Contents Section: Automatic Trans All sections

Automatic Transmission/transaxle External Controls: Diagnosis Jaguar XKR I рестайлинг

Automatic Trans 12 illustrations ~1967 words

Inspection and verification

WARNINGDanger of accident. Apply the parking brake. Shift the gear selector lever to P . Failure to follow these instructions may result in personal injury.
  1. Verify the customer concern.
  2. Confirm which, if any, warning lights and/or messages were displayed on the instrument cluster. NOTE: If any warning lights and/or messages were displayed when the fault occurred, refer to the Driver Information table for DTCs associated with the display, then to the DTC index table for possible sources and actions. Some warnings will appear to clear when the ignition is cycled. This is often because the warning has flagged as a result of one of the vehicle's on-board diagnostic routines having run to detect the fault. If the same routine is not run when the ignition is switched ON, the warning will not reflag until the routine does run. See the DTC summaries for drive cycle routines.
  3. Visually inspect for obvious signs of mechanical or electrical damage.

Visual Inspection Chart

MechanicalElectrical
Visibly damaged or worn parts Transmission selector cable adjustment Refer to Selector Lever Cable Adjustment - General Procedures .Fuse(s) Loose or corroded electrical connector(s)

Visual Inspection Chart

  1. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  2. Where the Jaguar approved diagnostic system is available, complete the S93 report before clearing any or all fault codes from the vehicle.
  3. If the cause is not visually evident and the Jaguar approved diagnostic system is not available, use a fault code reader to retrieve any fault codes before proceeding to the Diagnostic Trouble Code (DTC) Index Chart, or the Symptom Chart if no DTCs are set.
  4. Using the Jaguar approved diagnostic system where available, and a scan tool where not, check the freeze frame data for information on the conditions applicable when the fault was flagged. The format of this will vary, depending on the tool used, but can provide information useful to the technician in diagnosing the fault.

Symptom Chart

CAUTIONWhen probing connectors to take measurements in the course of the pinpoint tests, use the adaptor kit, part number 3548-1358-00.

Note. Check and rectify basic faults before beginning diagnostic routines involving pinpoint tests.

Note. Check and rectify basic faults before beginning diagnostic routines involving pinpoint tests.

Note. When performing electrical voltage or resistance tests, always use a digital multimeter (DMM) accurate to 3 decimal places, and with an up-to-date calibration certificate. When testing resistance, always take the resistance of the DMM leads into account.

Symptom (general)Symptom (specific)Possible sourceAction
Gear selector illumination malfunctionGear selector position indicator misaligned with position selectedSelector lever indicator adjustment incorrect Selector lever indicator failure CAN bus communication failureFor selector lever adjustment and replacement, Refer to Selector Lever Indicator Assembly - Removal and Installation . For CAN tests, Refer to Module Communications Network article.
Erratic selection of D to 5 shiftLinear switch does not detect lever movement from D to 5Position alignment switch circuit failure Position alignment microswitch failureFor position alignment switch circuit tests, Refer to Pinpoint Test C .
Erratic operation of brake shift interlockInterlock function will not operate/releaseNot-in-Park microswitch circuit failure Not-in-Park microswitch failure Brake shift interlock solenoid circuit failure Brake shift interlock solenoid failureFor not-in-park switch tests, Refer to Pinpoint Test D . For interlock solenoid circuit tests, Refer to Pinpoint Test E .
Erratic operation of the keylock solenoidKeylock function will not operate/releaseNot-in-Park microswitch circuit failure Not-in-Park microswitch failure Keylock solenoid circuit failure Keylock solenoid failureFor not-in-park switch circuit tests, Refer to Pinpoint Test D . For keylock solenoid circuit tests, Refer to Pinpoint Test F .

