Automatic Transaxle System Diagnosis: Specifications Kia Rio III

Specification

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & engine "OFF".
3. Select "Current Data" mode and monitor "Inhibitor switch" parameter.
4. Change a shift lever from P-range to D-range.
5. Is the Inhibitor switch value changed in specification? YES Fault is intermittent caused by poor contact of PCM and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S26827370072013031400000) " procedure. NO Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-536170-S41030190572013031400000) " procedure.

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & engine "OFF".
3. Selet "Current Data" mode and monitor "Inhibitor switch" parameter.
4. Change a shift lever from P-range to D-range.
5. Is the Inhibitor switch value changed in specification? YES Fault is intermittent caused by poor contact of PCM and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S14058023062013031400000) " procedure. NO Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-536170-S39706552682013031400000) " procedure.

Scheme 155

Scheme 156

Scheme 157

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Selet "Current Data" mode and monitor "Oil temperature sensor" parameter. Specification : Increasing Gradually
4. Is the Oil temperature sensor within specification? YES Fault is intermittent caused by poor contact of PCM and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S18833592522013031400000) " procedure. NO Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-536170-S05838869432013031400000) " procedure.

Scheme 158

Scheme 159

Scheme 160

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Selet "Current Data" mode and monitor "Oil temperature sensor" parameter. Specification : Increasing Gradually
4. Is the Oil temperature sensor within specification? YES Fault is intermittent caused by poor contact of PCM and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S41102294662013031400000) " procedure. NO Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-536170-S10691977842013031400000) " procedure.

Scheme 161

Scheme 162

Scheme 163

Scheme 164

Scheme 165

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

Scheme 171

Scheme 172

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Selet "Current Data" mode and monitor "Input speed sensor(PG-A)" parameter.
4. Driving above 20 Km/h. Specification : Increasing Gradually
5. Is measured "Input speed sensor" value within specification? YES Fault is intermittent caused by poor contact between TCM and Sensor, and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S40332683792013031400000) " procedure. NO Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-536170-S23940157022013031400000) " procedure.

OPERATING STEP TABLE AT EACH STATUS

Scheme 173

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Selet "Current Data" mode and monitor "Output speed sensor(PG-B)" parameter.
4. Driving above 20 Km/h. Specification : Increasing Gradually
5. Is measured "Output speed sensor" value within specification? YES Fault is intermittent caused by poor contact between TCM and Sensor, and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S32680231662013031400000) " procedure. NO Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-536170-S07080640342013031400000) " procedure.

OPERATING STEP TABLE AT EACH STATUS

Scheme 186

Scheme 187

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Selet "Current Data" mode and monitor "Engine speed, Input speed sensor(PG-A), Output speed sensor(PG-B) and Gear position" parameter.
4. Disconnect Inhibitor switch for locked into 3rd gear and do "Stall Test". Specification : 2200 ~ 2900 engine rpm OPERATING STEP TABLE AT EACH STATUS Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P o o o o 1st o o 2nd o o o 3rd o o 4th o 5th o o 6th o o o L o o REV o o o o: Connected status : Connected at Vehicle speed above 8km/h Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • o • D2 • • D3 • • D4 • • D5 • • D6 • • o: Operated at Vehicle speed under 5km/h NOTE: The process of "Stall Test" and Cause at D-RANGE 3RD SPEED The process of "Stall Test" Warm engine enough. Disconnect valve badly for locked into 3rd gear and Measure the highest engine speed by full accelerating. * If slip is happened at D-RANGE 3RD SPEED, then It must be detected by stall test at D-RANGE 3RD SPEED. Cause If there isn't mechanical fault in Transmission then the toque converter absorb all slips. So only engine speed value is changed but input/output speed sensor value is zero by wheel locking. If D-RANGE 3RD SPEED is fault then input speed sensor has some value at above status. If Output speed sensor value isn't zero, cause by not enough braking, so Do test again with full braking.
5. Is measured value within specification? YES Go to " «SIGNAL CIRCUIT INSPECTION»(ref-536170-S01336740332013031400000) " procedure. NO Go to " «COMPONENT INSPECTION»(ref-536170-S23912854912013031400000) " procedure. CAUTION: Make it sure that anybody isn't near testing vehicle during test, vehicle can be moved. Check ATF gage status, temperature and Engine Coolant Temperature. ATF gage status: check gage appoint "HOT". ATF temperature: 80~100 °C. Coolant Temperature: 80~100 °C. Set sticks at each wheels. Set Parking Brake and push brake pedal with all force. Do not "Stall Test" over 8 sec. If do "Stall Test" over 2 times then ATF temperature should be down by Engine speed(about 1000rpm) down and changed Shift lever "N-Range".

