Inspection

Check that the resistance between the 2 pins of the sensor is within the standard value.

Standard value

Resistance (at 20°C) : 560~680 ohms

Scheme 244

Scheme 244: Replacement

Scheme 245

Scheme 245
  1. Remove the bolt to remove the input speed sensor from the ATM.
  2. Install the input speed sensor with the bolt to the ATM. Tightening torque : 4~7 Nm (0.4~0.7 kgf.m, 2.89~5.06 lb-ft) Bolt size (3): M6x1.0x14mm

Check that the resistance between the 2 pins of the sensor is within the standard value.

Standard value

Resistance (at 20 °C) : 560~680 ohms

Scheme 246

Scheme 246: Replacement

Scheme 247

Scheme 247
  1. Remove the bolt to remove the input speed sensor from the ATM.
  2. Install the input speed sensor with the bolt to the ATM. Tightening torque : 4~7 Nm (0.4~0.7 kgf.m, 2.89~5.06 lb-ft) Bolt size (3): M6x1.0x14mm

Scheme 248

Scheme 248: Description
  1. The oil temperature sensor (A), which is integrated with the transmission wires, is installed on the front valve body. It directly detects the oil temperature within the hydraulic pressure control circuit and transmits a signal based on that temperature to the TCU.
