Automatic Transmission/transaxle: Overhaul Jaguar XKR I рестайлинг

Input Shaft Seal - Assembly and Disassembly

Special Tools Tool Illustration Tool Name Tool Number Front Seal Installer 308-246 Seal Remover Input and Output 308-375 Slide Hammer 100-012 Slide Hammer Adaptor 100-012-01 Torque Converter Handles 307-139

Scheme 16

Scheme 17

Scheme 18

Scheme 19

1. Remove the transmission assembly. See «Transmission - 3.0L»(ref-311025-S17650801762009032300000) , «Transmission - 3.5L/4.2L»(ref-311025-S17650801762009032300000) or «Transmission - 2.7L Diesel»(ref-311025-S17650801762009032300000) .
2. Using the special tools, remove the torque converter. Drain any remaining fluid into a suitable container.
3. Using the special tools, remove the input shaft seal.
4. Clean and inspect the transmission housing seal face.
5. Using the special tool, install a new input shaft seal.
6. Using the special tools, install the torque converter.
7. Install the transmission assembly. See «Transmission - 3.0L»(ref-311025-S17650801762009032300000) , «Transmission - 3.5L/4.2L»(ref-311025-S17650801762009032300000) or «Transmission - 2.7L Diesel»(ref-311025-S17650801762009032300000) .

Transmission - Installation

Special Tools Tool Illustration Tool Name Tool Number Powertrain Assembly Jack HTJ1200-02 Engine Lifting Brackets 303-356 Engine Support Bracket 303-021

All vehicles

1. Flush the transmission fluid cooler and tubes.
2. Apply a thin layer of high-temperature grease to the centering spigot bore on the torque converter.
3. Install the automatic transmission to the vehicle. Raise the automatic transmission to the vehicle. Install the transmission to engine retaining bolts. Tighten to 48 Nm.
4. Install the transmission to engine retaining bolts. Tighten to 48 Nm.
5. Attach the transmission mount bracket.
6. Install the transmission mount bracket retaining bolts.
7. Remove the tie down strap.
8. Install the automatic transmission mount retaining bolts. Raise the rear of the transmission. Tighten to 50 Nm.
9. Remove the special tool.
10. Install the transmission to engine lower retaining bolts. Tighten to 48 Nm.
11. Connect the automatic transmission electrical connectors.
12. Attach the transmission fluid cooler tubes to the automatic transmission. Attach the transmission fluid cooler tubes to the automatic transmission. Install the retaining plate. Install the retaining bolt. Tighten to 23 Nm.
13. Attach the selector lever cable and bracket. Tighten to 11 Nm.
14. Attach the selector lever cable to the transmission gear selector.
15. Install the transmission heat shields.
16. Attach the transmission fluid cooler tubes.
17. Install the torque converter retaining bolts. Rotate the torque converter to gain access to the remaining two retaining bolts. Tighten to 55 Nm.
18. Install the torque converter retaining bolt access cover.
19. Install the driveshaft. Refer to «Driveshaft»(ref-311018-S38478700512009032300000) .
20. Remove the special tool. Loosen the special tool adjustment bolts.
21. Remove the special tool.
22. Remove the special tool.

Vehicles with supercharger

1. Attach the crankcase ventilation tube.
2. Attach the wiring harness.

All vehicles

1. Attach the catalytic converters. Refer to «Catalytic Converter LH»(ref-311027-S06727633272009032300000) and «Catalytic Converter RH»(ref-311027-S05437639872009032300000) .
2. Connect the battery ground cable. Refer to «Battery Ground Cable»(ref-311034) .
3. Carry out a transmission fluid level check. Refer to «Transmission Fluid Level Check»(ref-311025-S21011166372009032300000) .