Scheme 188

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Selet "Current Data" mode and monitor "Engine speed, Input speed sensor(PG-A), Output speed sensor(PG-B) and Gear position" parameter used select option.
4. Engine speed up to about 2000rpm and check Input speed(PG-A)&Output speed(PG-B) are within specific at 3rd speed of gear. Specification Output speed>(input speed+200rpm)/3rd. gear ratio Output speed<(input speed-200rpm)/3rd. gear ratio
5. Are measured Input speed(PG-A)&Output speed(PG-B) within specifiction? YES Go to " «COMPONENT INSPECTION»(ref-536170-S23912854912013031400000) " procedure. NO Check there are electrical noise at Inout/output speed and Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S30237631682013031400000) " procedure.

Scheme 189

1. Connect oil pressure gage at "UD brake" port and "3/5/R brake" port.
2. Engine ON.
3. Driving with 3rd speed of gear at sports mode.
4. Check by below specification table. Specification : See below specification table Shiftlever position RPM Solenoid current(mA) ON/OFF Solenoid Pressure(kgf/cm 2 ) UD/B OD/C 26/B 35R/C LP T/CON SS-A SS-B UD/C OD/C 26/B 35R/C LR/B RED1 RED2 DR DA D1 2500 0 852 0 852 0 0 OFF OFF 16.2±0.4 - 0.1 under - - 5.0±0.2 5.5±0.2 7.3±0.4 4.4±0.4 ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 0.6~1.4 - - - - - - - - ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 2.7~3.1 - - - - - - - - ↑ 500 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 4.6~5.4 - - - - - - - - D2 ↑ 0 852 852 852 0 0 OFF OFF 15~17.5 - 162.2±0.4 0.03~0.4 - 5.0±0.2 5.5±0.2 - - ↑ ↑ ↑ 352 ↑ ↑ ↑ ↑ ↑ - - 0.9~1.7 - - - - - - ↑ ↑ ↑ 452 ↑ ↑ ↑ ↑ ↑ - - 2.8~3.2 - - - - - - ↑ ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ - - 4.6~5.4 - - - - - - D3 ↑ 0 852 0 0 0 0 OFF ON 15~17.5 0.03~0.4 - 16.2±0.4 0.03~0.4 5.0±0.5 5.5±0.5 - - ↑ ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ - - - 0.4~1.2 - - - - - ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ ↑ - - - 2.5~2.9 - - - - - ↑ ↑ ↑ ↑ 500 ↑ ↑ ↑ ↑ - - - 4.3~5.1 - - - - - D4 ↑ 0 0 0 852 0 0 OFF OFF 15~17.5 15~17.5 - - - 5.0±0.5 5.5±0.5 - - ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ - 0.6~1.4 - - - - - - - ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ ↑ - 2.2~2.6 - - - - - - - D5 ↑ 852 0 0 0 0 0 OFF ON 0.03~0.4 16.2±0.4 - 15~17.5 - 5.0±0.5 5.5±0.5 - - D6 ↑ 852 0 852 852 0 852 OFF OFF - 15~17.5 15~17.5 - - 5.0±0.5 5.5±0.5 0~0.2 7.7~8.4 ↑ ↑ ↑ ↑ ↑ 400 ↑ ↑ ↑ - 2.5~13.5 - - - - - - - ↑ ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ - 8.1~9.1 - - - - - - - ↑ ↑ ↑ ↑ ↑ 852 ↑ ↑ ↑ - 4.0~5.0 - - - - - - - ↑ ↑ ↑ ↑ ↑ 0 552 OFF OFF - - - - - - - DA-DR:3.2~4.2 ↑ ↑ ↑ ↑ ↑ ↑ 452 ↑ ↑ - - - - - - - DA-DR:1.3~2.3 L ↑ 0 0 0 852 0 0 ON OFF 15~17.5 - - - 16.2±0.4 - - - - D1 600 0 852 0 852 0 0 OFF OFF Above 7 (1) - - - - - - - - N ↑ 852 0 0 852 0 0 ON OFF - - - - Above 7 5.0±0.5 5.5±0.5 - - R 2500 852 852 0 0 0 0 OFF ON - - - 15~17.5 16±1 5.0±0.5 5.5±0.5 - - (1) A6LF1, 2, 3: Above 7 A6MF1, 2: Above 6 Above specification value can be different by vehicle model/measured variation.
5. Is measured oil pressure value within specification? YES Repair automatic transmission and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S30237631682013031400000) " procedure. NO Repair automatic transmission(valve body) and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S30237631682013031400000) " procedure.

