AIR INTAKE SYSTEM

Note. DO NOT adjust by-pass valve full-close screw. Adjustment is preset at factory.

Intake Air By-Pass (IAB) Valve (Prelude H22A1)

1. Check valve shaft for binding and sticking. Check valve for smooth movement. Ensure tab on valve contacts stopper when valve is fully open. (Scheme 118)
2. Ensure tab of by-pass valve contacts full-close screw when valve is fully closed. If any fault is found, clean linkage and shafts using carburetor cleaner. If problem still exists after cleaning, disassemble intake manifold and inspect by-pass valve.

Scheme 118

IAB Control Solenoid Valve (Prelude H22A1)

1. Start and idle engine. Remove vacuum hose No. 13 from by-pass control diaphragm. (Scheme 119) Connect vacuum gauge to hose. If vacuum exists, go to next step. If vacuum does not exist, remove vacuum hose No. 12 from vacuum tank. Check for vacuum. If vacuum exists, go to step 3). If vacuum does not exist, repair blockage or leak between vacuum tank and intake manifold. Retest system.
2. Increase engine speed to 5000 RPM. Check for vacuum at hose No. 13. If vacuum does not exist, solenoid is okay. If vacuum exists, unplug connector at solenoid. Check for vacuum again. If vacuum still exists, replace solenoid valve. If vacuum no longer exists, solenoid valve is okay.
3. Unplug connector at solenoid. Measure voltage between solenoid terminal connector. If battery voltage is present, replace by-pass control solenoid valve. If battery voltage is not present, check continuity of harness wiring to solenoid valve.

Scheme 119

Intake Control Diaphragm (Prelude H22A1)

Connect vacuum pump to vacuum hose on intake control diaphragm. Apply vacuum. If diaphragm holds vacuum, intake diaphragm is okay. If vacuum does not hold, inspect vacuum line for improper connection and disconnected hose. If hose is okay, replace intake control diaphragm.

Ground Circuits

1. Measure resistance to ground at appropriate ECM ground terminals. See «POWER & GROUND CIRCUIT TERMINAL IDENTIFICATION»(ref-15916-S04509278292001121400000) table. (Scheme 120) Resistance should be zero ohms for each circuit. If resistance is not zero ohms, repair open to ground.
2. Connect negative lead of DVOM to a good ground. Connect positive lead to each ground terminal. With engine running, voltmeter should indicate less than 0.1 volt. If voltage is greater than 0.1 volt, check for open, corrosion, or loose connection on ground lead.

Power Circuits

1. Check for battery voltage between ECM power terminal and ground. See «POWER & GROUND CIRCUIT TERMINAL IDENTIFICATION»(ref-15916-S04509278292001121400000) table. (Scheme 120) If battery voltage does not exist, check appropriate ECM fuse i n underhood fuse box. See «ECM POWER CIRCUIT FUSE IDENTIFICATION»(ref-15916-S08675268942001121400000) table. If fuse is okay, check for an open in wire between underhood fuse box and appropriate ECM power circuit terminal.
2. Turn ignition on. Check for battery voltage between appropriate ECM power circuit terminal and ground. See POWER & GROUND CIRCUIT TERMINAL IDENTIFICATION table. If battery voltage does not exist, check appropriate fuse in underhood fuse box. See ECM POWER CIRCUIT FUSE IDENTIFICATION table. If fuse is okay, check for open in wire between fuse box and appropriate ECM power circuit terminal, and check for defective ignition switch.

POWER & GROUND CIRCUIT TERMINAL IDENTIFICATION

ECM POWER CIRCUIT FUSE IDENTIFICATION

Scheme 120

ENGINE SENSORS & SWITCHES

Note. Test Harness (07LAJ-PT3010A) is required for testing certain components or systems. (Scheme 121) Connect test harness between control unit and main wiring harness connectors.

Scheme 121

BAROMETRIC PRESSURE (BARO) SENSOR

Barometric pressure (BARO) sensor is built into ECM. See TESTS W/CODES - 2.2L article for testing.

EGR VALVE LIFT SENSOR

See EMISSION SYSTEMS & SUB-SYSTEMS .

HEATED OXYGEN SENSOR (HO2S)

Note. Heated oxygen sensor may also be referred as O2 sensor.

