Message Center - Service Information Jeep Grand Cherokee WK2

Scheme 50

The Electronic Vehicle Information Center (EVIC) features a driver-interactive display (21). The display is located in the middle of the instrument cluster between the speedometer and tachometer. This system conveniently allows the driver to select a variety of useful information by pressing the switches mounted on the steering wheel. The EVIC displays information related to the following

1. Audio mode display
2. Compass display
3. Fuel saver indicator, Economizer (ECO) display
4. Navigation system screens - If Equipped
5. Outside temperature display
6. Park Assist System - If Equipped
7. Personal Settings (customer programmable features)
8. System Status
9. Tire Pressure Monitor System - If Equipped
10. Trip computer functions
11. U-Connect™ hands-free communication system displays - If Equipped
12. Vehicle information warning message displays

The EVIC system is comprised of several different components. Those components are

1. Instrument Cluster
2. Steering Wheel Switches
3. Ambient Temperature Sensor
4. Electronic Overhead Module
5. Remote Compass Module
6. Controller Area Network (CAN) Data Bus
7. Local Interface Network (LIN) Data Bus

The EVIC display is part of the Instrument Cluster assembly and is not serviced as a separate component. If the display is inoperative the complete Instrument Cluster assembly must be replaced. Refer to REMOVAL . If the EVIC function buttons are inoperative and require replacement, for the appropriate procedure, refer to SWITCH, EVIC CONTROL , REMOVAL . If the Remote Compass Module (RCM) (Electronic Overhead Module) is inoperative and requires replacement, for the appropriate procedure, refer to MODULE, COMPASS , REMOVAL .

OPERATION

The Electronic Vehicle Information Center (EVIC) uses both non-switched and ignition switched sources of battery current so that some of its features remain operational at any time, while others may only operate with the ignition switch in the "ON" position. When the ignition switch is turned to the "ON" position, the EVIC display will return to the last function being displayed before the ignition was turned to the "OFF" position.

The EVIC system is comprised of several different components that communicate over the Controller Area Network (CAN) and Local Interface Network (LIN) Data Buses. If the system is inoperative a scan tool and the appropriate diagnostic information must be used to diagnose the system.

Scheme 51

The EVIC function buttons are used to operate the different functions of the EVIC system. Pressing and releasing the MENU buttons (5 & 6) allows the driver to scroll though and select the Compass/Temperature, Trip Computer, Personal Settings or System Status functions. The STEP button (3) allows the selection of setting or resetting of the function currently displayed at that time. Pressing and releasing the BACK button (4) will cause the EVIC to return to the main menu.

SYSTEM STATUS

Displays warnings and user interaction messages. Initial warnings will be displayed accompanied by a series of audible beeps. Critical text warnings will be displayed until the failure is corrected. Non-critical text warnings will be displayed for 60 seconds. The driver can scroll to view multiple messages by using the menu buttons.

When the appropriate conditions exist, the EVIC displays the following messages

1. Turn signal on
2. Perform service
3. Key not programmed - damaged key
4. Key not programmed - invalid key
5. Key not programmed - exceeded key program limit
6. Programming active - new key programmed
7. Service security key
8. Invalid key - try alternate key
9. Driver/passenger door open (with graphic)
10. Left/right rear door open (with graphic)
11. Doors open (with graphic)
12. Liftgate open (with graphic)
13. Liftgate/door open (with graphic)
14. Liftgate/doors open (with graphic)
15. Liftglass open (with graphic)
16. Hood open (with graphic)
17. Hood/door open (with graphic)
18. Hood/doors open (with graphic)
19. Liftgate/hood open (with graphic)
20. Hood/glass/door open (with graphic)
21. Hood/glass/doors open (with graphic)
22. Hood/gate/door open (with graphic)
23. Hood/gate/doors open (with graphic)
24. Liftglass/door open (with graphic)
25. Liftglass/doors open (with graphic)
26. Liftglass/hood open (with graphic)
27. Washer fluid low (with graphic)
28. Coolant low (with graphic)
29. Oil change required
30. Oil change reset
31. Check gauges
32. Auto highbeam on
33. Auto highbeam off
34. Park assist disabled
35. Service suspension
36. Service park assist system
37. Transmission over temp
38. Check shift procedure
39. Service 4wd system
40. 4wd system in neutral
41. Low brake fluid level
42. Warning! Limit speed
43. Check gas cap
44. ESC off
45. IOD fuse out
46. Hill descent control
47. Memory #1 positions set
48. Memory #2 positions set
49. Memory system disabled - seatbelt fastened (with graphic)
50. Memory system disabled - vehicle not in park
51. Driver 1 memory
52. Driver 2 memory
53. Adj. Pedals disabled - cruise control set
54. Adj. Pedals disabled - shifter in reverse
55. Tire low pressure
56. Check TPM system
57. Exhaust Service Required - See Dealer Now (diesel models only)
58. Exhaust System - Regeneration Required Now (diesel models only)
59. Left front low pressure (premium TPM system only)
60. Right front low pressure (premium TPM system only)
61. Left rear low pressure (premium TPM system only)
62. Right rear low pressure (premium TPM system only)
63. Spare low pressure (premium TPM system only)
64. Water in fuel (diesel models only)
65. Service blind spot system
66. Blind spot system unavailable
67. Blind spot system off

