
  8. Remove the shift cable by removing the bolt (A) and clip (B).
  9. Disconnect the transaxle oil cooler hoses (A) from the tubes (C) by loosening the clamps (B).
  10. Remove the transaxle mounting bolts (B, C).
  11. Using the SST (09200-38001), hold the engine and transaxle assembly safely.
  12. Remove the transaxle insulator mounting bolt (A).
  13. Remove the front wheels.
  14. Remove the power steering column joint bolt, (see «MECHANICAL POWER STEERING SYSTEM»(ref-269605) )
  15. Lift up the vehicle.
  16. Remove the under cover (A).
  17. Drain transaxle oil.
  18. Drain power steering oil through the return tube, (see «MECHANICAL POWER STEERING SYSTEM»(ref-269605) )
  19. Disconnect the power steering pressure tube (A) from the power steering oil pump.
  20. Disconnect the lower arm, the tie rod end ball joint, the stabilizer bar link from the front knuckle, (see «FRONT SUSPENSION SYSTEM»(ref-269598) )
  21. Remove the roll stopper mounting bolts (A, B).
  22. Remove the mounting bolts from the sub frame by supporting the sub frame with a jack, (see «FRONT SUSPENSION SYSTEM»(ref-269598) )
  23. Remove drive shaft from transaxle. (see «DRIVESHAFT»(ref-269594) ).
  24. Install a jack for supporting the transaxle assembly.
  25. Remove the transaxle under mounting bolts (A) and the drive plate bolts (B).
  26. Lifting the vehicle up and lowering the jack slowly, remove the transaxle assembly.

INSTALLATION

Installation is in the reverse order of removal.

Perform the following

  1. Adjust the shift cable.
  2. Refill the transaxle with fluid.
  3. Refill the radiator with engine coolant.
  4. Bleed air from the cooling system with the heater valve open.
  5. Clean the battery posts and cable terminals with sandpaper, assemble them, and apply grease to prevent corrosion.
  1. Lowering the vehicle or lifting up a jack, install the transaxle assembly.
  2. Tighten the transaxle under mounting bolts. TORQUE: 65~85 Nm (650~850 kgf.cm, 47.0~61.5 lb-ft)
  3. Install the starter motor, (see «STARTING SYSTEM»(ref-269579) ). TORQUE: 65~85 Nm (650~850 kgf.cm, 47.0~61.5 lb-ft)
  4. Tighten the transaxle under mounting bolts (A, B). TORQUE:46~53 Nm (460~530 kgf.cm, 33.3~38.3 lb-ft)
  5. After removing a jack, insert the drive shafts, (see «DRIVESHAFT»(ref-269594) )
  6. Install the sub frame, (see «FRONT SUSPENSION SYSTEM»(ref-269598) ).
  7. Tighten the roll stopper mounting bolts (A, B) TORQUE: 90~110 Nm (900~1100 kgf.cm, 65.1~79.5 lb-ft)
  8. Connect the return tube with a clamp, (see «MECHANICAL POWER STEERING SYSTEM»(ref-269605) )
  9. Connect the lower arm, the tie rod end ball joint, the stabilizer bar link to the front knuckle, (see «FRONT SUSPENSION SYSTEM»(ref-269598) )
  10. Connect the power steering pressure tube (A) to the power steering oil pump.
  11. Install the under cover (A).
  12. Install the steering column joint bolt, (see «MECHANICAL POWER STEERING SYSTEM»(ref-269605) ).
  13. Install the front wheels and tires.
  14. Tighten the transaxle insulator mounting bolt (A). TORQUE: 90~110 Nm (900~1100 kgf.cm, 65.1~79.5 lb-ft)
  15. Tighten the transaxle mounting bolts (B, C). TORQUE: 65~85 Nm (650~850 kgf.cm, 47.0~61.5 lb-ft)
  16. Remove the SST (09200-38001) holding the engine and transaxle assembly.
  17. Connect the transaxle oil cooler hoses (A) to the tubes (C) by fastening the clamps (B).
  18. Install the shift cable by tightening the bolt (A) and clip (B). TORQUE: 10~14 Nm (100~140 kgf.cm, 7.2~10.1 lb-ft)
  19. Connect the transaxle wire harness connectors. Install the inhibitor switch connector (A). Install the solenoid valve connector (A). Install the input speed sensor connector (A). Install the output speed sensor connector (A). Install the vehicle speed sensor connector (A). Install the CKP sensor connector (A).
  20. Install the battery tray (B) by tightening the four mounting bolts (A).
  21. Connect the air cleaner hose (B) by fastening the clamp (A).
  22. Install the air cleaner assembly (A).
  23. Install the air cleaner upper cover (B) by fastening the clips (A).
  24. Connect the AFS connector (A).
  25. Install the battery (A).