1. Unplug 4-pin connector at HO2S. Sensor is threaded into exhaust manifold or exhaust pipe. Turn ignition on. Measure voltage between White and Green/White wires at HO2S connector. If voltage is less than .1 volt, go to next step. If voltage is greater than .1 volt, replace HO2S.
2. Check for open in White wire between ECM connector terminal D14 and HO2S. Check Green/White wire of ECM connector terminal D22. Repair wire(s) as necessary. Recheck system.

OXYGEN SENSOR (O2S)

Note. All models use heated oxygen sensor. See HEATED OXYGEN SENSOR (HO2S) . Oxygen sensor may be referred to as O2 sensor.

POWER STEERING PRESSURE (PSP) SWITCH

1. Connect test harness between ECM and wiring harness. (Scheme 121) Turn ignition on. Measure voltage between test harness terminal s B8 and A26. (Scheme 120) If voltage i s greater than one volt, go to next step. If voltage is not greater than one volt, go to step 4).
2. Unplug connector on PSP switch. Switch is located on steering gear. On Accord and Odyssey, connect jumper wire between Green and Black wire terminals. On Prelude, connect jumper wire between Red/Green and Black wire terminals.
3. On all models, check for voltage at test harness terminals A26 and B8. If voltage is not present, replace PSP switch. If voltage is present, repair open in Green wire (Accord and Odyssey) or Red/Green wire (Prelude) between ECM terminal B8 and PSP switch, or Black wire between PSP switch and ground.
4. Start engine. Turn steering wheel slowly. Measure voltage between test harness terminals A26 and B8 (Odyssey). If battery voltage is present, PSP signal is okay. If battery voltage is not present, go to next step.
5. Turn ignition off. Unplug test harness connector "B" from main wiring harness only, not ECM. Turn ignition on. If battery voltage is present, go to next step. If battery voltage is not present, replace ECM and retest system.
6. Reconnect harness connector "B" to main wiring harness. Unplug connector from PSP switch. If battery voltage is present, replace PSP switch. If battery voltage is not present, repair short in Green, Brown/Red or Red/Green wire between ECM terminal B8 (B12 on Odyssey) and PSP switch.

TDC/CKP/CYP SENSOR

1. Turn ignition off. Unplug TDC/CKP/CYP sensor connector, located at distributor. Check resistance between terminals "B" and "F", terminals "C" and "G" and terminals "D" and "H". (Scheme 122) If resistance is 700-1300 ohms (350-700 ohms for Accord F22B2 engine and Odyssey) for each pair, go to next step. If any of resistance is not as specified, replace distributor.
2. Check for continuity between each distributor terminal and chassis ground. If continuity exists at any terminal, replace distributor.

Scheme 122

THROTTLE POSITION (TP) SENSOR

1. Turn ignition off. Connect test harness between ECM and vehicle harness connector. (Scheme 121)
2. Turn ignition on. Measure voltage between ECM test harness terminals D11 (D6 on Odyssey) and D22. Open and close throttle while observing voltmeter. Voltage should be about 0.5 volt with throttle fully closed and 4.5 volts with throttle wide open. Voltage should change smoothly as throttle opens and closes.
3. If voltage is not as specified on Accord M/T and Prelude M/T, replace TP sensor. If voltage is as specified, replace ECM and retest system. If voltage is not as specified on Accord A/T, Odyssey and Prelude A/T, go to next step.
4. Unplug 22-pin connector from Transmission Control Module (TCM). TCM is located below center of dashboard. Measure voltage again as throttle is opened and closed. If voltage does not change as specified in step 2), go to next step. If voltage now changes as specified, replace TCM.
5. If voltage is not as specified, check for short or open in Red/Black wire between ECM terminal D11 (D6 on Odyssey) and TP sensor. If wire is okay, replace TP sensor. If problem still exists, see TESTS W/CODES - 2.2L article.

VEHICLE SPEED SENSOR (VSS)

1. Turn ignition off. Connect test harness between ECM and main harness connector. (Scheme 121) Raise and support front of vehicle so front wheels are free to rotate. Connect voltmeter between ECM terminals B10 and A26. (Scheme 120)
2. Turn ignition on. Slowly rotate left front wheel. Voltage should pulse between zero and specified voltage. See VEHICLE SPEED SENSOR (VSS) TEST table. If voltage pulses as specified, replace ECM and retest system. If voltage does not pulse as specified, check for open or short in wiring between ECM terminal B10 and speed sensor. See «WIRING DIAGRAMS»(ref-15916-S00050853792001121400000) section. If wiring is okay, replace defective VSS or ECM.