OPERATING STEP TABLE AT EACH STATUS

Scheme 190

Scheme 191

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Selet "Current Data" mode and monitor "Engine speed, Input speed sensor(PG-A), Output speed sensor(PG-B) and Gear position" parameter.
4. Disconnect Solenoid valve for locked into 4th gear and do "Stall Test". Specification : 2200 ~ 2900 engine rpm OPERATING STEP TABLE AT EACH STATUS Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P o o o o 1st o o 2nd o o o 3rd o o 4th o 5th o o 6th o o o L o o REV o o o o: Connected status : Connected at Vehicle speed above 8km/h Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • o • D2 • • D3 • • D4 • • D5 • • D6 • • o: Operated at Vehicle speed under 5km/h NOTE: The process of "Stall Test" and Cause at D-RANGE 4TH SPEED The process of "Stall Test" Warm engine enough. Disconnect Solenoid valve connector for locked into 4th gear and Measure the highest engine speed by full accelerating. * If slip is happened at D-RANGE 4TH SPEED, then It must be detected by stall test at D-RANGE 4TH SPEED. Cause If there isn't mechanical fault in Transmission then the toque converter absorb all slips. So only engine speed value is changed but input/output speed sensor value is zero by wheel locking. If D-RANGE 4TH SPEED is fault then input speed sensor has some value at above status. If Output speed sensor value isn't zero, cause by not enough braking, so Do test again with full braking.
5. Is measured value within specification? YES Go to " «SIGNAL CIRCUIT INSPECTION»(ref-536170-S09231577972013031400000) " procedure. NO Go to " «COMPONENT INSPECTION»(ref-536170-S02751399702013031400000) " procedure.

Scheme 192

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Selet "Current Data" mode and monitor "Engine speed, Input speed sensor(PG-A), Output speed sensor(PG-B) and Gear position" parameter used select option.
4. Engine speed up to about 2000rpm and check Input speed(PG-A)&Output speed(PG-B) are within specific at 4th speed of gear. Specification Output speed>(input speed+200rpm)/4th. gear ratio Output speed<(input speed-200rpm)/4th. gear ratio
5. Are measured Input speed(PG-A)&Output speed(PG-B) within specifiction? YES Go to " «COMPONENT INSPECTION»(ref-536170-S02751399702013031400000) " procedure. NO Check there are electrical noise at Inout/output speed and Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S11425843792013031400000) " procedure.

