Automatic Transaxle Control System: Specifications Kia Rio III

Automatic Trans 16 illustrations ~138 words

Specifications

Type: Negative Thermal Coefficient Type

Temp.[(°C)°F]Resistance (kohms)
(-40)-4048.1
(-20)-4.015.6
(0)32.05.88
(20)68.02.51
(40)104.01.11
(60)140.00.61
(80)176.00.32
(100)212.00.18
(120)248.00.10
(140)284.00.06
(150)302.00.05

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52: Circuit Diagram
Scheme 52: Circuit Diagram

Type: Hall effect sensor

Operation condition [°C(°F)]((-)40 ~ 150)) -40 ~ 302
Air gap(mm)in.(1.2 ~ 1.8) 0.0472 ~ 0.0709
Output voltage(V)High1.18 ~ 1.68
Low0.59 ~ 0.84

Scheme 53

Scheme 53: Circuit Diagram
Scheme 53: Circuit Diagram

Scheme 54

Scheme 54: Signal Waveform
Scheme 54: Signal Waveform

Scheme 55

Scheme 55
Scheme 55

Type: Hall effect sensor

Operation condition [°C(°F)]((-)40 ~ 150)) -40 ~ 302
Air gap(mm)in.(0.85 ~ 1.3) 0.0335 ~ 0.0512
Output voltageHigh1.18 ~ 1.68
Low0.59 ~ 0.84

Scheme 56

Scheme 56: Circuit Diagram
Scheme 56: Circuit Diagram

Scheme 57

Scheme 57: Signal Waveform
Scheme 57: Signal Waveform

Scheme 58

Scheme 58
Scheme 58

Direct control VFS[T/CON]

  1. Control type: Normal low type
Control Pressure kpa (kgf/cm 2 , psi)9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

Scheme 59

Scheme 59: Circuit Diagram
Scheme 59: Circuit Diagram

Direct control VFS[26/B]

  1. Control type: Normal low type
Control Pressure kpa (kgf/cm 2 , psi)9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

Scheme 60

Scheme 60: Circuit Diagram
Scheme 60: Circuit Diagram

Direct control VFS[LINE Pressure]

  1. Control type: Normal low type
Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

Scheme 61

Scheme 61: Circuit Diagram
Scheme 61: Circuit Diagram

Direct control VFS[35R/C]

  1. Control type: Normal low type
Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

Scheme 62

Scheme 62: Circuit Diagram
Scheme 62: Circuit Diagram

Direct control VFS[35R/C]

  1. Control type: Normal low type
Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

Scheme 63

Scheme 63: Circuit Diagram
Scheme 63: Circuit Diagram

Direct control VFS[35R/C]

  1. Control type: Normal low type
Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

Scheme 64

Scheme 64: Circuit Diagram
Scheme 64: Circuit Diagram

ON/OFF Solenoid Valve(SS-A, SS-B)

  1. Control type: Normal low type
Control pressure kpa (kgf/cm 2 , psi)490.33(5.0, 71.12)
Internal resistance(ohms)10 ~ 11

Scheme 65

Scheme 65: Circuit Diagram
Scheme 65: Circuit Diagram

ON/OFF Solenoid Valve(SS-A, SS-B)

  1. Control type: Normal low type
Control pressure kpa (kgf/cm 2 , psi)490.33(5.0, 71.12)
Internal resistance(ohms)10 ~ 11

Scheme 66

Scheme 66: Circuit Diagram
Scheme 66: Circuit Diagram

Type: Combination of output signals from 4 terminals

Power supply (V)12
Output typeCombination of output signals
