Specifications
Purge Control Solenoid Valve (PCSV)
- Specification PCSV SPECIFICATIONS Item Specification Coil Resistance (ohms) 19.0 ~ 22.0 (20°C (68°F))
Fuel Tank Pressure Sensor (FTPS)
- Type: Piezo-Resistive Pressure Sensor
- Specification FTPS SPECIFICATIONS Pressure (kPa (kgf/cm 2 , in H2O)) Output Voltage (V) -6.67 (-0.068, -26.8) 0.5 0 2.5 +6.67 (0.068, 26.8) 4.5
Canister Close Valve (CCV)
- Specification CANISTER CLOSE VALVE SPECIFICATION Item Specification Coil Resistance (ohms) 19.8 ~ 21.8 (20°C (68°F))
Tightening Torques
| Item | Kgf.m | N.m |
|---|---|---|
| Positive crankcase ventilation valve installation | 0.19 ~ 0.29 | 1.9 ~ 2.8 |
| Canister installation bolt | 0.4 ~ 0.6 | 3.9 ~ 5.9 |
TORQUE SPECIFICATIONS
Scheme 179
Scheme 180
Scheme 181
| PCV Valve Canister Purge Control Solenoid Valve (PCSV) Fuel Tank Pressure Sensor (FTPS) Canister Close Valve (CCV) Fuel Level Sensor (FLS) Fuel Tank Air Filter Catalytic Converter |
