Automatic Transaxle System - General Information: Other Kia Rio III

Automatic Trans 2 illustrations ~273 words

Sensors

Input Speed Sensor

  1. Type: Hall effect sensor
  2. Specifications
Operation condition (°C)°F((-)40 ~ 150)) -40 ~ 302
Air gap(mm)in.(1.2 ~ 1.8) 0.0472 ~ 0.0709
Output voltage(V)High1.18 ~ 1.68
Low0.59 ~ 0.84

Output Speed Sensor

  1. Type: Hall effect sensor
  2. Specifications
Operation condition (°C)°F((-)40 ~ 150)) -40 ~ 302
Air gap(mm)in.(0.85 ~ 1.3) 0.0335 ~ 0.0512
Output voltageHigh1.18 ~ 1.68
Low0.59 ~ 0.84

Oil Temperature Sensor

  1. Type: Negative thermal coefficient type
  2. Specifications
Temp.[(°C)°F]Resistance (kohms)
(-40)-4048.1
(-20)-4.015.6
(0)32.05.88
(20)68.02.51
(40)104.01.11
(60)140.00.61
(80)176.00.32
(100)212.00.18
(120)248.00.10
(140)284.00.06
(150)302.00.05

Inhibitor Switch

  1. Type: Combination of output signals from 4 terminals
  2. Specifications
Power supply (V)12
Output typeCombination of output signals

Solenoid Valves

Direct control VFS[26/B, T/CON]

  1. Control type: Normal low type
Control Pressure kpa (kgf/cm 2 , psi)9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

Direct control VFS[UD/B, OD/C, 35R/C]

  1. Control Type: Normal high type
Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

Line Pressure Control VFS

  1. Control type: Normal high type
Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

ON/OFF Solenoid Valve(SS-A, SS-B)

  1. Control type: Normal low type
Control pressure kpa (kgf/cm 2 , psi)490.33(5.0, 71.12)
Internal resistance(ohms)10 ~ 11

Lubricants

ItemSpecified lubricantQuantity
Transaxle fluidSK ATF SP-[], MICHANG ATF SP-[], NOCA ATF SP-[], Kia Genuine ATF SP-[] or other brands meeting the above specification approved by Kia Motors Corp.7.3L (1.93 U.S gal., 7.71 U.S.qt., 6.42 lmp.qt.)

Sealant

ItemSpecified sealant
Rear coverLOCTITE FMD-546(P/N: UM010CH046) or equivalent
Torque converter housing
Valve body cover

Special Service Tools

Tool (Number and Name) Illustration Use 09200-38001, 3N000 (Beam) 09200-1P100, 4X000 (Adapter) 09200-2S200 (Supporter) Engine support assembly Removal and installation of the transaxle. Use assembling 09200-1P100, 4X000 (Adapter) and 09200-2S200 (Supporter) on 09200-38001, 3N000 (Beam). 09200-3N000 Engine support fixture (Beam) Removal and installation of the transaxle. Use this adapter (SST No.: 09200-1P100, 4X000) with the supporter (SST No.: 09200-2S200). Permit operating with 09200-38001. 09200-1P100 Engine support fixture (Adapter) Removal and installation of the transaxle. Use this beam (SST No.: 09200-38001/09200-3N000) with the supporter (SST No.: 09200-2S200) and adapter (SST No.: 09200-4X000) 09200-4X000 Engine support fixture (Adapter) Removal and installation of the transaxle. Use this beam (SST No.: 09200-38001/3N000) with the supporter (SST No.: 09200-2S200) and adapter (SST No.: 09200-1P100) 09200-2S200 Engine support fixture (Supporter) Removal and installation of the transaxle. Use this beam (SST No.: 09200-38001/09200-3N000) with the adapter (SST No.: 09200-1P100, 4X000) 09452-26100 Oil seal installer Installation of transaxle case oil seal. [Using with handle (SST No.:09231-H1100)] 09231-H1100 Bar Installation of transaxle case oil seal. [Using with oil seal installer (SST No.:09452-26100)] * Engine support fixture special tool assembly drawing

Scheme 1

Scheme 1: Special Service Tools
Scheme 1: Special Service Tools

Scheme 2

Scheme 2
Scheme 2
Engine Support Fixture Parts Call Out
1. 09200-3N000(Main bar)10. 09200-3N000(Snap ring)
2. 09200-3N000(Sub bar)11. 09200-3N000(Sub fixture)
3. 09200-3N000(Handle)12. 09200-3N000(Stopper)
4. 09200-3N000(Stopper)13. 09200-3N000(Nut)
5. 09200-3N000(Bolt-1)14. 09200-2S100(Spacer)
6. 09200-4X000 (Adapter)15. 09200-1P100(Sub fixture)
7. 09200-1P100(Supporter)16. 09200-1P100(Nut)
8. 09200-2S200(Supporter)17. 09200-3N000(Pin)
9. 09200-3N000(Nut)