VEHICLE SPEED SENSOR (VSS) TEST

Main Relay (PGM-FI)

1. If vehicle starts and continues to run, relay is okay. To test, remove main relay, located under left side of dash. Using jumper wires, connect terminal No. 6 to battery voltage. Connect terminal No. 8 to ground. (Scheme 123)
2. Check for continuity between relay terminals No. 5 and 7. Continuity should exist. If continuity does not exist, replace relay. Disconnect battery leads. Repeat measurement. If continuity does not exist, go to next step. If continuity exists, replace relay.
3. Connect battery voltage to relay terminal No. 5. Connect terminal No. 2 to ground. Check for continuity between terminals No. 1 and 3. Continuity should exist. Disconnect battery leads. Repeat measurement. Continuity should not exist. If continuity exists, replace relay.
4. Connect battery voltage to relay terminal No. 3. Connect terminal No. 8 to ground. Check for continuity between terminals No. 5 and 7. Disconnect battery leads. Repeat measurement. If continuity does not exist, relay is okay. If continuity exists, replace relay. If fuel pump still fails to operate, test main relay harness. See MAIN RELAY HARNESS under «INJECTOR RESISTANCE»(ref-15916-S03481568182001121400000) under FUEL SYSTEM.

Scheme 123

IAB Control Solenoid

See AIR INDUCTION SYSTEMS .

Idle Air Control (IAC) Valve

See IDLE CONTROL SYSTEM .

EGR Control Solenoid Valve

See EXHAUST GAS RECIRCULATION (EGR) SYSTEM under EMISSION SYSTEMS & SUB-SYSTEMS.

EVAP Purge Control Solenoid Valve

See FUEL EVAPORATION under EMISSION SYSTEMS & SUB-SYSTEMS.

FUEL DELIVERY

Note. For fuel system pressure testing, see BASIC TESTING - 2.2L article.

Fuel Injectors

Unplug connector at injector. Measure resistance between injector terminals. Resistance should be as specified. See FUEL INJECTOR RESISTANCE table. If resistance is not as specified, replace injector.

INJECTOR RESISTANCE

FUEL INJECTOR RESISTANCE

Fuel Injector Resistor (Accord, Odyssey & Prelude)

Unplug injector resistor harness connector. Injector resistor is located over left front fenderwell on Accord and at upper left firewall on Odyssey and Prelude. Measure resistance between each injector resistor terminal ("B", "C", "D" and "E") and power terminal ("A"). (Scheme 124) Resistance should be 5-7 ohms for each pair of terminals. If any measurement is not as specified, replace injector resistor.

Scheme 124

ELECTRIC LOAD DETECTOR

1. Unplug 3-pin ELD connector (located on right fender apron near underhood fuse panel). Turn ignition on. Measure voltage between Black/Yellow wire (+) and Black wire (-) at ELD connector. If battery voltage exists, go to step 3). If battery voltage does not exist, go to next step.
2. Measure voltage between Black/Yellow wire and chassis ground. If battery voltage exists, repair open in Black wire between ELD connector and ground connection behind right kick panel. If battery voltage does not exist, repair open in Black/Yellow wire between ELD connector and No. 4 fuse (Accord and Odyssey) or ECM fuse (Prelude) in underhood fuse panel.
3. Measure voltage in Green/Red wire between ELD connector and ground. If voltage is about 5 volts, go to next step. If voltage is not as specified, check for open or short in Green/Red wire between ECM and ELD connector. Repair wire as necessary.
4. Turn ignition off. Reconnect ELD connector. Connect test harness between ECM and connectors. (Scheme 121) Start engine and allow it to idle. While measuring voltage between terminals A26 and D10 of ECM connector, turn headlights on low beam. If voltage does not drop when headlights are turned on, replace ELD. If voltage drops, replace ECM with known-good unit. If voltage drop symptom disappears, replace original ECM.

1. Turn ignition off. Unplug IAC valve connector. IAC is located near throttle body. Turn ignition on. Measure voltage between Yellow/Black wire on harness connector and ground. If battery voltage exists, go to next step. If battery voltage does not exist, repair Yellow/Black wire between IAC valve and PGM-FI main relay.
2. Turn ignition off. Connect test harness to vehicle wiring harness, not to ECM. (Scheme 121) Turn ignition on. Momentarily connect terminal A9 (A5 on Odyssey) to terminal A23 (A12 on Odyssey, or A26 on Prelude). If IAC valve clicks, substitute known-good ECM and retest system. If IAC valve does not click, repair Black/Blue wire between IAC and ECM terminal A9 (A5 on Odyssey).

