Automatic Transaxle Control System - (TB-65/60N): Adjustments Hyundai Genesis I

Automatic Trans 6 illustrations ~316 words

How To Adjust Shift Cable

  1. Insert the shift cable to the bracket and hold it with a new clip.
  2. Align the manual lever hole to the hole on the transmission case and hold the position with a bar.
  3. Eliminate shift cable free play of the shift cable.
  4. Firmly hold the special bolt with a spanner and tighten the nut with the specified torque. Tightening torque : 13~16 Nm (1.3~1.6 kgf.m, 9.40~11.57 lb-ft)
  5. Take off the bar holding the manual lever.
  6. Shifting the each position, check that the shift lever moves smoothly.

Scheme 238

Scheme 238: Removal
Scheme 238: Removal

Scheme 239

Scheme 239
Scheme 239

Scheme 240

Scheme 240
Scheme 240

Scheme 241

Scheme 241
Scheme 241

Scheme 242

Scheme 242
Scheme 242
  1. Pull the shift lever knob (A) upward to remove.
  2. Remove the center console, (refer to «INTERIOR»(ref-345931) )
  3. Disconnect the sport mode connector (A).
  4. Disconnect the wire (A) for the airbag assembly.
  5. Take off the clip (A) and remove the shift cable assembly (B).
  6. Remove the shift lever assembly (A) by removing the four bolts.
  7. Remove the shift cable assembly from the transmission (refer to «REMOVAL»(ref-345914-S37941916302009102300000) )
  8. Pull the rubber plug on the floor and pull out the shift cable assembly.

Scheme 243

Scheme 243
Scheme 243
  1. Insert the shift cable assembly and place the rubber plug on the floor.
  2. Install the shift lever assembly (A) by tightening the four bolts. Tightening torque : 9~14 Nm (0.9~1.4 kgf.m, 6.51~10.12 lb-ft)
  3. Install the shift cable assembly (B) and insert the clip (A). CAUTION: Place the waving shape end of the shift cable upward.
  4. Install the shift cable assembly to the transmission (refer to «INSTALLATION»(ref-345914-S11136081222009102300000) ) CAUTION: Check that the shift cable is installed properly referring to ' «HOW TO ADJUST THE SHIFT CABLE»(ref-345912-S19284745342009102300000) '.
  5. Connect the wire (A) for the airbag assembly.
  6. Connect the sport mode connector (A).
  7. Install the center console, (refer to8 «INTERIOR»(ref-345931) )
  8. Insert the shift lever knob (A) with the specified force. Specification : 2.2~3.6 N (22~36 kgf, 48.5~79.4 lb)
