Automatic Transaxle System: Other Kia Sedona II

Automatic Trans 27 illustrations ~952 words

CLUTCHES AND BRAKES FOR EACH RANGE

UD ClutchOD Clutch2ND BrakeLR BrakeREV ClutchRED BrakeDIR ClutchOWC1OWC 2
POO
ROOO
NOO
D1stOOO
2ndOOO
3rdOOO
4thOOO
5thOOO
(•: Locked when driving)

CLUTCH AND BRAKE RANGE

FUNCTIONS OF CLUTCHES AND BRAKES

ElementSignFunction
Underdrive clutchUDConnect the input shaft with the underdrive sun gear
Reverse clutchREVConnect the input shaft with the reverse sun gear
Overdrive clutchODConnect the input shaft with the overdrive carrier
Direct clutchDIRConnect the direct sun gear with the direct carrier
Low & Reverse brakeLRFix the planetary gear and the overdrive carrier
2nd brake2NDFix the reverse sun gear
Reduction brakeREDFix the direct sun gear
One way clutch 1OWC 1Control the rotational driection of the low & reverse ring gear
One way clutch 2OWC 2Control the rotational driection of the direct sun gear

CLUTCH AND BRAKE FUNCTION CHART

Scheme 117

Scheme 117: P/N

Scheme 118

Scheme 118: D (1 RANGE)

Scheme 119

Scheme 119: D (2 RANGE)

Scheme 120

Scheme 120: D (3 RANGE)

Scheme 121

Scheme 121: D (4 RANGE)

Scheme 122

Scheme 122: D (5 RANGE)

Scheme 123

Scheme 123: R RANGE

VERIFICATION OF VEHICLE REPAIR

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTCs)" mode.
  2. Using a scantool, Clear DTC.
  3. Operate the vehicle within DTC Enable conditions in General information.
  4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

MONITOR SCANTOOL DATA

Refer to DTC P0707 .

Refer to DTC P0707 .

Scheme 124

Scheme 124: COMPONENT LOCATION

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTCs)" mode.
  2. Using a scantool, Clear DTC.
  3. Operate the vehicle within DTC Enable conditions in General information.
  4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Refer to DTC P0712 .

Refer to DTC P0712 .

Scheme 125

Scheme 125: COMPONENT LOCATION

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
  2. Using a scan tool, Clear DTC.
  3. Operate the vehicle within DTC Enable conditions in General information.
  4. Is resistance within specification? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Refer to DTC P0717 .

Scheme 126

Scheme 126: COMPONENT LOCATION

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTCs)" mode.
  2. Using a scantool, Clear DTC.
  3. Operate the vehicle within DTC Enable conditions in General information.
  4. Are any DTCs present ? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 127

Scheme 127: COMPONENT LOCATION

Refer to DTC P0731 .

Scheme 128

Scheme 128: COMPONENT LOCATION

Refer to DTC P0731 .

Scheme 129

Scheme 129: COMPONENT LOCATION

Go to " SIGNAL CIRCUIT INSPECTION " procedure.

OPERATING ELEMENT OF EACH SHIFTING RANGE

GEAR POSITIONELEMENT
L/R BRAKE2ND BRAKEU/D CLUTCHO/D CLUTCHRED BRAKEDIR CLUTCHREV CLUTCH0WC10WC2
1stOOO
2ndOOO
3rdOOO
4thOOO
5thOOO
REVOOO
N, POO

OPERATING ELEMENT OF EACH SHIFTING RANGE

Low & Reverse Brake is released When the vehicle speed over the 5MPH (7km/h)

Scheme 130

Scheme 130: SIGNAL CIRCUIT INSPECTION
  1. Connect Scantool.
  2. Engine "ON".
  3. Monitor the "INPUT & OUTPUT SPEED SENSOR" parameter on the scantool.
  4. Accelerate the Engine speed until about 2000 RPM in the 4th gear. Specification: INPUT SPEED - (OUTPUT SPEED x GEAR RATIO) < or = 200 RPM
  5. Is "INPUT & OUTPUT SPEED SENSOR" within specifications? YES Go to " «COMPONENT INSPECTION»(ref-269576-S08041867542007110100000) " procedure. NO Check for electrical noise of circuit in INPUT & OUTPUT SPEED SENSOR or Replace INPUT & OUTPUT SPEED SENSOR. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269576-S15833780392007110100000) " procedure.

