Testing & Diagnostics 8 illustrations ~271 words

Except AT-PZEV (SULEV) model

Note. When the third HO2S is replaced, the secondary HO2S must be replaced at the same time to keep their performance matched (see Secondary HO2S Replacement ).

Scheme 680

Scheme 680: Except AT-PZEV (SULEV) model
  1. Disconnect the third HO2S 4P connector (A), then remove the third HO2S (B).
  2. Install the third HO2S in the reverse order of removal.

Scheme 681

Scheme 681: MAP Sensor Replacement
  1. Disconnect the MAP sensor 3P connector.
  2. Remove the MAP sensor (A).
  3. Install the sensor in the reverse order of removal with a new O-ring (B).

Scheme 682

Scheme 682: CKP Sensor Replacement
  1. Disconnect the CKP 3P connector.
  2. Remove the CKP sensor (A).
  3. Install the sensor in the reverse order of removal with a new O-ring (B).

Scheme 683

Scheme 683: ECT Sensor Replacement
  1. Remove the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-176536-S12188318782005050600000) ).
  2. Disconnect the ECT sensor 2P connector.
  3. Remove the ECT sensor (A).
  4. Install the sensor in the reverse order of removal with a new O-ring (B).

Scheme 684

Scheme 684: CMP Sensor Replacement
  1. Remove the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-176536-S12188318782005050600000) ).
  2. Disconnect the CMP sensor 3P connector.
  3. Remove the CMP sensor (A).
  4. Install the sensor in the reverse order of removal with a new O-ring (B).

Scheme 685

Scheme 685: IAT Sensor Replacement
  1. Disconnect the IAT sensor 2P connector.
  2. Remove the IAT sensor (A).
  3. Install the sensor in the reverse order of removal with a new O-ring (B).

Scheme 686

Scheme 686: Knock Sensor Replacement
  1. Remove the intake manifold (see «INTAKE MANIFOLD REMOVAL AND INSTALLATION»(ref-176526-S38419045822005050600000) ).
  2. Disconnect the knock sensor 1P connector.
  3. Remove the knock sensor (A).
  4. Install the sensor in the reverse order of removal.

Scheme 687

Scheme 687: Brake Booster Pressure Sensor Replacement
  1. Disconnect the brake booster pressure sensor 3P connector.
  2. Remove the brake booster pressure sensor (A).
  3. Install the sensor in the reverse order of removal.