Diagnostic Trouble Code (DTC) Index

DTCDescriptionPossible SourceAction
P0706Gear selector position plausibility faultTCM/linear switch module CAN fault Linear switch module failure TCM/control valve failureFor TCM/linear switch module CAN fault, and module failure, Refer to Module Communications Network article. For transmission mechanical failure, Refer to Automatic Transmission/Transaxle article.
P0709Gear selector intermediate position faultLinear switch module failureFor linear switch module failure, Refer to Module Communications Network article.
P0860Linear switch module CAN network malfunctionCAN open circuit fault CAN short circuit fault Linear switch module failureFor CAN circuit faults or linear switch module failure, Refer to Module Communications Network article.
P1516Gear change P/N driving malfunctionECM P/N circuit; short circuit to ground, short circuit to high voltage, high resistance Gear selector cable adjustment incorrect Linear switch module incorrect adjustment Linear switch module/ECM CAN faultFor ECM P/N circuit tests, Refer to Pinpoint Test A . For gear selector cable adjustment, Refer to Selector Lever Cable Adjustment - General Procedures . For linear switch module adjustment, and Transmission control switch. For CAN circuit faults, Refer to Module Communications Network article.
P1517Gear change P/N starting malfunctionECM P/N circuit; short circuit to ground, short circuit to high voltage, high resistance Gear selector cable adjustment incorrectFor ECM P/N circuit tests, Refer to Pinpoint Test A . For gear selector cable adjustment, Refer to Selector Lever Cable Adjustment - General Procedures . For CAN circuit faults, Refer to Module Communications Network article.
P1774CAN J-gate time-outCAN open circuit fault - TCM to linear switch module CAN short circuit fault Linear switch module failureFor CAN circuit faults or linear switch module failure, Refer to Module Communications Network article.

Pinpoint Test : CHECK FOR POWER AND GROUND SUPPLIES TO THE LINEAR SWITCH MODULE

  1. CHECK IGNITION SUPPLY VOLTAGE Disconnect the linear switch module electrical connector, FC100. Turn the ignition switch to the ON position. Measure the voltage between FC100, pin 04 (WR) and GROUND. Is the voltage less than 10 volts? YES: REPAIR the circuit between the linear switch module and battery. This circuit includes the driver's side fuse box, (fuse 16) the ignition positive relay, and the high power protection module. For additional information, refer to the wiring diagrams. CLEAR the DTC. TEST the system for normal operation. NO: Go to step 2 .
  2. CHECK GROUND CIRCUIT Turn the ignition switch to the OFF position. Measure the resistance between FC100, pin 11 (B) and GROUND. Is the resistance greater than 5 ohms? YES: REPAIR the high resistance circuit. For additional information, refer to the wiring diagrams. CLEAR the DTC. TEST the system for normal operation. NO: Check for DTCs. Carry out tests indicated by the DTCs logged.

Pinpoint Test A: DTC P1516, P1517; GEAR CHANGE P/N DRIVING/STARTING MALFUNCTION

Pinpoint Test A

A1 CHECK THE ECM TO TCM CIRCUIT FOR HIGH RESISTANCE
  1. Disconnect the battery negative terminal.
  2. Disconnect the ECM electrical connector, EM80.
  3. Disconnect the TCM electrical connector, GB02.
  4. Measure the resistance between EM80, pin 31 (G) and GB02, pin 10 (G).
Is the resistance greater than 5 ohms?
YES REPAIR the high resistance circuit. For additional information, refer to the wiring diagrams. CLEAR the DTC. TEST the system for normal operation.
NO Go to step 2 . → A2
A2 CHECK THE ECM TO TCM CIRCUIT FOR SHORT TO HIGH VOLTAGE
  1. Reconnect the battery negative terminal.
  2. Turn the ignition switch to the ON position.
  3. Measure the voltage between EM80, pin 31 (G) and GROUND.
Is the voltage greater than 1 volt?
YES REPAIR the short circuit. For additional information, refer to the wiring diagrams. CLEAR the DTC. TEST the system for normal operation.
NO Go to step 3 . → A3
A3 CHECK THE ECM TO TCM CIRCUIT FOR SHORT TO GROUND
  1. Measure the resistance between EM80, pin 31 (G) and ground.
Is the resistance less than 10,000 ohms?
YES REPAIR the short circuit. For additional information, refer to the wiring diagrams. CLEAR the DTC. TEST the system for normal operation.
NO Recheck the DTCs. Contact Dealer technical support for advice on possible ECM or TCM failure.

