Specifications
Purge Control Solenoid Valve (PCSV)
Specification
| Item | Specification |
|---|---|
| Coil Resistance (ohms) | 19.0 ~ 22.0 [20°C(68°F)] |
Fuel Tank Pressure Sensor (FTPS)
Type: Piezo-Resistive Pressure Sensor
Specification
| Pressure [kPa (kgf/cm, in H2O)] | Output Voltage (V) |
|---|---|
| 6.67 (-0.068, -26.8) | 0.5 |
| 0 | 2.5 |
| +6.67 (0.068, 26.8) | 4.5 |
Canister Close Valve (CCV)
Specification
| Item | Specification |
|---|---|
| Coil Resistance (ohms) | 19.8 ~ 21.8 [20°C(68°F)] |
NVLD (Natural Vacuum Leakage Detection)
Specification
| Item | Current (mA) | |
|---|---|---|
| Switch open | Switch close | |
| Power supply | Approx. 2.0 | Approx. 3.0 |
| Data line | Approx. 10.0 | |
Tightening Torques
| Item | Kgf.m | N.m |
|---|---|---|
| Positive crankcase ventilation valve installation | 0.19 ~ 0.29 | 1.9 ~ 2.8 |
| Canister protector installation bolt | 0.9 ~ 1.4 | 8.8 ~ 13.7 |
| Canister installation bolt | 0.4 ~ 0.6 | 3.9 ~ 5.9 |
| Auxiliary canister installation nut | 0.4 ~ 0.6 | 3.9 ~ 5.9 |
| Fuel tank air filter bracket installation bolt | 0.4 ~ 0.6 | 3.9 ~ 5.9 |
| Natural Vacuum Leakage Detection (NVLD) installation screw | 0.2 ~ 0.3 | 2.3 ~ 3.3 |
EMISSION CONTROL SYSTEM TORQUE SPECIFICATIONS
Scheme 107
1. PCV Valve 2. Canister 3. Purge Control Solenoid Valve (PCSV) 4. Fuel Tank Pressure Sensor (FTPS) 6. Fuel Level Sender (FLS) 5. NVLD (Natural Vacuum Leakage Detection) Module 7. Canister Close Valve (CCV) 8. Fuel Tank Air Filter 9. Catalytic Converter (WCC) 9. Catalytic Converter (UCC) 10. Auxiliary canister