Scheme 131

Scheme 131: COMPONENT INSPECTION
  1. Connect oil pressure gauge to "2ND" and "OD" and "RED" port.
  2. Engine "ON".
  3. Drive a car with gear position 4 in "SPORTS MODE".
  4. Compare it with reference data as below. Specification: refer to Standard Oil Pressure Table ( «DTC P0731»(ref-269576-S14206638092007110100000) )
  5. Is oil pressure value within specifications? YES Repair AUTO TRANSAXLE (Clutch or Brake) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269576-S15833780392007110100000) " procedure. NO Replace AUTO TRANSAXLE (BODY CONTROL VALVE faulty) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269576-S15833780392007110100000) " procedure.

Refer to DTC P0731 .

Scheme 132

Scheme 132: COMPONENT LOCATION

Go to " SIGNAL CIRCUIT INSPECTION " procedure

GEAR POSITIONELEMENT
L/R BRAKE2ND BRAKEU/D CLUTCHO/D CLUTCHRED BRAKEDIR CLUTCHREV CLUTCH0WC10WC2
1stOOO
2ndOOO
3rdOOO
4thOOO
5thOOO
REVOOO
N, POO

OPERATING ELEMENT OF EACH SHIFTING RANGE

Low & Reverse Brake is released When the vehicle speed over the 5MPH (7km/h)

Scheme 133

Scheme 133: SIGNAL CIRCUIT INSPECTION
  1. Connect Scan tool.
  2. Engine "ON".
  3. Monitor the "INPUT & OUTPUT SPEED SENSOR" parameter on the scan tool.
  4. Accelerate the Engine speed until about 2000 RPM in the 5th gear. Specification: INPUT SPEED - (OUTPUT SPEED x GEAR RATIO) < or = 200 RPM
  5. Does "INPUT & OUTPUT SPEED SENSOR" follow the reference data? YES Go to " «COMPONENT INSPECTION»(ref-269576-S30392021332007110100000) " procedure. NO Check for electrical noise of circuit in INPUT & OUTPUT SPEED SENSOR or Replace INPUT & OUTPUT SPEED SENSOR. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269576-S34887718652007110100000) " procedure.

Scheme 134

Scheme 134: COMPONENT INSPECTION
  1. Connect oil pressure gauge to "OD" and "2nd" and "DIR" port.
  2. Engine "ON".
  3. Drive a car with gear position "5".
  4. Compare it with reference data as below. Specification: refer to Standard Oil Pressure Table ( «DTC P0731»(ref-269576-S14206638092007110100000) )
  5. Is oil pressure value within specification? YES Repair AUTO TRANSAXLE (Clutch or Brake) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269576-S34887718652007110100000) " procedure. NO Replace AUTO TRANSAXLE (BODY CONTROL VALVE faulty) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269576-S34887718652007110100000) " procedure.

Refer to DTC P0731 .

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTCs)" mode.
  2. Using a scantool, Clear DTC.
  3. Operate the vehicle within DTC Enable conditions in General information.
  4. Are any DTCs present ? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Refer to DTC P0741 .

Scheme 135

Scheme 135: COMPONENT LOCATION

Refer to DTC P0741 .

Scheme 136

Scheme 136: COMPONENT LOCATION

Refer to DTC P0741 .

Scheme 137

Scheme 137: COMPONENT LOCATION

Refer to DTC P0741 .

Scheme 138

Scheme 138: COMPONENT LOCATION

Refer to DTC P0750 .

Scheme 139

Scheme 139: COMPONENT LOCATION

Refer to DTC P0750 .

Scheme 140

Scheme 140: COMPONENT LOCATION

Refer to DTC P0750 .

Scheme 141

Scheme 141: COMPONENT LOCATION

Refer to DTC P0750 .

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTCs)" mode.
  2. Using a scantool, Clear DTC.
  3. Operate the vehicle within DTC Enable conditions in General information.
  4. Are any DTCs present ? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Refer to DTC P0885 .

Refer to DTC P0885 .

Refer to DTC P0885 .

Refer to DTC P0885 .

Scheme 142

Scheme 142: COMPONENTS

Scheme 143

Scheme 143
