DIAGNOSTIC TROUBLE CODE IDENTIFICATION
| Code (1) | Description |
|---|---|
| P0030 | Front Heater Oxygen Sensor Heater Circuit Malfunction |
| P0031 | Front Heater Oxygen Sensor Heater Circuit low Input |
| P0032 | Front Heater Oxygen Sensor Heater Circuit High Input |
| P0036 | Rear Heated Oxygen Sensor Heated Circuit Malfunction |
| P0037 | Rear Heated Oxygen Sensor Heated Circuit Low Input |
| P0038 | Rear Heated Oxygen Sensor Heated Circuit High Input |
| P0101 | Mass Air Flow Sensor Circuit Range/Performance Malfunction |
| P0102 | Mass Or Volume Airflow Circuit Low Input |
| P0103 | Mass Or Volume Airflow Circuit High Input |
| P0112 | Intake Air Temperature Sensor Circuit Low Input |
| P0113 | Intake Air Temperature Sensor Circuit High Input |
| P0116 | Engine Coolant Temperature Sensor Circuit Range/Performance Malfunction |
| P0117 | Engine Coolant Temperature Sensor Circuit Low Input |
| P0118 | Engine Coolant Temperature Sensor Circuit High Input |
| P0121 | Throttle Position Sensor Circuit Range/Performance Malfunction |
| P0122 | Throttle Position Sensor Circuit Low Input |
| P0123 | Throttle Position Sensor Circuit High Input |
| P0125 | Insufficient Engine Coolant Temperature For Closed Loop Fuel Control |
| P0128 | Coolant Thermostat Stuck |
| P0130 | Front Heated Oxygen Sensor Circuit Malfunction |
| P0131 | Front Heated Oxygen Sensor Low Input |
| P0132 | Front Heated Oxygen Sensor High Input |
| P0133 | Front Heated Oxygen Sensor Circuit Slow Response |
| P0134 | Front Heated Oxygen Sensor Circuit No Activity Detected |
| P0136 | Rear Heated Oxygen Sensor Circuit Malfunction |
| P0137 | Rear Heated Oxygen Sensor Circuit Low Input |
| P0138 | Rear Heated Oxygen Sensor Circuit High Input |
| P0139 | Rear Heated Oxygen Sensor Slow Response |
| P0140 | Rear Heated Oxygen Sensor Circuit No Activity Detected |
| P0171 | Fuel System Too Lean |
| P0172 | Fuel System Too Rich |
| P0261 | Fuel Injector No. 1 Circuit Low Input |
| P0262 | Fuel Injector No. 1 Circuit High Input |
| P0264 | Fuel Injector No. 2 Circuit Low Input |
| P0265 | Fuel Injector No. 2 Circuit High Input |
| P0267 | Fuel Injector No. 3 Circuit Low Input |
| P0268 | Fuel Injector No. 3 Circuit High Input |
| P0270 | Fuel Injector No. 4 Circuit Low Input |
| P0271 | Fuel Injector No. 4 Circuit High Input |
| P0300 | Random Misfire Detected |
| P0301 | Cylinder No. 1 Misfire Detected |
| P0302 | Cylinder No. 2 Misfire Detected |
| P0303 | Cylinder No. 3 Misfire Detected |
| P0304 | Cylinder No. 4 Misfire Detected |
| P0325 | Knock Sensor Circuit Malfunction |
| P0335 | Crankshaft Position Sensor Circuit Malfunction |
| P0340 | Camshaft Position Sensor Circuit Malfunction |
| P0420 | Main Catalyst Efficiency Below Threshold |
| P0422 | Main Catalyst Efficiency Deterioration |
| P0441 | EVAP Emission Control System Purge Control Solenoid Valve Stuck Open |
| P0442 | EVAP Emission Control System Small Leak Detected (1 mm) |
| P0444 | EVAP Emission Control System Purge Control Solenoid Valve Circuit Open |
| P0445 | EVAP Emission Control System Purge Control Solenoid Valve Circuit Shorted |
| P0447 | EVAP Emission Control System Vent Control Circuit Open |
| P0448 | EVAP Emission Control System Vent Control Circuit Shorted |
| P0451 | EVAP Emission Control System Pressure Sensor Range/Performance Malfunction |
| P0452 | EVAP Emission Control System Pressure Sensor Low Input |
| P0453 | EVAP Emission Control System Pressure Sensor High Input |
| P0454 | EVAP Emission Control System Pressure Sensor Intermittent |
| P0455 | EVAP Emission Control System Large Leak Detected |
| P0456 | EVAP Emission Control System Small Leak Detected (0.5 mm) |
| P0501 | Vehicle Speed Sensor Circuit Malfunction |
| P0506 | Idle Control System Rpm Lower Than Expected |
| P0507 | Idle Control System Rpm Higher Than Expected |
| P0560 | System Voltage Malfunction |
| P0562 | System Voltage Low Input |
| P0563 | System Voltage High Input |
| P0605 | Engine Control Module Rom Error |
| P0650 | Malfunction Indicator Light Circuit Malfunction |
| P1166 | Lambda Bank Control Limit |
| P1505 | Idle Air Control Valve Opening Coil Signal Low Input |
| P1506 | Idle Air Control Valve Opening Coil Signal High Input |
| P1507 | Idle Air Control Valve Closing Coil Signal Low Input |
| P1508 | Idle Air Control Valve Closing Coil Signal High input |
| P1529 | Transaxle Control Module Request For MIL On/Freeze Frame to ECM via CAN |
| P1586 | Automatic Transaxle Or Manual Transaxle Encoding Malfunction |
| P1693 | Malfunction Indicator Light Request Circuit Malfunction |
| (1) For diagnosis, of transmission codes, see appropriate DIAGNOSIS article in AUTOMATIC TRANSMISSIONS. | |
| (1) | For diagnosis, of transmission codes, see appropriate DIAGNOSIS article in AUTOMATIC TRANSMISSIONS. |
DIAGNOSTIC TROUBLE CODE IDENTIFICATION
ECM LOCATION & CONNECTORS IDENTIFICATION
Engine Control Module (ECM) is located, behind the left side kick trim panel on driver side. (Scheme 22)and (Scheme 23).
