Transmission/transaxle Cooling: Removal & Installation Jaguar XKR I рестайлинг

Installation

1. Install the transmission fluid cooler return tube.
2. Install the transmission fluid cooler tubes. Attach the transmission fluid cooler tubes. Install the retaining plate. Install the retaining bolt . Tighten to 23 Nm.
3. Install the transmission heat shield.
4. Install the transmission fluid cooler tube retaining bracket.
5. Install the left-hand engine mount. Refer to «Engine»(ref-311051) article.
6. Carry out transmission fluid level check. Refer to «Automatic Transmission/Transaxle»(ref-311025) article.

Scheme 76

Scheme 77

Scheme 78

1. Carry out the air conditioning (A/C) system recovery procedure. Refer to «Climate Control System - General Information»(ref-311053) article.
2. Disconnect the transmission fluid cooler supply tube. Remove and discard the O-ring seal.
3. Remove the left-hand catalytic converter. Refer to «Exhaust System»(ref-311027) article.
4. Disconnect the air conditioning line. Remove and discard the O-ring seal.
5. Remove the left-hand engine mount. Refer to «Engine»(ref-311051) article.
6. Remove the transmission fluid cooler retaining.
7. Detach the transmission fluid cooler supply tube.
8. Remove the transmission heat shield.
9. Detach the transmission fluid cooler supply tube and return tube. Remove the retaining bolt. Remove the retaining plate. CAUTION: Make sure the transmission fluid cooler tubes are not removed from the automatic transmission by using a pry bar. Failure to follow this instruction may result in damage to the vehicle. Detach the transmission fluid cooler tubes. Allow the transmission fluid to drain into a suitable container.
10. Remove the transmission fluid cooler supply tube.

1. Attach the transmission fluid cooler tubes. Attach the transmission fluid cooler tubes. Install the retaining plate. Install the retaining bolt . Tighten to 23 Nm.
2. Install the transmission heat shield.
3. Install the transmission fluid cooler tube retaining bracket.
4. Install the left-hand engine mount. Refer to «Engine»(ref-311051) article.
5. Install the left-hand catalytic converter. Refer to «Exhaust System»(ref-311027) article.
6. Connect the air conditioning line.
7. Lower the vehicle.
8. Connect the transmission fluid cooler supply pipe. Tighten to 20 Nm.
9. Carry out transmission fluid level check. Refer to «Automatic Transmission/Transaxle»(ref-311025) article.
10. Carry out the air conditioning (A/C) evacuation and charging procedure. Refer to «Climate Control System - General Information»(ref-311053) article.