FAST IDLE THERMO VALVE (ACCORD, ODYSSEY & PRELUDE)

1. Remove intake air duct from throttle body. Start engine. Remove fast idle valve cover. Fast idle valve is located near throttle body. Place finger on valve seat area. Check for airflow with engine cold and idling. If airflow does not exist, replace fast idle valve.
2. Warm engine to full operating temperature (cooling fan comes on). Verify valve is completely closed. Valve is leaking if engine speed decreases when lower port is covered and suction can be felt in valve seat area. Replace valve if valve operation is not as specified.

IGNITION SYSTEM

Note. For basic ignition checks, see BASIC TESTING - 2.2L article.

EGR Valve

Ensure all connectors between EGR valve lift sensor and ECM are securely connected. Warm engine to full operating temperature. Disconnect vacuum hose from EGR valve. Connect vacuum pump to EGR valve. Apply vacuum. EGR valve should hold vacuum and engine should die once vacuum is applied. If results are not as specified, replace EGR valve.

Accord & Prelude

1. Start and idle engine. Disconnect hose No. 16 from EGR valve, located at top of engine. Connect vacuum pump/gauge to hose. If vacuum exists, go to next step. If vacuum does not exist, go to step 4).
2. On Accord, unplug 2-pin connector from control box, located on firewall. On Prelude, unplug 2-pin connector from EGR control solenoid valve, located over left front fenderwell. On all models, check for vacuum on hose No. 16. If vacuum does not exist, go to next step. If vacuum exists, check EGR system vacuum hose routing. If hoses are okay, replace EGR control solenoid valve.
3. Turn ignition off. Unplug ECM connector "A". Check for continuity between ground and Pink wire or Red wire (Prelude) at control box connector. If continuity exists, repair short in appropriate wire. If continuity does not exist, replace ECM and retest system.
4. Connect vacuum pump/gauge to EGR valve. With engine idling, apply 8 in. Hg to EGR valve. If engine stalls or runs roughly, and EGR valve holds vacuum, go to next step. If engine operation remains same or EGR valve does not hold vacuum, replace EGR valve.
5. Turn ignition off. On Accord, unplug electrical connector from control box, located on firewall. On Prelude, unplug electrical connector from EGR control solenoid valve, located over left front fenderwell. On all models, turn ignition on. Measure voltage between harness connector Black/Yellow wire and ground. If battery voltage exists, go to next step. If battery voltage does not exist, repair Black/Yellow wire between harness connector and fuse panel.
6. Connect vacuum pump/gauge to hose disconnected in step 1). Connect fused jumper wire between positive battery terminal and Red wire on EGR solenoid valve connector. Observe voltmeter while connecting jumper wire between Black/Yellow wire on EGR solenoid valve connector and negative battery terminal.
7. On all models, gauge should indicate about 8 in. Hg within one second. If gauge indicates as specified, go to next step. If gauge does not indicate as specified, go to step 14).
8. Turn ignition off. Reconnect harness connector. Unplug EGR valve lift sensor harness connector. Turn ignition on. On Accord, measure voltage between Yellow/Blue and Green/Blue wires on harness connector. On Prelude, measure voltage between Red/White and Green/White wires on harness connector. If voltage is about 5 volts, go to step 9). If voltage is not about 5 volts, go to step 15).
9. Turn ignition off. Reconnect wiring to valve lift sensor. Connect ECM test harness. (Scheme 121) Turn ignition on. Measure voltage between specified terminals with no vacuum applied to EGR valve. Apply 8 in. Hg to EGR valve. Voltage should be about 1.2 volts with no vacuum applied and 4.3 volts with vacuum applied. If voltage is not as specified, go to next step. If voltage is as specified, go to step 11).
10. Check for open or short in circuit between EGR valve and ECM terminal D12. (Scheme 120) If wire is okay, replace EGR valve.
11. Observe voltmeter as vacuum is applied and released. If voltage increases and decreases smoothly, go to next step. If voltage does not change smoothly, replace EGR valve.
12. Reconnect hose to EGR valve. Start and idle engine. Connect jumper wire between terminals A6 (A11 on Prelude) and A26. If engine stalls or runs roughly, replace ECM and retest system. If engine does not stall or run rough, repair open in Red wire between ECM terminal A6 (A11 on Prelude) and EGR control solenoid valve.
13. Turn ignition off. Inspect hoses No. 16 and 24 for leaks, restrictions and misrouting. If hoses are okay, go to next step. Make any repairs as necessary.
14. Disconnect lower hose from EGR control solenoid. Connect vacuum pump/gauge to hose. Start and idle engine. If 6-10 in. Hg vacuum exists, replace EGR solenoid valve. If vacuum is not 6-10 in. Hg, replace EGR valve.
15. Measure voltage at Yellow/Blue (Accord) or Red/White (Prelude) wire. If voltage is not about 5 volts, go to next step. If voltage is about 5 volts, repair open in wire between EGR valve and ECM terminal D22.
16. Turn ignition off. Connect test harness connector "D" to ECM only, not to vehicle harness. Turn ignition on. Measure voltage between terminals D20 and D22. If voltage is about 5 volts, repair open in Yellow/Blue (Accord) or Red/White (Prelude) wire between EGR lift sensor and ECM terminal D20. If voltage is not about 5 volts, replace ECM and retest system.