Pinpoint Test D: CHECK THE NOT-IN-PARK SWITCH CIRCUIT

Pinpoint Test D

D1 CHECK THE NOT-IN-PARK SWITCH LOGIC GROUND
  1. Disconnect the not-in-park switch electrical connector, FC87
  2. Measure the resistance between FC87, pin 03 (BK) and GROUND.
Is the resistance greater than 5 ohms?
YES REPAIR the high resistance circuit. For additional information, refer to the wiring diagrams. TEST the system for normal operation.
NO Go to step 2 . → D2
D2 CHECK THE NOT-IN-PARK SWITCH TO BODY PROCESSOR MODULE (BPM) CIRCUIT FOR HIGH RESISTANCE
  1. Disconnect the battery negative terminal.
  2. Disconnect the BPM electrical connector, FC14.
  3. Measure the resistance between FC87, pin 01 (YB) and FC14, pin 58 (YB).
Is the resistance greater than 5 ohms?
YES REPAIR the high resistance circuit. For additional information, refer to the wiring diagrams. TEST the system for normal operation.
NO Go to step 3 . → D3
D3 CHECK THE NOT-IN-PARK SWITCH TO BODY PROCESSOR MODULE (BPM) CIRCUIT FOR SHORT TO HIGH VOLTAGE
  1. Reconnect the battery negative terminal.
  2. Measure the voltage between FC87, pin 01 (YB) and GROUND.
Is the voltage greater than 3 volts?
YES REPAIR the short circuit. For additional information, refer to the wiring diagrams. TEST the system for normal operation.
NO Go to step 4 . → D4
D4 CHECK THE NOT-IN-PARK SWITCH TO BODY PROCESSOR MODULE (BPM) CIRCUIT FOR SHORT TO GROUND
  1. Measure the resistance between FC87, pin 01 (YB) and GROUND.
Is the resistance less than 10,000 ohms?
YES REPAIR the short circuit. For additional information, refer to the wiring diagrams. TEST the system for normal operation.
NO INSTALL a new not-in-park switch. CLEAR the DTC. TEST the system for normal operation.

Pinpoint Test E: CHECK THE INTERLOCK SOLENOID CIRCUIT

Pinpoint Test E

E1 CHECK THE INTERLOCK SOLENOID GROUND
  1. Disconnect the interlock solenoid electrical connector, FC86.
  2. Measure the resistance between FC86, pin 02 (B) and GROUND.
Is the resistance greater than 5 ohms?
YES REPAIR the high resistance circuit. For additional information, refer to the wiring diagrams. TEST the system for normal operation.
NO Go to step 2 . → E2
E2 CHECK THE INTERLOCK SOLENOID OUTPUT FROM BPM
  1. Turn the ignition switch to the ON position.
  2. Apply the footbrake.
  3. Measure the voltage between FC86, pin 01 (OG) and GROUND.
Is the voltage less than 10 volts?
YES Go to step 3 . → E3
NO INSTALL a new interlock solenoid. Refer to «Brake Shift Interlock Actuator - Removal and Installation»(ref-311060-S14754768832009032300000) . TEST the system for normal operation.
E3 CHECK THE INTERLOCK SOLENOID OUTPUT CIRCUIT FROM BPM FOR HIGH RESISTANCE
  1. Disconnect the battery negative terminal.
  2. Disconnect the BPM electrical connector, FC14.
  3. Measure the resistance between FC86, pin 01 (OG) and FC14, pin 48 (OG).
Is the resistance greater than 5 ohms?
YES REPAIR the high resistance circuit. For additional information, refer to the wiring diagrams. TEST the system for normal operation.
NO Check for DTCs indicating a brake switch malfunction. Check the brake switch signal to the BPM (SCP network)

