Function of TCU

  1. Shift control and L-up control According to each shift schedule, TCU sends signals to the S1, S2, S3, S4, SR, SL1, SL2 which operates control "Shift Control" and the SLU which operates linear control "L-up Control" on the basis of the vehicle speed and the throttle opening. The TB-60SN and TB-65SN have a "AUTO CRUISE MODE" switch. Other mode does not have a driving mode selector switch that allows drivers to select a mode themselves. The vehicle is ordinarily in Economy mode. However, when specific conditions are met, the TCU selects a shifting pattern appropriate to driving conditions from all of the shifting patterns and switches automatically. ECONOMY MODE Used during normal driving. ECONOMY mode is basic shift schedule and the ideal shift schedule to be consistent with fuel economy and acceleration performance. This mode is normally selected where no other higher priority shift mode is activated. Full shift schedule map is available including lockup for this mode. HIGH OIL TEMPERATURE MODE This mode is protect the gearbox from the overheating. This mode is activated where the T/M oil temperature is too high, and will prevent the T/M oil temperature increasing by torque converter slipping. HIGH OIL TEMPERATURE MODE shift schedule map is available including lockup depending on the T/M oil temperature area for this mode. UP SLOPE MODE 1,2 The UP-SLOPE 1, 2 detect up hill road condition and change the shift map to powerful map to avoid busy shifting at up hill condition. When start condition of up-slope mode is detected, shift map is changed upslope1 or upslope2 map depending on slope gradient if no higher priority mode is activated. AUTO CRUISE MODE The AUTO CRUISE CONTROL detects "ACC ON" signal and use specific point to prevent shift hunting during ACC ON. When cruise control is ON, gears are fixed to perform smooth driving. GEAR HOLD MODE The GEAR HOLD according to the request by TCS/VDC in order to support the vehicle stability. This function can be activated in every shift mode except for MANUAL MODE. When start condition is fulfilled, gear is held to current gear. The gear hold is performed after shift control finished if start condition is fulfilled during shifting.
  2. Sports mode Driver oneself can select favorite gear and enjoy sports driving of manual transmission sense by shifting shift lever from "D" to manual gear position and shift gate or steering switch M+(Up shift)/M-(Down shift). But L-up control is operated automatically. Shift control is operated again by shifting from manual gear position to "D". Following control is operated when Sports shift mode.
  3. L-up control Based on rpm signals, signals from the engine control unit (engine rpm and throttle opening) and vehicle speed, smooth lock-up control is achieved through linear control of the lock-up control solenoid (SLU).
  4. L-up cut control This control cuts L-up operation at shift down or idle condition and avoid engine stall by depressing brake pedal at low speed driving.
  5. Inhibit 5-6 shifting (low engine temp) When engine water temperature signal detects cold, TCU prohibits 5-6 shifting.
  6. Torque reduction control and line pressure control This control improves the shift quality due to sending torque reduction request signal from TCU to PCM and cutting engine torque increase of shift at 1 <--> 2 <--> 3 <--> 4 <--> 5 <--> 6 Line pressure control improves the shift quality due to controllable line pressure at 1 <--> 2 <--> 3 <--> 4 <--> 5 <--> 6.

Scheme 250

Scheme 250: Terminal of TCU
TerminalSignalNameTerminalSignalName
1+BBattery voltage (+)28RNeutral start switch "R"
2GNDTCU Ground (-)29-40
341S4Shift solenoid S4
4IGIgnition switch42SRShift solenoid SR
5IGIgnition switch43SL2Clutch pressure control solenoid No.2 (+)
6SPGOutput speed sensor (-)44NTInput speed sensor (+)
7TIP DOWNManual shift switch (Down)45SG1Output speed sensor ground
8TIP UPManual shift switch (Up)46
9PNeutral start switch "P"47NNeutral start switch "N"
10-1248-52
13CANHCAN communication (CAN-H)53OTOil temperature sensor (+)
14CANLCAN communication (CAN-L)54-60
15-1661S1Shift solenoid S1
17SL1GClutch pressure control solenoid No.1 (-)62S2Shift solenoid S2
18SL2GClutch pressure control solenoid No.2 (-)63NTGInput speed sensor (-)
19SLTGLine pressure control solenoid (-)64SG2Input speed sensor Ground
20SLUGLock-up control solenoid (-)65-66
21GNDTCU Ground (-)67DNeutral start switch "D"
22SLTLine pressure control solenoid (+)68-71
23SLULock-up control solenoid (+)72OTGOil temperature sensor (-)
24SL1Clutch pressure control solenoid No.1 (+)73-78
25SPOutput speed sensor (+)79SFLShift lock solenoid
2680
27TIPMManual shift operation switch (M)81S3Shift solenoid S3

CONNECTOR TERMINAL REFERENCE

Scheme 251

Scheme 251: Removal

Scheme 252

Scheme 252

Scheme 253

Scheme 253

Scheme 254

Scheme 254
  1. Disconnect (-) terminal from the battery. NOTE: The battery is placed right side of the temporary tire in the trunk.
  2. Remove the plastic cover (A) from the driver's side of the engine room.
  3. Disconnect the connectors (A) of ECU and TCU.
  4. Remove the ECU and TCU with the bracket (B) by removing the four bolts and the nut.
  5. Remove the TCU (A) from the ECU by removing the four bolts.