PERSONAL SETTINGS MODE (CUSTOMER PROGRAMMABLE FEATURES)

Allows the driver to set and recall features when the transmission is in Park by pressing and releasing the MENU buttons until Personal Settings is displayed in the EVIC. The following personal settings can be set and recalled by pressing the STEP button

1. Fuel Saver indicator, Economizer (ECO), On or Off
2. Language: English, Spanish, German, Italian or French
3. Display units in English or Metric
4. Lock doors automatically at 15 MPH (24 kph), On or Off
5. Unlock door automatically on exit, On or Off
6. Remote Keyless Entry unlock driver door on first press or unlock all doors on first press
7. Recall Memory with Remote Keyless Entry Unlock, On or Off
8. Sound horn with Remote Keyless Entry Lock, On or Off
9. Flash lights with Remote Keyless Entry Lock, On or Off
10. Delay turning headlamps off for 0, 30, 60 or 90 seconds
11. Automatic High Beams (Available with SmartBeam Only)
12. Illuminated approach on for 0, 30, 60 or 90 seconds
13. Headlamps on with wipers, On or Off
14. Rain Sensing Intermittent Wipers, On or Off
15. Service interval (Gasoline engines), 3200•••9600 KM, in increments of 800 KM/2000•••6000 miles in increments of 500 miles.
16. Service interval (Diesel engines), 4000•••20000 KM, in increments of 1000 KM/2500•••12500 miles in increments of 625 miles
17. Automatically move seat back on exit, On or Off
18. Key Off Power Delay
19. Hill Start Assist
20. Park Assist System: Off Sound only Sound and display
21. Blind Spot Monitor System: Off Lights only Lights and chime
22. Liftgate chime, On or Off

COMPASS/TEMPERATURE/TRIP COMPUTER

This display provides the outside temperature, one of the eight compass headings to indicate the direction the vehicle is facing, and vehicle trip information. The compass and temperature display is the normal display.

The trip computer function will be displayed if the STEP button is pressed from the Compass/Temperature display mode. The trip computer displays the following information

1. Average Fuel Economy/Fuel Saver Mode (5.7L Engine Only)
2. Distance To Empty
3. Trip A
4. Trip B
5. Elapsed Time
6. Service Distance
7. Display Units of Measure in
8. Tire pressure display (if equipped)

HANDS FREE TELEPHONE - IF EQUIPPED

Provides the following information and features for the optional hands-free communications system

1. Phone status: idle, voice mail, roaming, battery strength and signal strength in increments of 20 percent
2. Call status: Incoming call, connecting, connected, air time in minutes and seconds, call ended, busy, call failed, roaming and no phone connection
3. UConnect Active
4. Caller ID phone number display

UNIVERSAL GARAGE DOOR TRANSCEIVER

The Electronic Vehicle Information Center (EVIC) features a driver-interactive display which includes HomeLink system messages. Refer to DESCRIPTION .

ELECTRONIC VEHICLE INFORMATION CENTER

The Electronic Vehicle Information Center (EVIC) data is obtained from several components on the Controller Area Network (CAN) and Local Interface Network (LIN) Data Bus circuits. The EVIC will not function properly if the bus messages from any of these components is not received. If no EVIC data is displayed or the display indicates dashes "- -", check the CAN Data Bus circuit communications, the Instrument Cluster functions, the RCM and the Totally Integrated Power Module (TIPM).

The use of a scan tool and the proper diagnostic procedures information are recommended for further testing of the EVIC, the RCM, the CAN Data Bus and Local Interface Network (LIN) Data Bus circuits.

