Specifications
Type: Negative Thermal Coefficient Type
| Temp.(°C)°F | Resistance (kohms) |
|---|---|
| (-40)-40 | 46.8 |
| (-20)-4.0 | 15.6 |
| (0)32.0 | 5.88 |
| (20)68.0 | 2.51 |
| (40)104.0 | 1.17 |
| (60)140.0 | 0.59 |
| (80)176.0 | 0.32 |
| (100)212.0 | 0.18 |
| (120)248.0 | 0.11 |
| (140)284.0 | 0.07 |
| (165)329.0 | 0.04 |
Scheme 71
Scheme 72
Scheme 73
- Turn ignition switch OFF.
- Remove the air duct (A). Tightening torque: 7.8 ~ 9.8 N.m (0.8 ~ 1.0kgf.m, 5.8 ~ 7.2 lb-ft)
- Remove the air cleaner assembly. Disconnect the breather hose (A). Disconnect the air intake hose (B) and then remove the air cleaner assembly (C). Tightening torque: Hose clamp bolt: 2.9 ~ 4.9 N.m (0.3 ~ 0.5kgf.m, 2.2 ~ 3.6 lb-ft) Air cleaner assembly bolts: 7.8 ~ 9.8 N.m (0.8 ~ 1.0kgf.m, 5.8 ~ 7.2 lb-ft) NOTE: When installing the air intake hose, the plate of the hose clamp must be in line with the stopper of the hose. When installing the air intake hose, the center of the mark of hose must be in line with the throttle body rib.
- Remove the solenoid valve connector (A).
- Measure resistance between sensor signal terminal and sensor ground terminal.
- Check that the resistance is within the specification.
Type: Hall effect sensor
| Operation condition (°C)°F | ((-)40 ~ 150)) -40 ~ 302 | |
|---|---|---|
| Air gap(mm)in. | (0.95~1.65) 0.037 ~ 0.065 | |
| Output voltage(V) | High | 1.18 ~ 1.68 |
| Low | 0.59 ~ 0.84 | |
Scheme 74
Scheme 75
Scheme 76
Type: Hall effect sensor
| Operation condition (°C)°F | ((-)40 ~ 150)) -40 ~ 302 | |
|---|---|---|
| Air gap(mm)in. | (0.25 ~ 1.9) 0.00984 ~ 0.0748 | |
| Output voltage | High | 1.18 ~ 1.68 |
| Low | 0.59 ~ 0.84 | |
Scheme 77
Scheme 78
Scheme 79
Direct control VFS [E/C]
Control type: Normal low type
| Control Pressure kpa (kgf/cm 2 , psi) | 9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54) |
|---|---|
| Current value (mA) | 50~850 |
| Internal resistance (ohms) | 5.1 |
Scheme 80
Direct control VFS[26/B]
Control type: Normal low type
| Control Pressure kpa (kgf/cm 2 , psi) | 9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54) |
|---|---|
| Current value (mA) | 50 ~ 850 |
| Internal resistance (ohms) | 5.1 |
Scheme 81
Direct control VFS[LINE Pressure]
Control type: Normal high type
| Control Pressure kpa (kgf/cm 2 , psi) | 500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42) |
|---|---|
| Current value (mA) | 50 ~ 850 |
| Internal resistance (ohms) | 5.1 |
Scheme 82
Direct control VFS[35R/C]
Control type: Normal high type
| Control Pressure kpa (kgf/cm 2 , psi) | 500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42) |
|---|---|
| Current value (mA) | 50 ~ 850 |
| Internal resistance (ohms) | 5.1 |
Scheme 83
Direct control VFS [UD/B]
Control type: Normal high type
| Control Pressure kpa (kgf/cm 2 , psi) | 500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42) |
|---|---|
| Current value (mA) | 50 ~ 850 |
| Internal resistance (ohms) | 5.1 |
Scheme 84
Direct control VFS [OD/C]
Control type: Normal high type
| Control Pressure kpa (kgf/cm 2 , psi) | 500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42) |
|---|---|
| Current value (mA) | 50 ~ 850 |
| Internal resistance (ohms) | 5.1 |
Scheme 85
ON/OFF Solenoid Valve(SS-A, SS-B)
Control type: Normal low type
| Control Pressure kpa (kgf/cm 2 , psi) | 490.33 (5.0, 71.12) |
|---|---|
| Internal resistance (ohms) | 10 ~ 11 |
Scheme 86
ON/OFF Solenoid Valve (SS-A, SS-B)
Control type: Normal low type
| Control Pressure kpa (kgf/cm 2 , psi) | 490.33 (5.0, 71.12) |
|---|---|
| Internal resistance (ohms) | 10 ~ 11 |
Scheme 87
Type: Combination of output signals from 4 terminals
| Power supply (V) | 12 |
|---|---|
| Output type | Combination of output signals |
TERMINAL OUTPUT SIGNALS SPECIFICATIONS
| PIN No. | P | P-R | R | R-N | N | N-D | D |
|---|---|---|---|---|---|---|---|
| Signal "1" | 12V | 12V | 0 | 0 | 0 | 0 | 0 |
| Signal "2" | 0 | 12V | 12V | 12V | 0 | 0 | 0 |
| Signal "3" | 0 | 0 | 0 | 12V | 12V | 12V | 0 |
| Signal "4" | 0 | 0 | 0 | 0 | 0 | 12V | 12V |
SIGNAL CODE