Odyssey

1. Start and idle engine. Disconnect vacuum hose No. 16 from EGR valve. Connect vacuum pump/gauge to hose. If vacuum is present, go to next step. If vacuum is not present, go to step 4).
2. Disconnect 2-pin connector EGR control solenoid control box. Check for vacuum on hose No. 16. If vacuum is not present, go to next step. If vacuum is present, check EGR system vacuum hose routing. If hoses are okay, replace EGR control solenoid valve.
3. Turn ignition off. Unplug ECM connector "A". (Scheme 120) Check for continuity between EGR control solenoid valve 2-pin connector terminal No. 2 (Red wire) and ground. If continuity is present, repair short in wire between ECM terminal A16 and EGR control solenoid valve. If continuity is not present, replace ECM and retest system.
4. Turn ignition off. Unplug 3-pin connector from EGR valve lift sensor. Turn ignition on. Measure voltage between harness connector terminals No. 2 (Green/Blue wire) and No. 3 (Yellow/Blue wire). Reading should be about 5 volts. If reading is as specified, go to step 7). If reading is not as specified, go to next step.
5. Measure voltage between EGR valve lift sensor terminal No. 3 (Yellow/Blue wire) and ground. Reading should be about 5 volts. If reading is as specified, repair open in wire between EGR valve lift sensor and ECM. If reading is not as specified, go to next step.
6. Turn ignition off. Disconnect ECM connector "D". (Scheme 120) Using DVOM, check continuity between ECM connector terminal D21 and EGR valve lift sensor 3-pin connector terminal No. 3 (Yellow/Blue wire). If continuity is present, replace ECM. If continuity is not present, repair open in wire between EGR valve lift sensor and ECM.
7. Install vacuum pump/gauge to EGR valve. Reconnect ECM harness connectors. Start and idle engine. Apply 8 in. Hg to EGR valve. If engine stalls or run rough, go to next step. If engine idle quality does not change, replace EGR valve.
8. Turn ignition off. Unplug 2-pin connector from EGR control solenoid valve. Turn ignition on. Measure voltage between EGR control solenoid valve 2-pin connector terminal No. 1 (Black/Yellow wire) and ground. If battery voltage is present, go to next step. If battery voltage is not present, repair open in circuit between solenoid valve and ECM fuse No. 4 in passenger compartment fuse/relay block.
9. Install vacuum pump/gauge to vacuum hose No. 16. Start and idle engine. Connect battery voltage to EGR control solenoid 2-pin connector terminal No. 1 (Black/Yellow wire). Connect a jumper between EGR control solenoid 2-pin connector terminal No. 2 (Red wire) and ground. Check vacuum gauge. If 18 in. Hg is present within one second, go to step 11). If vacuum reading is not as specified, go to next step.
10. Check vacuum hose(s) for leaks, restrictions or misrouting. Repair as necessary. If hoses are okay, disconnect lower vacuum hose on EGR control solenoid valve and connect vacuum gauge to hose. Start and idle engine. If 6-10 in. Hg is present, replace EGR control solenoid valve. If vacuum is not present, EGR vacuum control valve.
11. Turn ignition off. Reconnect EGR valve lift sensor connector. Reconnect vacuum pump/gauge to EGR valve. Turn ignition on. Measure voltage between ECM connector terminals No. D17 and D22. (Scheme 120) Voltage reading should be about 1.2 volts with no vacuum ap plied, and about 4.3 volts with vacuum applied. If voltage readings are as specified, go to next step. If voltage readings are not as specified, go to step 13).
12. Repair open or short in wire between EGR valve lift sensor and ECM terminal D17. (Scheme 120) If wire is okay, replace EGR valve.
13. Change vacuum readings. If voltage increases/decreases as vacuum is increased/decreased, go to next step. If voltage does not change or is inconsistent, replace EGR valve.
14. Reconnect EGR vacuum hose No. 16. Start and idle engine. Jumper ECM connector terminals No. A12 and A16. (Scheme 120) If engine stalls or runs rough, replace ECM and retest system. If engine idle quality did not change, repair open in wire between EGR control solenoid and ECM terminal A16.