Scheme 193

1. Connect oil pressure gage at "UD brake" port and "OD Clutch" port.
2. Engine ON.
3. Driving with 4th speed of gear at sports mode.
4. Check by below specification table. Specification : See below specification table Shiftlever position RPM Solenoid current(mA) ON/OFF Solenoid Pressure(kgf/cm 2 ) UD/B OD/C 26/B 35R/C LP T/CON SS-A SS-B UD/C OD/C 26/B 35R/C LR/B RED1 RED2 DR DA D1 2500 0 852 0 852 0 0 OFF OFF 16.2±0.4 - 0.1 under - - 5.0±0.2 5.5±0.2 7.3±0.4 4.4±0.4 ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 0.6~1.4 - - - - - - - - ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 2.7~3.1 - - - - - - - - ↑ 500 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 4.6~5.4 - - - - - - - - D2 ↑ 0 852 852 852 0 0 OFF OFF 15~17.5 - 162.2±0.4 0.03~0.4 - 5.0±0.2 5.5±0.2 - - ↑ ↑ ↑ 352 ↑ ↑ ↑ ↑ ↑ - - 0.9~1.7 - - - - - - ↑ ↑ ↑ 452 ↑ ↑ ↑ ↑ ↑ - - 2.8~3.2 - - - - - - ↑ ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ - - 4.6~5.4 - - - - - - D3 ↑ 0 852 0 0 0 0 OFF ON 15~17.5 0.03~0.4 - 16.2±0.4 0.03~0.4 5.0±0.5 5.5±0.5 - - ↑ ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ - - - 0.4~1.2 - - - - - ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ ↑ - - - 2.5~2.9 - - - - - ↑ ↑ ↑ ↑ 500 ↑ ↑ ↑ ↑ - - - 4.3~5.1 - - - - - D4 ↑ 0 0 0 852 0 0 OFF OFF 15~17.5 15~17.5 - - - 5.0±0.5 5.5±0.5 - - ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ - 0.6~1.4 - - - - - - - ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ ↑ - 2.2~2.6 - - - - - - - D5 ↑ 852 0 0 0 0 0 OFF ON 0.03~0.4 16.2±0.4 - 15~17.5 - 5.0±0.5 5.5±0.5 - - D6 ↑ 852 0 852 852 0 852 OFF OFF - 15~17.5 15~17.5 - - 5.0±0.5 5.5±0.5 0~0.2 7.7~8.4 ↑ ↑ ↑ ↑ ↑ 400 ↑ ↑ ↑ - 2.5~13.5 - - - - - - - ↑ ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ - 8.1~9.1 - - - - - - - ↑ ↑ ↑ ↑ ↑ 852 ↑ ↑ ↑ - 4.0~5.0 - - - - - - - ↑ ↑ ↑ ↑ ↑ 0 552 OFF OFF - - - - - - - DA-DR:3.2~4.2 ↑ ↑ ↑ ↑ ↑ ↑ 452 ↑ ↑ - - - - - - - DA-DR:1.3~2.3 L ↑ 0 0 0 852 0 0 ON OFF 15~17.5 - - - 16.2±0.4 - - - - D1 600 0 852 0 852 0 0 OFF OFF Above 7 (1) - - - - - - - - N ↑ 852 0 0 852 0 0 ON OFF - - - - Above 7 5.0±0.5 5.5±0.5 - - R 2500 852 852 0 0 0 0 OFF ON - - - 15~17.5 16±1 5.0±0.5 5.5±0.5 - - (1) A6LF1, 2, 3: Above 7 A6MF1, 2: Above 6 Above specification value can be different by vehicle model/measured variation.
5. Is measured oil pressure value within specification? YES Repair automatic transmission and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S11425843792013031400000) " procedure. NO Repair automatic transmission(valve body) and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S11425843792013031400000) " procedure.

