Automatic Transaxle Control System: Removal & Installation Kia Rio III

Automatic Trans 14 illustrations ~972 words

Replacement

Note. When replacing the TCM, the vehicle equipped with immobilizer must be performed the procedure as below. [In the case of installing used TCM] Perform "TCM neutralization mode" procedure with GDS. (Refer to " IMMOBILIZER " in BE group) Insert the key and turn it to the IGN ON and OFF position. Then the TCM key register process is completed automatically. [In the case of installing new TCM]- Insert the key and turn it to the IGN ON and OFF position. Then the TCM key register process is completed automatically.

Scheme 119

Scheme 119: Replacement
Scheme 119: Replacement

Scheme 120

Scheme 120
Scheme 120

Scheme 121

Scheme 121
Scheme 121
  1. Turn ignition switch OFF and disconnect the negative (-) battery cable.
  2. Disconnect the TCM connector (A).
  3. Remove the bracket installation bolts (A) and the nut (B). TCM installation bolt/nut: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)

Installation

  1. Installation is reverse of removal. NOTE: In the case of the vehicle equipped with immobilizer or button engine start system, perform "Key Teaching" procedure together (Refer to " «IMMOBILIZER»(ref-536094) " or "Button Engine Start System in BE group).

Removal

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

  1. Installation is the reverse of removal.

Scheme 122

Scheme 122: Components
Scheme 122: Components

Scheme 123

Scheme 123: Shift Lever Assembly Replacement
Scheme 123: Shift Lever Assembly Replacement

Scheme 124

Scheme 124
Scheme 124

Scheme 125

Scheme 125
Scheme 125
  1. Remove the center console. (Refer to " «INTERIOR (CONSOLE)»(ref-536097-S12136420642013031400000) " in BD group)
  2. Disconnect the connector (A)
  3. Remove the control cable (B).
  4. Remove the shift lock cable (A). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.8 lb-ft)
  5. Remove the wiring clip (A).
  6. Remove the AT lever(shift lever) assembly (B) by removing the bolts (4ea). Tightening torque: 8.8 ~ 13.7 N.m (0.9 ~ 1.4 kgf.m, 6.5 ~ 10.1 lb-ft)
  7. Installation is the reverse of removal. NOTE: Adjust the shift lock cable. (Refer to «Adjustment»(ref-536108-S17396802822013031400000) .

Scheme 126

Scheme 126: Control Cable Assembly Replacement
Scheme 126: Control Cable Assembly Replacement

Scheme 127

Scheme 127
Scheme 127

Scheme 128

Scheme 128
Scheme 128
  1. Remove the center console. (Refer to " «INTERIOR (CONSOLE)»(ref-536097-S12136420642013031400000) " in BD group)
  2. Remove the control cable (A).
  3. Remove the crash pad. (Refer to " «INTERIOR (CRASH PAD)»(ref-536097-S26973898002013031400000) " in BD group.)
  4. Remove the heater unit. (Refer to " «HEATER (HEATER UNIT)»(ref-536103-S17573433402013031400000) " in HA group.)
  5. Remove the retainer (A) and nuts (B). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.8 lb-ft)
  6. Remove the nut (A) from the manual control lever.
  7. Remove the control cable (B) from the bracket (C) at transaxle assembly side. (Refer to " «AUTOMATIC TRANSAXLE»(ref-536105-S07404976402013031400000) " in this group) Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.8 lb-ft)
  8. Remove the control cable at cabin room.
  9. Installation is the reverse of removal. NOTE: Set room side AT lever(shift lever) and automatic transaxle side manual control lever to "N" position. Control cable must be free unreasonable bending.

Scheme 129

Scheme 129: Shift Lock Cable Replacement
Scheme 129: Shift Lock Cable Replacement

Scheme 130

Scheme 130
Scheme 130
  1. Remove the center console. (Refer to " «INTERIOR (CONSOLE)»(ref-536097-S12136420642013031400000) " in BD group.
  2. Remove the shift lock cable (A). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.8 lb-ft)
  3. Remove the shift lock cable (B) from the brake pedal (A).
  4. Installation is the reverse of removal. NOTE: Shift lock cable must be free unreasonable bending.

Scheme 131

Scheme 131: Adjusting the control cable
Scheme 131: Adjusting the control cable
  1. Set room side AT lever(shift lever) and automatic transaxle side manual control lever to "N" position.
  2. Connect control cable to room side AT lever(shift lever).
  3. Fix temporary control cable (A) in automatic transaxle side manual control lever.
  4. Push the control cable (A) lightly to "F" direction shown to eliminate the free play.
  5. Tighten the adjusting nut (B). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.8 lb-ft)
  6. After adjusting, check that this part operates at each range of the manual control lever corresponding to each position of the AT lever(shift lever).

Scheme 132

Scheme 132: Adjusting Procedure For Lock Cam And Shift Lock Cable
Scheme 132: Adjusting Procedure For Lock Cam And Shift Lock Cable
  1. Shift lock cable must be fixed to brake pedal(brake pedal must not be pressed down), and at lever(shift lever) must be "N" position
  2. Shift lock cable must be assembled to at lever(shift lever) assembly (Scheme 132) cable end must be inserted into fixing pin (A) of lock cam securely.
  3. Maintain close adhesion lock cam (E) and lock cam stopper (D) slightly pull outer casing of shift lock cable (E) in direction "E" to remove slack of shift lock cable (E).
  4. After checking that cable end is touched to cable fixing pin of lock cam, fix adjust plate.
  5. Check that cable end (B) is touched to cable fixing pin of lock cam (A).
