Evaporative Emission Control System - 2.4L - Optima: Removal & Installation Kia Optima III рестайлинг

Testing & Diagnostics 8 illustrations ~340 words

Removal

[Type 1 for TF]

Scheme 242

Scheme 242: Removal

Scheme 243

Scheme 243

Scheme 244

Scheme 244

Scheme 245

Scheme 245
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the ventilation hose (A) from the fuel tank air filter.
  3. Disconnect the vapor tube quick-connector (A) and the quick-connector (B).
  4. Remove the rear muffler assembly. Refer to «MUFFLER»(ref-675275-S01374227142014120400000) .
  5. Remove the protector cover (A) in the direction of arrow.
  6. Remove installation bolts and then remove the canister assembly (B).
  7. Remove the auxiliary canister (A) from the canister after removing a nuts (B).

(Type 2 for QF)

  1. Disconnect the canister close valve connector (A).
  2. Disconnect the ventilation tube quick-connector (B) and the vapor tube quick-connectors (C, D).
  3. Remove the installation bolts (E), and then remove the canister.

Installation

Installation is the reverse of removal.

Canister installation bolt

3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft)

Auxiliary canister installation nut

3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft)

Install in the reverse order of removal.

ORVR installation bolt

1.9 ~ 2.9 N.m (0.2 ~ 0.3 kgf.m, 1.4 ~ 2.1 lb-ft)

(Type 1 for TF)

Scheme 246

Scheme 246: Removal

Scheme 247

Scheme 247

Scheme 248

Scheme 248

Scheme 249

Scheme 249
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Lift the vehicle.
  3. Disconnect the canister close valve connector (A).
  4. Disconnect the ventilation hose (B).
  5. Remove the fuel tank air filter after removing 2 bolts (C).
  6. Release the lever (A) and then rotate the canister close valve (B) in the direction of the arrow in the illustration.
  7. Remove CCV from the fuel tank air filter after coinciding installation parts (A, B).
  8. Replace new fuel tank air filter.
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the canister close valve connector (A).
  3. Disconnect the ventilation tube quick connector (B).
  4. Release the lever (C), and then remove the fuel tank air filter (D) after rotating it in the direction of the arrow in the illustration.
CAUTIONInstall the component with the specified torques. Note that internal damage may occur when the component is dropped.
  1. Installation is reverse of removal.