OPERATING STEP TABLE AT EACH STATUS

Scheme 194

OPERATING STEP TABLE AT EACH STATUS

Scheme 195

Scheme 196

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Selet "Current Data" mode and monitor "Engine speed, Input speed sensor(PG-A), Output speed sensor(PG-B) and Gear position" parameter.
4. Do a stall test at 1st speed of gear. Specification : 2200 ~ 2900 engine rpm OPERATING STEP TABLE AT EACH STATUS Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P o o o o 1st o o 2nd o o o 3rd o o 4th o 5th o o 6th o o o L o o REV o o o o: Connected status : Connected at Vehicle speed above 8km/h Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • o • D2 • • D3 • • D4 • • D5 • • D6 • • o: Operated at Vehicle speed under 5km/h NOTE: The process of "Stall Test" and Cause at D-RANGE 1ST SPEED The process of "Stall Test" Warm engine enough. Measure the highest engine speed by full accelerating at D-RANGE 1ST SPEED. * If slip is happened at D-RANGE 1ST SPEED, then It must be detected by stall test at D-RANGE 1ST SPEED. Cause If there isn't mechanical fault in Transmission then the toque converter absorb all slips. So only engine speed value is changed but input/output speed sensor value is zero by wheel locking. If D-RANGE 1ST SPEED is fault then input speed sensor has some value at above status. If Output speed sensor value isn't zero, cause by not enough braking, so Do test again with full braking.
5. Is measured value within specification? YES Go to " «SIGNAL CIRCUIT INSPECTION»(ref-536170-S16083272262013031400000) " procedure. NO Go to " «COMPONENT INSPECTION»(ref-536170-S09694880482013031400000) " procedure.

Scheme 197

1. Connect scantool to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Selet "Current Data" mode and monitor "Engine speed, Input speed sensor(PG-A), Output speed sensor(PG-B) and Gear position" parameter used select option.
4. Engine speed up to about 2000rpm and check Input speed(PG-A)&Output speed(PG-B) are within specific at 1st speed of gear. Specification : Output speed<(input speed-200rpm)/1st. gear ratio
5. Are measured Input speed(PG-A)&Output speed(PG-B) within specifiction? YES Go to " «COMPONENT INSPECTION»(ref-536170-S09694880482013031400000) " procedure. NO Check there are electrical noise at Inout/output speed and Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S05672062772013031400000) " procedure.

