Hydraulic System - Optima Hev: Specifications Kia Optima III рестайлинг

Automatic Trans 8 illustrations

Specifications

PumpPumping capacityAbout 6.46cc per one revolution
TypeInternal gear
MotorTypeBrushless DC motor (3 phases)
TorqueRated 1.5 N.m
Speed range100~2, 500 RPM

Scheme 26

Scheme 26: Circuit Diagram
Scheme 26: Circuit Diagram

Scheme 27

Scheme 27: Component Location
Scheme 27: Component Location

Scheme 28

Scheme 28: Removal
Scheme 28: Removal

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31
  1. Disconnect the 12V battery negative (-) cable.
  2. Remove the under cover (A). Tightening torque: 7.8 ~ 11.7 N.m (0.8 ~ 1.2 kgf.m, 5.7 ~ 8.6 lb-ft)
  3. Remove the electric oil pump (EOP) connector (A, B).
  4. Remove the EOP (A) after removing the bolt and nut. Tightening torque : 42.2 ~ 53.9 N.m (4.3 ~ 5.5 kgf.m, 31.1 ~ 39.8 lb-ft)
Operating voltage(V)12
Current15 ~ 20A (normal), 45A (Max.)

Scheme 32

Scheme 32: Components Location
Scheme 32: Components Location

Scheme 33

Scheme 33: OPU connector and terminal function
Scheme 33: OPU connector and terminal function
