Pgm-Fi System (Gx): Overview Honda Civic VI

Testing & Diagnostics 11 illustrations ~744 words

Scheme 50

Scheme 50: System Description

The PGM-FI system on this model is a sequential multiport fuel injection system.

Description

The low fuel indicator light turns on when the fuel level is low.

The low fuel indicator light blinks when a problem is detected with the fuel tank pressure sensor or the fuel tank temperature sensor.

Note. If a fuel leak is detected, the fuel pressure regulator shut-off solenoid valve/fuel tank internal solenoid valve will not reopen until the PCM is reset.

Scheme 51

Scheme 51: Description
DTCDescription
DTC P0107A Low Voltage (High Vacuum) Problem In The Manifold Absolute Pressure (MAP) Sensor
DTC P0108A High Voltage (Low Vacuum) Problem In The Manifold Absolute Pressure (MAP) Sensor
DTC P1128Manifold Absolute Pressure (MAP) Lower Than Expected
DTC P1129Manifold Absolute Pressure (MAP) Higher Than Expected
DTC P0112A Low Voltage (High Temperature) Problem In The Intake Air Temperature (IAT) Sensor Circuit
DTC P0113A High Voltage (Low Temperature) Problem In The Intake Air Temperature (IAT) Sensor Circuit
DTC P0116A Range/Performance Problem In The Engine Coolant Temperature (ECT) Sensor Circuit
DTC P0117A Low Voltage (High Temperature) Problem In The Engine Coolant Temperature (ECT) Sensor Circuit
DTC P0118A High Voltage (Low Temperature) Problem In The Engine Coolant Temperature (ECT) Sensor Circuit
DTC P0122A Low Voltage Problem In The Throttle Position (TP) Sensor Circuit
DTC P0123A High Voltage Problem In The Throttle Position (TP) Sensor Circuit
DTC P1121Throttle Position (TP) Lower Than Expected
DTC P1122Throttle Position (TP) Higher Than Expected
DTC P0131A Low Voltage Problem In The Primary Heated Oxygen Sensor (HO2S) (Sensor 1) Circuit
DTC P0132A High Voltage Problem In The Primary Heated Oxygen Sensor (Primary HO2S) (Sensor 1) Circuit
DTC P0133A Slow Response Problem In The Primary Heated Oxygen Sensor (Primary HO2S) (Sensor 1) Circuit
DTC P0137A Low Voltage Problem In The Secondary Heated Oxygen Sensor (Secondary HO2S) (Sensor 2) Circuit
DTC P0138A High Voltage Problem In The Secondary Heated Oxygen Sensor (Secondary HO2S) (Sensor 2) Circuit
DTC P0139A Slow Response Problem In The Secondary Heated Oxygen Sensor (HO2S) (Sensor 2) Circuit.
DTC P0135, P0141Heated Oxygen Sensor Heater circuit
DTC P0171, P0172The Fuel System Is Too Rich/Lean
DTC P0191A Range/Performance Problem In The Fuel Pressure Circuit
DTC P0192A Low Voltage (Low Fuel Pressure) Problem In The Fuel Pressure Sensor
DTC P0193A High Voltage (High Fuel Pressure) Problem In The Fuel Pressure Sensor
DTC P0301, P0302, P0303, P0304Misfire Detected
DTC P0300, P0301, P0302, P0303, P0304Random Misfire
DTC P0335, P0336, P1361, P1362, P1381, P1382CKP Sensor Circuit, TDC Sensor Circuit, CYP Sensor Circuit
DTC P0501A Range/Performance Problem In The Vehicle Speed Sensor (VSS) Circuit
DTC P1106A Range/Performance Problem In The Barometric Pressure (Baro) Sensor Circuit
DTC P1107, P1108A High/Low Voltage Problem In The Baro Sensor Circuit
DTC P1182A Low Voltage (High Temperature) Problem In The Fuel Temperature Sensor Circuit
DTC P1183A High Voltage (Low Temperature) Problem In The Fuel Temperature Sensor Circuit
DTC P1187A Low Voltage (High Temperature) Problem In The Fuel Tank Temperature Sensor Circuit
DTC P1188A High Voltage (Low Temperature) Problem In The Fuel Tank Temperature Sensor Circuit
DTC P1192A Low Voltage (Low Fuel Pressure) Problem In The Fuel Tank Pressure Sensor
DTC P1193A High Voltage (High Fuel Pressure) Problem In The Fuel Tank Pressure Sensor Circuit
DTC P1297A Low Voltage Problem In The Electrical Load Detector (ELD) Circuit
DTC P1298A High Voltage Problem In The Electrical Load Detector (ELD) Circuit
DTC P1336, P1337CKF Sensor Circuit
DTC P1359A Problem In The Crankshaft Position/Top Dead Center/Cylinder Position (CKP/TDC/CYP) Sensor Circuit
DTC P1607A PCM Internal Circuit Problem

DIAGNOSTIC TROUBLE CODES (DTC) LIST

By controlling the air/fuel ratio with a Primary HO2S (Sensor 1) and a Secondary HO2S (Sensor 2), the deterioration of the Primary HO2S (Sensor 1) can be evaluated by its feedback period. When the feedback period of the HO2S exceeds a certain value during stable driving conditions, the sensor will be judged as deteriorated.