Scheme 198

1. Connect oil pressure gage at "UD" port and "L/R" port.
2. Engine ON.
3. Driving with 1st speed of gear at sports mode.
4. Check by below specification table. Specification : See below specification table Shiftlever position RPM Solenoid current(mA) ON/OFF Solenoid Pressure(kgf/cm 2 ) UD/B OD/C 26/B 35R/C LP T/CON SS-A SS-B UD/C OD/C 26/B 35R/C LR/B RED1 RED2 DR DA D1 2500 0 852 0 852 0 0 OFF OFF 16.2±0.4 - 0.1 under - - 5.0±0.2 5.5±0.2 7.3±0.4 4.4±0.4 ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 0.6~1.4 - - - - - - - - ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 2.7~3.1 - - - - - - - - ↑ 500 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 4.6~5.4 - - - - - - - - D2 ↑ 0 852 852 852 0 0 OFF OFF 15~17.5 - 162.2±0.4 0.03~0.4 - 5.0±0.2 5.5±0.2 - - ↑ ↑ ↑ 352 ↑ ↑ ↑ ↑ ↑ - - 0.9~1.7 - - - - - - ↑ ↑ ↑ 452 ↑ ↑ ↑ ↑ ↑ - - 2.8~3.2 - - - - - - ↑ ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ - - 4.6~5.4 - - - - - - D3 ↑ 0 852 0 0 0 0 OFF ON 15~17.5 0.03~0.4 - 16.2±0.4 0.03~0.4 5.0±0.5 5.5±0.5 - - ↑ ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ - - - 0.4~1.2 - - - - - ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ ↑ - - - 2.5~2.9 - - - - - ↑ ↑ ↑ ↑ 500 ↑ ↑ ↑ ↑ - - - 4.3~5.1 - - - - - D4 ↑ 0 0 0 852 0 0 OFF OFF 15~17.5 15~17.5 - - - 5.0±0.5 5.5±0.5 - - ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ - 0.6~1.4 - - - - - - - ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ ↑ - 2.2~2.6 - - - - - - - D5 ↑ 852 0 0 0 0 0 OFF ON 0.03~0.4 16.2±0.4 - 15~17.5 - 5.0±0.5 5.5±0.5 - - D5 ↑ 852 0 852 852 0 852 OFF OFF - 15~17.5 15~17.5 - - 5.0±0.5 5.5±0.5 0~0.2 7.7~8.4 ↑ ↑ ↑ ↑ ↑ 400 ↑ ↑ ↑ - 2.5~13.5 - - - - - - - ↑ ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ - 8.1~9.1 - - - - - - - ↑ ↑ ↑ ↑ ↑ 852 ↑ ↑ ↑ - 4.0~5.0 - - - - - - - ↑ ↑ ↑ ↑ ↑ 0 552 OFF OFF - - - - - - - DA-DR:3.2~4.2 ↑ ↑ ↑ ↑ ↑ ↑ 452 ↑ ↑ - - - - - - - DA-DR:1.3~2.3 L ↑ 0 0 0 852 0 0 ON OFF 15~17.5 - - - 16.2±0.4 - - - - D1 600 0 852 0 852 0 0 OFF OFF Above 7 (1) - - - - - - - - N ↑ 852 0 0 852 0 0 ON OFF - - - - Above 7 5.0±0.5 5.5±0.5 - - R 2500 852 852 0 0 0 0 OFF ON - - - 15~17.5 16±1 5.0±0.5 5.5±0.5 - - (1) A6LF1, 2, 3: Above 7 A6MF1, 2: Above 6 Above specification value can be different by vehicle model/measured variation.
5. Is measured oil pressure value within specification? YES Repair automatic transmission and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S05672062772013031400000) " procedure. NO Repair automatic transmission(valve body) and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S05672062772013031400000) " procedure.

OPERATING STEP TABLE AT EACH STATUS

Scheme 199

1. Supplied pressure 5.5 kgf/cm 2 (Controlled pressure area 0~5.5)
2. Working temperature: -40°C~150°C
3. Internal resistance: 5.1 ± 0.3 ohms(25°C normal temperature)
4. Hysteresis: 0.3 kgf/cm 2

Scheme 200

Scheme 201

Scheme 202

Scheme 203

Scheme 204

Scheme 205

* Working above 3rd speed, but it may be working or not by driving variation at 3rd speed.

Scheme 206

Scheme 207

Scheme 208

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Selet "Current Data" mode and monitor "Torque converter clutch" parameter. Specification : See below data
5. Is Torque converter clutch value within specification? YES Fault is intermittent caused by poor contact of PCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S07499443222013031400000) " procedure. NO Go to " «COMPONENT INSPECTION»(ref-536170-S02025691512013031400000) " procedure.

Scheme 214

Scheme 215

1. DC Solenoid valve Inspection Ignition OFF. Disconnect ATM Solenoid valve connector. Measure resistance between DC solenoid vale terminal of ATM Solenoid valve component and ON/START power. Specification : 5.1 ± 0.3 ohms(25°C) Is measured resistance within specification? YES Substitute with a known-good PCM and check for proper operation. If the problem is corrected, replace PCM and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S07499443222013031400000) " procedure. NO Exchange with a known-good DC Solenoid valve and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S07499443222013031400000) " procedure.

1. Working temperature: -40°C~150°C
2. Internal resistance: 5.1 ± 0.3 ohms(25°C normal temperature)

Scheme 216

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Scheme 221

* Working above 3rd speed, but it may be working or not by driving variation at 3rd speed.

