Automatic Transaxle Control System - (TB-65/60N): Removal & Installation Hyundai Genesis I

Automatic Trans 1 illustration ~114 words

Installation

  1. Install the TCU (A) to the ECU by tightening the four bolts.
  2. Install the ECU and TCU with the bracket (B) by tightening the four bolts and the nut.
  3. Connect the connectors (A) of ECU and TCU.
  4. Install the plastic cover (A) to the driver's side of the engine room.
  5. Connect (-) terminal to the battery. NOTE: The battery is placed right side of the temporary tire in the trunk.

Scheme 249

Scheme 249: Description
Scheme 249: Description
  1. Input speed sensor detects Input speed from rotation number of direct & reverse disc clutch case, and transmit to TCU as a signal.
  2. Adoption of electromagnetic pick sensor of high detection precision.