For complete circuit diagrams, refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector pin-out information and location views for the various wire harness connectors, splices and grounds.

OIL CHANGE REQUIRED INDICATOR RESET

Note. A change oil indicator is standard equipment on all instrument clusters. However, on vehicles manufactured for export markets, this indicator is electronically disabled. This indicator is located within the odometer/trip odometer Liquid Crystal Display (LCD) unit. The change oil indicator consists of cycling textual CHANGE and OIL messages which appear in place of the odometer/trip odometer information in the odometer LCD unit.

This vehicle is equipped with an engine oil change indicator system. The "Oil Change Required" message will flash in the EVIC display for approximately 10 seconds after a single chime has sounded, to indicate the next scheduled oil change interval. The engine oil change indicator system is duty cycle based, which means the engine oil change interval may fluctuate, dependent upon your personal driving style.

Unless reset, this message will continue to display each time you turn the ignition switch to the ON/RUN position. To turn off the message temporarily, press and release the MENU button. To reset the oil change indicator system (after performing the scheduled maintenance), refer to the following procedure.

1. Turn the ignition switch to the ON position (Do not start the engine).
2. Fully depress the accelerator pedal, slowly, three times within 10 seconds.
3. Turn the ignition switch to the OFF/LOCK position.

Note. If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset. If necessary, repeat this procedure.

Scheme 52

The Remote Compass Module (RCM) (2) is a separate stand alone module mounted to the top side of the headliner (1) at the left rear of the vehicle. The RCM can be accessed by removing both quarter trim panels and the headliner molding, then carefully lowering the rear of the headliner at the D-pillar area.

If the compass position sensor (Remote Compass Module) is inoperative and requires replacement. Refer to MODULE, COMPASS , REMOVAL .

The Compass Temperature Display system uses both non-switched and ignition switched sources of battery current so that some of its features remain operational at any time, while others may only operate with the ignition switch in the ON position. When the ignition switch is turned to the ON position, the display will return to the last function being displayed before the ignition was turned to the OFF position. Pressing and holding the instrument cluster push-button allows setting variance zones and manual calibration of the compass.

The Compass Temperature Display system is comprised of several different components that communicate over the Controller Area Network (CAN) and Local Interface Network (LIN) Data Bus circuits. If the system is inoperative a scan tool and the appropriate diagnostic information must be used to diagnose the system and related data buses.

REMOTE COMPASS MODULE

The Remote Compass Module (RCM) data is transferred on the Controller Area Network (CAN) Data Bus circuit. The RCM and Electronic Vehicle Information Center (EVIC)/Compass Temperature Display will not function properly if the bus messages are not properly received. If no EVIC/Compass Temperature Display data is displayed, check the CAN Data Bus circuit communications, the RCM (if equipped), the Instrument Cluster functions and the Totally Integrated Power Module (TIPM). Any diagnosis of the RCM and EVIC/Compass Temperature Display system should begin with the use of a scan tool and the appropriate diagnostic service information.

For complete circuit diagrams, refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector pin-out information and location views for the various wire harness connectors, splices and grounds.

Scheme 53

A degaussing tool (Special Tool (special tool #6029, De Gauser)) is used to demagnetize, or degauss, the roof panel above the remote compass module. Equivalent units must be rated as continuous duty for 110/115 volts and 60 Hz. They must also have a field strength of over 350 gauss at 7 millimeters (0.25 inch) beyond the tip of the probe.

Scheme 54

Demagnetize the roof panel as follows

1. Be certain that the ignition switch is in the Off position, before you begin the demagnetizing procedure.
2. Place a piece of paper approximately 22 by 28 centimeters (8.5 by 11 inches), oriented on the vehicle lengthwise from front to rear, on the exterior surface of the roof panel at the left D-pillar in the area of the compass module. The purpose of the paper is to protect the roof panel from scratches, and to define the area to be demagnetized.
3. Connect the degaussing tool to an electrical outlet, while keeping the tool at least 61 centimeters (2 feet) away from the compass unit.
4. Slowly approach the center line of the roof panel at the windshield header, with the degaussing tool connected.
5. Contact the roof panel with the plastic coated tip of the degaussing tool. Be sure that the template is in place to avoid scratching the roof panel. Using a slow, back-and-forth sweeping motion, and allowing 13 millimeters (0.50 inch) between passes, move the tool at least 11 centimeters (4 inches) to each side of the roof center line, and 28 centimeters (11 inches) back from the windshield header.
6. With the degaussing tool still energized, slowly back it away from the roof panel. When the tip of the tool is at least 61 centimeters (2 feet) from the roof panel, disconnect the tool.
7. Calibrate the compass and adjust the compass variance. Refer to «MODULE, COMPASS , STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#message-center-service-information) .