When deterioration has been detected during two consecutive trips, the MIL comes on and DTC P0133 will be stored.

Note. If DTC P0131, P0132 and/or P0135 are stored at the same time as DTC P0133, troubleshoot those DTCs first, then troubleshoot DTC P0133.

By monitoring the Long Term Fuel Trim, long term malfunctions in the fuel system will be detected.

If a malfunction has been detected during two consecutive trips, the MIL will come on and DTC P0171 and/or P0172 will be stored.

Note. If some of the DTCs listed below are stored at the same time as DTC P0171 and/or P0172, troubleshoot those DTCs first, then troubleshoot DTC P0171 and/or P0172.

P0107, P0108, P1128-9: MAP Sensor

P0191: Fuel Pressure Sensor

P0135: Primary HO2S Heater

P0137, P0138: Secondary HO2S

P0141: Secondary HO2S Heater

P0401: EGR Flow Insufficient

P1259: VTEC System

P1491: EGR Valve Lift Insufficient

P1498: EGR Valve Lift Sensor High Voltage

Misfire detection is accomplished by monitoring the crankshaft speed with the crankshaft speed fluctuation (CKF) sensor which is attached to the crankshaft.

If misfiring strong enough to damage the catalyst is detected, the MIL will blink during the time of its occurrence, and DTC P0301, P0302, P0303 or P0304 will be stored. Then, after the misfire has ceased, the MIL will come on.

If misfiring that increases emissions is detected during two consecutive driving cycles, the MIL will come on, and DTC P0301, P0302, P0303 or P0304 will be stored.

Note. If some of the DTCs listed below are stored at the same time as a misfire DTC, troubleshoot those DTCs first, then troubleshoot the misfire DTC.

P0131, P0132: HO2S

P0171, P0172: Fuel supply system

P0335, P0336: CKF sensor

P0401, P1491, P1498: EGR system

P1359, P1361, P1362: TDC sensor

P1381, P1382: CYP sensor

Misfire detection is accomplished by monitoring the crankshaft speed with the crankshaft speed fluctuation (CKF) sensor which is attached to the crankshaft.

If misfiring strong enough to damage the catalyst is detected, the MIL will blink during the time of its occurrence, and DTC P0300 and some of DTCs P0301 through P0304 will be stored. Then, after misfire has ceased, the MIL will come on.

If misfiring that increases emissions is detected during two consecutive driving cycles, the MIL will come on, and DTC P0300 and some of DTCs P0301 through P0304 will be stored.

Note. If some of the DTCs listed below are stored at the same time as a misfire DTC. Troubleshoot those DTCs first, then troubleshoot the misfire DTC.

P1128, P01129: MAP sensor

P0131, P0132: HO2S

P0171, P0172: Fuel metering

P0401, P1491, P1498: EGR system

P0505: Idle Control System

P1253: VTEC System

P1361, P1362: TDC sensor

P1381, P1382: CYP sensor

P1508: IAC valve

The CKP Sensor determines timing for fuel injection and ignition of each cylinder and also detects engine speed. The TDC Sensor determines ignition timing at start-up (cranking) and when crank angle is abnormal. The CYP Sensor detects the position of No. 1 cylinder for sequential fuel injection to each cylinder. The CKP/TDC/CYP Sensor is built into the distributor.

Note. If DTC P1359 is stored at the same time as DTC P0335, P0336, P1361, P1362, P1381 and/or P1382, troubleshoot DTC P1359 first, then troubleshoot those DTCs.

Scheme 52

Scheme 52: Description

Scheme 53

Scheme 53

Scheme 54

Scheme 54: DTC P0501: A Range/Performance Problem In The Vehicle Speed Sensor (VSS) Circuit

Scheme 55

Scheme 55: DTC P1106: A Range/Performance Problem In The Barometric Pressure (Baro) Sensor Circuit

Scheme 56

Scheme 56: DTC P1107, P1108: A High/Low Voltage Problem In The Baro Sensor Circuit

The diagnostic system has a pulser rotor on the crankshaft and a pulse pick-up sensor on the engine block. The PCM monitors the crankshaft speed fluctuation based on the CKF sensor signal, and judges that an engine misfire occurred if the fluctuation goes beyond a predetermined limit.

Scheme 57

Scheme 57: Description

Scheme 58

Scheme 58

Scheme 59

Scheme 59: DTC P1359: A Problem In The Crankshaft Position/Top Dead Center/Cylinder Position (CKP/TDC/CYP) Sens

Scheme 60

Scheme 60: DTC P1607: A PCM Internal Circuit Problem
