Engine Control System - Optima Hev: Specifications Kia Optima III рестайлинг

Testing & Diagnostics 26 illustrations ~235 words

Specification

Pressure (kPa)Output Voltage (V)
20.00.79
46.71.84
101.34.0

Scheme 1

Scheme 1
Scheme 1

Scheme 2

Scheme 2: Waveform
Scheme 2: Waveform

Scheme 3

Scheme 3: Circuit Diagram
Scheme 3: Circuit Diagram
Temperature [°C(°F)]Resistance (kohms)
40(-40)40.93 ~ 48.35
20(-4)13.89 ~ 16.03
0(32)5.38 ~ 6.09
10(50)3.48 ~ 3.90
20(68)2.31 ~ 2.57
40(104)1.08 ~ 1.21
50(122)1.56 ~ 1.74
60(140)0.54 ~ 0.62
80(176)0.29 ~ 0.34

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5: Circuit Diagram
Scheme 5: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

Scheme 6

Scheme 6: Circuit Diagram
Scheme 6: Circuit Diagram
ItemSpecification
Capacitance (pF)850 ~ 1, 150

Scheme 7

Scheme 7: Circuit Diagram
Scheme 7: Circuit Diagram

Scheme 8

Scheme 8: Removal
Scheme 8: Removal

Scheme 9

Scheme 9
Scheme 9
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Drain the engine coolant (Refer to «COOLANT»(ref-675057-S24250348822014120400000) ).
  3. Remove the radiator upper hose (Refer to «RADIATOR»(ref-675057-S14418344162014120400000) ).
  4. Disconnect the knock sensor connector (A).
  5. Remove the intake manifold (Refer to «INTAKE MANIFOLD»(/kia/optima/iii-2013-2015/remont/exhaust/#intake-exhaust-system-optima-hev) ).
  6. Remove the mounting bolt (A), and then remove the sensor from the cylinder block.
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T0.7 ~ 0.80.29 ~ 0.46
W.O.T3.85 ~ 4.351.93 ~ 2.18

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11: Circuit Diagram
Scheme 11: Circuit Diagram
Pressure [kPa (kgf/cm, in H2O)Output Voltage (V)
6.67 (-0.068, -26.8)0.5
02.5
+6.67 (0.068, 26.8)4.5

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13: Circuit Diagram
Scheme 13: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)13.8 ~ 15.2 [20°C(68°F)]

Scheme 14

Scheme 14: Circuit Diagram
Scheme 14: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.0 ~ 22.0 [20°C(68°F)]

Scheme 15

Scheme 15: Circuit Diagram
Scheme 15: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)6.9 ~ 7.9 [20°C(68°F)]

Scheme 16

Scheme 16: Circuit Diagram
Scheme 16: Circuit Diagram
Pressure [kPa (kgf/cm, in H2O)]Output Voltage (V)
6.67 (-0.068, -26.8)0.5
02.5
+6.67 (0.068, 26.8)4.5

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18: Waveform
Scheme 18: Waveform

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20: Circuit Diagram
Scheme 20: Circuit Diagram

Scheme 21

Scheme 21: Removal
Scheme 21: Removal

Scheme 22

Scheme 22
Scheme 22
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the NVLD connector (A).
  3. Disconnect the ventilation hoses (B, C).
  4. Remove the NVLD after by loosening the bolts (A).
ItemSpecification
Coil Resistance (ohms)19.8 ~ 21.8 [20°C(68°F)

Scheme 23

Scheme 23: Circuit Diagram
Scheme 23: Circuit Diagram

Scheme 24

Scheme 24: Removal
Scheme 24: Removal

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26
  1. Turn the ignition switch OFF and disconnect the battery negative (-) terminal.
  2. Lift the vehicle.
  3. Disconnect the canister close valve connector (A).
  4. Disconnect the ventilation hose (B) from the fuel tank air filter and canister close valve.
  5. Remove the fuel tank air filter assembly after removing bolts (C).
  6. Release the lever (A), and then separate the canister close valve (B) from the fuel tank air filter (C) after rotating it in the direction of the arrow shown in the illustration.