Scheme 55

Compass variance, also known as magnetic declination, is the difference in angle between magnetic north and true geographic north. In some geographic locations, the difference between magnetic and geographic north is great enough to cause the compass to give false readings. If this problem occurs, the compass variance must be set.

Note. If the vehicle is taken on long trips into a new variance zone the compass function may be effected. Compass variance will need to be updated to the new zone number to function properly.

Note. The default for the compass variance from the factory is 8.

SET THE COMPASS VARIANCE MANUALLY AS FOLLOWS

1. Using the Variance Settings Map, find your geographic location and note the zone number.
2. Turn the ignition switch to the ON/RUN position. Press and release the SCROLL push buttons (5 or 6) until "System Set-up" is displayed and highlighted.
3. Press and release the STEP push button (3) to open the menu.
4. Using the scroll buttons, scroll through until " Compass Variance" is displayed and highlighted.
5. Momentarily depress and release the STEP push button to begin.
6. Using the same button toggle through the zone numbers (1-15), until the zone number for your geographic location appears in the display. The zone number will set automatically. NOTE: The default for the compass variance from the factory is 8. During programming, the Zone value will wrap around from Zone 15 to Zone 1.
7. Momentarily depress and release the BACK push button (4) return to the main menu.
8. Confirm that the correct direction is now indicated by the compass.
9. Using the scroll button (5 and 6), select " Turn Off Menu " to exit.

MANUAL COMPASS CALIBRATION

Note. Confirmation that the proper variance zone is programmed, is recommended whenever manual compass calibration is performed, for the appropriate procedure, refer to MODULE, COMPASS , STANDARD PROCEDURE .

The electronic compass unit features a self-calibrating design, which simplifies the calibration procedure. This feature automatically updates the compass calibration while the vehicle is being driven. This allows the compass unit to compensate for small changes in the residual magnetism that the vehicle may acquire during normal use. If the compass readings appear to be erratic or the Electronic Vehicle Information Center (EVIC) displays "CAL", perform the following manual calibration procedure. Also, any time EVIC service replacement components are installed, they must be calibrated using this procedure. Do not attempt to calibrate the compass near large metal objects such as other vehicles, large buildings, or bridges; or, near overhead or underground power lines.

Note. Do not attempt to calibrate the compass near large metal objects such as other vehicles, large buildings, or bridges; or, near overhead or underground power lines.

CALIBRATE THE COMPASS MANUALLY AS FOLLOWS

1. Start the engine but leave the vehicle in "PARK".
2. Press and release the SCROLL push buttons (5 or 6) until "System Set-up" is displayed and highlighted.
3. Press the STEP push button (3) to open the menu.
4. Using the scroll buttons, scroll through until " Calibrate Compass " is displayed and highlighted.
5. Momentarily depress and release the STEP push button to initiate the calibration procedure. The "CAL" symbol will come on solid in the EVIC display next to the compass direction that is displayed.
6. Slowly drive the vehicle on a level surface, away from large metal objects and power lines, through one or two complete circles not exceeding 8 km/h (5 mph). The "CAL" message will disappear from the display to indicate successful compass calibration.
7. Confirm that the correct direction is now indicated by the compass.
8. Using the scroll button, select " Turn Off Menu " to exit.

Note. If the compass display indicates an inaccurate compass heading or the display is locked up, the RCM (if equipped) may be inoperative and require replacement.

Note. If the "CAL" message remains in the display, either there is excessive magnetism near the compass, or the EVIC is inoperative. Attempt the calibration procedure at least one more time before performing EVIC diagnosis.

Note. If the wrong direction is still indicated in the compass display, the area selected for calibration may be too close to a strong magnetic field. Repeat the manual calibration procedure in another location.

Scheme 56

1. Disconnect and isolate the negative battery cable.
2. Partially remove the headliner (1) to gain access to the Remote Compass Module (RCM) (2). Refer to «HEADLINER , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#body-interior-exterior) .
3. Disconnect the RCM electrical connector (3).
4. Remove the RCM fasteners (4).
5. Remove the RCM (2) from the vehicle.

