Automatic Transmission/transaxle External Controls: Removal & Installation Jaguar XKR I рестайлинг

Installation

1. To install, reverse the removal procedure. Tighten to 5 Nm.

Scheme 50

Scheme 51

Scheme 52

1. Move the transmission selector lever to the "R" position.
2. Remove the floor console. Refer to «Instrument Panel and Console»(ref-311041) article.
3. Detach the selector lever cable from the transmission selector lever linkage.
4. Detach the selector lever cable from the transmission selector lever bracket.
5. Remove the selector lever cable retaining tie strap.
6. Raise and support the vehicle. Refer to «Jacking and Lifting»(ref-311011) article.
7. Detach the selector lever cable from the automatic transmission gear selector.
8. Detach the selector lever cable and bracket.
9. Detach the grommet and remove the selector lever cable and bracket.

1. Install the selector lever cable and bracket.
2. Attach the selector lever cable and bracket. Tighten to 11 Nm.
3. Attach the selector lever cable to the automatic transmission gear selector.
4. Lower the vehicle.
5. Install a new selector lever cable retaining tie strap.
6. Make sure the selector lever cable is in the "R" position.
7. Make sure the transmission selector lever is in the "R" position.
8. Attach the selector lever cable to the transmission selector lever bracket.
9. Attach the selector lever cable to the transmission selector lever linkage.
10. Adjust the selector lever cable adjustment nuts to lock against the retaining bracket. Do not fully tighten the selector lever cable adjustment nuts.
11. Make sure all transmission selector lever positions select the relevant automatic transmission states.
12. Tighten the selector lever cable adjustment nuts. Tighten to 20 Nm.
13. Install the floor console. Refer to «Instrument Panel and Console»(ref-311041) article.

Scheme 53

Scheme 54

Scheme 55

Scheme 56

1. Remove the floor console. Refer to «Instrument Panel and Console»(ref-311041) article.
2. Disconnect the drive to fifth switch electrical connector.
3. Remove the transmission selector lever knob. Refer to «Transmission Selector Lever Knob - Removal and Installation»(ref-311060-S05174469992009032300000) .
4. Remove the transmission selector lever knob locking collar.
5. Disconnect the selector lever indicator assembly electrical connector.
6. Remove the selector lever indicator assembly.

1. To install, reverse the removal procedure.

Scheme 57

1. Remove the transmission selector lever. Refer to «Transmission Selector Lever - Removal and Installation»(ref-311060-S16308570092009032300000) .
2. Remove the transmission control switch.

Scheme 58

Scheme 59

Scheme 60

Scheme 61

1. Align the transmission control switch to the transmission selector lever.
2. Loosely install the transmission control switch.
3. Move the selector lever to position 4.
4. Hold the selector lever in position 4 and adjust the transmission control switch .
5. Tighten the transmission control switch retaining screws.
6. Move the selector lever to all positions to check the transmission control switch is correctly aligned.
7. Install the transmission selector lever. Tighten to 11 Nm.
8. Attach the wiring harness electrical connector.
9. Connect the park position switch and selector lever indicator assembly electrical connectors.
10. Connect the brake shift interlock actuator and transmission control switch electrical connectors.
11. Connect the drive to fifth switch electrical connector.
12. Make sure the selector lever cable is in the "R" position.
13. Move the transmission selector lever to the "R" position.
14. Attach the selector lever cable to the transmission selector lever bracket.
15. Attach the selector lever cable to the transmission selector lever linkage.
16. Adjust the selector lever cable adjustment nuts to lock against the retaining bracket. Do not fully tighten the selector lever cable adjustment nuts.
17. Make sure all transmission selector lever positions select the relevant automatic transmission states.
18. Tighten the selector lever cable adjustment nuts. Tighten to 20 Nm.
19. Turn the ignition switch to the ON position
20. Move the transmission selector lever to the "R" position.
21. Loosen the transmission control switch retaining screws.
22. Adjust the transmission control switch until the "R" position of the selector lever indicator is illuminated.
23. Tighten the transmission control switch retaining screws.
24. Make sure all transmission selector lever positions illuminate the relevant transmission selector lever indicator positions.
25. Make sure the engine starts when the transmission selector lever is in the "P" and "N" positions.
26. Install the floor console. Refer to «Instrument Panel and Console»(ref-311041) article.

Removal

1. Move the transmission selector lever to the "R" position.
2. Remove the floor console. Refer to «Instrument Panel and Console»(ref-311041) article.
3. Detach the selector lever cable from the transmission selector lever linkage.
4. Detach the selector lever cable from the transmission selector lever bracket.
5. Disconnect the drive to fifth switch electrical connector.
6. Disconnect the brake shift interlock actuator and transmission control switch electrical connectors.
7. Disconnect the park position switch and selector lever indicator assembly electrical connectors.
8. Detach the wiring harness electrical connector.
9. Remove the transmission selector lever.

1. Install the transmission selector lever. Tighten to 11 Nm.
2. Attach the selector lever indicator assembly electrical connector.
3. Connect the park position switch and selector lever indicator assembly electrical connectors.
4. Connect the brake shift interlock actuator and transmission control switch electrical connectors.
5. Connect the drive to fifth switch electrical connector.
6. Make sure the selector lever cable is in the "R" position.
7. Make sure the transmission selector lever is in the "R" position.
8. Attach the selector lever cable to the transmission selector lever bracket.
9. Attach the selector lever cable to the transmission selector lever linkage.
10. Adjust the selector lever cable adjustment nuts to lock against the retaining bracket. Do not fully tighten the selector lever cable adjustment nuts.
11. Make sure all transmission selector lever positions select the relevant automatic transmission states.
12. Tighten the selector lever cable adjustment nuts. Tighten to 20 Nm.
13. Install the floor console. Refer to «Instrument Panel and Console»(ref-311041) article.

Scheme 62

1. Using a suitable tool, loosen the transmission selector lever knob locking collar.
2. Remove the transmission selector lever knob.

1. Install the transmission selector lever knob.
2. Using a suitable tool, tighten the transmission selector lever knob locking collar.

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

1. Remove the transmission selector lever knob. Refer to «Transmission Selector Lever Knob - Removal and Installation»(ref-311060-S05174469992009032300000) .
2. Remove the transmission control switch. Refer to «Transmission Control Switch - Removal and Installation»(ref-311060-S37931138482009032300000) .
3. Remove the transmission selector lever knob locking collar.
4. Remove the selector lever indicator assembly.
5. Detach the park position switch electrical connector.
6. Remove the brake shift interlock actuator cover.
7. Remove the brake shift interlock actuator.
8. Remove the side plate.
9. Remove the slide block and shaft assembly.
10. Remove the brake shift interlock lever.
11. Remove the selector lever assembly.
12. Remove the return spring.
13. Remove the selector lever pivot brackets.