Scheme 222

Scheme 223

Scheme 224

Scheme 225

Scheme 226

Scheme 227

Scheme 228

Scheme 229

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Selet "Current Data" mode and monitor "Torque converter clutch" parameter.
5. Is Torque converter clutch value within specification? YES Fault is intermittent caused by poor contact of PCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S26353987922013031400000) " procedure. NO Go to " «COMPONENT INSPECTION»(ref-536170-S42229127752013031400000) " procedure.

1. Working temperature: -40°C~150°C
2. Internal resistance: 5.1 ± 0.3 ohms(25°C normal temperature)

Scheme 230

Scheme 231

Scheme 232

Scheme 233

Scheme 234

Scheme 235

Scheme 236

Scheme 237

Scheme 238

Scheme 239

Scheme 240

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Selet "Current Data" mode and monitor "Pressure Control Solenoid Valve" parameter. Specification : See below data
5. Is Pressure Control Solenoid Valve within specification? YES Fault is intermittent caused by poor contact of PCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S40533786492013031400000) " procedure. NO Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-536170-S19092731802013031400000) " procedure.

OPERATING STEP TABLE AT EACH STATUS

Scheme 241

Scheme 242

Scheme 243

Scheme 244

Scheme 245

Scheme 246

Scheme 247

Scheme 248

Scheme 249

Scheme 250

Scheme 251

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Selet "Current Data" mode and monitor "Shift Control Solenoid Valve(UD-VFS)" parameter current value. Specification : See below data OPERATING STEP TABLE AT EACH STATUS Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P o o o o 1st o o 2nd o o o 3rd o o 4th o 5th o o 6th o o o L o o REV o o o o: Connected status : Connected at Vehicle speed above 8km/h Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • o • D2 • • D3 • • D4 • • D5 • • D6 • • o: Operated at Vehicle speed under 5km/h
5. Is Shift Control Solenoid Valve(UD-VFS) within specification? YES Fault is intermittent caused by poor contact of PCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S26279907222013031400000) " procedure. NO Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-536170-S32463044802013031400000) " procedure.

OPERATING STEP TABLE AT EACH STATUS

Scheme 252

Scheme 253

Scheme 254

Scheme 255

Scheme 256

Scheme 257

Scheme 258

Scheme 259

Scheme 260

Scheme 261

Scheme 262

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Selet "Current Data" mode and monitor "Shift Control Solenoid Valve(26/B-VFS)" parameter current value. Specification : See below data OPERATING STEP TABLE AT EACH STATUS Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P o o o o 1st o o 2nd o o o 3rd o o 4th o 5th o o 6th o o o L o o REV o o o o: Connected status : Connected at Vehicle speed above 8km/h Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • o • D2 • • D3 • • D4 • • D5 • • D6 • • o: Operated at Vehicle speed under 5km/h
5. Is Shift Control Solenoid Valve(26/B-VFS) within specification? YES Fault is intermittent caused by poor contact of PCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S09797913552013031400000) " procedure. NO Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-536170-S30916399512013031400000) " procedure.

OPERATING STEP TABLE AT EACH STATUS

1. Working temperature: -40°C~150°C
2. Internal resistance: 5.1 ± 0.3 ohms(25°C normal temperature)

Scheme 263

Scheme 264

Scheme 265

Scheme 266

Scheme 267

Scheme 268

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Selet "Current Data" mode and monitor "Shift Control Solenoid Valve(35R/C-VFS)" parameter current value. Specification : See below data OPERATING STEP TABLE AT EACH STATUS Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P o o o o 1st o o 2nd o o o 3rd o o 4th o 5th o o 6th o o o L o o REV o o o o: Connected status : Connected at Vehicle speed above 8km/h Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • o • D2 • • D3 • • D4 • • D5 • • D6 • • o: Operated at Vehicle speed under 5km/h
5. Is Shift Control Solenoid Valve(26/B-VFS) within specification? YES Fault is intermittent caused by poor contact of PCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S17295491542013031400000) " procedure. NO Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-536170-S11516377142013031400000) " procedure.

