Description
The Evaporative Emission Control System prevents fuel vapor stored in fuel tank from vaporizing into the atmosphere. When the fuel evaporates in the fuel tank, the vapor passes through vent hoses or tubes to a canister filled with charcoal.
The canister temporarily holds the vapor in the charcoal. The ECM will control the system in order to draw the gathered vapor into the combustion chambers during certain operating conditions. Engine manifold vacuum is used to draw the vapor into intake manifold.
Scheme 228
Operation
Normal Status Full Fuel Vehicle Rollover / steep Valve open Valve close Valve close
Scheme 229
Scheme 230
Scheme 231
Scheme 232
Scheme 233
- Turn the ignition switch OFF, and then remove battery (-) cable.
- Remove the fuel tank. (Refer to FUEL TANK ).
- Disconnect the vapor hose (A).
- Remove installation bolts (B), and then remove the ORVR valve (C) from the fuel tank.
Scheme 234
Scheme 235
- Visually check if the valve and gasket seal are deformed or damaged.
- Check if the air is passed smoothly when blowing into the nipple of ORVR valve as below position.
- Check if there is resistance when blowing into the nipple of ORVR valve as below position.
A ratchet tightening device on the threaded fuel filler cap reduces the chances of incorrect installation, which seals the fuel filler. After the gasket on the fuel filler cap and the filler neck flange contact each other, the ratchet produces a loud clicking noise indicating the seal has been set.
Scheme 236
