TCM Learning

When shift shock is occurred or parts related with the transaxle are replaced, TCM learning should be performed.

In the following case, TCM learning is required.

Transaxle assembly replacement
TCM replacement
TCM upgrading

Scheme 133

TCM learning condition ATF temperature: 40 ~ 100°C (104 ~ 212°F)
TCM learning procedure Stop learning Repeat the below shift pattern four times or more with stepping on the brake. Driving learning Drive the vehicle through all gears at D range. Drive from stop to 1st to 2nd to 3rd to 4th to 5th to 6th with keeping fixed throttle open. Down shift from 6th to 5th, 5th to 4th, 4th to 3rd, 3rd to 2nd, 2nd to 1st. Repeat the above driving pattern four times or more. Up-shift throttle open: 15 ~ 25%

Scheme 134

Scheme 134: Circuit Diagram

Scheme 135

Scheme 135: [Vehicle Components]

Scheme 136

Scheme 136: [Transaxle Components]

Connector [EGGG-AA]

Pin	Description
22	Shift solenoid D (VFS-OD)
23	Pressure cont solenoid (VFS-LINE)
26	Shift solenoid F (SS-B)
37	Sports mode up switch
38	Sports mode select switch
39	Oil temperature sensor (+)
43	Shift solenoid A (VFS-UD)
44	Shift solenoid C (VFS-35R)
45	Torque converter control solenoid (T/CON_VFS)
46	Shift solenoid B (VFS-26B)
58	Sports mode down switch
59	Oil temperature sensor (-)
73	Inhibitor switch signal "S4"
74	Inhibitor switch signal "S2"
75	Inhibitor switch signal "S3"
87	Solenoid power 1
88	Solenoid power 2
89	Shift solenoid E (SS-A)
94	Inhibitor switch signal "S1"
95	Output speed sensor power
96	Input speed sensor power
99	Input speed sensor signal
100	Output speed sensor signal

Connector [EGGG-AK]

Pin	Description
1	GND (Power)
2	GND (Power)
3	VB (Battery voltage)
4	Ground (Power)
5	VB
60	CAN High
68	IG.1 (Ignition key)
77	CAN Low

Scheme 137

Scheme 137: Circuit Diagram

Scheme 138

Signal Code Table

	P	P-R	R	R-N	N	N-D	D
S1	12V	12V	0	0	0	0	0
S2	0	12V	12V	12V	0	12V	0
S3	0	0	0	12V	12V	0	0
S4	0	0	0	0	0	12V	12V

Scheme 139

Scheme 139: Circuit Diagram

Scheme 140

Scheme 140: Removal

Scheme 141

Scheme 142

Make sure vehicle does not roll before setting room side shift lever and T/M side manual control lever to "N" position.
Remove the battery and the battery tray. (Refer to " «CHARGING SYSTEM»(ref-536081) " in EE group.)
Remove the air cleaner assembly. (Refer to " «INTAKE MANIFOLD»(ref-536078-S21176328432013031400000) " in EM group.)
Remove the shift cable mounting nut (B). Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 Kgf.m, 5.7 ~ 8.6 lb-ft)
Disconnect the inhibitor switch connector (A).
Remove the manual control lever (B) and the washer after removing a nut (A). CAUTION: When installing, affix the manual control lever and the inhibitor switch with ø5mm (0.1969in.). Then tighten the inhibitor assembly mounting bolts.
Remove the inhibitor assembly (A) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: When installing, tighten the inhibitor assembly mounting bolt lightly, so that necessary adjustments can be made. Tighten to specifications.

Checking List Of Shift Lock

Brake pedal being not depressed. AT lever (shift lever) must not be shifted from "P" position to "R" position.
Brake pedal being not depressed. AT lever (shift lever) must not be shifted from "N" position to "R" posion.
Brake pedal being depressed by stroke 15-26mm in "P" position. Push button can be operated and AT lever (shift lever) can be shifted smoothly from each position to other positions.
Brake pedal must be operated smoothly without interruption at all positions.