OPERATING STEP TABLE AT EACH STATUS

1. Working temperature: -40°C~150°C
2. Internal resistance: 5.1 ± 0.3 ohms(25°C normal temperature)

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

Scheme 279

Scheme 280

Scheme 281

Scheme 282

Scheme 283

Scheme 284

Scheme 285

Scheme 286

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Selet "Current Data" mode and monitor "Shift Control Solenoid Valve(OD/C-VFS)" parameter current value. Specification : See below data OPERATING STEP TABLE AT EACH STATUS Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P o o o o 1st o o 2nd o o o 3rd o o 4th o 5th o o 6th o o o L o o REV o o o o: Connected status : Connected at Vehicle speed above 8km/h Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • o • D2 • • D3 • • D4 • • D5 • • D6 • • o: Operated at Vehicle speed under 5km/h
5. Is Shift Control Solenoid Valve(OD/C-VFS) within specification? YES Fault is intermittent caused by poor contact of PCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S25126690942013031400000) " procedure. NO Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-536170-S24008842412013031400000) " procedure.

OPERATING STEP TABLE AT EACH STATUS

1. Working voltage: under 7.5v (Supplied perssure 5.0kgf/cm 2 , Oil temperature 85°C)
2. Release voltage: under 5.5v (Supplied perssure 5.0kgf/cm 2 , Oil temperature 85°C)
3. Release current: under 5.5v (Supplied perssure 0.51kgf/cm 2 , Oil temperature 85°C)
4. Inetrnal resistance: 10 ~ 11 ohms(20°C)

Scheme 287

Scheme 288

Scheme 289

Scheme 290

Scheme 291

Scheme 292

Scheme 293

Scheme 294

Scheme 295

Scheme 296

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Selet "Current Data" mode and monitor "Shift Control Solenoid Valve(SS-A)" parameter current value. Specification : See below data OPERATING STEP TABLE AT EACH STATUS Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P o o o o 1st o o 2nd o o o 3rd o o 4th o 5th o o 6th o o o L o o REV o o o o: Connected status : Connected at Vehicle speed above 8km/h Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • o • D2 • • D3 • • D4 • • D5 • • D6 • • o: Operated at Vehicle speed under 5km/h
5. Is Shift Control Solenoid Valve(SS-A) within specification? YES Fault is intermittent caused by poor contact of PCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S04238141972013031400000) " procedure. NO Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-536170-S37680283842013031400000) " procedure.

OPERATING STEP TABLE AT EACH STATUS

1. Working voltage: under 7.5v (Supplied perssure 5.0kgf/cm 2 , Oil temperature 85°C)
2. Release voltage: under 5.5v (Supplied perssure 5.0kgf/cm 2 , Oil temperature 85°C)
3. Release current: under 5.5v (Supplied perssure 0.51kgf/cm 2 , Oil temperature 85°C)
4. Inetrnal resistance: 10 ~ 11 ohms(20°C)

Scheme 297

Scheme 298

Scheme 299

Scheme 300

Scheme 301

Scheme 302

Scheme 303

Scheme 304

Scheme 305

Scheme 306

1. Connect GDS to Data Link Connector(DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Selet "Current Data" mode and monitor "Shift Control Solenoid Valve(SS-B)" parameter current value. Specification : See below data OPERATING STEP TABLE AT EACH STATUS Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P o o o o 1st o o 2nd o o o 3rd o o 4th o 5th o o 6th o o o L o o REV o o o o: Connected status : Connected at Vehicle speed above 8km/h Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • o • D2 • • D3 • • D4 • • D5 • • D6 • • o: Operated at Vehicle speed under 5km/h
5. Is Shift Control Solenoid Valve(SS-B) within specification? YES Fault is intermittent caused by poor contact of PCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536170-S33074243022013031400000) " procedure. NO Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-536170-S06102365232013031400000) " procedure.
