DTC P0365: CMP Sensor No Signal Honda Insight ZE2

Testing & Diagnostics 5 illustrations ~567 words

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 226

Scheme 226: DTC P0365: CMP Sensor No Signal
Scheme 226: DTC P0365: CMP Sensor No Signal

Scheme 227

Scheme 227
Scheme 227

Scheme 228

Scheme 228
Scheme 228

Scheme 229

Scheme 229
Scheme 229

Scheme 230

Scheme 230
Scheme 230
  1. Turn the ignition switch to ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine.
  4. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0365 indicated? YES -Go to step 5 . NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the CMP sensor and the PCM.
  5. Turn the ignition switch to LOCK (0).
  6. Disconnect the CMP sensor 3P connector.
  7. Turn the ignition switch to ON (II).
  8. Measure the voltage between CMP sensor 3P connector terminal No. 3 and body ground. Is there battery voltage? YES -Go to step 9 . NO -Repair an open in the wire between the CMP sensor and PGM-FI main relay 1, then go to step 18 .
  9. Measure the voltage between CMP sensor 3P connector terminal No. 1 and body ground. Is there about 5 V? YES -Go to step 10 . NO -Go to step 11 .
  10. Measure the voltage between CMP sensor 3P connector terminals No. 2 and No. 3. Is there battery voltage? YES -Go to step 16 . NO -Repair an open in the wire between the CMP sensor and G101 (see «ENGINE WIRE HARNESS (ENGINE SECTION)»(ref-360302-S11950116962010042800000) ), then go to step 18 .
  11. Turn the ignition switch to LOCK (0).
  12. Jump the SCS line with the HDS.
  13. Disconnect PCM connector C (44P).
  14. Check for continuity between PCM connector terminal C31 and body ground. Is there continuity? YES -Repair a short in the wire between the PCM (C31) and the CMP sensor, then go to step 18 . NO -Go to step 15 .
  15. Check for continuity between CMP sensor 3P connector terminal No. 1 and PCM connector terminal C31. Is there continuity? YES -Go to step 23 . NO -Repair an open in the wire between the PCM (C31) and the CMP sensor, then go to step 18 .
  16. Turn the ignition switch to LOCK (0).
  17. Replace the CMP sensor (see «CMP SENSOR REPLACEMENT»(ref-360284-S25838473272010042800000) ).
  18. Reconnect all connectors.
  19. Turn the ignition switch to ON (II).
  20. Reset the PCM with the HDS.
  21. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-360285-S23715037572010042800000) ).
  22. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0365 indicated? YES -Check for poor connections or loose terminals at the CMP sensor and the PCM, then go to step 1 . NO -Troubleshooting is complete. If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.
  23. Reconnect all connectors.
  24. Update the PCM if it does not have the latest software (see «PCM UPDATE»(ref-360284-S30758408212010042800000) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(ref-360279-S07789660702010042800000) ).
  25. Check for Pending or Confirmed DTCs with the HDS.

Is DTC P0365 indicated?

YES -Check for poor connections or loose terminals at the CMP sensor and the PCM. If the PCM was updated, substitute a known-good PCM (see SUBSTITUTING THE PCM ), then recheck. If the PCM was substituted, go to step 1 .

NO -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see PCM REPLACEMENT ). If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.
