Material
| Item | Specification | Fill Capacity |
|---|---|---|
| FNR5 Automatic Transmission Fluid XT-9-QMM5 | Mazda MES MN 117C (ATF-M V) | 6.7L (7 qt) |
| Motorcraft Premium Automatic Transmission Fluid XT-8-QAW (US); CXT-8-LAW12 (Canada) | WSS-M2C924-A | 7.0L (7.4 qt) |
Material
Transaxle Cooling - 6 Speed
These vehicles are equipped with an internal transmission fluid cooler. The transmission fluid cooler is mounted in the engine radiator tank. During operation, transmission fluid travels from the transaxle to the transmission fluid cooler, then back to the transaxle. The transmission fluid cooler transfers heat from the transmission fluid to the engine coolant.
Scheme 528
| Item | Part Number | Description |
|---|---|---|
| 1 | 8005 | Radiator |
| 2 | 7H420 | Transmission fluid cooler tube assembly |
| 3 | 19710-A | Transmission mounted fluid cooler tube |
Transaxle Cooling - FNR5
These vehicles are equipped with an internal transmission fluid cooler. The transmission fluid cooler is mounted in the engine radiator tank. During operation, transmission fluid travels from the transaxle to the transmission fluid cooler, then back to the transaxle. The transmission fluid cooler transfers heat from the transmission fluid to the engine coolant.
Scheme 529
| Item | Part Number | Description |
|---|---|---|
| 1 | 8005 | Radiator |
| 2 | 7H420 | Transmission fluid cooler tube assembly |
Special Tools Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
Scheme 530
| Item | Specification |
|---|---|
| Motorcraft Premium Automatic Transmission Fluid XT-8-QAW (US); CXT-8-LAW12 (Canada) | WSS-M2C924-A |
Material
Special Tools Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
| Item | Specification |
|---|---|
| FNR5 Automatic Transmission Fluid XT-9-QMM5 | Mazda MES MN 117C (ATF-M V) |
Material
