Automatic Transmission/transaxle: Removal & Installation Jaguar XKR I рестайлинг

Removal

All vehicles

Scheme 2

Scheme 3

1. Disconnect the battery ground cable. Refer to «Battery Disconnect»(ref-311034) .
2. Remove the air deflector. Refer to «Air Deflector»(ref-311035) .
3. Drain the transmission. Refer to «Transmission Fluid Drain and Refill»(ref-311025-S17650801762009032300000)
4. Detach the catalytic converter temperature sensor wiring harness from the fluid pan.
5. Remove the fluid pan, gasket and filter. Remove the retaining bolts.

Installation

All vehicles

1. Install the new fluid pan, gasket and filter. Tighten to 8 Nm.
2. Attach the catalytic converter temperature sensor wiring harness onto the fluid pan.
3. Fill the transmission. Refer to «Transmission Fluid Drain and Refill»(ref-311025-S17650801762009032300000)
4. Install the air deflector. Refer to «Air Deflector»(ref-311035) .
5. Lower the vehicle.
6. Connect the battery ground cable. Refer to «Battery Connect»(ref-311034) .

1. Install the new seals.
2. Install the new seals.
3. Install the TCM and main control valve body sealing block.
4. Align the transmission selector shaft to the TCM and main control valve body.
5. Install the TCM and main control valve body retaining bolts. Tighten to 8 Nm.
6. Install the new seals.
7. Install the sealing tube.
8. Reposition the TCM and main control valve body electrical connector retaining ring. Connect the electrical connector. Reposition the electrical connector retaining ring.
9. Reposition the locking device.
10. Install the fluid pan, gasket and filter. Refer to «Fluid Pan, Gasket and Filter»(ref-311025-S05894424882009032300000) .

Transmission - Removal

Special Tools Tool Illustration Tool Name Tool Number Powertrain Assembly Jack HTJ1200-02 Engine Lifting Brackets 303-356 Engine Support Bracket 303-021

All vehicles

1. Move the transmission selector lever to the "N" position.
2. Disconnect the battery ground cable. Refer to «Battery, Mounting and Cables»(ref-311034) .
3. Remove the catalytic converters. Refer to «Exhaust System»(ref-311027) .

Vehicles with supercharger

Scheme 4

1. Detach the wiring harness.
2. Detach the crankcase ventilation tube.

All vehicles

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. Install the special tool.
2. Install the special tool.
3. Install the special tool. Rotate the special tool adjustment bolts a suitable amount of turns to improve access to the top of the automatic transmission.
4. Remove the driveshaft. Refer to «Driveshaft»(ref-311018) .
5. Remove the torque converter retaining bolt access cover.
6. Remove the torque converter retaining bolts. Rotate the torque converter to gain access to the remaining two retaining bolts.
7. Detach the transmission fluid cooler tubes.
8. Remove the transmission heat shields.
9. Detach the selector lever cable transmission gear selector.
10. Reposition the selector lever cable and bracket.
11. Detach the transmission fluid cooler tubes from the automatic transmission. Remove the retaining bolt. Remove the retaining plate. CAUTION: Make sure the transmission fluid cooler tubes are not removed from the automatic transmission by using a pry bar. Failure to follow this instruction may result in damage to the vehicle. Detach the transmission fluid cooler tubes from the automatic transmission. Allow the transmission fluid to drain into a suitable container.
12. Disconnect the automatic transmission electrical connectors.
13. Remove the transmission to engine lower retaining bolts.
14. Install the special tool.
15. Lower the rear of the transmission. Remove the automatic transmission mount retaining bolts.
16. Install the tie down strap.
17. Remove the transmission mount bracket retaining bolts.
18. Detach the transmission mount bracket.
19. Remove the transmission to engine retaining bolts.
20. Remove the automatic transmission from the vehicle. Remove the transmission to engine retaining bolts. Lower the automatic transmission from the vehicle.