Scheme 57

1. Position the Remote Compass Module (RCM) (2) into the bracket on the upper side of the headliner (1).
2. Install the RCM fasteners (4).
3. Connect the electrical connector (3).
4. Install the headliner assembly. Refer to «HEADLINER , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#body-interior-exterior) .
5. Connect the negative battery cable.
6. Perform the Compass Variance Adjustment. Refer to «MODULE, COMPASS , STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#message-center-service-information) .
7. Perform the Manual Compass Calibration. Refer to «MODULE, COMPASS , STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#message-center-service-information) .
8. Verify proper compass operation.

Scheme 58

The ambient temperature sensor is a variable resistor type sensor that is mounted behind the radiator grille assembly on the left side of the vehicle.

The ambient temperature sensor cannot be adjusted or repaired, if inoperative or damaged, it must be replaced.

The ambient temperature sensor is a variable resistor that operates on a five-volt reference signal sent by the Totally Integrated Power Module (TIPM). The resistance in the sensor changes as temperature changes, changing the temperature sensor signal circuit voltage to the TIPM. Based upon the resistance in the sensor, the TIPM senses a specific voltage on the temperature sensor signal circuit. The TIPM then translates the voltage into a temperature reading that it sent over the Controller Area Network (CAN) data bus circuit to other modules utilizing temperature information.

AMBIENT TEMPERATURE SENSOR

The temperature function is supported by the ambient temperature sensor, a wiring circuit, and the Totally Integrated Power Module (TIPM). When the sensor is exposed to temperatures above 60° C (140° F), or if the sensor circuit is shorted, 60° C (130/140° F) will appear in the display in place of the temperature. When the sensor is exposed to temperatures below - 40° C (- 40° F) or if the sensor circuit is open, - - ° C (- - ° F) will be displayed on Electronic Vehicle Information Center (EVIC) equipped vehicles.

Note. The system displays the last known temperature when starting the vehicle and may take some time/mileage to update to an accurate current reading, up to 5 minutes at a maintained speed above 40 mph (64.3 kph). Customers with very short commutes may not get an updated reading before the vehicle is turned off, or if the ignition does not remain in the OFF position for more than 255 minutes (4hrs. 15min.). This strategy was intended to eliminate wildly fluctuating readings and may cause some customer confusion leading to unnecessary diagnostics/parts replacements.

SENSOR TEST

1. Turn the ignition switch to the Off position. Disconnect and isolate the battery negative cable. Disconnect the ambient temperature sensor harness connector.
2. Measure the resistance of the ambient temperature sensor. At - 40° C (- 40° F), the sensor resistance is 336 kilohms. At 55° C (130° F), the sensor resistance is 2.488 kilohms. The sensor resistance should read between these two values. If OK, refer to appropriate Electrical Diagnostic article. If not OK, replace the inoperative ambient temperature sensor.

The ambient temperature sensor circuit can also be diagnosed using the following Sensor Test, and Sensor Circuit Test. If the temperature sensor and circuit are confirmed to be OK, but the temperature display is inoperative or incorrect, test the EVIC operation. Refer to CENTER, ELECTRONIC VEHICLE INFORMATION , DIAGNOSIS AND TESTING .

SENSOR CIRCUIT TEST

Refer to the appropriate wiring information for complete circuit schematic or connector pin-out information.

1. Turn the ignition switch to the Off position. Disconnect and isolate the battery negative cable. Disconnect the wire harness connectors from the ambient temperature sensor and the TIPM.
2. Connect a jumper wire between the two terminals in the body half of the ambient temperature sensor harness connector.
3. Check for continuity between the sensor return circuit and the ambient temperature sensor signal circuit cavities of the TIPM harness connector. There should be continuity. If OK, refer to 4 . If not OK, repair the open sensor return circuit or ambient temperature sensor signal circuit to the ambient temperature sensor as required.
4. Check for continuity between the ambient temperature sensor signal circuit cavity of the TIPM harness connector and a good ground. There should be no continuity. If OK, test the EVIC operation. Refer to «CENTER, ELECTRONIC VEHICLE INFORMATION , DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#message-center-service-information) . If not OK, repair the shorted ambient temperature sensor signal circuit as required.

The most reliable, efficient and accurate means to diagnose the ambient temperature circuit requires the use of a scan tool and the proper diagnostic procedure information. Refer to wiring for the appropriate information.

