Automatic Transaxle System - Optima Hev: Removal & Installation Kia Optima III рестайлинг

Removal

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Shut off the high voltage circuit. Refer to «HIGH VOLTAGE SHUT-OFF PROCEDURE»(ref-675050-S21464474132014120400000) .
2. Remove the under cover (A). Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2kgf.m, 5.8 ~ 8.7 lb-ft)
3. Drain the coolant of hybrid motor cooling system. (Refer to " «COOLANT»(ref-675058-S26752267332014120400000) ")
4. Drain the coolant of engine & transaxle cooling system. (Refer to " «COOLANT»(ref-675057-S24250348822014120400000) ")
5. Remove the hybrid power control unit assembly. (Refer to " «HPCU (HYBRID POWER CONTROL UNIT)»(ref-675059-S32697489462014120400000) ")
6. Remove the duct (A). Tightening torque: 7.8 ~ 9.8 N.m (0.8 ~ 1.0 kgf.m, 5.8 ~ 7.2 lb-ft)
7. Remove the air cleaner assembly. Disconnect the breather hose (A). Disconnect the air intake hose (B) and then remove the air cleaner assembly (C). Tightening torque : Hose clamp bolt: 2.9 ~ 4.9 N.m (0.3 ~ 0.5 kgf.m, 2.2 ~ 3.6 lb-ft) Air cleaner assembly bolts: 7.8 ~ 9.8 N.m (0.8 ~ 1.0 kgf.m, 5.8 ~ 7.2 lb-ft) NOTE: When installing the air intake hose, the plate of the hose clamp must be in line with the stopper of the hose. When installing the air intake hose, the center of the mark of hose must be in line with the throttle body rib.
8. Remove the hybrid power control unit (HPCU) tray (A). Tightening torque : 19.6 ~ 29.4 N.m (2.0 ~ 3.0 kgf.m, 14.5 ~ 21.7 lb-ft)
9. Remove heater hose pump (A).
10. Disconnect the solenoid valve connector (B) and inhibitor switch connector (A).
11. Disconnect the resolver sensor connector (A) and then remove the wiring bracket (B, C).
12. Remove the motor connector (A).
13. Remove the electric oil pump (EOP) connector (A).
14. Remove the shift cable (C) after removing the nut (A) and the bolt (B).
15. Remove the ground line after removing the bolt (A).
16. Remove the ATF warmer hose (A).
17. Remove the automatic transaxle upper mounting bolt (A-2ea). Tightening torque : 42.2 ~ 53.9 N.m (4.3 ~ 5.5 kgf.m, 31.1 ~ 39.8 lb-ft)
18. Assemble the engine support fixture. (Refer to " «SPECIAL SERVICE TOOLS»(ref-675099-S12684667022014120400000) ")
19. Using the engine support fixture, hold the engine and transaxle assembly safely.
20. Remove the cover (A).
21. Remove the automatic transaxle mounting bracket bolts (A). Tightening torque : 107.9 ~ 127.5 N.m (11.0 ~ 13.0 kgf.m, 79.6 ~ 94.0 lb-ft)
22. Remove the automatic transaxle support bracket (A). Tightening torque : 58.8 ~ 78.5 N.m (6.0 ~ 8.0 kgf.m, 43.4 ~ 57.9 lb-ft)
23. Remove the electric oil pump (EOP) connector (A) and clips (B).
24. Remove the clutch pressure sensor (CPS) connector (C).
25. Remove the Drive shaft assembly. (Refer to " «FRONT DRIVESHAFT»(ref-675072-S27254949242014120400000) ")
26. Remove the Sub frame assembly. (Refer to " «FRONT CROSS MEMBER»(ref-675064-S29483981212014120400000) ")
27. Remove the heat protector (A). Tightening torque: Transaxle side : 11.8 ~ 13.7 N.m (1.2 ~ 1.4 kgf.m, 8.7 ~ 10.1 lb-ft) Engine side : 21.6 ~ 25.5 N.m (2.2 ~ 2.6 kgf.m, 15.9 ~ 18.8 lb-ft)
28. Remove the mounting bolts (A, B) after supporting the transaxle by a jack. Tightening torque: (A) 42.2 ~ 48.1 N.m (4.3 ~ 4.9 kgf.m, 31.1 ~ 35.4 lb-ft) (B) 42.2 ~ 53.9 N.m (4.3 ~ 5.5 kgf.m, 31.1 ~ 39.8 lb-ft)
29. Remove the transaxle while slowly lowering the jack. NOTE: Be careful not to damage other system or parts when removing the transaxle assembly.

Scheme 22

Scheme 23

1. Installation is the reverse of removal. NOTE: If installing a new transaxle, remove the hanger bracket (A) and then install the transaxle. (Does not need to be reinstalled) If the oil seal on the transaxle case side is damaged and fluid is leaking, replace the oil seal with a new oil seal. When installing the new oil seal, use the specialized tool (oil seal installer, 09452-3D100). Perform the procedures below after replacing the transaxle. Refill the automatic transaxle with fluid. (Refer to " «FLUID»(ref-675073-S29262681622014120400000) ") Refill the engine & transaxle system with coolant. (Refer to " «COOLANT»(ref-675057-S24250348822014120400000) ") Refill the hybrid motor cooling system with coolant and then perform the air bleeding using the GDS. (Refer to " «COOLANT»(ref-675058-S26752267332014120400000) ") Clear the diagnostic trouble codes (DTC) using the GDS. Even though disconnecting the battery negative terminal, the DTCs will not be cleared. So, be sure to clear the DTCs using the GDS. Reset the automatic transaxle adaptive values using the GDS. Perform the resolver sensor calibration using the GDS. (Refer to " «RESOLVER CALIBRATION»(ref-675080-S11216037652014120400000) ") Perform the clutch pressure sensor calibration using the GDS. (Refer to " «CLUTCH PRESSURE SENSOR CALIBRATION»(ref-675059-S08167330082014120400000) ") Perform the TCM adaptive values learning procedure. (Refer to " «TCM LEARNING»(ref-675082-S18222391372014120400000) ")
