Description

The hydraulic system consists of oil, an oil filter, an oil pump, and a valve body (valves and solenoid valves). The oil pump is powered by the engine. ATF passes through the oil filter and gets distributed along the oil channels. The oil becomes highly pressurized as it exits the oil pump and passes through the line pressure valve before being fed to the clutch & brake control valve, clutch, and brakes. TCM controls the hydraulic pressure using solenoid valves and controls clutch and brake operations.

Scheme 25

Scheme 25: Components Location

The oil pump is built-in as a single unit with the 26 brake chamber. Rotation of the pump builds the hydraulic pressure needed for the lubrication of the various parts of the transaxle and operation of the clutch and brakes. The oil also circulates through the torque converter and the cooler.

Scheme 26

Scheme 26: Description

Scheme 27

Scheme 27: Components

Scheme 28

Scheme 28: Oil Pump Operation Flow

Scheme 29

Scheme 29: Components Location

The valve body is essential to automatic transaxle control and consists of various valves used to control the oil feed from the oil pump. Specifically, these valves consist of pressure regulator valves, oil redirection valves, shift valves, and manual valves. The body also features electronic solenoid valves that ensure smooth gear changes.

Scheme 30

Scheme 30: Description

Scheme 31

Scheme 31: Components Location

Scheme 32

Scheme 32: Valve Body Flow

Scheme 33

Scheme 33: Removal

Scheme 34

Scheme 34

Scheme 35

Scheme 35

Scheme 36

Scheme 36

Scheme 37

Scheme 37
  1. Remove the battery and the battery tray. (Refer to " «CHARGING SYSTEM»(ref-536081) " in EE group.)
  2. Remove the under cover (A). Tightening torque: 6.9 ~ 10.8 N.m (0.7 ~ 1.1 kgf.m, 5.1 ~ 8.0 lb-ft)
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to 6 .
  4. Remove the valve body cover (B). Tightening torque: 13.7 ~ 15.7 N.m (1.4 ~ 1.6 kgf.m, 10.1 ~ 11.6 lb-ft)
  5. Remove the air breather hose (A).
  6. Remove the plate and the detent spring (A) after removing the bolt. Tightening torque: 11.8 ~ 15.7 N.m (1.2 ~ 1.6 kgf.m, 8.7 ~ 11.6 lb-ft)
  7. Remove the bolt (3ea) after disconnecting the solenoid valve (B) connector and the oil temperature sensor connector (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  8. Remove the valve body assembly (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)

Scheme 38

Scheme 38: Installation
  1. Installation is the reverse of removal. CAUTION: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. NOTE: The gasket of the valve body gasket (A) use new one. Adding automatic transaxle fluid. (Refer to 6 . Perform TCM learning after replacing the valve body to prevent slow transaxle response, jerky acceleration and jerky startup. (Refer to «TCM LEARNING»(ref-536108-S22821437182013031400000) .