Pinpoint Test F: CHECK THE KEYLOCK SOLENOID CIRCUIT

Pinpoint Test F

F1 CHECK THE KEYLOCK SOLENOID GROUND
  1. Disconnect the keylock solenoid electrical connector, SC05.
  2. Measure the resistance between SC05, pin 02 (B) and GROUND.
Is the resistance greater than 5 ohms?
YES REPAIR the high resistance circuit. For additional information, refer to the wiring diagrams. TEST the system for normal operation.
NO Go to step 2 . → F2
F2 CHECK THE KEYLOCK SOLENOID OUTPUT FROM THE BPM
  1. Turn the ignition switch to the ON position.
  2. Move the gear selector lever to the D position.
  3. Measure the voltage between SC05, pin 01 (RW) and GROUND.
Is the voltage less than 10 volts?
YES Go to step 3 . → F3
NO INSTALL a new keylock solenoid. TEST the system for normal operation.
F3 CHECK THE KEYLOCK SOLENOID OUTPUT CIRCUIT FROM THE BPM FOR HIGH RESISTANCE
  1. Disconnect the battery negative terminal.
  2. Disconnect the BPM electrical connector, FC14.
  3. Measure the resistance between SC05, pin 01 (RW) and FC14, pin 51 (RW).
Is the resistance greater than 5 ohms?
YES REPAIR the high resistance circuit. For additional information, refer to the wiring diagrams. TEST the system for normal operation.
NO Contact Dealer technical support for advice on possible BPM failure.

Scheme 38

Scheme 38: Brake Shift Interlock Actuator Manual Override - General Procedures
Scheme 38: Brake Shift Interlock Actuator Manual Override - General Procedures

Scheme 39

Scheme 39
Scheme 39
  1. Remove the selector lever blanking screw.
  2. Using a suitable tool, press and hold the brake shift interlock actuator manual override and simultaneously move the selector lever to the "N" position.
  3. Remove the suitable tool.
  4. Install the selector lever blanking screw.

Scheme 40

Scheme 40: Selector Lever Cable Adjustment - General Procedures
Scheme 40: Selector Lever Cable Adjustment - General Procedures

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42
  1. Move the transmission selector lever to the "R" position.
  2. Remove the floor console. Refer to «Instrument Panel and Console»(ref-311041) article.
  3. Detach the selector lever cable from the transmission selector lever linkage.
  4. Detach the selector lever cable from the transmission selector lever bracket.
  5. Make sure the selector lever cable is in the "R" position.
  6. Make sure the transmission selector lever is in the "R" position.
  7. Attach the selector lever cable to the transmission selector lever bracket.
  8. Attach the selector lever cable to the transmission selector lever linkage.
  9. Adjust the selector lever cable adjustment nuts to lock against the retaining bracket. Do not fully tighten the selector lever cable adjustment nuts.
  10. Make sure all transmission selector lever positions select the relevant automatic transmission states.
  11. Tighten the selector lever cable adjustment nuts. Tighten to 20 Nm.
  12. Install the floor console. Refer to «Instrument Panel and Console»(ref-311041) article.

Scheme 43

Scheme 43: Transmission Control Switch Adjustment - General Procedures
Scheme 43: Transmission Control Switch Adjustment - General Procedures

Scheme 44

Scheme 44
Scheme 44
  1. Remove the floor console. Refer to «Instrument Panel and Console»(ref-311041) article.
  2. Turn the ignition switch to the ON position
  3. Move the transmission selector lever to the "R" position.
  4. Loosen the transmission control switch retaining screws.
  5. Adjust the transmission control switch until the "R" position of the selector lever indicator is illuminated.
  6. Tighten the transmission control switch retaining screws.
  7. Make sure all transmission selector lever positions illuminate the relevant transmission selector lever indicator positions.
  8. Make sure the engine starts when the transmission selector lever is in the "P" and "N" positions.
  9. Install the floor console. Refer to «Instrument Panel and Console»(ref-311041) article.

Scheme 45

Scheme 45: Removal
Scheme 45: Removal

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49
  1. Remove the floor console. Refer to «Instrument Panel and Console»(ref-311041) article.
  2. Disconnect the brake shift interlock actuator electrical connector.
  3. Disconnect the park position switch and selector lever indicator assembly electrical connectors.
  4. Detach the park position switch and selector lever indicator assembly electrical connectors.
  5. Remove the brake shift interlock actuator cover.
  6. Remove the brake shift interlock actuator retaining nuts.
  7. Remove the brake shift interlock actuator.