Scheme 59

1. Disconnect and isolate the negative battery cable.
2. Remove the radiator grille assembly. Refer to «GRILLE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#body-interior-exterior) .
3. Disconnect the wire harness connector (3) from the ambient temperature sensor (2).
4. Remove the push pin type retainer (1), and remove the sensor.

INSTALLATION

1. Position the ambient temperature sensor (2) in the vehicle and install the push pin type retainer (1).
2. Connect the wire harness connector (3) to the ambient temperature sensor.
3. Install the radiator grille assembly. Refer to «GRILLE , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#body-interior-exterior) .
4. Connect the negative battery cable.

DESCRIPTION

The Electronic Vehicle Information Center (EVIC) conveniently allows the driver to navigate through, and select, a variety of information by pressing the EVIC function buttons located on the left side of the steering wheel. For more information on the EVIC, its functions and many of the systems that are supported, refer to CENTER, ELECTRONIC VEHICLE INFORMATION , DESCRIPTION and CENTER, ELECTRONIC VEHICLE INFORMATION , OPERATION .

REMOVAL

Scheme 60

Scheme 61

Scheme 62

1. Disconnect and isolate the battery negative cable.
2. Remove the driver airbag assembly from the steering wheel. Refer to «AIR BAG, DRIVER , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/airbag/#restraints-service-information) .
3. From the back of the steering wheel (4), remove the two screws (2) that secure the center spoke of the rear cover (1) to the center spoke of the steering wheel spoke front bezel (3).
4. From the face of the steering wheel, remove the four screws (2) that secure the front spoke bezel (4) to the steering wheel armature within the steering wheel hub cavity.
5. Using a trim stick (special tool # (special tool #C-4755, Trim Stick)) or equivalent, carefully pry at the parting line between the front spoke bezel and the steering wheel rear cover enough to unsnap the two horizontal members of the bezel from those of the rear cover.
6. Pull the front spoke bezel away from the steering wheel far enough to access and disconnect the steering wheel wire harness connections from the Electronic Vehicle Information Center (EVIC) switch pod (1) and the speed control switch pod (3).
7. From the back of the steering wheel spoke front bezel (4), remove the three screws (2) that secure the EVIC switch pod (3) mounting tabs to the bezel.
8. Remove the switch from the bezel.

Scheme 63

1. Position the Electronic Vehicle Information center (EVIC) switch pod (3) to the back of the steering wheel spoke front bezel (4).
2. Install and tighten the three screws (2) that secure the switch mounting tabs to the bezel. Tighten the screws securely.
3. Position the front spoke bezel close enough to the steering wheel to reconnect the steering wheel wire harness connections to the Electronic Vehicle Information Center (EVIC) switch pod and the speed control switch pod connector receptacles (3).
4. Position the front spoke bezel (4), EVIC switch pod (1) and speed control switch pod (3) as a unit to the steering wheel. Be certain that the steering wheel wire harness is routed between the lower or upper bezel stanchions and the inside circumference of the steering wheel hub cavity so that the wiring will not be pinched when the driver airbag is reinstalled.
5. Use hand pressure to squeeze the horizontal spokes of both the front spoke bezel and the steering wheel rear cover together until all of the snap features are fully engaged.
6. Install and tighten the four screws that secure the stanchions of the front spoke bezel to the steering wheel armature within the steering wheel hub cavity. Tighten the screws securely.
7. From the back of the steering wheel (4), install and tighten the two screws (2) that secure the center spoke of the rear cover (1) to the center spoke of the steering wheel spoke front bezel (3). Tighten the screws securely.
8. Install the driver airbag assembly (2). Refer to «AIR BAG, DRIVER , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/airbag/#restraints-service-information) .
9. Do not reconnect the battery negative cable at this time. The Supplemental Restraint System (SRS) verification test procedure should be performed following service of any SRS component. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/airbag/#occupant-restraint-controller-orc-restraints-system-pre-diagnostic-troubleshooting-procedure-intermittent-test-verificat) .
10. Connect the negative battery cable.

See also:
• REMOVAL
• DESCRIPTION
• HEADLINER , REMOVAL
• WARNING
• STANDARD PROCEDURE
• SWITCH, EVIC CONTROL , REMOVAL
• MODULE, COMPASS , REMOVAL
• CENTER, ELECTRONIC VEHICLE INFORMATION , DESCRIPTION
• CENTER, ELECTRONIC VEHICLE INFORMATION , OPERATION