1. Disconnect vacuum hose from EVAP purge control diaphragm valve, located on charcoal canister. Connect vacuum gauge to hose. Start and idle engine. Engine coolant temperature must be less than 167°F (75°C).
2. If vacuum does not exist, go to step 4). If vacuum exists, unplug connector at EVAP purge control solenoid valve. See EVAP PURGE CONTROL SOLENOID LOCATION table. Measure voltage between specified wires. See EVAP PURGE CONTROL SOLENOID CONNECTOR IDENTIFICATION table. EVAP PURGE CONTROL SOLENOID LOCATION Application Location Accord In Control Box On Firewall Odyssey On Right Side Of Firewall Prelude Near Throttle Position Sensor EVAP PURGE CONTROL SOLENOID CONNECTOR IDENTIFICATION Application Positive Terminal Wire Color Negative Terminal Wire Color Accord & Odyssey Yellow/Black Red/Yellow Prelude Black/Yellow Red/Green
3. If battery voltage is present, inspect vacuum hose for leaks, blockage and incorrect routing. If hose is okay, replace EVAP purge control solenoid valve. If voltage does not exist, measure voltage between positive terminal and chassis ground. If battery voltage is not present, repair open circuit in appropriate positive wire. If voltage is present, check for open circuit between negative terminal and ECM. If wire is okay, replace ECM.
4. Warm engine to full operating temperature (cooling fan comes on). Turn off and restart engine. If vacuum now exists, go to EVAP CANISTER. If vacuum does not exist, unplug connector at EVAP purge control solenoid valve.
5. If vacuum now exists, check for short circuit in negative wire between harness connector and ECM. If wire is okay, substitute known good ECM. Retest system. If system now operates properly, replace ECM. If vacuum still does not exist, check vacuum hose for leaks, blockage and improper routing. If hose is okay, replace EVAP purge control solenoid valve.

Note. EVAP canister may also be referred to as charcoal canister or EVAP charcoal canister.

EVAP Canister

Connect vacuum gauge to canister purge air hose, located at bottom of canister. (Scheme 125) Start engine. Increase engine speed to 3500 RPM. Vacuum should register on gauge within one minute. If results are not as specified, inspect purge hose for blockage. If hose is okay, replace charcoal canister.

Scheme 125

EVAP 2-Way Valve

1. Remove fuel filler cap. Disconnect vapor hose from fuel tank side of 2-way valve, located in fuel tank area. Install "T" fitting into hose. Connect vacuum gauge and vacuum pump to "T" fitting.
2. Slowly apply vacuum while observing vacuum gauge. Vacuum should stabilize momentarily at 0.2-0.6 in. Hg. If vacuum is as specified, go to next step. If vacuum is not as specified, replace 2-way valve. Retest system.
3. Move vacuum hose from vacuum to pressure fitting side of vacuum pump. Slowly pressurize vapor line while observing gauge. If pressure stabilizes at 0.4-1.4 in. Hg, valve is okay. If pressure stabilizes at less than 0.4 in. Hg or greater than 1.4 in. Hg, replace valve and retest.

POSITIVE CRANKCASE VENTILATION (PCV)

Inspect crankcase ventilation hoses and connections for leaks and clogging. Start engine. With engine at idle, pinch and release PCV hose. Valve should click. If valve does not click, check for vacuum at PCV valve end of hose. If manifold vacuum exists, replace PCV valve and recheck. If vacuum does not exist, clear blockage in hose.

Wiring Diagram (Accord 2.2L - 1 Of 2). Scheme 126
